Generators & Regulators: Overhaul Lexus LS III рестайлинг

Disassembly

1. Remove rear end cover. Remove nut and terminal insulator. Remove rear seal plate from brush holder. Remove brush holder. (Scheme 2) Remove front seal plate from coil. Use generator Pulley Set Nut Wrench Set (SST 09820-63010) to remove generator pulley.
2. To remove pulley, install SST "A" and "B" to rotor shaft and tighten SST "B" clockwise to 29 ft. lbs. (39 N.m). (Scheme 3) Place SST "C" securely into a vise. Verify that SST "A" is secured to rotor shaft and install SST "A" and "B" and generator into SST "C". Turn SST "A" in correct direction to loosen pulley nut. (Scheme 3) To prevent damage to rotor shaft, DO NOT loosen pulley nut more than 1/2 turn. Remove generator from SST "C". Turn SST "A" and "B", remove pulley nut and pulley.
3. Remove coil assembly using Puller (SST 09286-46011). Remove generator washer. Remove rotor from drive end frame.

Scheme 2

Scheme 3

Assembly

To assemble, reverse disassembly procedure. Use generator Pulley Set Nut Wrench Set (SST 09820-63010) to install generator pulley. Place SST "C" securely into a vise. Install SST "A" and "B" and generator into SST "C". (Scheme 3) Tighten pulley nut in the opposite direction of disassembly. See TORQUE SPECIFICATIONS. Using 29 mm socket, slowly press in coil assembly. To complete assembly, reverse disassembly procedure. After completing assembly, verify rotor turns smoothly.
