Engine Control System (Diagnostic Codes (P0010-P0171)): Other Lexus IS II facelift 2

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

CASE 1

CASE 2

TYPICAL MALFUNCTION THRESHOLDS

CASE 1

CASE 2

COMPONENT OPERATING RANGE

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on.
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0010 or P0020.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
12. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 98

PROCEDURE

1. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the oil control valve (for intake camshaft) using the Techstream. OK Tester Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2 and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . NG --> See step 2 OK --> See step 4
2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve (for intake camshaft). Refer to «INSPECTION [08/2012 - ]»(ref-606499-S04243091422014032500000) . NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (OCV - ECM) Disconnect the E18 or E11 OCV connector. Disconnect the E3 or E5 ECM connectors. Measure the resistance according to the value(s) in the table below. Standard resistance (check for open) Tester Connection Specified Condition E18-1 - E3-34 (OC1+) Below 1 ohms E18-2 - E3-33 (OC1-) Below 1 ohms E11-1 - E5-9 (OC2+) Below 1 ohms E11-2 - E5-8 (OC2-) Below 1 ohms Standard resistance (check for short) Tester Connection Specified Condition E18-1 or E3-34 (OC1+) - Body ground 10 kohms or higher E18-2 or E3-33 (OC1-) - Body ground 10 kohms or higher E11-1 or E5-9 (OC2+) - Body ground 10 kohms or higher E11-2 or E5-8 (OC2-) - Body ground 10 kohms or higher Reconnect the OCV and ECM connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OCV - ECM) OK --> See step 6
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
5. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S06461608722014032500000)
6. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

ADVANCED CAMSHAFT TIMING

RETARD CAMSHAFT TIMING

1. If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2012 - ] .

Scheme 99

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Idle the engine for 3 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0011, P0012, P0021 or P0022.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
14. Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
15. Idle the engine for 3 minutes or more [G].
16. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
17. Read the pending DTCs [H]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0011, P0012, P0021 OR P0022) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. Result Display (DTC Output) Proceed to P0011, P0012, P0021 or P0022 A P0011, P0012, P0021 or P0022 and other DTCs B HINT: If any DTCs other than P0011, P0012, P0021 or P0022 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Tester Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2 and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . NG --> See step 4 OK: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0011, P0012, P0021 and/or P0022 are output B HINT: DTC P0011, P0012, P0021 or P0022 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain set even if the system returns to normal after a short time. Those foreign objects may then be captured by the oil filter. B --> See step 4 A --> See step 9
4. CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft pulley, and align its groove with the timing mark "0" of the timing chain cover. Check that the timing marks of the camshaft timing gears are aligned with the timing marks of the bearing cap as shown in the illustration. If not, turn the crankshaft 1 revolution (360°), then align the marks as above. OK Timing marks on camshaft timing gears are aligned as shown in the illustration. Reinstall the cylinder head covers. NG --> See step 11 OK: Go to next step
5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve (for intake camshaft). Refer to «INSPECTION [08/2012 - ]»(ref-606499-S04243091422014032500000) . NG --> See step 12 OK: Go to next step
6. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the oil pipe No. 1 or No. 2. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. NG --> See step 13 OK: Go to next step
7. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank1 or bank 2). Refer to «REMOVAL [08/2012 - ]»(ref-606457-S31282357042014032500000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0011, P0012, P0021 or P0022 are output B B --> See step 14 A --> END
9. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
11. ADJUST VALVE TIMING. Refer to «REASSEMBLY [08/2012 - ]»(ref-606457-S34508900282014032500000)
12. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S06461608722014032500000)
13. REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [08/2012 - ] - Step 9»(ref-606457-S18284791532014032500000)
14. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

ALL

CASE 1

CASE 2

CASE 1

CASE 2

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on.
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0013 or P0023.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
12. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 100

1. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the Techstream. OK Tester Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1, VVT Ex OCV Duty #2 and VVT Ex Chg Angle #2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . NG --> See step 2 OK --> See step 4
2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve (for exhaust camshaft). Refer to «INSPECTION [08/2012 - ]»(ref-606499-S04243091422014032500000) . NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (OCV - ECM) Disconnect the E21 or E31 OCV connector. Disconnect the E3 or E5 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (check for open) Tester Connection Specified Condition E21-1 - E3-9 (OE1+) Below 1 ohms E21-2 - E3-8 (OE1-) Below 1 ohms E31-1 - E5-24 (OE2+) Below 1 ohms E31-2 - E5-23 (OE2-) Below 1 ohms Standard resistance (check for short) Tester Connection Specified Condition E21-1 or E3-9 (OE1+) - Body ground 10 kohms or higher E21-2 or E3-8 (OE1-) - Body ground 10 kohms or higher E31-1 or E5-24 (OE2+) - Body ground 10 kohms or higher E31-2 or E5-23 (OE2-) - Body ground 10 kohms or higher Reconnect the OCV and ECM connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OCV - ECM) OK --> See step 6
4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
5. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S06461608722014032500000)
6. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

ADVANCED CAMSHAFT TIMING

RETARD CAMSHAFT TIMING

1. If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2012 - ] .

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Idle the engine for 3 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0014, P0015, P0024 or P0025.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
14. Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
15. Idle the engine for 3 minutes or more [G].
16. Enter the following menus: Powertrain / Engine / Trouble Codes [H].
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC output) Proceed to P0014, P0015, P0024 or P0025 A P0014, P0015, P0024 or P0025 and other DTCs B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Tester Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1, VVT Ex OCV Duty #2 and VVT Ex Chg Angle #2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . NG --> See step 4 OK: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0014, P0015, P0024 or P0025 are output B HINT: DTC P0014, P0015, P0024 or P0025 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain set even if the system returns to normal after a short time. Those foreign objects may then be captured by the oil filter. B --> See step 4 A --> See step 10
4. CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft pulley, and align its groove with the timing mark "0" of the timing chain cover. Check that the timing marks of the camshaft timing gears are aligned with the timing marks of the bearing cap as shown in the illustration. If not, turn the crankshaft 1 revolution (360°), then align the marks as above. OK Timing marks on crankshaft timing gears are aligned as shown in the illustration. Reinstall the cylinder head covers. NG --> See step 11 OK: Go to next step
5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve (for exhaust camshaft). Refer to «INSPECTION [08/2012 - ]»(ref-606499-S04243091422014032500000) . NG --> See step 12 OK: Go to next step
6. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the oil pipe No. 1 or No. 2. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK Filter is not clogged. NG --> See step 13 OK: Go to next step
7. REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing exhaust gear assembly (bank 1 or bank 2). Refer to «REMOVAL [08/2012 - ]»(ref-606457-S31282357042014032500000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0014, P0015, P0024 or P0025 are output B B --> See step 14 A --> END
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
10. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
11. ADJUST VALVE TIMING. Refer to «REASSEMBLY [08/2012 - ]»(ref-606457-S34508900282014032500000)
12. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S06461608722014032500000)
13. REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [08/2012 - ] - Step 9»(ref-606457-S18284791532014032500000)
14. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

Scheme 101

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0016 or P0018.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
13. Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Idle the engine for 5 minutes or more [F].
15. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
16. Read the pending DTCs [G]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Check the DTC judgment result.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0016 or P0018 A P0016 or P0018 and other DTCs B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the oil control valve using the Techstream. OK Tester Operation Specified Condition 0% Normal engine idle speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2 and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . NG --> See step 4 OK: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0016 or P0018 are output B HINT: DTC P0016 or P0018 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain set even if the system returns to normal after a short time. Those foreign objects may then be captured by the oil filter. B --> See step 4 A --> See step 14
4. CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover RH and LH. NG --> See step 10 OK: Go to next step
5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve (for intake camshaft). Refer to «INSPECTION [08/2012 - ]»(ref-606499-S04243091422014032500000) . NG --> See step 11 OK: Go to next step
6. CHECK OIL CONTROL VALVE FILTER AND OIL PIPE Remove the oil pipe No. 1 or No. 2. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. Reinstall the oil pipe No. 1 or No. 2. NG --> See step 12 OK: Go to next step
7. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «REMOVAL [08/2012 - ]»(ref-606457-S31282357042014032500000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0016 or P0018 are output B B --> See step 13 A --> END
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
10. ADJUST VALVE TIMING. Refer to «REASSEMBLY [08/2012 - ]»(ref-606457-S34508900282014032500000)
11. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S06461608722014032500000)
12. REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [08/2012 - ] - Step 9»(ref-606457-S18284791532014032500000)
13. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
14. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)

Scheme 102

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0017 or P0019.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
13. Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Idle the engine for 5 minutes or more [F].
15. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
16. Read the pending DTCs [G]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Check the DTC judgment result.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0017 or P0019 A P0017 or P0019 and other DTCs B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the Techstream. OK Tester Operation Specified Condition 0% Normal engine idle speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1, VVT Ex OCV Duty #2 and VVT Ex Chg Angle #2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . NG --> See step 4 OK: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0017 or P0019 are output B HINT: DTC P0017 or P0019 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain set even if the system returns to normal after a short time. Those foreign objects may then be captured by the oil filter. B --> See step 4 A --> See step 14
4. CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMP TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft to align the matchmarks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the matchmarks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the matchmarks do not align. Check if they align once again. OK The matchmarks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover RH and LH. NG --> See step 10 OK: Go to next step
5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve (for exhaust camshaft). Refer to «INSPECTION [08/2012 - ]»(ref-606499-S04243091422014032500000) . NG --> See step 11 OK: Go to next step
6. CHECK OIL CONTROL VALVE FILTER AND OIL PIPE Remove the oil pipe No. 1 or No. 2. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. Reinstall the oil pipe No. 1 or No. 2. NG --> See step 12 OK: Go to next step
7. REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing exhaust gear assembly (bank 1 or bank 2). Refer to «REMOVAL [08/2012 - ]»(ref-606457-S31282357042014032500000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0017 or P0019 are output B B --> See step 13 A --> END
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
10. ADJUST VALVE TIMING. Refer to «REASSEMBLY [08/2012 - ]»(ref-606457-S34508900282014032500000)
11. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S06461608722014032500000)
12. REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [08/2012 - ] - Step 9»(ref-606457-S18284791532014032500000)
13. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
14. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)

ALL

P0031 AND P0051

P0032 AND P0052

P0031 AND P0051

P0032 AND P0052

P0031 AND P0051

P0032 AND P0052

Scheme 103

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the pending DTC [E]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0031, P0032, P0051 or P0052.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
14. If no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 104

1. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606469-S10135141532014032500000) . NG --> See step 8 OK: Go to next step
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) Disconnect the air fuel ratio sensor connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition E42-2 (+B) - Body ground Engine switch on (IG) 11 to 14 V E38-2 (+B) - Body ground Engine switch on (IG) 11 to 14 V Reconnect the air fuel ratio sensor connector. NG --> See step 4 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition E42-1 (HA1A) - E6-6 (HA1A) Always Below 1 ohms E38-1 (HA2A) - E6-4 (HA2A) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition E42-1 (HA1A) or E6-6 (HA1A) - Body ground Always 10 kohms or higher E38-1 (HA2A) or E6-4 (HA2A) - Body ground Always 10 kohms or higher Reconnect the air fuel ratio sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 9
4. INSPECT RELAY (A/F RELAY) Remove the A/F relay from the engine room relay block No. 2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 No battery voltage applied across terminals 1 and 2 10 kohms or higher 3 - 5 Battery voltage applied across terminals 1 and 2 Below 1 ohms Reinstall the A/F relay. NG --> REPLACE RELAY (A/F RELAY) OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - A/F RELAY) Disconnect the air fuel ratio sensor connector. Remove the A/F relay from engine room relay block No. 2. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition E42-2 (+B) - A/F relay terminal 3 Always Below 1 ohms E38-2 (+B) - A/F relay terminal 3 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition E42-2 (+B) or A/F relay terminal 3 - Body ground Always 10 kohms or higher E38-2 (+B) or A/F relay terminal 3 - Body ground Always 10 kohms or higher Reinstall the A/F relay. Reconnect the air fuel ratio sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. CHECK TERMINAL VOLTAGE (A/F RELAY) Remove the A/F relay from engine room relay block No. 2. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A/F relay terminal 5 - Body ground Always 11 to 14 V Reinstall the A/F relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (BATTERY - A/F RELAY) OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (A/F RELAY - BODY GROUND) Remove the A/F relay from engine room relay block No. 2. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition A/F relay terminal 2 - Body ground Always Below 1 ohms Reinstall the A/F relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI MAIN RELAY - A/F RELAY)
8. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000)
9. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

ALL

P0037 AND P0057

P0038 AND P0058 (CASE 1)

P0038 AND P0058 (CASE 2)

P0141 AND P0161

P0037 AND P0057

P0038 AND P0058 (CASE 1)

P0038 AND P0058 (CASE 2)

P0141 AND P0161

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2012 - ] .

Scheme 105

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the pending DTC [E]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0037, P0038, P0057, P0058, P0141 or P0161.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) Inspect the heated oxygen sensor. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606469-S21964964852014032500000) . NG --> See step 7 OK: Go to next step
2. INSPECT INTEGRATION RELAY (EFI MAIN RELAY) Remove the integration relay from the engine room R/B No. 2. Inspect the EFI MAIN relay. Standard resistance Terminal Connection Specified Condition 2A-8 - 2C-1 10 kohms or higher 2A-8 - 2C-1 Below 1 ohms (when battery voltage applied to terminals 2A-7 and 2A-6) Reinstall the integration relay. NG --> See step 8 OK: Go to next step
3. INSPECT ECM (HT1B OR HT2B VOLTAGE) Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Terminal Connection Specified Condition A6-2 (HT1B) - E3-6 (E03) 11 to 14 V A6-1 (HT2B) - E3-6 (E03) 11 to 14 V HINT: The HT1B means the heated oxygen sensor bank 1 sensor 2. The HT2B means the heated oxygen sensor bank 2 sensor 2. OK --> See step 6 NG: Go to next step
4. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - EFI NO. 2 FUSE) Check the harness and connector between the HO2 sensor and EFI No. 2 fuse. Disconnect the J68*1 or J40*2 or Q4*3 HO2 sensor connector. HINT: *1: Bank 1 Sensor 2 *2: Bank 2 Sensor 2 (2WD) *3: Bank 2 Sensor 2 (AWD) Remove the EFI No. 2 fuse from the engine room R/B No. 2. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Terminal Connection Specified Condition J68-2 (+B) - 2 (EFI No. 2 fuse) Below 1 ohms J40-2 (+B) - 2 (EFI No. 2 fuse) Below 1 ohms Q4-2 (+B) - 2 (EFI No. 2 fuse) Below 1 ohms Standard resistance (Check for short) Terminal Connection Specified Condition J68-2 (+B) or 2 (EFI No. 2 fuse) - Body ground 10 kohms or higher J40-2 (+B) or 2 (EFI No. 2 fuse) - Body ground 10 kohms or higher Q4-2 (+B) or 2 (EFI No. 2 fuse) - Body ground 10 kohms or higher Reconnect the HO2 sensor connector. Reconnect the EFI No. 2 fuse. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Check the harness and connector between the ECM and HO2 sensor. Disconnect the J68*1 or J40*2 or Q4*3 HO2 sensor connector. HINT: *1: Bank 1 Sensor 2 *2: Bank 2 Sensor 2 (2WD) *3: Bank 2 Sensor 2 (AWD) Disconnect the A6 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Terminal Connection Specified Condition J68-1 (HT1B) - A6-2 (HT1B) Below 1 ohms J40-1 (HT2B) - A6-1 (HT2B) Below 1 ohms Q4-1 (HT2B) - A6-1 (HT2B) Below 1 ohms Standard resistance (Check for short) Terminal Connection Specified Condition J68-1 (HT1B) or A6-2 (HT1B) - Body ground 10 kohms or higher J40-1 (HT2B) or A6-1 (HT2B) - Body ground 10 kohms or higher Q4-1 (HT2B) or A6-1 (HT2B) - Body ground 10 kohms or higher Reconnect the HO2 sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
7. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S36251004202014032500000)
8. REPLACE INTEGRATION RELAY. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S37087880432014032500000)

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Record the Freeze Frame Data.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
5. Turn the engine switch off and wait for at least 30 seconds.
6. Turn the engine switch on (IG) and turn the Techstream on.
7. Based on engine rpm, engine load and other freeze frame data stored in the ECM, reproduce the conditions present when the DTC was stored.
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0087.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shown ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
13. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK FUEL LEAK (HIGH PRESSURE SIDE) Check around and beneath the car for fuel leaks, fumes, etc. OK No fuel leaks present. NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
2. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0087) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Start the engine. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs using Techstream. Result Display (DTC output) Proceed to P0087 A P0087 and other DTCs B HINT: If any codes other than P0087 are output, perform troubleshooting for those DTCs first. B --> See step 12 A: Go to next step
3. CONFIRM IF VEHICLE HAS RUN OUT OF FUEL IN PAST Has the vehicle run out of fuel in the past? YES --> DTC CAUSED BY RUNNING OUT OF FUEL NO: Go to next step
4. CHECK MISFIRE COUNT (CYLINDER #1 (TO #6) MISFIRE COUNT) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Cylinder #1 (to #6) Misfire Count. Allow the engine to idle. Read each value of Cylinder #1 (to #6) Misfire Count displayed on the Techstream. Check if there is a particular cylinder that the misfire count is concentrated on. Result Misfire Count Proceed to No misfire counts, or misfire counts occur randomly in all cylinders A Misfire counts occur in particular cylinder B B --> See step 13 A: Go to next step
5. CHECK FUEL PRESSURE SENSOR Connect Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Fuel Press. Check that the fuel pressure fluctuates when the engine condition changes from idling to racing. Result Inspection Result Proceed to Fuel pressure does not fluctuate A Fuel pressure fluctuates B Fuel pressure does not rise C A --> See step 14 B --> See step 8 C: Go to next step
6. CHECK FUEL PUMP (FUEL PUMP OPERATION) Check the fuel pump operation. Refer to «ON-VEHICLE INSPECTION [08/2012 - ] - Step 1»(ref-606500-S22943507332014032500000) . NG --> See step 15 OK: Go to next step
7. CHECK FUEL PRESSURE (LOW PRESSURE SIDE) Check the fuel pressure (low pressure side). Refer to «ON-VEHICLE INSPECTION [08/2012 - ] - Step 2»(ref-606500-S22943507332014032500000) . NG --> See step 16 OK: Go to next step
8. CHECK FUEL LEAK (HIGH PRESSURE FUEL LINE) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following menus: Powertrain / Engine / Data List / Fuel Press. Start the engine. Check that the fuel pressure fluctuations when the engine switch is turned off. HINT: Turn the engine switch off and on (IG) before checking the fuel pressure. Result Inspection Result Proceed to Fuel pressure is almost constant, or fluctuations are gradual A Fuel pressure drops suddenly B A --> See step 10 B: Go to next step
9. CHECK RELIEF VALVE Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following menus: Powertrain / Engine / Data List / Fuel Press. Start the engine. Check the fuel pressure fluctuations when the fuel hose is pressed with your fingers. Result Inspection Result Proceed to Pressing the hose raises the fuel pressure slightly A Fuel pressure does not fluctuate B B --> See step 17 A: Go to next step
10. REPLACE FUEL PUMP FOR HIGH PRESSURE Replace the fuel pump for high pressure. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S14943552132014032500000) . NEXT: Go to next step
11. CHECK IF DTC OUTPUT REOCCURS (SEE IF DTC P0087 IS OUTPUT AGAIN) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC output) Proceed to P0087 A No output B B --> END A --> See step 18
12. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
13. REPLACE FUEL INJECTOR. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S37719690802014032500000)
14. REPLACE FUEL PRESSURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S19904209032014032500000)
15. REPLACE FUEL PUMP. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S25077043542014032500000)
16. REPLACE FUEL PRESSURE REGULATOR. Refer to «REMOVAL [08/2012 - ] - Step 12»(ref-606492-S20246847722014032500000)
17. REPLACE RELIEF VALVE. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S25213992442014032500000)
18. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Record the Freeze Frame Data.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
5. Turn the engine switch off and wait for at least 30 seconds.
6. Turn the engine switch on (IG) and turn the Techstream on.
7. Based on engine rpm, engine load and other freeze frame data stored in the ECM, reproduce the conditions present when the DTC was stored.
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0088.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
13. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0088) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs using Techstream. Result Display (DTC output) Proceed to P0088 A P0088 and other DTCs B HINT: If any codes other than P0088 are output, perform troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
2. CHECK FUEL PRESSURE SENSOR Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine / Data List / Fuel Press. Check that the fuel pressure fluctuates when the engine is raced. OK Fuel pressure fluctuates. NG --> See step 6 OK: Go to next step
3. REPLACE FUEL PUMP FOR HIGH PRESSURE Replace the fuel pump for high pressure. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S14943552132014032500000) . NEXT: Go to next step
4. CHECK IF DTC OUTPUT REOCCURS (SEE IF DTC P0088 IS OUTPUT AGAIN) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs using Techstream. Result Display (DTC output) Proceed to P0088 A No output B B --> END A --> See step 7
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
6. REPLACE FUEL PRESSURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S19904209032014032500000)
7. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

Scheme 106

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG).
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
5. Turn the engine switch off and wait for at least 30 seconds.
6. Turn the engine switch on (IG) and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
8. Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0101.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream ON. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0101 A P0101 and other DTCs B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. OK No leaks in air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
3. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [08/2012 - ] - Step 1»(ref-606467-S26337115042014032500000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> See step 5
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
5. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000)

P0102

P0103

Scheme 107

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 5 seconds [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Run the engine at an engine speed of 4000 rpm or more for 5 seconds [D].
11. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
12. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Input the DTC: P0102 or P0103.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 108

1. READ DTC OUTPUT (DTC P0102 OR P0103) Connect the Techstream to the DLC3. Turn the engine switch on (IG) (do not run the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0102 is output A DTC P0103 is output B B --> See step 6 A: Go to next step
2. INSPECT MASS AIR FLOW METER (POWER SOURCE VOLTAGE) Disconnect the E29 Mass Air Flow (MAF) meter connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Specified Condition E29-3 (+B) - Body ground 11 to 14 V Reconnect the MAF meter connector. NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the E29 MAF meter connector. Disconnect the E5 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Specified Condition E29-5 (VG) - E5-27 (VG) Below 1 ohms E29-4 (E2G) - E5-26 (E2G) Below 1 ohms Standard resistance (Check for short) Tester Connection Specified Condition E29-5 (VG) or E5-27 (VG) - Body ground 10 kohms or higher Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT MASS AIR FLOW METER Perform On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606499-S11753186822014032500000) . Inspect the function of the mass air flow meter. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF. Check that the reading of the MAF value changes when the engine is raced. OK The reading changes. NG --> See step 8 OK --> See step 10
5. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - INTEGRATION RELAY) Disconnect the E29 MAF meter connector. Remove the integration relay from the engine room R/B No. 2. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Specified Condition E29-3 (+B) - 2A-8 Below 1 ohms Standard resistance (Check for short) Tester Connection Specified Condition E29-3 (+B) or 2A-8 - Body ground 10 kohms or higher Reconnect the MAF meter connector. Reinstall the integration relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 9
6. CHECK HARNESS AND CONNECTOR (SENSOR GROUND) Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition E5-26 (E2G) - Body ground Below 1 ohms NG --> See step 7 OK --> See step 8
7. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the E29 MAF meter connector. Disconnect the E5 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition E29-4 (E2G) - E5-26 (E2G) Below 1 ohms Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 10
8. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000)
9. CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-606495-S30782057562014032500000)
10. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

Scheme 109

1. The Intake Air Temperature (IAT) sensor, mounted on the Mass Air Flow (MAF) meter, monitors the IAT. The IAT sensor has a built in thermistor with a resistance that varies according to the temperature of the intake air. When the IAT is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes see scheme 1
2. The IAT sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
3. Resistor R and the IAT sensor are connected in series. When the resistance value of the IAT sensor changes, according to changes in the IAT, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability.

ALL

AFTER ENGINE STOP

AFTER COLD ENGINE START

AFTER ENGINE STOP

AFTER COLD ENGINE START

Scheme 110

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is below 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0111.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
13. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 111

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0111 and other DTCs A P0111 B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
2. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
3. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000)

P0112

P0113

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0112 or P0113.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
12. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 112

1. READ VALUE USING TECHSTREAM (INTAKE AIR) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard Same as actual Intake Air Temperature (IAT). Result Temperature Displayed Proceed to -40°C (-40°F) A Higher than 128°C (262°F) B Same as actual IAT C HINT: If there is an open circuit, Techstream indicates -40°C (-40°F). If there is a short circuit, Techstream indicates higher than 128°C (262°F). B --> See step 4 C --> See step 6 A: Go to next step
2. CHECK MASS AIR FLOW METER (CHECK FOR OPEN IN SENSOR) Confirm good connection of the mass air flow meter. Disconnect the E29 Mass Air Flow (MAF) meter connector. Connect terminals THA and E3 of the MAF meter wire harness side connector. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard Higher than 128°C (262°F) Reconnect the MAF meter connector. OK --> See step 7 NG: Go to next step
3. CHECK ECM (CHECK FOR OPEN IN ECM) Confirm good connection of the ECM. Disconnect the E29 MAF meter connector. Connect terminals THA and E3 of the E5 ECM connector. HINT: Before checking, do visual and contact pressure checks on the ECM connector. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard Higher than 128°C (262°F) Reconnect the MAF meter connector. OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR NG --> See step 8
4. CHECK MASS AIR FLOW METER (CHECK FOR SHORT IN SENSOR) Disconnect the E29 MAF meter connector. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the MAF meter connector. OK --> See step 9 NG: Go to next step
5. CHECK ECM (CHECK FOR SHORT IN ECM) Disconnect the E5 ECM connector. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the ECM connector. OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR NG --> See step 10
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
7. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000)
8. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
9. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000)
10. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

P0115

P0117

P0118

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0115, P0117 or P0118.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
12. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 113

1. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard Between 75 and 100°C (167 and 212°F) with warm engine. Result Temperature Displayed Proceed to -40°C (-40°F) A Higher than 135°C (275°F) B Between 75 and 100°C (167 and 212°F) C HINT: If there is an open circuit, Techstream indicates -40°C (-40°F). If there is a short circuit, Techstream indicates higher than 135°C (275°F). B --> See step 4 C --> See step 6 A: Go to next step
2. CHECK ENGINE COOLANT TEMPERATURE SENSOR (CHECK FOR OPEN IN SENSOR) Confirm good connection at the Engine Coolant Temperature (ECT) sensor. Disconnect the E40 ECT sensor connector. Connect terminals 1 and 2 of the ECT sensor connector on the wire harness side. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard Higher than 135°C (275°F) Reconnect the ECT sensor connector. OK --> See step 7 NG: Go to next step
3. CHECK ECM (CHECK FOR OPEN IN ECM) Disconnect the E40 ECT sensor connector. Connect terminals THW and E2 of the E3 and E5 ECM connectors. HINT: Before checking, do visual and contact pressure checks on the ECM connector. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard Higher than 135°C (275°F) Reconnect the ECT sensor connector. OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR NG --> See step 8
4. CHECK ENGINE COOLANT TEMPERATURE SENSOR (CHECK FOR SHORT IN SENSOR) Disconnect the E40 ECT sensor connector. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the ECT sensor connector. OK --> See step 9 NG: Go to next step
5. CHECK ECM (CHECK FOR SHORT IN ECM) Disconnect the E3 and E5 ECM connectors. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the ECM connector. OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR NG --> See step 10
6. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
7. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S17701837782014032500000)
8. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
9. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S17701837782014032500000)
10. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

ALL

COLD START MONITOR

SOAK MONITOR

COLD START MONITOR

SOAK MONITOR

Scheme 114

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Enter the following menu items: Powertrain / Engine / Data List / Coolant Temp.
4. Check that the engine coolant temperature is 60°C (140°F) or less.
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
6. Turn the engine switch off and wait for at least 30 seconds.
7. Turn the engine switch on (IG) and turn the Techstream on [A].
8. Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0116.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result sows INCOMPLETE or N/A, perform steps [D] and [E].
14. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
15. Check the DTC judgment result again [E]. HINT: If the judgment result sows INCOMPLETE or N/A, perform steps [D] and [E] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTC. Result Display (DTC output) Proceed to P0116 A P0116 and other DTCs B HINT: If any DTCs and other than P0116 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. INSPECT THERMOSTAT Inspect the thermostat. Refer to «INSPECTION [08/2012 - ]»(ref-606461-S03257781372014032500000) . NG --> See step 5 OK --> See step 3
3. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S17701837782014032500000)
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
5. REPLACE THERMOSTAT. Refer to «REMOVAL [08/2012 - ]»(ref-606461-S33206219272014032500000)

Scheme 115

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on [A].
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off [B].
5. With the engine stopped, leave the vehicle as is for 7.5 hours or more.
6. Turn the engine switch on (IG) and turn the Techstream on.
7. Start the engine and wait 60 seconds or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P011B.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P011B) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to P011B A P011B and other DTCs B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
3. READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
5. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000)
6. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
7. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S17701837782014032500000)

P0120, P0122, P0123, P0220, P0222, P0223 AND P2135

P0121

P0120

P0121

P0122

P0123

P0220

P0222

P0223

P2135 (CASE 1)

P2135 (CASE 2)

Scheme 116

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine.
7. With the vehicle stationary, fully depress and release the accelerator pedal [B].
8. Idle the engine for 2 seconds or more [C].
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the pending DTC [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
14. If no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the engine switch is then turned off.

Scheme 117

1. READ VALUE USING TECHSTREAM (THROTTLE POSITION SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Throttle Position No. 1 and Throttle Position No. 2. Read the values displayed on the Techstream. RESULT When Accelerator Pedal Fully Released When Accelerator Pedal Fully Depressed Trouble Area Proceed to Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V VC2 circuit open A 4.5 to 4.98 V 4.5 to 4.98 V 4.5 to 4.98 V 4.5 to 4.98 V E3 circuit open 0 to 0.2 V, or 4.5 to 4.98 V 2.1 V to 3.1 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V 2.1 V to 3.1 V (Fail-safe) VTA1 circuit open or ground short 0.6 V to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V 0.6 V to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V VTA2 circuit open or ground short 0.5 to 1.1 V 2.1 to 3.1 V 3.2 to 4.8 V (Not fail-safe) 4.6 to 4.98 V (Not fail-safe) Throttle position sensor circuit normal B HINT: DTC P0121 is stored when the voltages output from VTA1 and VTA2 are not consistent with the characteristics of the sensors. Therefore, check the Freeze Frame Data when this DTC is output. Use the following formula to confirm relative fluctuations in voltage. Characteristics Sensor Output VTA2 x 0.8 is approximately equal to VTA1 + 1.11 V VTA1: Throttle Position No. 1 VTA2: Throttle position No. 2 If DTC P0121 is output, proceed to the "CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM)". B --> See step 5 A: Go to next step
2. CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM) Disconnect the E17 throttle body assembly connector. Disconnect the E3 and E5 ECM connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition E17-5 (VC) - E5-29 (VC2) Always Below 1 ohms E17-6 (VTA) - E3-23 (VTA1) Always Below 1 ohms E17-4 (VTA2) - E3-22 (VTA2) Always Below 1 ohms E17-3 (E2) - E5-30 (E3) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition E17-5 (VC) or E5-29 (VC2) - Body ground Always 10 kohms or higher E17-6 (VTA) or E3-23 (VTA1) - Body ground Always 10 kohms or higher E17-4 (VTA2) or E3-22 (VTA2) - Body ground Always 10 kohms or higher Reconnect the ECM connectors. Reconnect the throttle body assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT ECM (VC VOLTAGE) Disconnect the E17 throttle body assembly connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition E17-5 (VC) - E17-3 (E2) Engine switch on (IG) 4.5 to 5.5 V Reconnect the throttle body assembly connector. NG --> See step 6 OK: Go to next step
4. REPLACE THROTTLE BODY ASSEMBLY Replace the throttle body assembly. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S23377712742014032500000) . NEXT: Go to next step
5. CHECK WHETHER DTC OUTPUT RECURS (THROTTLE POSITION SENSOR DTCS) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0120, P0121, P0122, P0123, P0220, P0222, P0223, and/or P2135 are output A DTC is not output B B --> END A --> See step 6
6. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

1. Leave the vehicle outside overnight.
2. Connect the Techstream to the DLC3.
3. Turn the engine switch on (IG) and turn the Techstream on.
4. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
5. Check that the engine coolant temperature is 10°C (50°F) or less.
6. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
7. Turn the engine switch off and wait for at least 30 seconds.
8. Turn the engine switch on (IG) and turn the Techstream on.
9. Start the engine.
10. Wait 21 minutes or more.
11. Enter the following menus: Powertrain / Engine / Trouble Codes.
12. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Input the DTC: P0125.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0125 A P0125 and other DTCs B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. INSPECT THERMOSTAT Inspect the thermostat. Refer to «INSPECTION [08/2012 - ]»(ref-606461-S03257781372014032500000) . NG --> See step 5 OK: Go to next step
3. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
5. REPLACE THERMOSTAT. Refer to «REMOVAL [08/2012 - ]»(ref-606461-S33206219272014032500000)
6. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S17701837782014032500000)

Scheme 118

1. Stop the engine and allow it to soak.
2. Connect the Techstream to the DLC3.
3. Turn the engine switch on (IG) and turn the Techstream on [A].
4. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
5. Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
6. Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
7. Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snapshot Configure / Duration / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 rpm and then racing the engine, etc. to raise the engine speed to a speed of 4000 rpm or more will cause data capture to start.
8. After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher. [C]

HINT

If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0128) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTC. Result Display (DTC Output) Proceed to P0128 A P0128 and other DTCs B HINT: If any DTC other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
3. INSPECT THERMOSTAT Inspect the thermostat. Refer to «INSPECTION [08/2012 - ]»(ref-606461-S03257781372014032500000) . NG --> See step 5 OK --> See step 6
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
5. REPLACE THERMOSTAT. Refer to «REMOVAL [08/2012 - ]»(ref-606461-S33206219272014032500000)
6. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)

ALL

P0136, P0137, P0156 AND P0157: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION AND LOW VOLTAGE)

P0136 AND P0156: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)

P0137 AND P0157: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)

P0138 AND P0158: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)

P0139 AND P0159: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT

P0136 AND P0156: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION)

P0137 AND P0157: HEATED OXYGEN SENSOR VOLTAGE CHECK (LOW VOLTAGE)

P0136 AND P0156: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)

P0137 AND P0157: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)

P0138 AND P0158: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)

P0139 AND P0159: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2012 - ] .

HINT

1. This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
2. Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (The catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.

P0136, P0137, P0138, P0156, P0157 and P0158

Scheme 119

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the shift lever in D, drive the vehicle at 60 to 120 km/h (37 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] and [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139 and P0159

Scheme 120

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the shift lever in S, drive the vehicle at 60 km/h (37 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0139 or P0159.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, drive the vehicle with the shift lever in S, and then perform steps [C] and [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 121

1. READ DTC OUTPUT (DTC P0136, P0137, P0138, P0139, P0156, P0157, P0158 OR P0159) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0138 or P0158 is output A DTC P0137 or P0157 is output B DTC P0136 or P0156 is output C DTC P0139 or P0159 is output D DTC P0136, P0137, P0138, P0156, P0157 or P0158 and other DTCs are output E HINT: If any DTCs other than P0136, P0137, P0138, P0139, P0156, P0157, P0158 and P0159 are output, troubleshoot those DTCs first. B --> See step 6 C --> See step 4 D --> See step 15 E --> See step 25 A: Go to next step
2. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Disconnect the J68*1 or J40*2, Q4*3 HO2 sensor connector. HINT: *1: Bank 1 Sensor 2 *2: Bank 2 Sensor 2 (2WD) *3: Bank 2 Sensor 2 (AWD) Measure the resistance according to the value(s) in the table below. Standard resistance (Bank 1 sensor 2) Tester Connection Specified Condition 2 (+B) - 4 (E2) 10 kohms or higher 2 (+B) - 3 (OX1B) 10 kohms or higher Standard resistance (Bank 2 sensor 2) Tester Connection Specified Condition 2 (+B) - 4 (E2) 10 kohms or higher 2 (+B) - 3 (OX2B) 10 kohms or higher NG --> See step 23 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Turn the engine switch off and wait for 5 minutes. Disconnect the A6 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition A6-2 (HT1B) - A6-28 (OX1B) 10 kohms or higher A6-1 (HT2B) - A6-17 (OX2B) 10 kohms or higher Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK --> See step 19
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / All Data / O2S B1S2 or O2S B2S2. Change the fuel injection volume using the Techstream, monitoring the voltage output of the heated oxygen sensors displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% to +12%. The injection volume can be changed in fine gradations within this range. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Voltage Fluctuates between 0.4 V or less and 0.55 V or more. NG --> See step 6 OK: Go to next step
5. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / All Data / AFS Voltage B1S1 or AFS Voltage B2S1. Change the fuel injection volume using the Techstream, and monitoring the voltage output of air fuel ratio and heated oxygen sensors displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% and +12%. The injection volume can be changed in fine graduations within the range. The air fuel ratio sensor is displayed as AFS Voltage B1S1 or AFS Voltage B2S1, and the heated oxygen sensor is displayed as O2S B1S2 or O2S B2S2, on the Techstream. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Result Techstream Display (Sensor) Voltage Variation Proceed to AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Alternates between more and less than 3.3 V OK Remains at more than 3.3 V NG Remains at less than 3.3 V NG HINT: A normal heated oxygen sensor voltage (O2S B1S2 or O2S B2S2) reacts in accordance with increases and decreases in fuel injection volumes. When the air fuel ratio sensor voltage remains at either less or more than 3.3 V despite the heated oxygen sensor indicating a normal reaction, the air fuel ratio sensor is malfunctioning. NG --> See step 12 OK --> See step 21
6. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
7. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 20 OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the J68*1 and J40*2, Q4*3 HO2 sensor connector. HINT: *1: Bank 1 Sensor 2 *2: Bank 2 Sensor 2 (2WD) *3: Bank 2 Sensor 2 (AWD) Disconnect the A6 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Terminal Connection Specified Condition J68-1 (HT1B) - A6-2 (HT1B) Below 1 ohms J68-3 (OX1B) - A6-28 (OX1B) Below 1 ohms J68-4 (E2) - A6-29 (O1B-) Below 1 ohms J40-1 (HT2B) - A6-1 (HT2B) Below 1 ohms J40-3 (OX2B) - A6-17 (OX2B) Below 1 ohms J40-4 (E2) - A6-18 (O2B-) Below 1 ohms Q4-1 (HT2B) - A6-1 (HT2B) Below 1 ohms Q4-3 (OX2B) - A6-17 (OX2B) Below 1 ohms Q4-4 (E2) - A6-18 (O2B-) Below 1 ohms Standard resistance (Check for short) Terminal Connection Specified Condition J68-1 (HT1B) or A6-2 (HT1B) - Body ground 10 kohms or higher J68-3 (OX1B) or A6-28 (OX1B) - Body ground 10 kohms or higher J68-4 (E2) or A6-29 (O1B-) - Body ground 10 kohms or higher J40-1 (HT2B) or A6-1 (HT2B) - Body ground 10 kohms or higher J40-3 (OX2B) or A6-17 (OX2B) - Body ground 10 kohms or higher J40-4 (E2) or A6-18 (O2B-) - Body ground 10 kohms or higher Q4-1 (HT2B) or A6-1 (HT2B) - Body ground 10 kohms or higher Q4-3 (OX2B) or A6-17 (OX2B) - Body ground 10 kohms or higher Q4-4 (E2) or A6-18 (O2B-) - Body ground 10 kohms or higher Reconnect the HO2 sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK: Go to next step
9. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S36251004202014032500000) . NEXT: Go to next step
10. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0136, P0137, P0138, P0156, P0157 and P0158). NEXT: Go to next step
11. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136, P0137, P0156 OR P0157) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input DTC: P0136, P0137, P0156 or P0157. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the driving pattern again but increase the vehicle speed. Result Result Proceed to ABNORMAL (DTC P0136, P00137, P0156 or P0157 is output) A NORMAL (DTC is not output) B B --> END A --> See step 22
12. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000) . NEXT: Go to next step
13. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0136, P0137, P0138, P0156, P0157 and P0158). NEXT: Go to next step
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136 OR P0156) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input DTC: P0136 or P0156. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the driving pattern again but increase the vehicle speed. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0136 or P0156 is output) B B --> See step 20 A --> END
15. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
16. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Turn the engine switch off and wait for 5 minutes. Disconnect the A6 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition A6-2 (HT1B) - A6-28 (OX1B) 10 kohms or higher A6-1 (HT2B) - A6-17 (OX2B) 10 kohms or higher Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
17. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0139 and P0159). NEXT: Go to next step
18. READ DTC OUTPUT (DTC P0139 OR P0159 IS OUTPUT AGAIN) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input DTC: P0139 or P0159. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to ABNORMAL (DTC P0139 or P0159 is output) A NORMAL (DTC is not output) B B --> See step 24 A --> See step 20
19. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
20. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S36251004202014032500000)
21. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO (FUEL INJECTOR, FUEL SYSTEM, AIR INDUCTION SYSTEM, ETC.). Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-606496-S21071983732014032500000)
22. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000)
23. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S36251004202014032500000)
24. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
25. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)

AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN RESPONSE RATE)

AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH RESPONSE RATE)

AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN DELAY)

AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH DELAY)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS [08/2012 - ] .

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 122

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG).
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
5. Turn the engine switch off and wait for at least 30 seconds.
6. Turn the engine switch on (IG) and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
8. Check that O2 Sensor / Current is incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1 do not exist in the Detail of O2 Sensor monitor at this time (the initial value of "0.000" is indicated in each test item).
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Check that O2 Sensor / Current becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1.
12. If the monitor item O2 Sensor / Current does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN [08/2012 - ]»(ref-606493-S13552386582014032500000) .
13. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
14. Read the pending DTC [C].
15. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
16. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
17. Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D.
18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
19. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 11 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the E38 and E42 A/F sensor connector. Disconnect the E6 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E42-1 (HA1A) - E6-6 (HA1A) Below 1 ohms E42-3 (A1A+) - E6-18 (A1A+) Below 1 ohms E42-4 (A1A-) - E6-17 (A1A-) Below 1 ohms E38-1 (HA2A) - E6-4 (HA2A) Below 1 ohms E38-3 (A2A+) - E6-28 (A2A+) Below 1 ohms E38-4 (A2A-) - E6-27 (A2A-) Below 1 ohms Standard resistance (Check for open) Tester Connection Specified Condition E42-1 (HA1A) or E6-6 (HA1A) - Body ground 10 kohms or higher E42-3 (A1A+) or E6-18 (A1A+) - Body ground 10 kohms or higher E42-4 (A1A-) or E6-17 (A1A-) - Body ground 10 kohms or higher E38-1 (HA2A) or E6-4 (HA2A) - Body ground 10 kohms or higher E38-3 (A2A+) or E6-28 (A2A+) - Body ground 10 kohms or higher E38-4 (A2A-) or E6-27 (A2A-) - Body ground 10 kohms or higher Reconnect the ECM connector. Reconnect the A/F sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 14 OK: Go to next step
5. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the DTCs. Result Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC is not output B B --> See step 12 A: Go to next step
7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000) . NEXT: Go to next step
8. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the DTCs. Result Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output B B --> See step 13 A --> END
10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
11. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000)
12. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2012 - ]»(ref-606493-S25856855752014032500000)
13. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-606496-S21071983732014032500000)
14. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000)

Scheme 123

1. Connect the Techstream to the DLC3.
2. Turn the engine switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) .
4. Turn the engine switch off and wait for at least 30 seconds.
5. Turn the engine switch on (IG) and turn the Techstream on [A].
6. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off [B].
7. With the engine warmed up, idle the engine for 2 minutes or more [C].
8. Drive the vehicle at between 60 and 135 km/h (37 and 84 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
11. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171, P0172, P0174 OR P0175) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171, P0172, P0174 or P0175 is output A DTC P0171, P0172, P0174 or P0175 and other DTCs are output B HINT: If any DTCs other than P0171, P0172, P0174 or P0175 are output, troubleshoot those DTCs first. B --> See step 27 A: Go to next step
2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION [08/2012 - ] - Step 1»(ref-606467-S26337115042014032500000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
3. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606502-S29277015052014032500000) . OK No leaks in air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / All Data / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2. Perform the Control the Injection Volume operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and the heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% and +12%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) +12% Rich Below 3.1 V -12% Lean Higher than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen) +12% Rich Higher than 0.55 V -12% Lean Below 0.4 V Result Status of AFS Voltage B1S1 or AFS Voltage B2S1 Status of O2S B1S2 or O2S B2S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - - A Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Fuel injector assembly blockage Gas leak from exhaust system Air induction system Fuel pressure Mass air flow meter Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Fuel injector leak or blockage Gas leak from exhaust system Ignition system Fuel pressure Mass air flow meter Engine coolant temperature sensor Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean: During the Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During the Control the Injection Volume for A/F Sensor Active Test, the AFS Voltage is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During the Control the Injection Volume for A/F Sensor Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1, AFS Voltage B2S1, O2S B1S2 and O2S B2S2]. Refer to «DATA LIST / ACTIVE TEST [08/2012 - ]»(ref-606493-S09638850392014032500000) . B --> See step 13 A: Go to next step
5. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read Coolant Temp twice, when the engine is both cold and warmed up. Standard With cold engine: Same as ambient air temperature. With warm engine: Between 75°C and 100°C (167°F and 212°F). NG --> See step 28 OK: Go to next step
6. READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 7.60 gm/s and 11.40 gm/s (shift lever: Neutral position, A/C: Off). NG --> See step 18 OK: Go to next step
7. CHECK FUEL PRESSURE (LOW PRESSURE SIDE) Check the fuel pressure (low pressure side). Refer to «ON-VEHICLE INSPECTION [08/2012 - ] - Step 2»(ref-606500-S22943507332014032500000) . NG --> REPAIR OR REPLACE FUEL SYSTEM (LOW PRESSURE SIDE) OK: Go to next step
8. CHECK FUEL PRESSURE SENSOR Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine / Data List / Fuel Press. While revving the engine, check that the fuel pressure fluctuates. OK Fuel pressure fluctuates. NG --> See step 32 OK: Go to next step
9. CHECK FUEL PRESSURE (HIGH PRESSURE SIDE) Check the fuel pressure (high pressure side). Refer to «ON-VEHICLE INSPECTION [08/2012 - ] - Step 3»(ref-606500-S22943507332014032500000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
10. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
11. CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606463-S09759795702014032500000) . HINT: If the result of the spark test is normal, proceed to the next step. NEXT: Go to next step
12. INSPECT FUEL INJECTOR ASSEMBLY Check the injection and volume. HINT: Refer to the fuel injector assembly inspection procedure. Refer to «INSPECTION [08/2012 - ]»(ref-606492-S11154703232014032500000) . If the injectors malfunction, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine / Data List / Gas Misfire / Cylinder #1 Misfire Count (to Cylinder #6 Misfire Count). Inspect the cold start injector. Refer to «INSPECTION [08/2012 - ]»(ref-606492-S33160903792014032500000) . OK --> See step 17 NG --> See step 29
13. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 30 OK: Go to next step
14. CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 23 OK: Go to next step
15. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
16. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000) . NEXT: Go to next step
17. PERFORM CONFIRMATION DRIVING PATTERN (DTC P0171, P0172, P0174 OR P0175) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171, P0172, P0174 or P0175 is output A DTC is not output B B --> END A: Go to next step
18. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harness between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [08/2012 - ]»(ref-606329-S18266896852014032500000) . HINT: Repair any problems. NEXT: Go to next step
19. CHECK WHETHER DTC OUTPUT RECURS (DTC P0171, P0172, P0174 OR P0175) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171, P0172, P0174 or P0175 is output A DTC is not output B B --> END A: Go to next step
20. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the E29 MAF meter connector. Disconnect the E5 ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Specified Condition E29-5 (VG) - E5-27 (VG) Below 1 ohms E29-4 (E2G) - E5-26 (E2G) Below 1 ohms Standard resistance (Check for short) Tester Connection Specified Condition E29-5 (VG) or E5-27 (VG) - Body ground 10 kohms or higher Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
21. REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S31539933142014032500000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
22. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2012 - ]»(ref-606493-S27629753512014032500000) . Turn the engine switch off and wait for at least 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0171, P0172, P0174 or P0175 is output B B --> See step 31 A --> END
23. INSPECT RELAY (A/F RELAY) See step 4 NG --> REPLACE RELAY (A/F RELAY) OK: Go to next step
24. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - A/F RELAY) See step 5 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
25. CHECK TERMINAL VOLTAGE (A/F RELAY) See step 6 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (A/F RELAY - BATTERY) OK: Go to next step
26. CHECK HARNESS AND CONNECTOR (A/F RELAY - BODY GROUND) See step 7 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI MAIN RELAY - A/F RELAY)
27. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606493-S22144303952014032500000)
28. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S17701837782014032500000)
29. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S37719690802014032500000)
30. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606469-S06587284652014032500000)
31. REPLACE ECM. Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
32. REPLACE FUEL PRESSURE SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606492-S19904209032014032500000)
