PRECAUTION

Note. When disconnecting the negative (-) battery terminal, initialize the following system after the terminal is reconnected.

Scheme 319

Scheme 320

Scheme 321

1. RESTRICTION OF STEP MOTORS CONTINUOUS OPERATION If the step motor is continuously operating for many hours, the step motor is forced to stop and the "AUTO" indicator blinks. In this case, the step motor automatically restores after cooling for approximately 7 minutes.

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

1. GENERAL The air conditioning system has the following features: In compliance with the temperature set at the temperature control switch, the neural network control calculates the outlet temperature based on the input signals from various sensors. In addition, corrections in accordance with the signals from the evaporative temperature sensor and the water temperature sensor are added to control the outlet air temperature. Controls the front and rear blower motors in accordance with the airflow volume that has been calculated by the neural network control based on the input signals from various sensors. Automatically switches the outlets in accordance with the outlet mode ratio that has been calculated by the neural network control based on the input signals from various sensors. Automatically controls the air inlet control damper in accordance with the airflow volume that has been calculated by the neural network control. Turns the compressor on/off and controls the discharge capacity based on the signals from various sensors. Based on the signals from the ambient temperature sensor, this control calculates the outside temperature, which is then corrected in the air conditioner ECU, and shown in the multi-information display in the combination meter. Switched the rear defogger and outside rear view mirror heaters on for 15 minutes when the rear defogger switch is switched on. Switched them off if the switch is pressed while they are operating. Controls the orientation and the angle of the front center register based on the input signals from various sensors and on the outlet mode. Determines whether the clean air filter (for the front A/C) is clogged by monitoring the air inlets, and airflow volume. The A/C amplifier automatically controls the air inlets based on the signals from the smog ventilation sensor. Improves the air quality by linking the air inlet control damper and the blower motor (for the rear A/C and air purifier), based on the signals from the exhaust gas sensor and the smoke sensor. Checks the sensors in accordance with operation of the air conditioner switches.
2. MODEL POSITION AND DAMPER OPERATION
3. AIR OUTLETS AND AIR VOLUME RATIONS

CUSTOMIZE PARAMETERS

HINT

The followings are the possible items to be customized.

Note. After confirming whether the items of the customer's request is applicable or not for the customized items, perform the customize operation. Be sure to record the current value before customizing. When troubleshooting, be aware that function may be set to OFF by customizing. (Example: In the case of "The wireless operation does not function", check that wireless operation is not set to OFF by customizing, then perform the troubleshooting.)

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

1. STEP MOTORS INITIALIZING FUNCTION Step motor initializing procedure (Automatic initializing) When the battery is reconnected and the ignition switch is turned to the ON position for the first time, the initializing function of the step motors is activated. In this case, the "FRONT DEF" indicator blinks. If mode indication is different from the actual air outlet in actuator check, turn the ignition switch to the ON or START position while pressing the "Rr DEF" and "OFF" switches simultaneously. Step motor initialization occurs and the "DEF" indicator blinks.

Scheme 334

Scheme 335

Scheme 336

Scheme 337

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

1. LIST OF OPERATION METHODS By operating each of the A/C control switches as shown in the diagram below, it is possible to enter the diagnostic check mode.
2. CHECK DLC3 The vehicle's ECM uses CAN and the to ISO 9141 - 2 for communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and meets the ISO 9141 - 2 format. HINT: If the display shows UNABLE TO CONNECT TO VEHICLE when you have connected the cable of the hand-held tester to the DLC3, turned the ignition switch ON and operated the tester, there is a problem on the vehicle side or tool side. If the communication is normal when the tool is connected to another vehicle, inspect the DLC3 on the original vehicle. If the communication is still impossible when the tool is connected to another vehicle, the problem is probably in the tool itself, so consult the Service Department listed in the tool's instruction manual.

Scheme 352

Scheme 353

Scheme 354

Scheme 355

1. INDICATOR CHECK Turn the ignition switch to the ON position while pressing the A/C control AUTO switch and R/F (Recirculation/Fresh) switch simultaneously. Check that the all indicators come on and go off 4 times in succession at 1 second intervals. HINT: After the indicator check is completed, the system enters the DTC mode automatically. Press the "OFF" switch to cancel the indicator mode.
2. DTC CHECK USING HAND-HELD TESTER Connect the hand-held tester to the DLC3. Read the DTC following the prompts on the tester screen. Please refer to the hand-held tester operator manual for further details. Clear the DTCs. HINT: After repairing the malfunctions, clear the DTC. Connect the hand-held tester to the DLC3. Turn the ignition switch to the ON position. Erase the DTCs following the prompts on the tester screen. HINT: Refer to the intelligent tester II operator manual for further details.

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

1. DATA LIST HINT: From the DATA LIST displayed on the hand-held tester, you can read the values of the displays, sensors, actuators and so on without parts removal. Reading the DATA LIST as the first step of troubleshooting is one way to shorten labor time. Connect the hand-held tester to the DLC3. Turn the ignition switch to the ON position. From the display on the tester, select the "DATA LIST". DATA LIST/AIR CONDITIONER: DATA LIST/ENGINE AND ECT/ALL
2. ACTIVE TEST HINT: Performing the ACTIVE TEST using the hand-held tester allows the relays, VSV, actuators and so on to operate without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one way to shorten labor time. It is possible to display the DATA LIST on the hand-held tester during the ACTIVE TEST. Connect the hand-held tester to the DLC3. Turn the ignition switch to the ON position. From the display on tester, perform the "ACTIVE TEST". ACTIVE TEST/AIR CONDITIONER
