Front Wiper & Washer: Overview Lexus LX J100 рестайлинг

Wiper/washer Systems 3 illustrations ~102 words

Scheme 46

Scheme 46: COMPONENTS
Scheme 46: COMPONENTS

Scheme 47

Scheme 47: REMOVAL
Scheme 47: REMOVAL

Scheme 48

Scheme 48
Scheme 48
  1. REMOVE THESE PARTS: Wiper arm caps Wiper arms Hood to cowl top seal
  2. REMOVE COWL TOP VENTILATOR LOUVER Remove the RH cowl top ventilator louver. Remove the LH cowl top ventilator louver.
  3. REMOVE WIPER MOTOR Disconnect the connector, unfasten the 4 bolts. Disconnect the wiper motor from the wiper link, then remove the wiper motor.
  4. REMOVE WIPER LINK Remove the 6 bolts. Remove the wiper link through the service hole.
  5. REMOVE WASHER NOZZLE Disconnect the washer hoses. Using a screwdriver, remove the washer nozzles. HINT: Tape the screwdriver tip before use.
