REPLACEMENT
HINT
- Installation is in the reverse order of removal.
- COMPONENTS: See «COMPONENTS»(ref-209432-S34514051502005121000000) .
Scheme 398
Scheme 399
Scheme 400
Scheme 401
Scheme 402
Scheme 403
Scheme 404
Scheme 405
- RESTORE SHIP MODE SETTING (W/CD CHANGER) (SEE «PRECAUTION»(ref-215676-S02548229242006011600000) )
- REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (SEE «REPLACEMENT»(ref-215685-S19902335712006011600000) )
- REMOVE PANEL INSTRUMENT CLUSTER FINISH LOWER (SEE «REPLACEMENT»(ref-215685-S19902335712006011600000) )
- REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET (SEE «REPLACEMENT»(ref-215676-S39499940232006011600000) )
- CONFIRM SHIP MODE (W/CD CHANGER) (SEE «PRECAUTION»(ref-215676-S02548229242006011600000) )
- REMOVE TEMPERATURE CONTROL SWITCH ASSY Using a screwdriver, release the 2 claws and remove the temperature control switch. HINT: Tape the screwdriver tip before use. Employ the same manner described above to the other side. Disconnect the connectors.
- REMOVE INTEGRATION CONTROL & PANEL ASSY Remove the 2 bolts. Release the 4 claws and remove the integration control & panel assy.
- REMOVE HEATER CONTROL BASE BRACKET No. 1 Remove the 4 screws and 2 heater control base brackets No. 1.
- REMOVE AIR CONDITIONER CONTROL ASSEMBLY Disconnect the connector. Remove the 4 screws, release the 4 claws and remove the air conditioner control assembly.
- REMOVE HEATER CONTROL HOUSING Remove the 2 screws release the 4 claws and remove the heater control housing.
- REMOVE HEATER CONTROL BULB Using a screwdriver, turn the bulbs to the left and pull out the bulbs.
- REMOVE HEATER CONTROL BASE SUB-ASSY Release the 4 claws and remove the heater control base.
- REMOVE AIR CONDITION PANEL SUB-ASSY
