Front Wiper & Washer: Adjustments Lexus LX J100 рестайлинг

ADJUST WASHER NOZZLE

Using a tool like the one (Scheme 49), change the direction of the nozzle hole to adjust the point where washer fluid hits the windshield.

Scheme 49

Scheme 50

Scheme 51

1. INSTALL WASHER NOZZLE
2. INSTALL WIPER LINK Install the wiper link through the service hole, then torque the 6 bolts. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) HINT: When installing the wiper link, connect the claw of wiper link to the panel.
3. INSTALL WIPER MOTOR Connect the wiper motor to wiper link. Install the wiper motor with 4 bolts. Connect the connector.
4. INSTALL COWL TOP VENTILATOR LOUVER Install the LH cowl top ventilator louver. Install the RH cowl top ventilator louver.
5. INSTALL HOOD TO COWL TOP SEAL
6. INSTALL WIPER ARM Operate the wipers once and turn the wiper switch OFF. Install the wiper arms and tighten nuts by hand. Adjust the installation position of the wiper arms to the positions (Scheme 51) Approx. 40 mm (1.57 in.) Approx. 16 - 26 mm (0.63 - 1.02 in.) Torque the nuts. Torque: 20 N.m (205 kgf.cm, 15 ft.lbf) Install the wiper arm caps.
