Lighting: Removal & Installation — Lexus IS II (2005-2008)

INSTALLATION

INSTALL HIGH MOUNTED STOP LIGHT SET Connect the connector. Install the high mounted stop light set with the 4 claws.

Scheme 210

Scheme 210: COMPONENTS

REMOVAL

REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-235599-S10274364092006062400000) )

Scheme 211

Scheme 211: INSPECTION

Scheme 212

INSPECT OVERHEAD JUNCTION BLOCK (PERSONAL LIGHT) Disconnect the R5 connector from the personal light. Measure the resistance of the connector. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition R5-18 (GND3) - Body ground Always Below 1 ohms Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition R5-1 (+B) - Body ground Always 10 to 14 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 1 and the (-) lead to terminal 18. Check that the personal light comes on. OK SPECIFIED CONDITION REFERENCE Condition Specified Condition LH side personal light ON LH side personal light comes ON LH side personal light OFF LH side personal light does not come ON RH side personal light ON RH side personal light comes ON RH side personal light OFF RH side personal light does not come ON If the result is not as specified, replace the overhead J/B assembly.

INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-235599-S41342360772006062400000) )

Scheme 213

Scheme 213: COMPONENTS

REMOVE SPOT LIGHT ASSEMBLY (See «REMOVAL»(ref-235599-S10274364092006062400000) )

Scheme 214

Scheme 214: INSPECTION

Scheme 215

Scheme 216

Scheme 217

INSPECT REAR ROOM LIGHT (PERSONAL LIGHT) Disconnect the R8 connector from the rear room light. Measure the resistance of the connector. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition R8-3 (RGND) - Body ground Always Below 1 ohms Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition R8-1 (RRMP) - Body ground Always 10 to 14 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 1 and the (-) lead to terminal 3. Check that the personal light comes on. OK SPECIFIED CONDITION REFERENCE Condition Specified Condition LH side personal light ON LH side personal light comes ON LH side personal light OFF LH side personal light does not come ON RH side personal light ON RH side personal light comes ON RH side personal light OFF RH side personal light does not come ON If the result is not as specified, replace the rear room light assembly.
INSPECT REAR ROOM LIGHT (DOME LIGHT) Disconnect the R8 connector from the rear room light. Measure the voltage of the connector. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition R8-1 (RRMP) - Body ground Always 10 to 14 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 4. Check that the rear interior light comes on. OK: Comes on If the result is not as specified, replace the rear room light assembly. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 5. Check that the rear seat light comes on. OK: Comes on If the result is not as specified, replace the rear room light assembly.

INSTALL SPOT LIGHT ASSEMBLY (See «INSTALLATION»(ref-235599-S41342360772006062400000) )

Scheme 218

Scheme 218: COMPONENTS

REMOVE COURTESY LIGHT ASSEMBLY (See «DISASSEMBLY»(ref-235587-S17204566112006062400000) )

Scheme 219

Scheme 219: INSPECTION

Scheme 220

INSPECT DOOR COURTESY LIGHT Disconnect the connector from the door courtesy light. Measure the voltage of the connector. Standard voltage LH Side: SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition M5-2 (+) - M5-1 (-) Any door is opened 10 to 14 V M5-2 (+) - M5-1 (-) All doors are closed Below 1 V RH Side: SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition L6-2 (+) - L6-1 (-) Any door is opened 10 to 14 V L6-2 (+) - L6-1 (-) All doors are closed Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1. Check that the door courtesy light comes on. OK: Comes on If the result is not as specified, replace the door courtesy light.

INSTALL COURTESY LIGHT ASSEMBLY (See «REASSEMBLY»(ref-235587-S42708921892006062400000) )

Scheme 221

Scheme 221: COMPONENTS

REMOVE NO. 2 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-235598-S11808948372006062400000) )

INSTALL NO. 2 ROOM LIGHT ASSEMBLY

Scheme 222

Scheme 222: COMPONENTS

Scheme 223

Scheme 223: REMOVAL

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent airbag deployment (See «PRECAUTION»(ref-235542-S10058841152006062400000) )
REMOVE FRONT DOOR SCUFF PLATE RH (w/o Illumination) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT DOOR SCUFF PLATE RH (w/ Illumination) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SIDE INSTRUMENT PANEL RH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «REMOVAL»(ref-235542-S26525252422006062400000) )
REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE GLOVE BOX LIGHT ASSEMBLY Remove the glove box light assembly.

Scheme 224

Scheme 224: INSPECTION

Scheme 225

INSPECT GLOVE BOX LIGHT Remove the glove box light. Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J56-2 - J56-1 Clove box is opened 10 to 14 V J56-2 - J56-1 Glove box is closed Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1. Check that the glove box light comes on. OK: Comes on If the result is not as specified, replace the glove box light.

Scheme 226

Scheme 226: INSTALLATION

INSTALL GLOVE BOX LIGHT ASSEMBLY Install the glove box light assembly.
INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-235542-S26749810932006062400000) )
INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SIDE INSTRUMENT PANEL RH (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR OPENING TRIM COVER RH (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE RH (w/o Illumination)
INSTALL FRONT DOOR SCUFF PLATE RH (w/ Illumination)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-235541-S32349848442006062400000) ).
INSPECT SRS WARNING LIGHT (See «PROBLEM SYMPTOMS TABLE»(ref-235542-S10426029612006062400000) )

Scheme 227

Scheme 227: COMPONENTS

REMOVE VISOR BRACKET COVER (See «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE VISOR ASSEMBLY (See «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE VANITY LIGHT ASSEMBLY (See «REMOVAL»(ref-235599-S10274364092006062400000) )

INSTALL VANITY LIGHT ASSEMBLY (See «INSTALLATION»(ref-235599-S41342360772006062400000) )
INSTALL VISOR ASSEMBLY (See «INSTALLATION»(ref-235599-S41342360772006062400000) )
INSTALL VISOR BRACKET COVER (See «INSTALLATION»(ref-235599-S41342360772006062400000) )

Scheme 228

Scheme 228: COMPONENTS

REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 2 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY (See «REMOVAL»(ref-235591-S19647718192006062400000) )

Scheme 229

Scheme 229: INSPECTION

INSPECT CONSOLE BOX LIGHT Remove the console box light. Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J46-2 - J46-1 Clove box is opened 10 to 14 V J46-2 - J46-1 Glove box is closed Below 1 V If the result is not as specified, repair or replace wire harness or connector.
Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1.
Check that the console box light comes on.

Comes on

If the result is not as specified, replace the console box light.

Scheme 230

INSTALL CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
INSTALL FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission) (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 2 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 1 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission)
INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission)

Scheme 231

Scheme 231: COMPONENTS

REMOVE FRONT DOOR SCUFF PLATE (See «REMOVAL»(ref-235599-S10274364092006062400000) )

Scheme 232

Scheme 232: INSPECTION

Scheme 233

INSPECT SCUFF PLATE LIGHT Disconnect the connector from the scuff plate light. Measure the voltage of the connector. Standard voltage LH Side: SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition Q8-2 (+) - Q8-1 (-) Any door is opened 10 to 14 V Q8-2 (+) - Q8-1 (-) All doors are closed Below 1 V RH Side: SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition P2-2 (+) - P2-1 (-) Any door is opened 10 to 14 V P2-2 (+) - P2-1 (-) All doors are closed Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1. Check that the scuff plate light comes on. OK: Comes on If the result is not as specified, replace the scuff plate.

INSTALL FRONT DOOR SCUFF PLATE (See «INSTALLATION»(ref-235599-S41342360772006062400000) )

Scheme 234

Scheme 234: COMPONENTS

Scheme 235

Scheme 235: REMOVAL

REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Remove the No. 1 interior illumination light assembly LH.
REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Remove the No. 1 interior illumination light assembly RH.

Scheme 236

Scheme 237

Scheme 237: INSPECTION

INSPECT FOOTWELL LIGHT Disconnect the connector from the footwell light. Measure the voltage of the connector. Standard voltage LH Side: SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J19-2 - J19-1 Doors unlock by the transmitter 10 to 14 V J19-2 - J19-1 All doors are closed Below 1 V RH Side: SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J60-2 - J60-1 Doors unlock by the transmitter 10 to 14 V J60-2 - J60-1 All doors are closed Below 1 V If the result is not as specified, repair or replace wire harness or connector.
Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1.
Check that the footwell light comes on.

Scheme 238

Comes on

If the result is not as specified, replace the footwell light.

Scheme 239

Scheme 239: INSTALLATION

Scheme 240

INSTALL NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY RH Install the No. 1 interior illumination light assembly RH.
INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY LH Install the No. 1 interior illumination light assembly LH.
INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-235591-S32740741772006062400000) )

Scheme 241

Scheme 241: COMPONENTS

Scheme 242

Scheme 242: REMOVAL

Scheme 243

REMOVE FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SIDE INSTRUMENT PANEL LH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY Disengage the clamp and remove the No. 1 interior illumination light assembly.
REMOVE FRONT DOOR SCUFF PLATE RH (w/o Illumination) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT DOOR SCUFF PLATE RH (w/ Illumination) (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SIDE INSTRUMENT PANEL RH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 2 INTERIOR ILLUMINATION LIGHT ASSEMBLY Disengage the clamp and remove the No. 2 interior illumination light assembly.

Scheme 244

Scheme 244: INSPECTION

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

INSPECT RESISTER ILLUMINATION (LH Side) Disconnect the connector from the resister. Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J33-2 (ILL+) - Body ground Dimmer switch ON 10 to 14 V J33-2 (ILL+) - Body ground Dimmer switch OFF Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1. Check that the resister illumination comes on. OK: Comes on If the result is not as specified, replace the resister illumination.
INSPECT RESISTER ILLUMINATION (RH Side) Disconnect the connector from the resister. Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J32-2 (ILL+) - Body ground Dimmer switch ON 10 to 14 V J32-2 (ILL+) - Body ground Dimmer switch OFF Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1. Check that the resister illumination comes on. OK: Comes on If the result is not as specified, replace the resister illumination.
INSPECT RESISTER ILLUMINATION (Center) Disconnect the connector from the resister. Measure the voltage of the connector. Standard voltage: LH Side SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J11-2 (ILL+) - Body ground Dimmer switch ON 10 to 14 V J11-2 (ILL+) - Body ground Dimmer switch OFF Below 1 V RH Side SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J73-2 (ILL+) - Body ground Dimmer switch ON 10 to 14 V J73-2 (ILL+) - Body ground Dimmer switch OFF Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 1. Check that the resister illumination comes on. OK: Comes on If the result is not as specified, replace the resister illumination.

Scheme 250

Scheme 250: INSTALLATION

Scheme 251

INSTALL NO. 2 INTERIOR ILLUMINATION LIGHT ASSEMBLY Install the No. 2 interior illumination light assembly with the clamp.
INSTALL NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See Step 10 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SIDE INSTRUMENT PANEL RH (See Step 17 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR OPENING TRIM COVER RH (See Step 18 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE RH (w/o Illumination)
INSTALL FRONT DOOR SCUFF PLATE RH (w/ Illumination)
INSTALL NO. 1 INTERIOR ILLUMINATION LIGHT ASSEMBLY Install the No. 1 interior illumination light assembly with the clamp.
INSTALL NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See Step 11 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SIDE INSTRUMENT PANEL LH (See Step 26 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR OPENING TRIM COVER LH (See Step 27 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See «INSTALLATION»(ref-235599-S41342360772006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See «INSTALLATION»(ref-235599-S41342360772006062400000) )

Scheme 252

Scheme 252: COMPONENTS

REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See Step 2 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE COURTESY LIGHT ASSEMBLY (See Step 3 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See Step 4 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE FRONT DOOR GLASS WEATHERSTRIP INNER (See Step 6 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE FRONT DOOR TRIM COVER (See Step 9 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE DOOR FRAME GARNISH (See Step 10 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE OUTER MIRROR CONTROL ECU (w/ Memory) (See Step 13 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
REMOVE OUTER MIRROR PROTECTOR (See Step 9 in «REMOVAL»(ref-235597-S05842560672006062400000) )
REMOVE OUTER REAR VIEW MIRROR ASSEMBLY (See Step 10 in «REMOVAL»(ref-235597-S05842560672006062400000) )

Scheme 253

Scheme 253: INSPECTION

Scheme 254

INSPECT DOOR MIRROR FOOT LIGHT Disconnect the connector from the door mirror foot light. Measure the voltage of the connector. Standard voltage: LH Side (Without Seat Position Memory) SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition M11-2 (+) - M11-8 (-) Doors unlock by the transmitter 10 to 14 V M11-2 (+) - M11-8 (-) All doors are locked Below 1 V LH Side (With Seat Position Memory) SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition M15-2 (+) - M15-8 (-) Doors unlock by the transmitter 10 to 14 V M15-2 (+) - M15-8 (-) All doors are locked Below 1 V RH Side (Without Seat Position Memory) SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition L12-2 (+) - L12-8 (-) Doors unlock by the transmitter 10 to 14 V L12-2 (+) - L12-8 (-) All doors are locked Below 1 V RH Side (With Seat Position Memory) SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition L14-2 (+) - L14-8 (-) Doors unlock by the transmitter 10 to 14 V L14-2 (+) - L14-8 (-) All doors are locked Below 1 V If the result is not as specified, repair or replace wire harness or connector. Connect the (+) lead from the battery to terminal 2 and the (-) lead to terminal 8. Check that the door mirror foot light comes on. OK: Comes on If the result is not as specified, replace the door mirror assembly.

INSTALL OUTER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION»(ref-235597-S34270808682006062400000) )
INSTALL OUTER MIRROR PROTECTOR (See Step 2 in «INSTALLATION»(ref-235597-S34270808682006062400000) )
INSTALL OUTER MIRROR CONTROL ECU (w/ Memory) (See Step 27 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL DOOR FRAME GARNISH (See Step 30 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL FRONT DOOR TRIM COVER (See Step 31 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL FRONT DOOR GLASS WEATHERSTRIP INNER (See Step 32 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See Step 36 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL COURTESY LIGHT ASSEMBLY (See Step 37 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See Step 38 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG (See Step 39 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
POWER WINDOW CONTROL SYSTEM INITIALIZATION (See «INITIALIZATION»(ref-235586-S29196739662006062400000) )

Scheme 255

Scheme 255: COMPONENTS

Scheme 256

Scheme 256: REMOVAL

Scheme 257

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent airbag deployment (See «PRECAUTION»(ref-235542-S10058841152006062400000) )
REMOVE NO. 2 LOWER STEERING WHEEL COVER (See Step 4 in «REMOVAL»(ref-235542-S05597931522006062400000) )
REMOVE NO. 3 LOWER STEERING WHEEL COVER (See Step 3 in «REMOVAL»(ref-235542-S05597931522006062400000) )
REMOVE STEERING PAD (See Step 5 in «REMOVAL»(ref-235542-S05597931522006062400000) )
REMOVE STEERING WHEEL ASSEMBLY (See Step 11 in «REMOVAL»(ref-235546-S15909269792006062400000) )
REMOVE STEERING COLUMN COVER (for Power Tilt and Power Telescopic) (See Step 12 in «REMOVAL»(ref-235546-S01736682752006062400000) )
REMOVE STEERING COLUMN COVER (for Manual Tilt and Telescopic) (See Step 12 in «REMOVAL»(ref-235546-S15909269792006062400000) )
REMOVE SPIRAL CABLE WITH STEERING ANGLE SENSOR (See Step 8 in «REMOVAL»(ref-235542-S33599905202006062400000) )
REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY (See Step 3 in «REMOVAL»(ref-235575-S36243743162006062400000) )
REMOVE HEADLIGHT DIMMER SWITCH ASSEMBLY Disconnect the connector. Disengage the clamp and claw. Remove the headlight dimmer switch assembly.

Scheme 258

Scheme 258: INSPECTION

REMOVE HEADLIGHT DIMMER SWITCH ASSEMBLY Measure the resistance according to the value(s) in «SPECIFIED CONDITION AND TESTER CONNECTION TABLE»(ref-235577-S22902276152006062400000) . Standard resistance: Light Control Switch SPECIFIED CONDITION AND TESTER CONNECTION TABLE Tester Connection Switch Condition Specified Condition f1-12 (EL) - f1-18 (T) OFF 10 k ohms or higher f1-18 (T) - f1-19 (AUTO) OFF 10 k ohms or higher f1-19 (AUTO) - f1-20 (H) OFF 10 k ohms or higher f1-12 (EL) - f1-18 (T) TAIL Below 1 ohms f1-12 (EL) - f1-18 (T) HEAD Below 1 ohms f1-18 (T) - f1-20 (H) HEAD Below 1 ohms f1-12 (EL) - f1-19 (AUTO) AUTO Below 1 ohms Headlight Dimmer Switch SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition f1-11 (HU) - f1-12 (EL) LOW BEAM Below 1 ohms f1-11 (HU) - f1-12 (EL) HI BEAM Below 1 ohms f1-12 (EL) - f1-17 (HF) HI BEAM Below 1 ohms Turn Signal Switch SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition f1-12 (EL) - f1-13 (TR) Right turn Below 1 ohms f1-12 (EL) - f1-13 (TR) Neutral 10 k ohms or higher f1-12 (EL) - f1-15 (TL) Neutral 10 k ohms or higher f1-12 (EL) - f1-15 (TL) Left turn Below 1 ohms Fog Light Switch SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition f1-3 (LFG) - f1-4 (BFG) OFF 10 k ohms or higher f1-3 (LFG) - f1-4 (BFG) Fog light switch ON Below 1 ohms If the result is not as specified, replace the headlight dimmer switch assembly.

Scheme 259

Scheme 259: INSTALLATION

Scheme 260

INSTALL HEADLIGHT DIMMER SWITCH ASSEMBLY Install the headlight dimmer switch assembly. Install the headlight dimmer switch assembly with the claw and the clamp. Connect the connector.
INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY (See «INSTALLATION»(ref-235575-S42416117012006062400000) )
INSTALL SPIRAL CABLE WITH STEERING ANGLE SENSOR (See Step 2 in «INSTALLATION»(ref-235542-S27816112932006062400000) )
INSTALL STEERING COLUMN COVER (for Manual Tilt and Telescopic) (See Step 7 in «INSTALLATION»(ref-235546-S07122382332006062400000) )
INSTALL STEERING COLUMN COVER (for Power Tilt and Power Telescopic) (See Step 8 in «INSTALLATION»(ref-235546-S34210807472006062400000) )
INSTALL STEERING WHEEL ASSEMBLY (See Step 9 in «INSTALLATION»(ref-235546-S07122382332006062400000) )
INSTALL STEERING PAD (See «INSTALLATION»(ref-235542-S14674145642006062400000) )
INSTALL NO. 3 LOWER STEERING WHEEL COVER (See Step 2 in «INSTALLATION»(ref-235542-S14674145642006062400000) )
INSTALL NO. 2 LOWER STEERING WHEEL COVER (See Step 3 in «INSTALLATION»(ref-235542-S14674145642006062400000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-235541-S32349848442006062400000) ).
INSPECT SRS WARNING LIGHT (See «PROBLEM SYMPTOMS TABLE»(ref-235542-S10426029612006062400000) )

Scheme 261

Scheme 261: COMPONENTS

Scheme 262

REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission) (See Step 4 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission) (See Step 5 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See Step 6 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 2 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See Step 7 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission) (See Step 8 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See Step 9 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See Step 10 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE FRONT ASH RECEPTACLE SUB-ASSEMBLY (See Step 11 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE CONSOLE BOX REGISTER ASSEMBLY (See Step 12 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE CONSOLE BOX (See Step 13 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See Step 14 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE CENTER LOWER INSTRUMENT CLUSTER FINISH PANEL (See Step 15 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) (See Step 13 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE NO. 1 RADIO BRACKET (w/o Navigation System) (See Step 14 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE NO. 2 RADIO BRACKET (w/o Navigation System) (See Step 15 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE RADIO RECEIVER ASSEMBLY (w/o Navigation System) (See Step 16 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) (See Step 17 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE NO. 1 RADIO BRACKET (w/ Navigation System) (See Step 18 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE NO. 2 RADIO BRACKET (w/ Navigation System) (See Step 19 in «REMOVAL»(ref-235589-S20177326342006062400000) )
REMOVE RADIO RECEIVER ASSEMBLY (w/ Navigation System) (See Step 20 in «REMOVAL»(ref-235589-S20177326342006062400000) )

Scheme 263

Scheme 263: INSPECTION

Scheme 264

INSPECT INTEGRATION CONTROL PANEL (Without Navigation System) Measure the resistance of the integration control panel. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition J54-12 (F) - J54-8 (E) Hazard warning switch OFF 10 k ohms or higher J54-12 (F) - J54-8 (E) Hazard warning switch ON Below 1 ohms If the result is not as specified, replace the integration control panel.
INSPECT CLOCK ASSEMBLY (With Navigation System) Measure the resistance of the clock assembly. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition J53-12 (F) - J53-2 (E) Hazard warning switch OFF 10 k ohms or higher J53-12 (F) - J53-2 (E) Hazard warning switch ON Below 1 ohms If the result is not as specified, replace the clock assembly.

INSTALL RADIO RECEIVER ASSEMBLY (w/o Navigation System) (See «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL NO. 2 RADIO BRACKET (w/o Navigation System) (See Step 2 in «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL NO. 1 RADIO BRACKET (w/o Navigation System) (See Step 3 in «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) (See Step 4 in «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL RADIO RECEIVER ASSEMBLY (w/ Navigation System) (See Step 5 in «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL NO. 2 RADIO BRACKET (w/ Navigation System) (See Step 6 in «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL NO. 1 RADIO BRACKET (w/ Navigation System) (See Step 7 in «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) (See «INSTALLATION»(ref-235589-S18433754322006062400000) )
INSTALL CENTER LOWER INSTRUMENT CLUSTER FINISH PANEL (See Step 40 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See Step 41 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL CONSOLE BOX (See Step 42 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL CONSOLE BOX REGISTER ASSEMBLY (See Step 43 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT ASH RECEPTACLE SUB-ASSEMBLY (See Step 44 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See Step 45 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) (See Step 46 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission) (See Step 47 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 2 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See Step 48 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 1 UPPER CONSOLE PANEL GARNISH (for Automatic Transmission) (See Step 49 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission)
INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission)

Scheme 265

Scheme 265: COMPONENTS

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent airbag deployment (See «PRECAUTION»(ref-235542-S10058841152006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See Step 50 in «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See Step 52 in «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SIDE INSTRUMENT PANEL LH (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE DRIVER SIDE KNEE AIRBAG ASSEMBLY (See Step 9 in «REMOVAL»(ref-235542-S32764164272006062400000) )
REMOVE STOP LIGHT SWITCH ASSEMBLY (See «REMOVAL»(ref-235547-S29824399822006062400000) )

Scheme 266

Scheme 266: INSPECTION

INSPECT STOP LIGHT SWITCH ASSEMBLY Remove the switch. Measure the resistance of the switch. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition 1 - 2 Pushed 10 k ohms or higher 1 - 2 Not pushed Below 1 ohms 3 - 4 Pushed Below 1 ohms 3 - 4 Not pushed 10 k ohms or higher If the result is not as specified, replace the switch assembly.

INSTALL STOP LIGHT SWITCH ASSEMBLY (See «INSTALLATION»(ref-235547-S07970680492006062400000) )
INSTALL DRIVER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-235542-S26103287292006062400000) )
INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY (See Step 24 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See Step 25 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SIDE INSTRUMENT PANEL LH (See Step 26 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR OPENING TRIM COVER LH (See Step 27 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See Step 88 in «INSTALLATION»(ref-235599-S41342360772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See Step 90 in «INSTALLATION»(ref-235599-S41342360772006062400000) )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-235541-S32349848442006062400000) ).
INSPECT SRS WARNING LIGHT (See «PROBLEM SYMPTOMS TABLE»(ref-235542-S10426029612006062400000) )

Scheme 267

Scheme 267: COMPONENTS

Scheme 268

Scheme 268: REMOVAL

REMOVE FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Using a "torx" socket wrench (T30), remove the "torx" bolt. Disconnect the connector and remove the front door courtesy light switch assembly.

Scheme 269

Scheme 269: INSPECTION

INSPECT FRONT DOOR COURTESY SWITCH Measure the resistance of the switch. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition 1 - Switch body Pushed 10 k ohms or higher 1 - Switch body Not pushed Below 1 ohms If the result is not as specified, replace the switch.

Scheme 270

Scheme 270: INSTALLATION

INSTALL FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Connect the connector. Using a "torx" socket wrench (T30), install the front door courtesy light switch assembly with the "torx" bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)

Scheme 271

Scheme 271: COMPONENTS

Scheme 272

Scheme 272: REMOVAL

REMOVE REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY Using a "torx" socket wrench (T30), remove the "torx" bolt. Disconnect the connector and remove the rear door courtesy light switch assembly.

REMOVE LUGGAGE COMPARTMENT DOOR ASSIST GRIP (See Step 2 in «REMOVAL»(ref-235598-S30906551882006062400000) )
REMOVE LUGGAGE LOCK CONTROL CABLE PLATE (See Step 2 in «DISASSEMBLY»(ref-235587-S10048742022006062400000) )
REMOVE LUGGAGE COMPARTMENT DOOR INSIDE HANDLE (See Step 3 in «DISASSEMBLY»(ref-235587-S10048742022006062400000) )
REMOVE LUGGAGE COMPARTMENT DOOR COVER (See Step 5 in «REMOVAL»(ref-235598-S30906551882006062400000) )
REMOVE LUGGAGE COMPARTMENT DOOR REINFORCEMENT (See Step 6 in «REMOVAL»(ref-235598-S30906551882006062400000) )
REMOVE LUGGAGE COMPARTMENT DOOR LOCK CYLINDER ASSEMBLY (See Step 7 in «DISASSEMBLY»(ref-235587-S10048742022006062400000) )
REMOVE LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (See Step 7 in «REMOVAL»(ref-235587-S03275892842006062400000) )

Scheme 273

Scheme 273: INSPECTION

INSPECT BACK DOOR COURTESY SWITCH Measure the resistance of the switch. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Switch Condition Specified Condition Q23-1 - Q23-2 Door LOCK position 10 k ohms or higher Q23-1 - Q23-2 Door UNLOCK position Below 1 ohms If the result is not as specified, replace the switch.

INSTALL LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (See «INSTALLATION»(ref-235587-S05733779662006062400000) )
INSTALL LUGGAGE COMPARTMENT DOOR LOCK CYLINDER ASSEMBLY (See Step 9 in «REASSEMBLY»(ref-235587-S33135290422006062400000) )
INSTALL LUGGAGE COMPARTMENT DOOR REINFORCEMENT
INSTALL LUGGAGE COMPARTMENT DOOR COVER
INSTALL LUGGAGE COMPARTMENT DOOR INSIDE HANDLE (See Step 13 in «REASSEMBLY»(ref-235587-S33135290422006062400000) )
INSTALL LUGGAGE LOCK CONTROL CABLE PLATE (See Step 14 «REASSEMBLY»(ref-235587-S33135290422006062400000) )
INSTALL LUGGAGE COMPARTMENT DOOR ASSIST GRIP

Scheme 274

Scheme 274: COMPONENTS

Scheme 275

Scheme 275: ON-VEHICLE INSPECTION

Scheme 276

INSPECT AUTOMATIC LIGHT CONTROL SENSOR Disconnect the K1 sensor connector. Connect the voltmeter's positive (+) lead to terminal 6 and the negative (-) lead to terminal 3. Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition K1-3 (CTLE) - K1-6 (CTLB) Engine switch on (IG) 10 to 14 V Measure the resistance of the connector. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition K1-3 (CTLE) - Body ground Always Below 1 ohms Reconnect the K1 sensor connector. Check the waveform of the K1 sensor connector. SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition Tester Range K1-3 (CTLE) - K1-5 (CTLS) Engine switch on (IG), Headlight dimmer switch in AUTO Correct waveform is as shown 5 V/DIV., 5 msec./DIV. HINT: If the ambient light becomes brighter, width A becomes narrower. If the result is not as specified, replace the automatic light control sensor.

REMOVE DEFROSTER NOZZLE GARNISH (See Step 12 in «DISASSEMBLY»(ref-235591-S03655466192006062400000) )
REMOVE AUTOMATIC LIGHT CONTROL SENSOR (See Step 13 in «DISASSEMBLY»(ref-235591-S03655466192006062400000) )

INSTALL AUTOMATIC LIGHT CONTROL SENSOR (See Step 3 in «REASSEMBLY»(ref-235591-S41509918092006062400000) )
INSTALL DEFROSTER NOZZLE GARNISH (See Step 4 in «REASSEMBLY»(ref-235591-S41509918092006062400000) )

Scheme 277

Scheme 277: COMPONENTS

Scheme 278

Scheme 279

Scheme 279: REMOVAL

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

REMOVE FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY (for 2WD) Disconnect the connector. Remove the nut. Remove the 2 bolts and front height control sensor sub-assembly.
REMOVE FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY (for 4WD) Disconnect the connector. Remove the bolt. Remove the 2 bolts and front height control sensor sub-assembly.
REMOVE REAR HEIGHT CONTROL SENSOR SUBASSEMBLY Disengage the clamp and disconnect the connector. Put matchmarks on the rear height control sensor link and bracket. Remove the 2 bolts, nut and rear height control sensor sub-assembly.

Scheme 286

Scheme 286: INSPECTION

Scheme 287

INSPECT FRONT HEIGHT CONTROL SENSOR SUBASSEMBLY Connect the 3 dry cell batteries (1.5 V) in series. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead from the battery to terminal 3. Measure the voltage between terminals 2 and 1 while slowly moving the link up and down. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition A17-2 (SHFL) - A17-1 (SHG) +45° Approx. 4.5 V A17-2 (SHFL) - A17-1 (SHG) 0° (normal) Approx 2.5 V A17-2 (SHFL) - A17-1 (SHG) -45° Approx 0.5 V If the result is not as specified, replace the sensor. Remove the height control sensor.
INSPECT REAR HEIGHT CONTROL SENSOR SUBASSEMBLY Connect the 3 dry cell batteries (1.5 V) in series. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead from the battery to terminal 3. Measure the voltage between terminals 2 and 1 while slowly moving the link up and down. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition Y2-2 (SHRL) - Y2-1 (SHG) +45° Approx. 4.5 V Y2-2 (SHRL) - Y2-1 (SHG) 0°(normal) Approx 2.5 V Y2-2 (SHRL) - Y2-1 (SHG) -45° Approx 0.5 V If the result is not as specified, replace the sensor.

Scheme 288

Scheme 288: INSTALLATION

Scheme 289

Scheme 290

Scheme 291

Scheme 292

INSTALL REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY When replacing the rear height control sensor subassembly: Align matchmarks and also the trace of the nut, and install the rear height control sensor sub-assembly and bracket. When reusing the rear height control sensor subassembly: Align matchmarks on the rear height control sensor sub-assembly and bracket. Install the rear height control sensor sub-assembly with the 2 bolts and nut. Torque: Bolt 14 N*m (143 kgf*cm, 10 ft.*lbf) Nut 5.4 N*m (55 kgf*cm, 48 in.*lbf) Install the clamp. Connect the connector.
REMOVE FRONT HEIGHT CONTROL SENSOR SUBASSEMBLY (for 4WD) Install the 2 bolts. Torque: 14 N*m (143 kgf*cm, 10 ft.*lbf) Install the front height control sensor sub-assembly with the bolt. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
INSTALL FRONT HEIGHT CONTROL SENSOR SUBASSEMBLY (for 2WD) Install the 2 bolts. Torque: 14 N*m (143 kgf*cm, 10 ft.*lbf) Install the front height control sensor sub-assembly with the nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
VEHICLE PREPARATION FOR HEADLIGHT AIM ADJUSTMENT (See «ADJUSTMENT»(ref-235577-S25613627832006062400000) )
PREPARATION FOR HEADLIGHT AIMING (Using a tester) (See Step 2 in «ADJUSTMENT»(ref-235577-S25613627832006062400000) )
PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See Step 3 in «ADJUSTMENT»(ref-235577-S25613627832006062400000) )
HEADLIGHT AIMING INSPECTION (See Step 4 in «ADJUSTMENT»(ref-235577-S25613627832006062400000) )
HEADLIGHT AIMING ADJUSTMENT (See Step 5 in «ADJUSTMENT»(ref-235577-S25613627832006062400000) )

Scheme 293

Scheme 294

Scheme 294: COMPONENTS

Scheme 295

Scheme 295: REMOVAL

Scheme 296

Scheme 297

REMOVE FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See Step 50 in «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See Step 52 in «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR OPENING TRIM COVER LH (See Step 27 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See Step 29 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE HEADLIGHT SWIVEL ECU ASSEMBLY Disengage the 2 clips and disconnect the connector holder. Remove the bolt and nut. Disconnect the connectors. Disengage the clamp and remove the headlight swivel ECU assembly.

Scheme 298

Scheme 298: INSTALLATION

Scheme 299

INSTALL HEADLIGHT SWIVEL ECU ASSEMBLY Install the clamp. Connect the connector. Install the headlight swivel ECU assembly with the bolt and nut. Install the connector holder with the 2 clips.
INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See Step 25 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR OPENING TRIM COVER LH (See Step 27 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See Step 88 in «INSTALLATION»(ref-235599-S41342360772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See Step 90 in «INSTALLATION»(ref-235599-S41342360772006062400000) )

Scheme 300

Scheme 301

Scheme 301: COMPONENTS

Scheme 302

Scheme 302: ON-VEHICLE INSPECTION

INSPECT TURN SIGNAL FLASHER ASSEMBLY Disconnect the J30 connector. Measure the voltage of the wire harness side connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J30-1 (IG) - Body ground Engine switch off Below 1 V J30-1 (IG) - Body ground Engine switch on (IG) 10 to 14 V J30-4 (B) - Body ground Always 10 to 14 V J30-7 (E) - Body ground Always Below 1 V Reconnect the connector. Measure the voltage of the connector. Standard voltage SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Condition Specified Condition J30-2 (LR) - Body ground Hazard warning switch OFF Below 1 V J30-2 (LR) - Body ground Hazard warning switch ON 10 to 14 V (60 to 120 times per minute) J30-2 (LR) - Body ground Engine switch on (IG) and turn signal switch (right turn) OFF Below 1 V J30-2 (LR) - Body ground Engine switch on (IG) and turn signal switch (right turn) ON 10 to 14 V (60 to 120 times per minute) J30-3 (LL) - Body ground Hazard warning switch OFF Below 1 V J30-3 (LL) - Body ground Hazard warning switch ON 10 to 14 V (60 to 120 times per minute) J30-3 (LL) - Body ground Engine switch on (IG) and turn signal switch (left turn) OFF Below 1 V J30-3 (LL) - Body ground Engine switch on (IG) and turn signal switch (left turn) ON 10 to 14 V (60 to 120 times per minute) J30-5 (EL) - Body ground Engine switch on (IG) and turn signal switch (left turn) OFF 10 to 14 V J30-5 (EL) - Body ground Engine switch on (IG) and turn signal switch (left turn) ON Below 1 V J30-6 (ER) - Body ground Engine switch on (IG) and turn signal switch (right turn) OFF 10 to 14 V J30-6 (ER) - Body ground Engine switch on (IG) and turn signal switch (right turn) ON Below 1 V J30-8 (HAZ) - Body ground Hazard warning switch OFF 10 to 14 V J30-8 (HAZ) - Body ground Hazard warning switch ON Below 1 V If the result is not as specified, replace the flasher assembly.

REMOVE STEERING COLUMN COVER (for Manual Tilt and Telescopic) (See Step 12 in «REMOVAL»(ref-235546-S15909269792006062400000) )
REMOVE STEERING COLUMN COVER (for Power Tilt and Power Telescopic) (See Step 12 in «REMOVAL»(ref-235546-S01736682752006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See Step 50 in «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See Step 52 in «REMOVAL»(ref-235599-S10274364092006062400000) )
REMOVE FRONT DOOR OPENING TRIM COVER LH (See Step 27 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE SIDE INSTRUMENT PANEL LH (See Step 28 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY (See Step 30 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See Step 32 in «REMOVAL»(ref-235591-S20751754672006062400000) )
REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY (See Step 3 in «REMOVAL»(ref-235575-S36243743162006062400000) )
REMOVE COMBINATION METER ASSEMBLY (See Step 11 in «REMOVAL»(ref-235585-S29291806492006062400000) )
REMOVE TURN SIGNAL FLASHER ASSEMBLY Disconnect the connector. Disengage the clamp and remove the turn signal flasher assembly.

INSTALL TURN SIGNAL FLASHER ASSEMBLY Install the turn signal flasher assembly with the clamp. Connect the connector.
INSTALL COMBINATION METER ASSEMBLY (See Step 2 in «INSTALLATION»(ref-235585-S01904546052006062400000) )
INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY (See «INSTALLATION»(ref-235575-S42416117012006062400000) )
INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See Step 22 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY (See Step 24 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL SIDE INSTRUMENT PANEL LH (See Step 26 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR OPENING TRIM COVER LH (See Step 27 in «INSTALLATION»(ref-235591-S32740741772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/o Illumination) (See Step 88 in «INSTALLATION»(ref-235599-S41342360772006062400000) )
INSTALL FRONT DOOR SCUFF PLATE LH (w/ Illumination) (See Step 90 in «INSTALLATION»(ref-235599-S41342360772006062400000) )
INSTALL STEERING COLUMN COVER (for Power Tilt and Power Telescopic) (See Step 8 in «INSTALLATION»(ref-235546-S34210807472006062400000) )
INSTALL STEERING COLUMN COVER (for Manual Tilt and Telescopic) (See Step 7 in «INSTALLATION»(ref-235546-S07122382332006062400000) )

Scheme 303

Scheme 303: ON-VEHICLE INSPECTION

INSPECT HEADLIGHT RELAY (Marking: HEAD LP) Remove the headlight relay from the engine room R/B No.1. Measure the resistance of the relay. Standard resistance SPECIFIED CONDITION AND TESTER CONNECTION Tester Connection Specified Condition 3 - 5 10 k ohms or higher 3 - 5 Below 1 ohms (when battery voltage is applied to terminals 1 and 2) If the result is not as specified, replace the relay.

Lighting: Removal & Installation Lexus IS II
