FAIL-SAFE CHART
FUEL SIGNAL (FUEL INJECTION SIGNAL)
| Condition | Response | Recovery |
|---|---|---|
| While the engine switch on (IG), fuel injection signal is interrupted for 60 seconds. | Fuel gauge calibration is performed using average fuel consumption data. | Engine switch off and then on (IG) and normal data is received. |
CONDITION RESPONSE REFERENCE CHART
ENGINE COOLANT TEMPERATURE GAUGE
| Condition | Response | Recovery |
|---|---|---|
| Engine coolant temperature data is interrupted for 5 seconds. | The gauge needle indicates less than "C". | Engine coolant temperature data is received. |
CONDITION RESPONSE REFERENCE CHART
SHIFT INDICATOR (*1)
| Condition | Response | Recovery |
|---|---|---|
| "P" to "D" data is interrupted for 3 seconds. | All indicator lights go off. | Normal data is received. |
| A/T range data is interrupted for 3 seconds, or more than 2 items are received simultaneously. | The A/T range indicator light and backlight LED goes off. | Normal data is received. |
CONDITION RESPONSE REFERENCE CHART
ABS & BRAKE
| Condition | Response | Recovery |
|---|---|---|
| ABS & brake data is interrupted for 1 second. | The warning light comes on. | Normal data is received. |
CONDITION RESPONSE REFERENCE CHART
DOOR
| Condition | Response | Recovery |
|---|---|---|
| Regular data is interrupted for 10 seconds. | The data received most recently remains indicated. | Normal data is received. |
CONDITION RESPONSE REFERENCE CHART
DRIVER SIDE SEAT BELT
| Condition | Response | Recovery |
|---|---|---|
| Driver side seat belt inner belt assembly data is interrupted for 10 seconds. | The data received most recently remains indicated. | Normal data is received. |
CONDITION RESPONSE REFERENCE CHART
FRONT PASSENGER SIDE SEAT BELT
| Condition | Response | Recovery |
|---|---|---|
| Front passenger side seat belt inner belt assembly data or occupant detection data is interrupted for 10 seconds. | The data received most recently remains indicated. | Normal data is received. |
CONDITION RESPONSE REFERENCE CHART
POWER STEERING
| Condition | Response | Recovery |
|---|---|---|
| EPS data is interrupted for 1 second. | The indicator light comes on. | Normal data is received. |
CONDITION RESPONSE REFERENCE
HEAD (*2)/TAIL (*3)
| Condition | Response | Recovery |
|---|---|---|
| Regular data is interrupted for 10 seconds. | The data received most recently remains indicated. | Normal data is received. |
CONDITION RESPONSE REFERENCE
BEAM
| Condition | Response | Recovery |
|---|---|---|
| Regular data is interrupted for 10 seconds. | The indicator light goes off. | Normal data is received. |
CONDITION RESPONSE REFERENCE
AIRBAG
| Condition | Response | Recovery |
|---|---|---|
| Airbag data is interrupted for 10 seconds or there is a malfunction in the combination meter (meter CPU). | The warning light comes on. | Normal data is received. |
CONDITION RESPONSE REFERENCE
METER ILLUMINATION
| Condition | Response | Recovery |
|---|---|---|
| Illumination data is interrupted for 10 seconds or abnormal data is received. | The display remains in daytime mode. | Normal data is received. |
METER ILLUMINATION CONDITION REFERENCE
MULTI-INFORMATION DISPLAY
| Condition | Response | Recovery |
|---|---|---|
| Cruise information data is interrupted for 60 seconds. | The display becomes blank (only measurement units are displayed). | Normal data is received. |
MULTI-INFORMATION DISPLAY DESCRIPTION CHART
*1: for Automatic Transmission
*2: for U.S.A.
*3: for Canada
Scheme 95
Scheme 96
- DATA LIST HINT: Using the intelligent tester to read the DATA LIST allows the values or states of switches, sensors, actuators, and other items to be read without removing any parts. This non intrusive inspection can be very useful as intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the DATA LIST information early in troubleshooting is one way to save diagnostic time. Warm up the engine. Engine switch off. Connect the intelligent tester to the DLC3. Engine switch on (IG) position. Turn the tester ON. Enter following menus: DIAGNOSIS / OBD/MOBD / METER / DATA LIST Check the values by referring to the table below. METER: METER DISPLAY DIAGNOSTIC REFERENCE Item Measurement Item/Range (Display) Normal Condition Diagnostic Note SPEED METER Vehicle speed/Min.: 0 km/h (0 mph), Max.: 255 km/h (158 mph) Almost same as actual vehicle speed (When driving) - TACHO METER Engine speed/Min.: 0 rpm, Max.: 12,750 rpm Almost same as actual engine speed (When engine is running) - FUEL GAUGE Fuel input signal Min.: 0, Max.: 255 Fuel gauge indicates (F): 35 Fuel gauge indicates (3/4): 85 Fuel gauge indicates (1/2): 145 Fuel gauge indicates (1/4): 186 Fuel gauge indicates (E): 205 - LIGHT RHEOSTAT Light Control Rheostat/Min.: 0, Max.: 255 Light control rheostat switch is Dark (0) --> Bright (255) - ODO/TRIP SW ODO/TRIP switch is ON/OFF ON: Switch is pushed OFF: Switch is released - TAIL CANCEL SW TAIL CANCEL switch is ON/OFF ON: Light control rheostat turns fully clockwise OFF: Light control rheostat does not turn fully clockwise - HINT: The tail cancel switch is used to cancel the link between taillight operation and dimming of the combination meter. ABS/VSC/TRAC: ABS/VSC/TRAC DISPLAY DIAGNOSTIC REFERENCE Item Measurement Item/Range (Display) Normal Condition Diagnostic Note FR/FL/RR/RL WHEEL SPD Vehicle speed/Min.: 0 km/h (0 mph), Max.: 326 km/h (202 mph) Almost same as actual vehicle speed (When driving) - VEHICLE SPD Vehicle speed/Min.: 0 km/h (0 mph), Max.: 326 km/h (202 mph) Almost same as actual vehicle speed (When driving) - LEVER POSITION A/T shift position P/R/N/D/B Same as actual shift position - PARKING BRAKE SW Parking brake switch is ON/OFF ON: Parking brake is on OFF: Parking brake is released - ENGINE: ENGINE DISPLAY DIAGNOSTIC REFERENCE Item Measurement Item/Range (Display) Normal Condition Diagnostic Note VEHICLE SPD Vehicle speed/Min.: -256 km/h (- 159 mph), Max.: 254 km/h (158 mph) Almost same as actual vehicle speed (When driving) - COOLANT TEMP Coolant temperature/Min.: -40°C (-40°F), Max.: 140°C (284°F) After warming up: 80 to 95°C (176 to 203°F) If the value is "-40°C (-40°F)" or "140°C (284°F)", sensor circuits are open or shorted.
- ACTIVE TEST HINT: Performing the ACTIVE TEST using the intelligent tester allows the meters, indicators and so on to operate without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one way to shorten diagnosis time. It is possible to display the DATA LIST on the intelligent tester during the ACTIVE TEST. Connect the intelligent tester to the DLC3. Engine switch on (IG). Turn the tester ON. Enter following menus: DIAGNOSIS / OBD/MOBD / METER / ACTIVE TEST From the display on tester, perform "ACTIVE TEST". METER: METER DIAGNOSTIC REFERENCE Item Test Details Diagnostic Note SPEED METER 0, 40 (24), 80 (48), 120 (72), 160 (96), 200 (120) km/h (mph) - TACHO METER 0, 1,000, 2,000, 3,000, 4,000, 5,000, 6,000, 7,000 (rpm) - FUEL GAUGE EMPTY, 1/2, FULL - COOLANT TEMP LOW, NORMAL, HIGH - SHIFT INDIC P/R/ N/D/S (*1) A/T shift indicator light P/R/N/D/S (OFF/ON) Confirm that the vehicle is stopped with the idling BRAKE WARN BRAKE warning light (OFF/ON) Confirm that the vehicle is stopped with the idling DISCHARGE WARN CHARGE warning light (OFF/ON) Confirm that the vehicle is stopped with the idling D-BELT REMIND D-SEAT BELT indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling P-BELT REMIND P-SEAT BELT indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling OPEN DOOR WARN DOOR warning light (OFF/ON) Confirm that the vehicle is stopped with the idling LOW FUEL WARN FUEL warning light (OFF/ON) Confirm that the vehicle is stopped with the idling ECT PWR INDIC (*1) ECT PWR indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling ECT SNOW INDIC (*1) ECT SNOW indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling CRUISE INDIC CLUISE indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling HEADLIGHT INDIC (*2) HEAD indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling TAILLIGHT INDIC (*3) TAIL indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling HIGH BEAM INDIC BEAM indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling SRS WARN AIRBAG indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling SLIP INDIC SLIP indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling ABS WARN ABS indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling ODO/TRIP DISP All the dot in the multi-information display (OFF/ON) Confirm that the vehicle is stopped with the idling TIRE PRESS WARN (*4) TIRE PRESS warning light (OFF/ON) Confirm that the vehicle is stopped with the idling KEY REMND BUZZR Key reminder buzzer (OFF/ON) Confirm that the vehicle is stopped with the idling SEAT BELT BUZZR Seat belt buzzer (OFF/ON) Confirm that the vehicle is stopped with the idling S SHFT RJCT BUZ Sports shift reject buzzer (OFF/ON) Confirm that the vehicle is stopped with the idling WARNING BUZZER Warning buzzer (OFF/ON) Confirm that the vehicle is stopped with the idling CLEARANCE SONAR (*5) CLEARANCE SONAR indicator light (OFF/ ON) Confirm that the vehicle is stopped with the idling A/T SHFT (*1) All the dot in the multi-information display (OFF/ON) Confirm that the vehicle is stopped with the idling AFS INDICATOR (*6) AFS OFF indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling EMPS EPS indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling MASTER WARN MASTER warning light (OFF/ON) Confirm that the vehicle is stopped with the idling MULTI-DISP All the dot in the multi-information display (OFF/ON) Confirm that the vehicle is stopped with the idling PCS (*7) PCS indicator light (OFF/ON) Confirm that the vehicle is stopped with the idling MAIN BODY: MAIN BODY DIAGNOSTIC CHART Item Test Details Diagnostic Notes DIMMER SIG Auto dimmer signal is (OFF/ON) Confirm that the vehicle is stopped with the idling *1: for Automatic Transmission *2: for U.S.A. *3: for Canada *4: with Tire Pressure Warning System *5: with Clearance Sonar System *6: with Intelligent AFS *7: with Pre-collision System
Scheme 97
- INSPECT SPEEDOMETER Check the operation. Using a speedometer tester (calibrated chassis dynamometer), check the speedometer indication according to the table below. Reference: mph (U.S.A.) CHASSIS DYNAMOMETER INDICATION REFERENCE Chassis dynamometer indication Acceptable range 20 mph 20.0 to 23.0 mph 40 mph 40.0 to 43.5 mph 60 mph 60.0 to 64.0 mph 80 mph 80.0 to 84.5 mph 100 mph 100.0 to 105.0 mph 120 mph 120.0 to 125.5 mph 140 mph 140.0 to 146.0 mph Reference: km/h (Canada) CHASSIS DYNAMOMETER INDICATION REFERENCE Chassis dynamometer indication Acceptable range Data in ( ) is for reference 20 km/h (17.5 to 21.5 km/h) 40 km/h 38.0 to 42.0 km/h 60 km/h 58.0 to 63.0 km/h 80 km/h 78.0 to 84.0 km/h 100 km/h 98.5 to 104.5 km/h 120 km/h 119.0 to 125.0 km/h 140 km/h 139.0 to 146.0 km/h 160 km/h 159.0 to 167.0 km/h 180 km/h 179.0 to 188.0 km/h 200 km/h 199.0 to 209.0 km/h 220 km/h 219.0 to 230.0 km/h 240 km/h 239.0 to 251.0 km/h NOTE: Tire wear as well as over or under inflation will cause errors. Check the deviation from the acceptable range of the speedometer indication. Reference: Less than 0.5 km/h (0.3 mph) HINT: If the indication is not as specified, go to «PROBLEM SYMPTOMS TABLE»(ref-235585-S32244280812006062400000) .
- INSPECT TACHOMETER Connect a tune-up tachometer, and start the engine. Compare the test results with the tachometer indications. DC 13.5 V, at 25°C (77°F) CHASSIS DYNAMOMETER INDICATION REFERENCE Chassis dynamometer indication (rpm) Acceptable range Data in ( ) is for reference 700 630 to 770 1,000 (900 to 1,100) 2,000 (1,850 to 2,150) 3,000 2,800 to 3,200 4,000 (3,800 to 4,200) 5,000 4,800 to 5,200 6,000 (5,750 to 6,250) 7,000 6,700 to 7,300 8,000 (7,700 to 8,300) HINT: If the indication is not as specified, go to the «PROBLEM SYMPTOMS TABLE»(ref-235585-S32244280812006062400000) .
- INSPECT ENGINE OIL PRESSURE SWITCH Disconnect the connector from the engine oil pressure switch. Engine switch on (IG). Ground the terminal of the wire harness side connector, then check the low oil pressure warning light. OK: Oil pressure warning light comes on. HINT: If the warning message is not displayed, go to the «PROBLEM SYMPTOMS TABLE»(ref-235585-S32244280812006062400000) .
- INSPECT ENGINE OIL LEVEL SENSOR Disconnect the engine oil level sensor connector. Engine switch on (IG), and check the multi-information display. OK: "LOW ENGINE OIL LEVEL" message is displayed. HINT: If the warning message is not displayed, go to the «PROBLEM SYMPTOMS TABLE»(ref-235585-S32244280812006062400000) .
- INSPECT MULTI-INFORMATION DISPLAY Engine switch off. Press the "DISP" button and hold it down. Engine switch on (IG). OK: All the dots in the multi-information display come on. HINT: This test is also available on «DATA LIST / ACTIVE TEST»(ref-235585-S19725847032006062400000) . Engine switch off to finish this test mode. HINT: If the result is not as specified, replace the combination meter assembly.
