Differential Oil: Removal & Installation Lexus LS III рестайлинг

REPLACEMENT

HINT

1. COMPONENTS: SEE «COMPONENTS»(ref-209422-S24380388522005121000000)
2. Use the same procedures for the RH side and LH side.

Scheme 5

Scheme 6

1. REMOVE REAR WHEEL
2. REMOVE REAR DIFFERENTIAL FILLER PLUG Using a hexagon wrench (10 mm), remove the filler plug and gasket.
3. REMOVE REAR DIFFERENTIAL DRAIN PLUG Using a hexagon wrench (10 mm), remove the drain plug and gasket. Drain the differential oil.
4. REMOVE REAR DRIVE SHAFT ASSY LH (SEE «AXLE SHAFTS»(ref-164200) )
5. REMOVE REAR DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL Using SST, remove the oil seal. SST 09308-10010
6. INSTALL REAR DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL Using SST and a hammer, install a new oil seal. Apply MP grease to the oil seal lip. SST 09950-70010 (09951-07150), 09223-15030 Oil seal drive in depth: 0 +/- 0.5 mm (0 +/- 0.020 in.)
7. INSTALL REAR DRIVE SHAFT ASSY LH (SEE «AXLE SHAFTS»(ref-164200) )
8. INSTALL REAR DIFFERENTIAL DRAIN PLUG Using a hexagon wrench (10 mm), install the drain plug with a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
9. ADD DIFFERENTIAL OIL Fill the rear differential carrier assay with differential gear oil. Oil type: Differential synthetic gear oil GL-5 75W-90 or equivalent. Capacity: 1.35 +/- 0.05 liters (1.43 +/- 0.05 US qts, 1.19 +/- 0.04 lmp. qts)
10. INSPECT DIFFERENTIAL OIL (SEE «DIFFERENTIAL OIL»(ref-209421-S13466155252005121000000) )
11. INSTALL REAR DIFFERENTIAL FILLER PLUG Using a hexagon wrench (10 mm), install the filler plug with a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
12. STABILIZE SUSPENSION (SEE «REAR WHEEL ALIGNMENT»(ref-209419-S22478848592005121000000) )
13. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (SEE «REAR WHEEL ALIGNMENT»(ref-209419-S22478848592005121000000) )
14. CHECK ABS SPEED SENSOR SIGNAL (SEE «TEST MODE PROCEDURE»(ref-209351-S31697443912005120900000) )
