Engine Control System (Service Information): Diagnosis Lexus IS II facelift

Engine Control Systems 12 illustrations ~1806 words

ON-VEHICLE INSPECTION

  1. INSPECT ACCELERATOR PEDAL Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch ON. Enter the following menus: Powertrain / Engine and ECT / Data List / Accelerator Position No. 1 and Accelerator Position No. 2. When depressing or releasing the accelerator pedal, check that the values of the Accelerator Position No. 1 and Accelerator Position No. 2 are within the specification. Accelerator Position No. 1 standard voltage Condition Specified Condition Accelerator pedal is released 0.5 to 1.1 V Accelerator pedal is depressed 2.6 to 4.5 V Accelerator Position No. 2 standard voltage Condition Specified Condition Accelerator pedal is released 1.2 to 2.0 V Accelerator pedal is depressed 3.4 to 5.0 V If the result is not as specified, check the accelerator pedal, wire harness or ECM.

Scheme 20

Scheme 20: REMOVAL
Scheme 20: REMOVAL
  1. REMOVE ACCELERATOR PEDAL Disconnect the accelerator pedal position sensor connector. Remove the 2 bolts and accelerator pedal. NOTE: Avoid physical shock to the accelerator pedal. Do not disassemble the accelerator pedal assembly.

Note. Perform the MAF meter inspection according to the procedures below. Only replace the MAF meter when both the LONG FT#1 value and MAF value in the DATA LIST (with the engine stopped) are not within the normal operating range.

  1. INSPECT MASS AIR FLOW METER Read the value using Techstream (MAF). NOTE: Turn off the engine. Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the MAF meter while it is installed to the air cleaner case (installed to the vehicle). During the test, do not use the exhaust air duct to perform suction on the exhaust pipe. Turn the engine switch on (ACC). Turn the engine switch on (IG) (do not run the engine). Turn the Techstream ON. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Wait 30 seconds, and read the values on the Techstream. Standard condition Less than 0.36 g/sec. If the result is not as specified, replace the MAF meter. If the result is within the specified range, inspect the cause of the extremely rich or lean air fuel ratio.

Scheme 21

Scheme 21
Scheme 21
  1. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 1»(ref-387327-S01811944422011022400000)
  2. REMOVE ENGINE ROOM SIDE COVER RH . Refer to «REMOVAL - Step 3»(ref-387327-S01811944422011022400000)
  3. REMOVE MASS AIR FLOW METER Disconnect the MAF meter connector. Remove the 2 screws and MAF meter. Remove the O-ring from the MAF meter.
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream main switch ON. Start and warm up the engine. Idle the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test. Specified condition Tester Display Test Part Control Range Diagnostic Note Control the VVT Linear (Bank1) Control VVT (bank 1) -128 to 127 % This valve added to present OCV control duty 100 %: Maximum advance -100 %: Maximum retard Engine stall or rough idle when VVT actuator operated by 100 %. Test possible during idle. Control the VVT System (Bank1) Turn on and off OCV (Oil Control Valve) ON/OFF Engine stalls or idles roughly when OCV turned ON Normal engine running or idling when OCV OFF Control the VVT Linear (Bank2) Control VVT (bank 2) Between -128 and 127% Same as above Control the VVT System (Bank2) Turn on and off OCV (Oil Control Valve) ON/OFF Engine stalls or idles roughly when OCV turned ON Normal engine running or idling when OCV OFF If the result is not as specified, check the oil control valve and wirings. HINT: VVT CTRS: Command to activate exhaust and intake side oil control valves of bank 1. VVT CTRS B1: Command to activate exhaust and intake side oil control valves of bank 2. VVT B1: Command to activate intake side oil control valve of bank 1. VVT B2: Command to activate intake side oil control valve of bank 2. VVT EX B1: Command to activate exhaust side oil control valve of bank 1. VVT EX B2: Command to activate exhaust side oil control valve of bank 2.

Scheme 22

Scheme 22: REMOVAL
Scheme 22: REMOVAL

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 1»(ref-387328-S29638762412011022400000)
  2. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL - Step 2»(ref-387328-S29638762412011022400000)
  3. REMOVE ENGINE ROOM SIDE COVER RH . Refer to «REMOVAL - Step 3»(ref-387328-S29638762412011022400000)
  4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-387327-S01811944422011022400000)
  5. REMOVE FRONT FENDER PROTECTOR UPPER LH . Refer to «REMOVAL - Step 4»(ref-387356-S14516267932011022400000)
  6. REMOVE FRONT FENDER PROTECTOR UPPER RH . Refer to «REMOVAL - Step 3»(ref-387327-S01811944422011022400000)
  7. REMOVE ROOF DRIP SIDE FINISH MOULDING LH . Refer to «REMOVAL - Step 1»(ref-387357-S31869193502011022400000)
  8. REMOVE ROOF DRIP SIDE FINISH MOULDING RH . Refer to «REMOVAL - Step 7»(ref-387356-S14516267932011022400000)
  9. REMOVE FRONT WIPER ARM HEAD CAP . Refer to «REMOVAL - Step 8»(ref-387356-S14516267932011022400000)
  10. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH . Refer to «REMOVAL - Step 10»(ref-387356-S14516267932011022400000)
  11. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH . Refer to «REMOVAL - Step 9»(ref-387356-S14516267932011022400000)
  12. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-387356-S14516267932011022400000)
  13. DISCHARGE FUEL SYSTEM PRESSURE . Refer to «REMOVAL - Step 13»(ref-387358-S33362158802011022400000)
  14. DRAIN ENGINE COOLANT . Refer to «ON-VEHICLE INSPECTION - Step 4»(ref-387331-S20198491732011022400000)
  15. REMOVE NO. 2 VENTILATION HOSE See step 5
  16. REMOVE AIR CLEANER CAP WITH AIR CLEANER HOSE See step 6
  17. SEPARATE THROTTLE BODY See step 7
  18. REMOVE COLD START INJECTOR . Refer to «REMOVAL - Step 4»(ref-387358-S05890432232011022400000)
  19. REMOVE INTAKE AIR SURGE TANK . Refer to «REMOVAL - Step 20»(ref-387358-S33362158802011022400000)
  20. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 1 Exhaust Side) Disconnect the camshaft timing oil control valve connector. Remove the bolt and camshaft timing oil control valve. Remove the O-ring from the camshaft timing oil control valve.
  21. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 1 Intake Side) Remove the bolt and V-bank cover bracket. Disconnect the camshaft timing oil control valve connector. Remove the bolt and camshaft timing oil control valve. Remove the O-ring from the camshaft timing oil control valve.
  22. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 2 Exhaust Side) Disconnect the camshaft timing oil control valve connector. Remove the bolt and camshaft timing oil control valve. Remove the O-ring from the camshaft timing oil control valve.
  23. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 2 Intake Side) Disconnect the 2 wire harness cramps from the bracket. Remove the 2 bolts and bracket. Disconnect the camshaft timing oil control valve connector. Remove the bolt and camshaft timing oil control valve. Remove the O-ring from the camshaft timing oil control valve.

Scheme 28

Scheme 28: INSPECTION
Scheme 28: INSPECTION

Scheme 29

Scheme 29
Scheme 29
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance between the terminals. Standard resistance 6.9 to 7.9 ohms at 20°C (68°F) If the result is not as specified, replace the oil control valve. Connect the battery's positive (+) lead to terminal 1 and negative (-) lead to terminal 2, and check the movement of the valve. OK Condition Specified Condition Battery positive (+) voltage is applied Valve moves in left arrow direction shown in illustration Battery positive (+) voltage is cut off Valve moves in right arrow direction shown in illustration If result is not as specified, replace the oil control valve. NOTE: If the valve cannot return properly because of foreign matter, a small pressure leak in the advanced direction may occur and a DTC may be output.

Scheme 30

Scheme 30: INSTALLATION
Scheme 30: INSTALLATION

Scheme 31

Scheme 31
Scheme 31
  1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 2 Intake Side) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve. Install the camshaft timing oil control valve with the bolt. Torque: 10 N*m ( 102 kgf*cm, 7 ft.*lbf) NOTE: Be careful that the O-ring is not cracked or jumped when installing the oil control valve. Connect the camshaft timing oil control valve connector. Install the bracket with the 2 bolts. Bolt A Torque: 10 N*m ( 104 kgf*cm, 7 ft.*lbf) Bolt B Torque: 21 N*m ( 214 kgf*cm, 16 ft.*lbf) Connect the 2 wire harness clamps to the bracket.
  2. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 2 Exhaust Side) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve. Install the camshaft timing oil control valve with the bolt. Torque: 10 N*m ( 102 kgf*cm, 7 ft.*lbf) NOTE: Be careful that the O-ring is not cracked or jumped when installing the oil control valve. Connect the camshaft timing oil control valve connector.
  3. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 1 Intake Side) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve. Install the camshaft timing oil control valve with the bolt. Torque: 10 N*m ( 102 kgf*cm, 7 ft.*lbf) NOTE: Be careful that the O-ring is not cracked or jumped when installing the oil control valve. Connect the camshaft timing oil control valve connector. Install the V-bank cover bracket with the bolt. Torque: 10 N*m ( 102 kgf*cm, 7 ft.*lbf)
  4. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE (for Bank 1 Exhaust Side) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve. Install the camshaft timing oil control valve with the bolt. Torque: 10 N*m ( 102 kgf*cm, 7 ft.*lbf) NOTE: Be careful that the O-ring is not cracked or jumped when installing the oil control valve. Connect the camshaft timing oil control valve connector.
  5. INSTALL INTAKE AIR SURGE TANK . Refer to «INSTALLATION - Step 13»(ref-387358-S04826469332011022400000)
  6. INSTALL THROTTLE BODY See step 1
  7. INSTALL AIR CLEANER CAP WITH AIR CLEANER HOSE See step 2
  8. CONNECT NO. 2 VENTILATION HOSE See step 3
  9. ADD ENGINE COOLANT . Refer to «ON-VEHICLE INSPECTION - Step 5»(ref-387331-S20198491732011022400000)
  10. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-387369-S16007212052011022400000)
  11. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 3»(ref-387356-S13984164612011022400000)
  12. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH . Refer to «INSTALLATION - Step 4»(ref-387356-S13984164612011022400000)
  13. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH . Refer to «INSTALLATION - Step 5»(ref-387356-S13984164612011022400000)
  14. INSTALL FRONT WIPER ARM HEAD CAP . Refer to «INSTALLATION - Step 6»(ref-387356-S13984164612011022400000)
  15. INSTALL ROOF DRIP SIDE FINISH MOULDING LH
  16. INSTALL ROOF DRIP SIDE FINISH MOULDING RH
  17. INSTALL FRONT FENDER PROTECTOR UPPER LH . Refer to «INSTALLATION - Step 9»(ref-387356-S13984164612011022400000)
  18. INSTALL FRONT FENDER PROTECTOR UPPER RH . Refer to «INSTALLATION - Step 10»(ref-387356-S13984164612011022400000)
  19. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 115»(ref-387327-S10826489542011022400000)
  20. INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION - Step 87»(ref-387328-S33997225912011022400000)
  21. INSTALL ENGINE ROOM SIDE COVER RH . Refer to «INSTALLATION - Step 88»(ref-387328-S33997225912011022400000)
  22. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 89»(ref-387328-S33997225912011022400000)
