Meter: Removal & Installation Lexus IS II

Gauges & Instrument Panels 1 illustration ~364 words

REMOVAL

  1. DISCHARGE FUEL SYSTEM PRESSURE HINT: (See «FUEL SYSTEM»(ref-235558-S30111442742006062400000) )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent airbag deployment (See «AIRBAG SYSTEM»(ref-235542-S13106599752006062400000) ).
  3. REMOVE REAR SEAT CUSHION ASSEMBLY (See «REMOVAL»(ref-235576-S10366850202006062400000) )
  4. REMOVE NO. 2 REAR FLOOR SERVICE HOLE COVER (See «REMOVAL»(ref-235448-S19127256622006062200000) )
  5. REMOVE FUEL SUCTION WITH PUMP AND GAUGE TUBE ASSEMBLY (See «REMOVAL»(ref-235448-S19127256622006062200000) )
  6. REMOVE FUEL SENDER GAUGE ASSEMBLY (for LH Side) (See «REMOVAL»(ref-235448-S19127256622006062200000) )
  7. REMOVE REAR FLOOR SERVICE HOLE COVER (See «REMOVAL»(ref-235448-S15368679272006062200000) )
  8. REMOVE FUEL SENDER GAUGE ASSEMBLY (for RH Side) (See «REMOVAL»(ref-235448-S15368679272006062200000) )

Scheme 94

Scheme 94: INSPECTION
Scheme 94: INSPECTION
  1. INSPECT FUEL SENDER GAUGE ASSEMBLY Disconnect the fuel sender gauge connector. Inspect the fuel sender gauge assembly (main). Remove the fuel sender gauge assembly (main). Check that the float moves smoothly between F and E. Measure the resistance between the terminals 2 (S) and 3 (FE) of connector according to the value(s) in the table below. Standard resistance: Main STANDARD RESISTANCE SPECIFICATION Float Level Resistance (ohms) F 6.5 to 8.5 Between E and F 6.5 to 242.6 (Gradually changes) E 237.6 to 242.6 Inspect the fuel sender gauge assembly (sub). Remove the fuel sender gauge assembly (sub). Check that the float moves smoothly between F and E. Measure the resistance between the terminals 1 (FS) and 2 (E) according to the value(s) in the table below. Standard resistance: Sub STANDARD RESISTANCE SPECIFICATION Float Level Resistance (ohms) F 6.5 to 8.5 Between E and F 6.5 to 171.9 (Gradually changes) E 167.9 to 171.9 HINT: If the value is not as specified, replace the fuel sender gauge assembly.

INSTALLATION

  1. INSTALL FUEL SENDER GAUGE ASSEMBLY (for RH Side) (See «INSTALLATION»(ref-235448-S35990757052006062200000) )
  2. INSTALL FUEL SENDER GAUGE ASSEMBLY (for LH Side) (See «INSTALLATION»(ref-235448-S20059344762006062200000) )
  3. INSTALL FUEL SUCTION WITH PUMP AND GAUGE TUBE ASSEMBLY (See «INSTALLATION»(ref-235448-S20059344762006062200000) )
  4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  5. CHECK FOR FUEL LEAKAGE (See «ON-VEHICLE INSPECTION»(ref-235448-S09877849372006062200000) )
  6. INSTALL REAR FLOOR SERVICE HOLE COVER (See «INSTALLATION»(ref-235448-S35990757052006062200000) )
  7. INSTALL NO. 2 REAR FLOOR SERVICE HOLE COVER (See «INSTALLATION»(ref-235448-S20059344762006062200000) )
  8. INSTALL REAR SEAT CUSHION ASSEMBLY (See «INSTALLATION»(ref-235576-S01201775472006062400000) )
  9. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-235541-S32349848442006062400000) ).
