CUSTOMIZE PARAMETERS
- CUSTOMIZING FUNCTION USING TECHSTREAM (REFERENCE) NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Tilt & Telescopic / Utility / Customize. Select a new setting by referring to the table below. TILT & TELESCOPIC Display Default Content Setting Auto away/Return function ON Turn the auto away/return function ON/OFF ON/OFF
TERMINALS OF ECU
1. MULTIPLEX TILT AND TELESCOPIC ECU
Scheme 61
| Terminal No. (Symbol) | Wiring Color | Terminal Description | Condition | Specified Condition |
|---|---|---|---|---|
| F116-2 (TEM+) - F109-11 (GND) | P - W-B | Telescopic motor output | Power switch on (IG) Steering column contracts | 11 to 14 V |
| Telescopic motor not operating | Below 1 V | |||
| F116-3 (VCE) - F116-5 (E2) | GR - Y | Telescopic sensor power source | Power switch on (IG) | 8 to 16 V |
| F116-4 (TES) - F116-5 (E2) | W - Y | Telescopic sensor signal | Telescopic motor operating | Pulse generation HI: 8 to 16 V LOW: Below 1 V |
| F116-5 (E2) - Body ground | Y - Body ground | Telescopic sensor ground | Always | Below 1 V |
| F116-6 (TEM-) - F109-11 (GND) | B - W-B | Telescopic motor output | Power switch on (IG) Steering column extends | 11 to 14 V |
| Telescopic motor not operating | Below 1 V | |||
| F109-1 (TIM-) - F109-11 (GND) | V - W-B | Tilt motor output | Power switch on (IG) Steering wheel tilts down | 11 to 14 V |
| Tilt motor not operating | Below 1 V | |||
| F109-2 (+B) - F109-11 (GND) | P - W-B | Motor power source | Always | 11 to 14 V |
| F109-3 (MSW) - F109-4 (VC) | GR - Y | Tilt and telescopic switch signal | Power switch on (IG) | 4.9 to 5.1 V |
| F109-5 (CANP) - F109-14 (CANN) | L - W | CAN communication | Power switch off | 54 to 69 ohms |
| F109-6 (VCI) - F109-17 (E1) | L - G | Tilt sensor power source | Power switch on (IG) | 8 to 16 V |
| F109-7 (TIS) - F109-17 (E1) | BR - G | Tilt sensor signal | Tilt motor operating | Pulse generation HI: 8 to 16 V LOW: Below 1 V |
| F109-8 (IG) - F109-11 (GND) | SB - W-B | IG signal/IG power source | Power switch on (IG) | 11 to 14 V |
| Power switch off | Below 1 V | |||
| F109-9 (ECUB) - F109-11 (GND) | GR - W-B | ECU power source | Always | 11 to 14 V |
| F109-10 (TIM+) - F109-11 (GND) | SB - W-B | Tilt motor output | Power switch on (IG) Steering wheel tilts up | 11 to 14 V |
| Tilt motor not operating | Below 1 V | |||
| F109-11 (GND) - Body ground | W-B - Body ground | ECU ground | Always | Below 1 V |
| F109-17 (E1) - Body ground | BR - Body ground | Tilt sensor ground | Always | Below 1 V |
FREEZE FRAME DATA
- FREEZE FRAME DATA NOTE: Freeze frame data values will vary depending on the measurement conditions, surroundings, or vehicle conditions. For this reason, there may be a problem even when the values are within specifications. Turn the power switch on (IG) and park the vehicle on level ground. Check the freeze frame data by using the Techstream. Turn the power switch off. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Check the freeze frame data. Enter the following menus: Body Electrical / Tilt & Telescopic / Trouble Codes. TILT & TELESCOPIC Tester Display Measurement Item/Range Normal Condition Diagnostic Note Tilt Position Current tilt position data/ Min.: 0 Max.: 65535 28672 to 36864 - Telesco Position Current telescopic position data/ Min.: 0 Max.: 65535 28672 to 36864 - Tilt Return Position Memorized tilt return position data/ Min.: 0 Max.: 65535 28672 to 36864 - Telesco Return Position Memorized telescopic return position data/ Min.: 0 Max.: 65535 28672 to 36864 - Tilt Up Switch Input state of tilt up by manual switch/ ON or OFF ON: Tilt up activated by manual switch OFF: Tilt up not activated by manual switch - Tilt Up SW(CAN) Input state of tilt up by manual switch/ ON or OFF - (This item is not related to this vehicle) Tilt Down Switch Input state of tilt down by manual switch/ ON or OFF ON: Tilt down activated by manual switch OFF: Tilt down not activated by manual switch - Tilt Down SW(CAN) Input state of tilt down by manual switch/ ON or OFF - (This item is not related to this vehicle) Telesco Short Switch Input state of telescopic short by manual switch/ ON or OFF ON: Telescopic short activated by manual switch OFF: Telescopic short not activated by manual switch - Telesco Short SW(CAN) Input state of telescopic short by manual switch/ ON or OFF - (This item is not related to this vehicle) Telesco Long Switch Input state of telescopic long by manual switch/ ON or OFF ON: Telescopic long activated by manual switch OFF: Telescopic long not activated by manual switch - Telesco Long SW(CAN) Input state of telescopic long by manual switch/ ON or OFF - (This item is not related to this vehicle) T&T Manual SW Data Voltage data of manual switch/ Min.: 0.00 V Max.: 4.99 V Neutral position: Below 0.2 V Tilt up: 1.67 to 2.13 V Tilt down: 0.54 to 0.74 V Telescopic contract: 1.08 to 1.40 V Telescopic extend: 2.22 to 2.77 V - Power Source Voltage Voltage data of power supply/ Min.: 0.00 V Max.: 19.99 V 11 to 14 V - Freeze Speed Info Vehicle speed data/ Min.: 0 km/h (0 mph) Max.: 255 km/h (158 mph) Actual vehicle speed - IG Switch (CAN) Communication state of power switch/ ON or OFF ON: Communication normal OFF: Communication interrupted - IG Switch Input state of power switch/ ON or OFF ON: Input signal normal OFF: Input signal interrupted - Receive from Meter Communication state of combination meter signal/ OK or Interpt OK: Communication normal Interpt: Communication interrupted - Receive from Seat ECU Communication state of position control ECU signal/ OK or Interpt OK: Communication normal Interpt: Communication interrupted - Receive from Combi Communication state of combination switch ECU signal/ OK or Interpt OK: Communication normal Interpt: Communication interrupted - J/B Communication state of main body ECU signal/ OK or Interpt OK: Communication normal Interpt: Communication interrupted - Handle Position Steering wheel position signal/ Away or Return Away: Steering wheel in away position Return: Steering wheel in return position (Except remote start) - The Number of DTCs Number of stored DTCs/ Min.: 0 Max.: 255 Actual number of stored DTCs
FAIL-SAFE CHART
HINT
If the power source voltage to the multiplex tilt and telescopic ECU returns to normal within 10 seconds during tilt or telescopic operation, the operation will be resumed. If it returns to normal after 10 seconds have elapsed, the operation restarts when a tilt or telescopic operation signal is again input to the multiplex tilt and telescopic ECU.
| DTC Code | Detection Item | Fail-safe Operation |
|---|---|---|
| B2603 | Tilt and Telescopic Switch Circuit Malfunction | The tilt and telescopic operation using the switch is suspended. |
| B2610 | Tilt Position Sensor or Tilt Motor Circuit Malfunction | The tilt operation is suspended. |
| B2611 | Telescopic Position Sensor or Telescopic Motor Circuit Malfunction | The telescopic operation is suspended. |
| B2620 | ECU Power Source Circuit Malfunction | The tilt and telescopic operation is suspended. |
| B2621 | Communication Interruption | The tilt and telescopic operation is limited depending on which ECU has lost communication. For details, refer to Fail-safe Function. |
| B2624 | Speed Signal Malfunction | The auto away/return function stops. |
FAIL-SAFE OPERATION
- FAIL-SAFE FUNCTION If a malfunction in the tilt position sensor signal or telescopic position sensor signal occurs while operating the power tilt or power telescopic function, the multiplex tilt and telescopic ECU stops the operation of the power tilt and power telescopic steering column system. If the power source voltage to the ECU drops below approximately 8 V while operating the power tilt or power telescopic function, the ECU stops the operation of the power tilt and power telescopic steering column system. If the ECU detects that the motor has locked during the operation of the power tilt or power telescopic function, the ECU stops the operation of the power tilt and power telescopic steering column system. If the communication of an ECU that is related to the power tilt and power telescopic steering column system is interrupted, the control of functions by the multiplex tilt and telescopic ECU is limited as shown in the table below. Tilt and Telescopic Operation Main Body ECU Communication Interruption Front Power Seat Switch (Position Control ECU) Communication Interruption All ECUs*1 Communication Interruption Manual o*2 o X*2 Auto away/return X o X Position memory (Memorization) X o X Position memory (Recall) X X X HINT: o: Operates X: Does not operate *1: All ECUs that are related to the power tilt and power telescopic steering column system *2: The operation is permitted if the power switch is on (IG) while the signal from the main body ECU is interrupted. The operation is prohibited if the power switch is off while the signal from the main body ECU is interrupted
