Power Window Control System (Diagnostics - Introduction): Other Lexus IS III

PRECAUTION [04/2013 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Air Conditioning System Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000) Variable Gear Ratio Steering System
2. POWER WINDOW CONTROL SYSTEM PRECAUTIONS NOTE: The power window control system uses the LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Troubleshoot the power window control system after confirming that the communication system is functioning properly. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665547-S10690388912014102400000) The power window control system prohibits the auto up and down function when the jam protection function malfunctions. If the power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to «INITIALIZATION [04/2013 - ]»(ref-665547-S39448188862014102400000) If the power window regulator motor assembly and door window regulator sub-assembly have been removed and installed, or if the power window regulator motor assembly was reused when a door glass or door glass run was replaced, initialize the power window control system. Refer to «INITIALIZATION [04/2013 - ]»(ref-665547-S39448188862014102400000) The jam protection function may operate unexpectedly, even when the power window control system is normal, due to detection of a value different than the operation learned value when the door glass moving speed changes sharply under any of the following conditions: A power window is being opened or closed while the vehicle is driven on a rough road. A power window is being opened or closed while the door is being opened or closed. The voltage changes abruptly. Do not disconnect the battery while the engine switch is on (IG). Otherwise, DTC B2313 will be stored. Refer to «DTC B2313: Glass Position Initialization Incomplete [04/2013 - ]»(ref-665860-S04377960542014102400000)

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

COMMUNICATION TABLE

CAUTION / NOTICE / HINT

HINT

1. Use the following procedure to troubleshoot the power window control system.
2. *: Use the Techstream.

PROCEDURE

1. VEHICLE BROUGHT TO WORKSHOP Result Proceed to NEXT Result: 1 NEXT See step 2
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms Result Proceed to NEXT Result: 1 NEXT See step 3
3. PRE-CHECK Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. Result Proceed to NEXT Result: 1 NEXT See step 4
4. INSPECT COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Using the Techstream, check for CAN communication system DTCs. Refer to «DIAGNOSIS SYSTEM [04/2013 - ]»(ref-665810-S14264089842014102400000) Result Result Proceed to CAN DTCs are not output A CAN DTCs are output B Result: 2 B GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665785-S15342612202014102400000) Result: 1 A See step 5
5. INSPECT COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Using the Techstream, check for LIN communication system DTCs. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665832-S32731231342014102400000) Result Result Proceed to LIN DTCs are not output A LIN DTCs are output B Result: 2 B GO TO LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665832-S17970494342014102400000) Result: 1 A See step 6
6. CHECK FOR DTC* Check for DTCs and make a note of any codes that are output. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665547-S06891713832014102400000) Body Electrical > Master Switch > Trouble Codes Body Electrical > D-Door Motor > Trouble Codes Body Electrical > P-Door Motor > Trouble Codes Body Electrical > RL-Door Motor > Trouble Codes Body Electrical > RR-Door Motor > Trouble Codes Clear the DTCs. Body Electrical > Master Switch > Clear DTCs Body Electrical > D-Door Motor > Clear DTCs Body Electrical > P-Door Motor > Clear DTCs Body Electrical > RL-Door Motor > Clear DTCs Body Electrical > RR-Door Motor > Clear DTCs Recheck for DTCs. Body Electrical > Master Switch > Trouble Codes Body Electrical > D-Door Motor > Trouble Codes Body Electrical > P-Door Motor > Trouble Codes Body Electrical > RL-Door Motor > Trouble Codes Body Electrical > RR-Door Motor > Trouble Codes Result Result Proceed to DTCs are not output A DTCs are output B Result: 2 B GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [04/2013 - ]»(ref-665547-S34661172472014102400000) Result: 1 A See step 7
7. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [04/2013 - ]»(ref-665547-S00167834322014102400000) Result Result Proceed to Fault is not listed in Problem Symptoms Table A Fault is listed in Problem Symptoms Table B Result: 2 B See step 9 Result: 1 A See step 8
8. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check Refer to «OPERATION CHECK [04/2013 - ]»(ref-665547-S10896905262014102400000) Terminals of ECU Refer to «TERMINALS OF ECU [04/2013 - ]»(ref-665547-S27903819292014102400000) Data List / Active Test Refer to «DATA LIST / ACTIVE TEST [04/2013 - ]»(ref-665547-S03276865012014102400000) Fail-safe Chart Refer to «FAIL-SAFE CHART [04/2013 - ]»(ref-665547-S31621180232014102400000) Inspection Result Proceed to NEXT Result: 1 NEXT See step 9
9. ADJUST, REPAIR OR REPLACE Check if any of the door window regulators, power window regulator motor assemblies, door glass or door glass runs have been removed and reinstalled. Result Result Proceed to Any of the door window regulators, power window regulator motor assemblies, door glass or door glass runs have been removed and reinstalled A The door window regulators, power window regulator motor assemblies, door glass or door glass runs have not been removed and reinstalled B Result: 2 B See step 11 Result: 1 A See step 10
10. INITIALIZE POWER WINDOW CONTROL SYSTEM If any of the door window regulators, power window regulator motor assemblies, door glass or door glass runs have been removed and reinstalled, perform "Initialize Power Window Control System" for the applicable door glass. Refer to «INITIALIZATION [04/2013 - ]»(ref-665547-S39448188862014102400000) Result Proceed to NEXT Result: 1 NEXT See step 11
11. CONFIRMATION TEST Result Proceed to NEXT Result: 1 NEXT END

Scheme 17

Scheme 18

1. CHECK WINDOW LOCK FUNCTION HINT: Before performing the window lock switch operation check, make sure that the window lock switch is off (the switch is not pushed in). When the window lock switch of the multiplex network master switch assembly is pushed: Check that the front passenger and rear windows are disabled. OK Front passenger and rear windows are disabled. When the window lock switch is pushed in again: Check that the front passenger and rear windows can be operated normally. OK Front passenger and rear windows operate normally.
2. CHECK MANUAL UP / DOWN FUNCTION Check that the driver door power window operates as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Driver door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Check that the front passenger door window and rear power windows operate as follows: OK Condition Regulator Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear LH door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear RH door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens)
3. CHECK AUTO UP / DOWN FUNCTION Check that the driver door power window operates as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Driver door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Check that the front passenger door window and rear power windows operate as follows: OK Condition Regulator Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear LH door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear RH door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens)
4. CHECK REMOTE MANUAL UP / DOWN FUNCTION Check that the front passenger door window and rear power windows operate as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear LH door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear RH door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens)
5. CHECK REMOTE AUTO UP / DOWN FUNCTION Check that the front passenger door window and rear power windows operate as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear LH door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear RH door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens)
6. CHECK KEY-OFF OPERATION FUNCTION Check that each power window can be operated with the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly after the engine switch is turned off. HINT: If the window lock switch is on, the power windows cannot be operated by using the power window regulator switch assembly and rear power window regulator switch assembly. Therefore, turn the window lock switch off before checking the window operation. Check that the key-off operation function does not operate immediately after the driver door or front passenger door is opened. HINT: Even if the driver door or front passenger door is opened during auto window operation while the key-off operation function is on, the window will stop operating. Check that all the power windows cannot be operated after more than approximately 43 seconds have elapsed since the engine switch is turned off.
7. CHECK WIRELESS TRANSMITTER-LINKED FUNCTION* *: This function is set through the customize function, as it is off by default. Check that all power windows operate as follows when operating the electrical key transmitter: OK Condition Transmitter Operation Power Window No key is inside vehicle, and all doors are closed and locked UNLOCK switch pressed for more than 2.4 seconds DOWN (Opens) No key is inside vehicle, and all doors are closed and locked UNLOCK switch released STOP
8. CHECK KEY-LINKED FUNCTION* *: This function is set through the customize function, as it is off by default. Check that all power windows operate as follows: OK Condition Door Key Cylinder Operation Power Window No key is inside vehicle, and all doors are closed Key is turned to the lock position and held for more than 1.5 seconds UP (Closes) No key is inside vehicle, and all doors are closed Returned to neutral position STOP No key is inside vehicle, and all doors are closed Key is turned to the unlock position and held for more than 1.5 seconds DOWN (Opens) No key is inside vehicle, and all doors are closed Returned to neutral position STOP
9. CHECK WINDOW OPEN WARNING FUNCTION Open a window by using the power window switch. When the engine switch is turned from on (IG) to off and the driver door is opened with the key in the vehicle, check that the warning buzzer in the combination meter assembly sounds once. Then, check that the multi-information display on the combination meter assembly displays "Window opened".
10. CHECK JAM PROTECTION FUNCTION Check the basic function. WARNING: Do not put your fingers between the door frame and door glass to check the jam protection function. Also, prevent any part of your body from being caught during inspection. HINT: The jam protection function is operative during both the auto up and manual up operations while the engine is running or the engine switch is on (IG), and also for approximately 43 seconds after the engine switch is turned off. Fully open the window. Set a check jig wrapped with a piece of cloth near the window fully closed position. *a Check Jig *b Cloth Operate the auto up or manual up function to check that the power window stops and goes down after the check jig is caught between the window and door frame, and stops when the opening reaches approximately 200 mm (7.87 in.) or approximately 5 seconds have elapsed. HINT: If the check jig is caught when the opening is approximately 75 mm (2.95 in.) or more, the power window goes down approximately 125 mm (4.93 in.) or approximately 2.5 seconds have elapsed. While the power window is moving down, check that the door glass cannot be raised using the power window switch.
11. CHECK POWER WINDOW SWITCH LED ILLUMINATION Check the LED illumination (multiplex network master switch assembly). Check that the LEDs located in the multiplex network master switch assembly illuminate when the engine switch is turned on (IG). Check the LED illumination (power window regulator switch assembly). Check that the LED located in the power window regulator switch assembly illuminates when the engine switch is turned on (IG). Check the LED illumination (rear power window regulator switch assembly). Check that the LED located in each rear power window regulator switch assembly illuminates when the engine switch is turned on (IG).

CUSTOMIZE PARAMETERS [04/2013 - ]

1. CUSTOMIZE POWER WINDOW CONTROL SYSTEM HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make notes of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Power Window. Select the setting by referring to the table below. Power Window Tester Display Description Default Setting ECU Door Key P/W Up This function is used to close the windows by operating the mechanical key. OFF 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Door Key P/W Down This function is used to open the windows by operating the mechanical key. OFF 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) P/W Down W/ Transmit This function is used to open the windows using the wireless key transmitter. OFF 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) P Window Auto Up This function is used to enable or disable the auto up function for the front passenger door window using the power window regulator switch assembly. Avail 0:Not Avl, 1:Avail Power window regulator motor assembly (for Front Passenger Door) P Window Auto Up From Driver This function is used to enable or disable the remote auto up function for the front passenger door window using the multiplex network master switch assembly. Avail 0:Not Avl, 1:Avail Power window regulator motor assembly (for Front Passenger Door) RR Window Auto Up This function is used to enable or disable the auto up function using the rear power window regulator switch assembly (for RH door). Avail 0:Not Avl, 1:Avail Power window regulator motor assembly (for Rear RH Door) RR Window Auto Up From Driver This function is used to enable or disable the remote auto up function for the rear RH door window using the multiplex network master switch assembly. Avail 0:Not Avl, 1:Avail Power window regulator motor assembly (for Rear RH Door) RL Window Auto Up This function is used to enable or disable the auto up function using the rear power window regulator switch assembly (for LH door). Avail 0:Not Avl, 1:Avail Power window regulator motor assembly (for Rear LH Door) RL Window Auto Up From Driver This function is used to enable or disable the remote auto up function for the rear LH door window using the multiplex network master switch assembly. Avail 0:Not Avl, 1:Avail Power window regulator motor assembly (for Rear LH Door) Enter the following menus: Customize Setting / Wireless Door Lock. Select the setting by referring to the table below. Wireless Door Lock Tester Display Description Default Setting ECU P/W Wireless Ope Buzz This function turns the wireless power window buzzer response on or off. ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Enter the following menus: Customize Setting / Security. Select the setting by referring to the table below. Security Tester Display Description Default Setting ECU Window Open Warning This function is used to enable or disable the window open warning. ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU)

INITIALIZATION [04/2013 - ]

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (ALL DOORS) NOTE: When a door window regulator assembly, power window regulator motor assembly, door glass or door glass run is reinstalled or replaced, the power window control system must be initialized. Functions such as the auto up and down function, jam protection function, remote control function, key-linked function, wireless transmitter-linked function, key-off operation function and window open warning function will not operate if initialization is not performed. When a power window regulator motor assembly is replaced, DTC B2313 is stored. Clear the DTC after initialization. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665547-S06891713832014102400000) When performing initialization, do not perform any other procedures. When performing initialization, use the power window switch of each door to initialize each door window. If initialization does not complete properly, the LIN communication system may be malfunctioning. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665832-S17970494342014102400000) Make sure to park the vehicle and turn off all electrical systems before performing initialization. Initialization will be canceled if the vehicle is driven during initialization. Make sure not to hit, strike or vibrate the door window glass during initialization because the vehicle is learning the sliding resistance of the door window glass. Make sure not to turn the engine switch on (IG) or off during initialization. HINT: If the battery has been replaced, it is not necessary to initialize the power window regulator motor assembly. Perform initialization according to the table below. Condition of Power Window Proceed to Initialization method when a power window regulator motor assembly has been replaced with a new one. Procedure A Initialization method when a power window regulator motor assembly has been removed/installed or a door glass and/or door glass run etc. have been removed/installed or replaced with new ones. HINT: Use this procedure if a power window regulator motor assembly is being reused. Procedure B Initialization method when a reverse rotation malfunction occurs due to a sliding resistance change resulting from adjustment etc. Procedure C Procedure A Connect the battery and turn the engine switch on (IG). Fully open the power window by fully pushing down the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling up the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 1 second or more after the power window is fully closed to reset the glass position and complete initialization. Procedure B Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling up the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway, even when the switch is fully pulled up, release the switch and fully pull it up again). Fully open the power window by fully pushing down the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 1 second or more after the power window is fully opened. Release the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 1 second or more after the power window is fully closed to reset the glass position and complete initialization. Procedure C Connect the battery and turn the engine switch on (IG). Fully open the power window by fully pushing down the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 1 second or more after the power window is fully opened. Fully close the power window by fully pulling up the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly, and hold the switch for 1 second or more after the power window is fully closed to reset the glass position and complete initialization.

FAIL-SAFE CHART [04/2013 - ]

1. PULSE FAILURE OR DISPLACEMENT OF NON-DETECTION RANGE TO THE OPENING DIRECTION If the pulse sensor built into the power window regulator motor malfunctions, the power window control system enters fail-safe mode. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up (Driver door window) X X - Manual down (Driver door window) o X - Auto up (Driver door window) (hold switch at auto up position) o* X - Auto up (Driver door window) X X - Auto down (Driver door window) X X - Manual up (Remote switch operation) X X - Manual down (Remote switch operation) X X - Auto up (Remote switch operation) (hold switch at auto up position) X X - Auto up (Remote switch operation) X X - Auto down (Remote switch operation) X X - Key-linked open and close - X X Wireless transmitter-linked open - X X POWER WINDOW REGULATOR SWITCH ASSEMBLY AND REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR LH AND RH DOORS) Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up X X - Manual down o X - Auto up (hold switch at auto up position) o* X - Auto up X X - Auto down X X - Key-linked open and close - X X Wireless transmitter-linked open - X X HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection Fail-safe deactivation condition When the pulse sensor is normal, to deactivate fail-safe mode, pull up the power window switch to the auto up position and hold it for at least 1 second to fully close the window from the fully open position. As a result, the auto up / down function will return.
2. INITIAL FAILURE During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM, the power window control system prohibits operation as follows. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up (Driver door window) X X - Manual down (Driver door window) o X - Auto up (Driver door window) (hold switch at auto up position) o* X - Auto up (Driver door window) X X - Auto down (Driver door window) X X - Manual up (Remote switch operation) X X - Manual down (Remote switch operation) X X - Auto up (Remote switch operation) (hold switch at auto up position) X X - Auto up (Remote switch operation) X X - Auto down (Remote switch operation) X X - Key-linked open and close - X X Wireless transmitter-linked open - X X POWER WINDOW REGULATOR SWITCH ASSEMBLY AND REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR LH AND RH DOORS) Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up X X - Manual down o X - Auto up (hold switch at auto up position) o* X - Auto up X X - Auto down X X - Key-linked open and close - X X Wireless transmitter-linked open - X X HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection Fail-safe deactivation condition Initialize the power window regulator motor assembly. Refer to «INITIALIZATION [04/2013 - ]»(ref-665547-S39448188862014102400000)
3. LIN COMMUNICATION FAILURE If the LIN communication line is malfunctioning (communication stop), the power window control system prohibits operation as follows. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Engine switch on (IG) Manual up o* Manual down o Auto up (hold switch at auto up position) - Auto up - Auto down - POWER WINDOW REGULATOR SWITCH ASSEMBLY AND REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR LH AND RH DOORS) Power Window Operation Condition Engine switch on (IG) Manual up o* Manual down o Auto up (hold switch at auto up position) o* Auto up o* Auto down o HINT: o: Operates X: Operation prohibited *: Jam protection can operate. Remote up and down function does not operate. Fail-safe deactivation condition Check LIN communication system. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665832-S17970494342014102400000)
4. PULSE FAILURE AND LIN COMMUNICATION FAILURE If the LIN communication line is malfunctioning (communication stop) and the pulse sensor for the jam protection function is malfunctioning, the power window control system prohibits operation as follows. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X POWER WINDOW REGULATOR SWITCH ASSEMBLY AND REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR LH AND RH DOORS) Power Window Operation Condition Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operates X: Operation prohibited Driver door window: When the jam protection function does not operate due to the LIN communication failure, the manual up and auto up functions will not operate. Remote switch operation: Not operative during the LIN communication failure
5. DISPLACEMENT OF NON-DETECTION RANGE TO THE OPENING DIRECTION AND LIN COMMUNICATION FAILURE / INITIAL FAILURE AND LIN COMMUNICATION FAILURE If the LIN communication line is malfunctioning (communication stop) and the window position or the learned value is abnormal, the power window control system prohibits operation as follows. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Always Manual up o* Manual down o Auto up (hold switch at auto up position) - Auto up - Auto down - POWER WINDOW REGULATOR SWITCH ASSEMBLY AND REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR LH AND RH DOORS) Power Window Operation Condition Always Manual up o* Manual down o Auto up (hold switch at auto up position) o* Auto up X Auto down X HINT: o: Operates X: Operation prohibited Remote switch operation: Operation is not possible during the LIN communication failure. *: Jam protection can operate and window reverses upon reaching the fully closed position.
