COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Automatic Light Control Sensor | (Scheme 12) |
| Back-Up Lights | (Scheme 13) |
| Body ECU (Driver Side J/B) | (Scheme 12), (Scheme 15) & (Scheme 16) |
| Combination Switch | (Scheme 12) |
| Daytime Running Light Main Relay | (Scheme 12) |
| DOME Fuse (Passenger Side J/B) | (Scheme 15) & (Scheme 16) |
| Door Courtesy Switches | (Scheme 15) & (Scheme 16) |
| ECU-IG Fuse (Driver Side J/B) | (Scheme 12), (Scheme 15) & (Scheme 16) |
| Front Fog Lights | (Scheme 12) |
| Front Fog Light Relay (Passenger Side J/B) | (Scheme 12) |
| FR FOG Fuse (Passenger Side J/B) | (Scheme 12) |
| Glove Compartment Door Courtesy Switch | (Scheme 15) & (Scheme 16) |
| H-LP LH Fuse (Engine Room J/B) | (Scheme 12) |
| H-LP RH Fuse (Engine Room J/B) | (Scheme 12) |
| Headlights | (Scheme 12) & (Scheme 13) |
| Headlight Beam Control ECU | (Scheme 14) |
| Headlight Beam Level Control Actuator | (Scheme 14) |
| Headlight Beam Level Control ECU | (Scheme 14) |
| Headlight Dimmer Relay (Engine Room R/B) | (Scheme 12) |
| Interior Lights | (Scheme 15) & (Scheme 16) |
| MPX-B Fuse (Passenger Side J/B) | (Scheme 12), (Scheme 15) & (Scheme 16) |
| PWR-IG Fuse (Engine Room J/B) | (Scheme 14) |
| Rear Fog Lights | (Scheme 13) |
| Rear Fog Light Switch | (Scheme 12) |
| TAIL Fuse (Driver Side J/B) | (Scheme 12) |
| Taillights | (Scheme 13) |
| Taillight Control Relay (Driver Side J/B) | (Scheme 12) |
