Rear Wiper & Washer: Overview Lexus LX J100 рестайлинг

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. REMOVE REAR WIPER ARM Open the cover. Remove the nut and the rear wiper arm. Remove the grommet.
2. REMOVE ASSIST GRIP Using a screwdriver, remove the 2 assist grip plugs. HINT: Tape up the screwdriver tip before use. Remove the 2 screws and the assist grip.
3. REMOVE INSIDE HANDLE BEZEL
4. REMOVE CENTER BACK DOOR GARNISH Using a screwdriver, remove the center back door garnish. HINT: Tape up the screwdriver tip before use.
5. REMOVE BACK DOOR GARNISH Using a screwdriver, remove the back door garnish. HINT: Tape up the screwdriver tip before use.
6. REMOVE REAR WIPER MOTOR AND LINK ASSEMBLY Disconnect the connector. Remove the 2 bolts. Unfasten the 3 bolts, and remove the rear wiper motor with the link assembly.
