PROCEDURE

1. INSPECT MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY (w/ Seat Position Memory System) Check that the LED illuminates. *a Component without harness connected (Multiplex Network Master Switch Assembly) Apply battery voltage to the multiplex network master switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 18 (LED) Battery negative (-) --> 12 (GND) LED illuminates If the result is not as specified, replace the multiplex network master switch assembly.
2. INSPECT MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY (w/o Seat Position Memory System) Check that the LED illuminates. *a Component without harness connected (Multiplex Network Master Switch Assembly) Apply battery voltage to the multiplex network master switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 19 (LED) Battery negative (-) --> 17 (GND) LED illuminates If the result is not as specified, replace the multiplex network master switch assembly.

1. INSTALL MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY w/o Screw: Engage the 12 claws to install the multiplex network master switch assembly to the front door armrest base panel. w/ Screw: Engage the 4 claws to temporarily install the multiplex network master switch assembly to the front door armrest base panel. Install the multiplex network master switch assembly with the 3 screws.
2. INSTALL MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 48»(ref-665779-S33938793612014102400000)

Scheme 23

1. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 5»(ref-665779-S40176917222014102400000)
2. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY Disengage the 6 claws to remove the power window regulator switch assembly from the front door armrest base panel.

Scheme 24

Scheme 25

1. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Check the switch function. *a Component without harness connected (Power Window Regulator Switch Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (UP) - 5 (GND) Auto up or up position Below 1 ohms 10 (DOWN) - 5 (GND) Auto down or down position Below 1 ohms 4 (AUTO) - 5 (GND) Auto up or auto down position Below 1 ohms 2 (UP) - 5 (GND) Off 10 kohms or higher 10 (DOWN) - 5 (GND) Off 10 kohms or higher 4 (AUTO) - 5 (GND) Off 10 kohms or higher If the result is not as specified, replace the power window regulator switch assembly. Check that the LED illuminates. *a Component without harness connected (Power Window Regulator Switch Assembly) Apply battery voltage to the power window regulator switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (GND) LED illuminates If the result is not as specified, replace the power window regulator switch assembly.

1. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY Engage the 6 claws to install the power window regulator switch assembly to the front door armrest base panel.
2. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 49»(ref-665779-S33938793612014102400000)

Scheme 26

CAUTION / NOTICE / HINT

HINT

1. Use the same procedure for the LH side and RH side.
2. The following procedure is for the LH side.

1. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH REAR DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 4»(ref-665779-S07345647622014102400000)
2. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY Disengage the 4 claws to remove the rear power window regulator switch assembly from the rear door armrest base panel.

Scheme 27

1. INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (for LH Door) Check the switch function. *a Component without harness connected (Rear Power Window Regulator Switch Assembly (for LH Door)) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (UP) - 5 (GND) Auto up or up position Below 1 ohms 10 (DOWN) - 5 (GND) Auto down or down position Below 1 ohms 4 (AUTO) - 5 (GND) Auto up or auto down position Below 1 ohms 2 (UP) - 5 (GND) Off 10 kohms or higher 10 (DOWN) - 5 (GND) Off 10 kohms or higher 4 (AUTO) - 5 (GND) Off 10 kohms or higher If the result is not as specified, replace the rear power window regulator switch assembly (for LH door). Check that the LED illuminates. *a Component without harness connected (Rear Power Window Regulator Switch Assembly (for LH Door)) Apply battery voltage to the rear power window regulator switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (GND) LED illuminates If the result is not as specified, replace the rear power window regulator switch assembly (for LH door).
2. INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (for RH Door) Check the switch function. *a Component without harness connected (Rear Power Window Regulator Switch Assembly (for RH Door)) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (UP) - 5 (GND) Auto up or up position Below 1 ohms 10 (DOWN) - 5 (GND) Auto down or down position Below 1 ohms 4 (AUTO) - 5 (GND) Auto up or auto down position Below 1 ohms 2 (UP) - 5 (GND) Off 10 kohms or higher 10 (DOWN) - 5 (GND) Off 10 kohms or higher 4 (AUTO) - 5 (GND) Off 10 kohms or higher If the result is not as specified, replace the rear power window regulator switch assembly (for RH door). Check that the LED illuminates. *a Component without harness connected (Rear Power Window Regulator Switch Assembly (for RH Door)) Apply battery voltage to the rear power window regulator switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (GND) LED illuminates If the result is not as specified, replace the rear power window regulator switch assembly (for RH door).

1. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY Engage the 4 claws to install the rear power window regulator switch assembly to the rear door armrest base panel.
2. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH REAR DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 37»(ref-665779-S03734538072014102400000)

Scheme 28

Scheme 29

*1 FRONT DOOR GLASS SUB-ASSEMBLY *2 FRONT DOOR SERVICE HOLE COVER *3 FRONT DOOR WINDOW REGULATOR ASSEMBLY *4 FRONT NO. 1 SPEAKER ASSEMBLY *5 FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY *6 BUTYL TAPE *7 FRONT DOOR WINDOW REGULATOR SUB-ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part MP grease

HINT

1. Use the same procedure for the RH side and LH side.
2. The procedure described below is for the LH side.

1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000)
3. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG Refer to «PROCEDURE - Step 3»(ref-665779-S40176917222014102400000)
4. REMOVE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL (for Driver Side) Refer to «PROCEDURE - Step 4»(ref-665779-S40176917222014102400000)
5. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL (for Front Passenger Side) Refer to «PROCEDURE - Step 5»(ref-665779-S40176917222014102400000)
6. REMOVE FRONT DOOR ARMREST COVER Refer to «PROCEDURE - Step 6»(ref-665779-S40176917222014102400000)
7. REMOVE COURTESY LIGHT ASSEMBLY Refer to «PROCEDURE - Step 1»(ref-665780-S19872540692014102400000)
8. REMOVE FRONT DOOR NO. 1 STIFFENER CUSHION Refer to «PROCEDURE - Step 8»(ref-665779-S40176917222014102400000)
9. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY Refer to «PROCEDURE - Step 9»(ref-665779-S40176917222014102400000)
10. REMOVE FRONT DOOR INNER GLASS WEATHERSTRIP Refer to «PROCEDURE - Step 13»(ref-665779-S40176917222014102400000)
11. REMOVE FRONT DOOR SERVICE HOLE COVER Refer to «PROCEDURE - Step 20»(ref-665779-S40176917222014102400000)
12. REMOVE FRONT NO. 1 SPEAKER ASSEMBLY Refer to «PROCEDURE - Step 9»(ref-665839-S18148802652014102400000)
13. REMOVE FRONT DOOR GLASS SUB-ASSEMBLY Refer to «PROCEDURE - Step 22»(ref-665779-S40176917222014102400000)
14. REMOVE FRONT DOOR WINDOW REGULATOR ASSEMBLY Refer to «PROCEDURE - Step 23»(ref-665779-S40176917222014102400000)
15. REMOVE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY Using a T25 "TORX" socket wrench, remove the 3 screws and front power window regulator motor assembly.

Scheme 30

Scheme 31

1. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH Apply positive (+) battery voltage to connector terminal 2 (B). *a Component without harness connected (Power Window Regulator Motor Assembly LH) *b Counterclockwise *c Clockwise NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Connect a negative (-) battery to connector terminals 1 (GND) and 7 (DOWN) or 10 (UP). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 10 (UP). Disconnect and reconnect the negative (-) battery lead for terminal 10 (UP) within 1 second. Motor gear rotates clockwise Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 7 (DOWN). Disconnect and reconnect the negative (-) battery lead for terminal 7 (DOWN) within 1 second. Motor gear rotates counterclockwise If the result is not as specified, replace the power window regulator motor assembly LH. NOTE: Initialize the power window control system after installing the power window regulator motor and regulator assembly.
2. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH Apply positive (+) battery voltage to connector terminal 2 (B). *a Component without harness connected (Power Window Regulator Motor Assembly RH) *b Clockwise *c Counterclockwise NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Connect a negative (-) battery to connector terminals 1 (GND) and 7 (DOWN) or 10 (UP). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 10 (UP). Disconnect and reconnect the negative (-) battery lead for terminal 10 (UP) within 1 second. Motor gear rotates counterclockwise Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 7 (DOWN). Disconnect and reconnect the negative (-) battery lead for terminal 7 (DOWN) within 1 second. Motor gear rotates clockwise If the result is not as specified, replace the power window regulator motor assembly RH. NOTE: Initialize the power window control system after installing the power window regulator motor and regulator assembly.

HINT

1. Use the same procedure for the RH side and LH side.
2. The procedure described below is for the LH side.

1. INSTALL FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY NOTE: The regulator arm must be below the intermediate position when installing the power window regulator motor assembly. Using a T25 "TORX" socket wrench, install the front power window regulator motor assembly with the 3 screws. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) HINT: When replacing a front power window regulator motor assembly, a new front power window regulator motor assembly uses self-tapping screws to thread new installation holes when the self-tapping screws are inserted.
2. INSTALL FRONT DOOR WINDOW REGULATOR ASSEMBLY Refer to «PROCEDURE - Step 30»(ref-665779-S33938793612014102400000)
3. INSTALL FRONT DOOR GLASS SUB-ASSEMBLY Refer to «PROCEDURE - Step 31»(ref-665779-S33938793612014102400000)
4. INSTALL FRONT NO. 1 SPEAKER ASSEMBLY Refer to «PROCEDURE - Step 1»(ref-665839-S20876006192014102400000)
5. INSTALL FRONT DOOR SERVICE HOLE COVER Refer to «PROCEDURE - Step 33»(ref-665779-S33938793612014102400000)
6. INSTALL FRONT DOOR INNER GLASS WEATHERSTRIP Refer to «PROCEDURE - Step 40»(ref-665779-S33938793612014102400000)
7. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY Refer to «PROCEDURE - Step 44»(ref-665779-S33938793612014102400000)
8. INSTALL FRONT DOOR NO. 1 STIFFENER CUSHION Refer to «PROCEDURE - Step 45»(ref-665779-S33938793612014102400000)
9. INSTALL COURTESY LIGHT ASSEMBLY Refer to «PROCEDURE - Step 2»(ref-665780-S39746886502014102400000)
10. INSTALL FRONT DOOR ARMREST COVER Refer to «PROCEDURE - Step 47»(ref-665779-S33938793612014102400000)
11. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL (for Front Passenger Side) Refer to «PROCEDURE - Step 49»(ref-665779-S33938793612014102400000)
12. INSTALL MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL (for Driver Side) Refer to «PROCEDURE - Step 48»(ref-665779-S33938793612014102400000)
13. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG Refer to «PROCEDURE - Step 50»(ref-665779-S33938793612014102400000)
14. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000)
15. INITIALIZE POWER WINDOW CONTROL SYSTEM Refer to «INITIALIZATION [04/2013 - ]»(ref-665547-S39448188862014102400000)
16. INSPECT POWER WINDOW OPERATION Refer to «OPERATION CHECK [04/2013 - ]»(ref-665547-S10896905262014102400000)

Scheme 32

Scheme 33

Scheme 34

*1 REAR DOOR WINDOW REGULATOR ASSEMBLY *2 REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY *3 REAR DOOR WINDOW REGULATOR SUB-ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque MP grease

HINT

1. Use the same procedure for the RH side and LH side.
2. The procedure described below is for the LH side.

1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000)
3. REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG Refer to «PROCEDURE - Step 3»(ref-665779-S07345647622014102400000)
4. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH REAR DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 4»(ref-665779-S07345647622014102400000)
5. REMOVE REAR DOOR NO. 3 ARMREST COVER Refer to «PROCEDURE - Step 5»(ref-665779-S07345647622014102400000)
6. REMOVE REAR DOOR NO. 1 STIFFENER CUSHION Refer to «PROCEDURE - Step 6»(ref-665779-S07345647622014102400000)
7. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY Refer to «PROCEDURE - Step 7»(ref-665779-S07345647622014102400000)
8. REMOVE REAR DOOR INNER GLASS WEATHERSTRIP Refer to «PROCEDURE - Step 9»(ref-665779-S07345647622014102400000)
9. REMOVE REAR DOOR SERVICE HOLE COVER Refer to «PROCEDURE - Step 12»(ref-665779-S07345647622014102400000)
10. DISCONNECT REAR DOOR WEATHERSTRIP Disconnect the rear door weatherstrip as shown in the illustration.
11. REMOVE REAR DOOR GLASS RUN Refer to «PROCEDURE - Step 16»(ref-665779-S07345647622014102400000)
12. REMOVE REAR DOOR LOWER WINDOW FRAME SUB-ASSEMBLY Refer to «PROCEDURE - Step 17»(ref-665779-S07345647622014102400000)
13. REMOVE REAR DOOR QUARTER WINDOW GLASS Refer to «PROCEDURE - Step 18»(ref-665779-S07345647622014102400000)
14. REMOVE REAR DOOR GLASS SUB-ASSEMBLY Refer to «PROCEDURE - Step 19»(ref-665779-S07345647622014102400000)
15. REMOVE REAR DOOR WINDOW REGULATOR ASSEMBLY Refer to «PROCEDURE - Step 23»(ref-665779-S07345647622014102400000)
16. REMOVE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY Using a T25 "TORX" socket wrench, remove the 3 screws and rear power window regulator motor assembly.

1. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH Apply positive (+) battery voltage to connector terminal 2 (B). *a Component without harness connected (Power Window Regulator Motor Assembly LH) *b Clockwise *c Counterclockwise NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Connect a negative (-) battery to connector terminals 1 (GND) and 7 (DOWN) or 10 (UP). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 10 (UP). Disconnect and reconnect the negative (-) battery lead for terminal 10 (UP) within 1 second. Motor gear rotates clockwise Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 7 (DOWN). Disconnect and reconnect the negative (-) battery lead for terminal 7 (DOWN) within 1 second. Motor gear rotates counterclockwise If the result is not as specified, replace the power window regulator motor assembly LH. NOTE: Initialize the power window control system after installing the power window regulator motor and regulator assembly.
2. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH Apply positive (+) battery voltage to connector terminal 2 (B). *a Component without harness connected (Power Window Regulator Motor Assembly RH) *b Counterclockwise *c Clockwise NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Connect a negative (-) battery to connector terminals 1 (GND) and 7 (DOWN) or 10 (UP). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect a positive (+) battery lead to terminal 2 (B), connect a negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 10 (UP). Disconnect and reconnect the negative (-) battery lead for terminal 10 (UP) within 1 second. Motor gear rotates counterclockwise Connect a positive (+) battery lead to terminal 2 (B), connect the negative (-) battery lead to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected, connect a negative (-) battery lead to terminal 7 (DOWN). Disconnect and reconnect the negative (-) battery lead for terminal 7 (DOWN) within 1 second. Motor gear rotates clockwise If the result is not as specified, replace the power window regulator motor assembly RH. NOTE: Initialize the power window control system after installing the power window regulator motor and regulator assembly.

HINT

1. Use the same procedure for both the RH and LH sides.
2. The procedure described below is for the LH side.

1. INSTALL REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY NOTE: The regulator arm must be below the intermediate position when installing the rear power window regulator motor assembly. Using a T25 "TORX" socket wrench, install the rear power window regulator motor assembly with the 3 screws. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) HINT: When replacing a rear power window regulator motor assembly, a new rear power window regulator motor assembly uses self-tapping screws to thread new installation holes when the self-tapping screws are inserted.
2. INSTALL REAR DOOR WINDOW REGULATOR ASSEMBLY Refer to «PROCEDURE - Step 18»(ref-665779-S03734538072014102400000)
3. INSTALL REAR DOOR GLASS SUB-ASSEMBLY Refer to «PROCEDURE - Step 22»(ref-665779-S03734538072014102400000)
4. INSTALL REAR DOOR QUARTER WINDOW GLASS Refer to «PROCEDURE - Step 23»(ref-665779-S03734538072014102400000)
5. INSTALL REAR DOOR LOWER WINDOW FRAME SUB-ASSEMBLY Refer to «PROCEDURE - Step 24»(ref-665779-S03734538072014102400000)
6. INSTALL REAR DOOR GLASS RUN Refer to «PROCEDURE - Step 25»(ref-665779-S03734538072014102400000)
7. CONNECT REAR DOOR WEATHERSTRIP Connect the rear door weatherstrip as shown in the illustration.
8. INSTALL REAR DOOR SERVICE HOLE COVER Refer to «PROCEDURE - Step 29»(ref-665779-S03734538072014102400000)
9. INSTALL REAR DOOR INNER GLASS WEATHERSTRIP Refer to «PROCEDURE - Step 32»(ref-665779-S03734538072014102400000)
10. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY Refer to «PROCEDURE - Step 34»(ref-665779-S03734538072014102400000)
11. INSTALL REAR DOOR NO. 1 STIFFENER CUSHION Refer to «PROCEDURE - Step 35»(ref-665779-S03734538072014102400000)
12. INSTALL REAR DOOR NO. 3 ARMREST COVER Refer to «PROCEDURE - Step 36»(ref-665779-S03734538072014102400000)
13. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH REAR DOOR ARMREST BASE PANEL Refer to «PROCEDURE - Step 37»(ref-665779-S03734538072014102400000)
14. INSTALL REAR DOOR INSIDE HANDLE BEZEL PLUG Refer to «PROCEDURE - Step 38»(ref-665779-S03734538072014102400000)
15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000)
16. INITIALIZE POWER WINDOW CONTROL SYSTEM Refer to «INITIALIZATION [04/2013 - ]»(ref-665547-S39448188862014102400000)
17. INSPECT POWER WINDOW OPERATION Refer to «OPERATION CHECK [04/2013 - ]»(ref-665547-S10896905262014102400000)

Scheme 35

*1 COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY *2 FRONT WIPER ARM AND BLADE ASSEMBLY LH *3 FRONT WIPER ARM AND BLADE ASSEMBLY RH *4 FRONT WIPER ARM HEAD CAP *5 WINDSHIELD OUTSIDE MOLDING LH *6 WINDSHIELD OUTSIDE MOLDING RH N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 36

Note. When replacing the windshield glass of a vehicle equipped with a lane departure warning camera, make sure to use a Lexus genuine part. The lane departure warning camera may not be able to be installed due to a missing bracket or the lane departure alert system may not operate properly due to a difference in the transmissivity or black ceramic border.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. REMOVE WINDSHIELD OUTSIDE MOLDING LH Refer to «PROCEDURE - Step 1»(ref-665772-S39482884612014102400000)
2. REMOVE WINDSHIELD OUTSIDE MOLDING RH HINT: Use the same procedure as for the LH side.
3. REMOVE FRONT WIPER ARM HEAD CAP Refer to «PROCEDURE - Step 1»(ref-665783-S31832538022014102400000)
4. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY LH Refer to «PROCEDURE - Step 2»(ref-665783-S31832538022014102400000)
5. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY RH Refer to «PROCEDURE - Step 3»(ref-665783-S31832538022014102400000)
6. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 4»(ref-665783-S31832538022014102400000)
7. REMOVE INNER REAR VIEW MIRROR ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665851-S03329096712014102400000)
8. REMOVE RAIN SENSOR (w/ Rain Sensor) Refer to «REMOVAL [04/2013 - ]»(ref-665783-S17356275042014102400000)
9. REMOVE LANE DEPARTURE WARNING CAMERA (w/ Lane Departure Alert System) Refer to «REMOVAL [04/2013 - ]»(ref-665556-S11195377702014102400000)
10. REMOVE ROOF HEADLINING ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665744-S20605909752014102400000)
11. REMOVE WINDSHIELD GLASS SUB-ASSEMBLY w/ Windshield Deicer System: Disconnect the connector. Apply protective tape to the area around the installation position of the windshield glass sub-assembly on the vehicle body to prevent it from being scratched. Protective Tape Using a knife, cut off the windshield outside molding as shown in the illustration. *a Cut Off Place matchmarks on the windshield glass sub-assembly and vehicle body on the locations indicated in the illustration. *a Matchmark HINT: Matchmarks are not necessary if the windshield glass sub-assembly is not going to be reused. Pass a piano wire between the vehicle body and windshield glass sub-assembly from the interior. *1 Windshield Glass Stopper *a Piano Wire Tie both wire ends to wooden blocks or similar objects that can serve as handles. Cut off the adhesive by pulling the piano wire around the windshield glass sub-assembly. NOTE: When separating the windshield glass sub-assembly, be careful not to damage the paint or interior and exterior ornaments. To prevent the safety pad from being scratched when removing the windshield glass, place a plastic sheet between the piano wire and safety pad. Disengage the windshield glass stoppers. *A for 1-piece Type *B for 2-piece Type *1 No. 1 Windshield Glass Stopper *2 No. 2 Windshield Glass Stopper NOTE: The No. 1 windshield glass stoppers and No. 2 windshield glass stoppers are installed on the windshield glass sub-assembly as shown in the illustration. Be careful not to damage the windshield glass sub-assembly when cutting off the adhesive. To prevent the windshield glass from falling when performing this operation, be sure to hold the windshield glass using suction cups. HINT: Depending on the vehicle, either 1-piece type or 2-piece type stoppers may be present. Using suction cups, remove the windshield glass sub-assembly. NOTE: Be careful not to drop the windshield glass sub-assembly. Leave as much adhesive on the vehicle body as possible when removing the windshield glass sub-assembly.
12. REMOVE WINDSHIELD GLASS ADHESIVE DAM When reusing the windshield glass: Using a scraper, remove the windshield glass adhesive dam from the back side of the windshield glass. NOTE: Be careful not to damage the windshield glass. Be sure to replace the windshield glass adhesive dam with a new one. *A Back Side
13. REMOVE FRONT WINDOW INNER MOLDING COVER LH When reusing the windshield glass: Using a scraper, remove the front window inner molding cover LH from the back side of the windshield glass. *A Back Side NOTE: Be careful not to damage the windshield glass. Be sure to replace the front window inner molding cover LH with a new one.
14. REMOVE NO. 1 INSTRUMENT PANEL CUSHION When reusing the windshield glass: Using a scraper, remove the No. 1 instrument panel cushion from the back side of the windshield glass. *A Back Side NOTE: Be careful not to damage the windshield glass. Be sure to replace the No. 1 instrument panel cushion with a new one.
15. REMOVE WINDSHIELD OUTSIDE MOLDING When reusing the windshield glass: Using a scraper, remove the windshield outside molding from the back side of the windshield glass. *A Back Side NOTE: Be careful not to damage the windshield glass. Be sure to replace the windshield outside molding with a new one.
16. REMOVE NO. 1 WINDSHIELD GLASS STOPPER (for 1-piece Type) When reusing the windshield glass: Using a scraper, remove the 2 No. 1 windshield glass stoppers from the back side of the windshield glass. *A Back Side NOTE: Be careful not to damage the windshield glass. Be sure to replace the 1-piece type No. 1 windshield glass stoppers with new 2-piece type No. 1 and No. 2 windshield glass stoppers.
17. REMOVE NO. 2 WINDSHIELD GLASS STOPPER (for 2-piece Type) When reusing the windshield glass: Using a scraper, remove the 2 No. 2 windshield glass stoppers from the back side of the windshield glass. *A Back Side NOTE: Be careful not to damage the windshield glass. Be sure to replace the No. 2 windshield glass stoppers with new ones.
18. REMOVE NO. 1 WINDSHIELD GLASS STOPPER (for 2-piece Type) Remove the 2 No. 1 windshield glass stoppers from the vehicle body. NOTE: Be sure to replace the No. 1 windshield glass stoppers with new ones.
19. CLEAN WINDSHIELD GLASS When reusing the windshield glass: Using a scraper, remove any remaining adhesive dam and adhesive residue from the windshield glass. NOTE: Be careful not to damage the windshield glass. Clean the outer circumference of the windshield glass with a non-residue solvent. NOTE: Do not touch the windshield glass surface after cleaning it. Even if using a new windshield glass, clean the windshield glass with a non-residue solvent.
20. CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away excess adhesive on the contact surface of the vehicle body as shown in the illustration. Standard Dimension Area Dimension a 1.0 mm (0.0394 in.) *a Vehicle Body Adhesive NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of cloth saturated with non-residue solvent. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Note. When replacing the windshield glass of a vehicle equipped with a lane departure warning camera, make sure to use a Lexus genuine part. The lane departure warning camera may not be able to be installed due to a missing bracket or the lane departure alert system may not operate properly due to a difference in the transmissivity or black ceramic border.

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. INSTALL NO. 1 WINDSHIELD GLASS STOPPER (for 2-piece Type) Install 2 new No. 1 windshield glass stoppers to the vehicle body as shown in the illustration. HINT: Only 2-piece type windshield glass stoppers are provided as supply parts. Use 2-piece type stoppers as replacements even if 1-piece type stoppers were originally installed.
2. INSTALL NO. 2 WINDSHIELD GLASS STOPPER (for 2-piece Type) Using a brush or sponge, coat the application area of 2 new No. 2 windshield glass stoppers with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the 2 new No. 2 windshield glass stoppers onto the windshield glass as shown in the illustration. *A Back Side *a Ceramic Notch *b Windshield Glass Edge Side Standard Dimension Area Dimension a 15.5 mm (0.610 in.) HINT: Only 2-piece type windshield glass stoppers are provided as supply parts. Use the 2-piece type stoppers as replacements even if 1-piece type stoppers were originally installed.
3. INSTALL WINDSHIELD OUTSIDE MOLDING Using a brush or sponge, coat the application area of a new windshield outside molding with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the new windshield outside molding onto the windshield glass as shown in the illustration. *A Back Side Edge Of Curved Surface Standard Dimension Area Dimension a 7.15 mm (0.282 in.)
4. INSTALL NO. 1 INSTRUMENT PANEL CUSHION Using a brush or sponge, coat the application area of a new No. 1 instrument panel cushion with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the new No. 1 instrument panel cushion onto the windshield glass as shown in the illustration. *A Back Side *a Ceramic Notch Standard Dimension Area Dimension a 19.7 mm (0.776 in.) b 158.4 mm (6.24 in.) c 58.4 mm (2.30 in.)
5. INSTALL FRONT WINDOW INNER MOLDING COVER LH Using a brush or sponge, coat the application area of new front window inner molding cover LH with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the new front window inner molding cover LH onto the windshield glass as shown in the illustration. *A Back Side *a Ceramic Notch Standard Dimension Area Dimension a 7.1 mm (0.280 in.) b 0 mm (0 in.) c 0 mm (0 in.)
6. INSTALL WINDSHIELD GLASS ADHESIVE DAM Cut the windshield glass adhesive dam so that it is the appropriate size as shown in the illustration. *a Cut Standard Dimension Area Dimension a 2740 mm (108 in.) Using a brush or sponge, coat the application area of a new windshield glass adhesive dam with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the windshield glass adhesive dam onto the windshield glass as shown in the illustration. *A Back Side - - *a Windshield glass adhesive dam positioning ceramic notch *b Windshield glass adhesive dam positioning center line Primer G - - Standard Dimension Area Dimension a 9.5 mm (0.374 in.) b 85.7 mm (3.37 in.)
7. INSTALL WINDSHIELD GLASS SUB-ASSEMBLY Position the windshield glass sub-assembly. *a Matchmark Using suction cups, place the windshield glass sub-assembly in the correct position. Check that the whole contact surface of the windshield glass sub-assembly rim is perfectly even. Align the matchmarks on the windshield glass sub-assembly and vehicle body. NOTE: Check that the windshield glass stoppers are attached to the vehicle body correctly. Remove the windshield glass sub-assembly. Using a brush, coat the installation surface on the vehicle body with primer M. NOTE: Do not coat the adhesive with primer M. Do not apply too much primer M. Allow the primer M to dry for 3 minutes or more. Throw away any leftover primer M. HINT: If an area other than specified is coated by accident, wipe off the primer M with a clean piece of cloth before it dries. Using a brush or sponge, coat the application area of adhesive with primer G. *A Back Side Primer G Standard Dimension Area Dimension a 11 mm (0.433 in.) b 7.1 mm (0.280 in.) c 6.0 mm (0.236 in.) d 19 mm (0.748 in.) NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: Apply primer G onto the ceramic notches. If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Apply adhesive to the windshield glass sub-assembly. Adhesive Toyota Genuine Windshield Glass Adhesive or equivalent Cut off the tip of the cartridge nozzle as shown in the illustration. *1 Sealer Gun *2 Nozzle Standard Dimension Area Dimension a 8.0 mm (0.315 in.) or more b 12.0 mm (0.472 in.) or more HINT: After cutting off the tip, use all adhesive within the time described in the table below. Usage Time Frame Temperature Usage Time Frame 35°C (95°F) 15 minutes 20°C (68°F) 1 hour and 40 minutes 5°C (41°F) 8 hours Load the sealer gun with the cartridge. Apply adhesive to the windshield glass sub-assembly as shown in the illustration. *A Back Side Adhesive Standard Dimension Area Dimension a 4.0 mm (0.158 in.) b 4.0 mm (0.158 in.) c 4.0 mm (0.158 in.) d 3.0 mm (0.118 in.) or more. e 4.0 mm (0.158 in.) f 8.0 mm (0.315 in.) HINT: Apply adhesive onto the ceramic notches. Install the windshield glass sub-assembly. *a Matchmark Using suction cups, position the windshield glass sub-assembly so that the matchmarks are aligned, and press it in gently along the rim. NOTE: Check that the windshield glass stoppers are attached to the vehicle body correctly. Check the clearance between the vehicle body and windshield glass sub-assembly. Lightly press the front surface of the windshield glass sub-assembly to ensure that the windshield glass is securely fit to the vehicle body. HINT: Press the glass with a force of 98 N (10 kgf, 22.0 lbf) or more. Using a scraper, remove any excess or protruding adhesive. Hold the windshield glass using protective tape until the applied adhesive becomes hard. NOTE: Do not drive the vehicle for the time described in the table below. Minimum Time Temperature Minimum Time prior to Driving Vehicle 35°C (95°F) 1 hour and 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours w/ Windshield Deicer System: Connect the connector.
8. INSPECT FOR LEAK After the adhesive has hardened, apply water from the outside of the vehicle. Check that no water leaks into the cabin. If water leaks into the cabin, allow the water to dry and add adhesive. Remove the protective tape.
9. INSTALL ROOF HEADLINING ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665744-S14510194262014102400000)
10. INSTALL LANE DEPARTURE WARNING CAMERA (w/ Lane Departure Alert System) Refer to «INSTALLATION [04/2013 - ]»(ref-665556-S35218584422014102400000)
11. INSTALL RAIN SENSOR (w/ Rain Sensor) Refer to «INSTALLATION [04/2013 - ]»(ref-665783-S11605388532014102400000)
12. INSTALL INNER REAR VIEW MIRROR ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665851-S22040311512014102400000)
13. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-665783-S42034201142014102400000)
14. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY LH Refer to «PROCEDURE - Step 4»(ref-665783-S42034201142014102400000)
15. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY RH Refer to «PROCEDURE - Step 5»(ref-665783-S42034201142014102400000)
16. INSTALL FRONT WIPER ARM HEAD CAP Refer to «PROCEDURE - Step 6»(ref-665783-S42034201142014102400000)
17. INSTALL WINDSHIELD OUTSIDE MOLDING LH Refer to «PROCEDURE - Step 3»(ref-665772-S40726927092014102400000)
18. INSTALL WINDSHIELD OUTSIDE MOLDING RH HINT: Use the same procedure as for the LH side.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. REMOVE NO. 1 AMPLIFIER ANTENNA ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665839-S10374597922014102400000)
2. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) Refer to «REMOVAL [04/2013 - ]»(ref-665531-S08239659682014102400000)
3. REMOVE NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) Refer to «REMOVAL [04/2013 - ]»(ref-665744-S35338260652014102400000)
4. REMOVE BACK WINDOW GLASS SUB-ASSEMBLY Disconnect each connector. Apply protective tape to the area around the installation position of the back window glass sub-assembly on the vehicle body to prevent it from being scratched. Protective Tape Using a knife, cut off the back window outside molding as shown in the illustration. *a Cut Off Place matchmarks on the back window glass sub-assembly and vehicle body on the locations indicated in the illustration. *a Matchmark HINT: Matchmarks are not needed to be placed if the back window glass sub-assembly will not be reused. Pass a piano wire between the vehicle body and back window glass sub-assembly from the interior. *1 Back Window Glass Stopper *a Piano Wire Tie both wire ends to wooden blocks or similar objects. Cut off the adhesive by pulling the piano wire around the back window glass sub-assembly. NOTE: When separating the back window glass sub-assembly, take care not to damage the paint or interior and exterior ornaments. NOTE: When separating the back window glass sub-assembly, take care not to damage the paint or interior and exterior ornaments. When cutting off the adhesive, take care not to damage the connectors on the back window glass sub-assembly. Disconnect the back window glass stoppers. *A for 1-piece Type *B for 2-piece Type *1 No. 1 Back Window Glass Stopper *2 No. 2 Back Window Glass Stopper NOTE: The No. 1 Back Window Glass Stoppers and No. 2 Back Window Glass Stoppers are installed on the back window glass sub-assembly as shown in the illustration. Be careful not to damage the back window glass sub-assembly when cutting off the adhesive. To prevent the back window glass sub-assembly from falling when performing this operation, be sure to hold the back window glass sub-assembly using suction cups. HINT: Depending on the vehicle, either 1-piece type or 2-piece type stoppers may be present. Using suction cups, remove the back window glass sub-assembly. NOTE: Be careful not to drop the back window glass sub-assembly. Leave as much adhesive on the vehicle body as possible when removing the back window glass sub-assembly.
5. REMOVE BACK WINDOW GLASS ADHESIVE DAM When reusing the back window glass: Using a scraper, remove the back window glass adhesive dam from the back side of the back window glass. *A Back Side NOTE: Be careful not to damage the back window glass. Be sure to replace the back window glass adhesive dam with a new one.
6. REMOVE BACK WINDOW OUTSIDE MOLDING When reusing the back window glass: Using a scraper, remove the back window outside molding from the back side of the back window glass. *A Back Side NOTE: Be careful not to damage the back window glass. Be sure to replace the back window outside molding with a new one.
7. REMOVE NO. 1 BACK WINDOW GLASS STOPPER (for 1-piece Type) When reusing the back window glass: Using a scraper, remove the 2 No. 1 back window glass stoppers from the back side of the back window glass. *A Back Side NOTE: Be careful not to damage the back window glass. Be sure to replace the 1-piece type No. 1 back window glass stoppers with new 2-piece type No. 1 and No. 2 back window glass stoppers.
8. REMOVE NO. 2 BACK WINDOW GLASS STOPPER (for 2-piece Type) When reusing the back window glass: Using a scraper, remove the 2 No. 2 back window glass stoppers from the back side of the back window glass. *A Back Side NOTE: Be careful not to damage the back window glass. Be sure to replace the No. 2 back window glass stoppers with new ones.
9. REMOVE NO. 1 BACK WINDOW GLASS STOPPER (for 2-piece Type) Remove the 2 No. 1 back window glass stoppers. NOTE: Be sure to replace the No. 1 back window glass stoppers with new ones.
10. CLEAN BACK WINDOW GLASS Using a scraper, remove any remaining adhesive dam and adhesive residue from the back window glass. NOTE: Be careful not to damage the back window glass. Clean the outer circumference of the back window glass with a non-residue solvent. NOTE: Do not touch the glass surface after cleaning it. Be careful not to damage the back window glass. Even if using a new back window glass, clean it with a non-residue solvent.
11. CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. *a Vehicle Body Adhesive Using a knife, cut away excess adhesive on the contact surface of the vehicle body as shown in the illustration. Standard Dimension Area Dimension a 1.0 mm (0.0394 in.) NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of cloth saturated with non-residue solvent. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 61

Scheme 62

1. INSTALL NO. 2 BACK WINDOW GLASS STOPPER (for 2-piece Type) Using a brush or sponge, coat the application area of 2 new No. 2 back window glass stoppers with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the 2 new No. 2 back window glass stoppers onto the back window glass as shown in the illustration. *A Back Side *a Ceramic Notch *b Back Window Glass Edge Side Standard Dimension Area Dimension a 14.6 mm (0.575 in.) HINT: Only 2-piece type back window glass stoppers are provided as supply parts. Use 2-piece type stoppers as replacements even if a 1-piece type was originally installed.
2. INSTALL NO. 1 BACK WINDOW GLASS STOPPER (for 2-piece Type) Install 2 new No. 1 back window glass stoppers to the vehicle body as shown in the illustration. HINT: Only 2-piece type back window glass stoppers are provided as supply parts. Use 2-piece type stoppers as replacements even if a 1-piece type was originally installed.
3. INSTALL BACK WINDOW OUTSIDE MOLDING Using a brush or sponge, coat the application area of a new back window outside molding with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the new back window outside molding onto the back window glass as shown in the illustration. *A Back Side *a Edge Of Curved Surface Standard Dimension Area Dimension a 7.4 mm (0.291 in.)
4. INSTALL BACK WINDOW GLASS ADHESIVE DAM Cut the back window glass adhesive dam so that it is the appropriate size as shown in the illustration. *a Cut Standard Dimension Area Dimension a 1227 mm (48.3 in.) Using a brush or sponge, coat the application area of a new back window glass adhesive dam with primer G. NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Install the new back window glass adhesive dam onto the back window glass as shown in the illustration. *A Back Side - - *a Back window glass adhesive dam positioning ceramic notch *b Back window glass adhesive dam positioning center line Standard Dimension Area Dimension a 15.2 mm (0.598 in.)
5. INSTALL BACK WINDOW GLASS SUB-ASSEMBLY Position the back window glass sub-assembly. *a Matchmark Using suction cups, place the back window glass sub-assembly in the correct position. Check that the whole contact surface of the back window glass sub-assembly rim is perfectly even. Align the matchmarks on the back window glass sub-assembly and vehicle body. NOTE: Check that the back window glass stoppers are attached to the vehicle body correctly. Remove the back window glass sub-assembly. Using a brush, coat the installation surface on the vehicle body with primer M. NOTE: Do not coat the adhesive with primer M. Do not apply too much primer M. Allow the primer M to dry for 3 minutes or more. Throw away any leftover primer M. HINT: If an area other than specified is coated by accident, wipe off the primer M with a clean piece of cloth before it dries. Using a brush or sponge, coat the adhesive application area with primer G. *A Back Side - - *a Adhesive center position *b Ceramic Notch Primer G - - Standard Dimension Area Dimension a 50.0 mm (1.969 in.) b 11 mm (0.433 in.) c 11 mm (0.433 in.) d 19 mm (0.748 in.) NOTE: Do not apply too much primer G. Allow the primer G to dry for 3 minutes or more. Throw away any leftover primer G. HINT: If an area other than specified is coated by accident, wipe off the primer G with a clean piece of cloth before it dries. Apply adhesive to the back window glass sub-assembly. Adhesive Toyota Genuine Windshield Glass Adhesive or equivalent Cut off the tip of the cartridge nozzle as shown in the illustration. *1 Sealer Gun *2 Nozzle Standard Dimension Area Dimension a 12.0 mm (0.472 in.) b 8.0 mm (0.315 in.) HINT: After cutting off the tip, use all adhesive within the time described in the table below. Usage Time Frame Temperature Usage Time Frame 35°C (95°F) 15 minutes 20°C (68°F) 1 hour and 40 minutes 5°C (41°F) 8 hours Load the sealer gun with the cartridge. Apply adhesive to the back window glass sub-assembly as shown in the illustration. *A Back Side - - *a Adhesive center position *b Ceramic Notch Adhesive - - Standard Dimension Area Dimension a 50.0 mm (1.969 in.) b 10.0 mm (0.394 in.) c 10.0 mm (0.394 in.) d 10.0 mm (0.394 in.) e 8.0 mm (0.315 in.) f 4.0 mm (0.158 in.) Install the back window glass sub-assembly. Using suction cups, position the back window glass sub-assembly so that the matchmarks are aligned and press it in gently along the rim. *a Matchmark NOTE: Check that the back window glass stoppers are attached to the vehicle body correctly. Check the clearance between the vehicle body and back window glass sub-assembly. Lightly press the front surface of the back window glass sub-assembly to ensure that the back window glass sub-assembly is securely fit to the vehicle body. HINT: Press the glass with force of 98 N (10 kgf, 22.0 lbf) or more. Using a scraper, remove any excess or protruding adhesive. Hold the back window glass sub-assembly using protective tape until the applied adhesive becomes hard. NOTE: Do not drive the vehicle for the time described in the table below. Minimum Time Temperature Minimum Time Prior to Driving Vehicle 35°C (95°F) 1 hour and 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours Connect each connector.
6. INSPECT FOR LEAK After the adhesive has hardened, apply water from the outside of the vehicle. Check that no water leaks into the cabin. If water leaks into the cabin, allow the water to dry and add adhesive. Remove the protective tape.
7. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) Refer to «INSTALLATION [04/2013 - ]»(ref-665531-S05502115432014102400000)
8. INSTALL NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) Refer to «INSTALLATION [04/2013 - ]»(ref-665744-S25064702102014102400000)
9. INSTALL NO. 1 AMPLIFIER ANTENNA ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665839-S30735482442014102400000)

Scheme 63

1. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 9»(ref-665744-S19081852182014102400000)
2. DISCONNECT HOOD LOCK CONTROL LEVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 10»(ref-665744-S19081852182014102400000)
3. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 11»(ref-665744-S19081852182014102400000)
4. REMOVE OUTER MIRROR HEATER SWITCH ASSEMBLY Disengage the 2 claws to remove the outer mirror heater switch assembly.

Scheme 64

1. INSPECT OUTER MIRROR HEATER SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Outer Mirror Heater Switch Assembly) Standard Resistance Tester Connection Condition Specified Condition 6 - 9 Outer mirror heater switch assembly on Below 1 ohms 6 - 9 Outer mirror heater switch assembly off 10 kohms or higher If the result is not as specified, replace the outer mirror heater switch assembly. Check that the indicator light illuminates. *a Indicator Light *b Illumination *c Component without harness connected (Outer Mirror Heater Switch Assembly) OK Tester Connection Specified Condition Battery positive (+) --> 6 Battery negative (-) --> 10 Outer mirror heater switch assembly indicator illuminates If the result is not as specified, replace the outer mirror heater switch assembly. Check that the illumination illuminates. OK Tester Connection Specified Condition Battery positive (+) --> 8 Battery negative (-) --> 7 Outer mirror heater switch assembly illumination illuminates If the result is not as specified, replace the outer mirror heater switch assembly.

1. INSTALL OUTER MIRROR HEATER SWITCH ASSEMBLY Engage the 2 claws to install the outer mirror heater switch assembly.
2. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 34»(ref-665744-S38149584352014102400000)
3. CONNECT HOOD LOCK CONTROL LEVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 35»(ref-665744-S38149584352014102400000)
4. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 36»(ref-665744-S38149584352014102400000)

Scheme 65

Scheme 66

Scheme 67

1. CHECK REAR WINDOW DEFOGGER OPERATION When the engine switch is on (IG) and the rear window defogger switch is pressed, check that the window defogger system operates.
2. INSPECT BACK WINDOW GLASS (REAR WINDOW DEFOGGER WIRE) NOTE: When cleaning the glass, wipe the glass along the wire using a soft dry cloth. Take care not to damage the wire. Do not use detergents or glass cleaners that have abrasive ingredients. When measuring voltage, wrap a piece of tin foil around the tip of the negative tester probe and press the foil against the wire with your finger as shown in the illustration. Turn the engine switch on (IG). *1 Rear Window Defogger Wire *a Tester Probe *b Tin Foil Turn the rear window defogger switch on. Measure the voltage at the center of each rear window defogger wire to check the wire as shown in the illustration. *a Foil Strip *b Center of Wire Result Voltage Criteria 4 to 6 V Wire is not broken 11 to 14 V Wire is broken between the center and ground side end Below 1 V Wire is broken between the center and battery side end HINT: If the voltage is 11 to 14 V, the wire may be broken between the center of the wire and the wire end on the ground side. If the voltage is below 1 V, the wire may be broken between the center of the wire and the wire end on the battery side. Place the positive (+) lead of the voltmeter against the rear window defogger wire on the battery side. *a 11 to 14 V *b Below 1 V *c Ground Side *d Battery Side *e Foil Strip *f Broken Wire Place the negative (-) lead of the voltmeter with the foil strip against the wire on the ground side. Slide the positive (+) lead from the battery side to the ground side. The point where the voltage drops to below 1 V from 11 to 14 V is the place where the rear window defogger wire is broken. HINT: If the rear window defogger wire is not broken, the voltmeter should indicate 11 to 14 V at the battery side. As the positive (+) lead is moved to the ground side, the voltage gradually decreases to below 1 V.

Scheme 68

1. REPAIR BACK WINDOW GLASS (REAR WINDOW DEFOGGER WIRE) *a Masking Tape *b Broken Wire *c Repair Point Clean the broken wire tips with a grease, wax and silicone remover. Place masking tape along both sides of the wire. Thoroughly mix the repair agent (Dupont paste No. 4817 or equivalent). Using a fine tip brush, apply a small amount of the agent to the wire. After a few minutes, remove the masking tape. NOTE: Do not use the rear window defogger for at least 24 hours after performing the repair.
