Hybrid / Battery Control (Service Information): Overview Lexus HS I

Engine Control Systems 53 illustrations ~3973 words

Scheme 235

Scheme 235: ON-VEHICLE INSPECTION
Scheme 235: ON-VEHICLE INSPECTION

Scheme 236

Scheme 236
Scheme 236

Scheme 237

Scheme 237
Scheme 237
  1. INSPECT FOR COOLANT LEAK (for Inverter) Remove the reserve tank cap. WARNING: To avoid the danger of being burned, do not remove the reserve tank cap while the coolant for the inverter is still hot. Install the radiator cap tester. Pump the radiator cap tester to 37 kPa (0.4 kgf/ cm 2 , 5.4 psi), and then check that the pressure does not drop. HINT: If the pressure drops, check the hoses, radiator, water pump, inverter with converter, and hybrid vehicle transaxle assembly for leaks. Reinstall the reserve tank cap.
  2. INSPECT COOLANT LEVEL IN RESERVE TANK (for Inverter) The coolant should be between the LOW and FULL lines when the coolant for the inverter is cold. HINT: If the coolant level is low, check for leaks and add TOYOTA Super Long Life Coolant (SLLC) or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology up to the FULL line.
  3. INSPECT COOLANT (for Inverter) Remove the reserve tank cap. WARNING: To avoid the danger of being burned, do not remove the reserve tank cap while the coolant for the inverter is still hot. Check for excessive deposits of rust or scale on and around the reserve tank cap and its opening. HINT: If excessively dirty, replace the coolant for the inverter. Reinstall the reserve tank cap.
  4. INSPECT INVERTER RESERVE TANK CAP (for Inverter) Inspect the reserve tank cap. TEXT IN ILLUSTRATION *1 O-ring *2 Rubber Packing If there are water stains or foreign matter on the O-ring, clean it with water and finger scouring. NOTE: Do not use any tools. Check that the O-ring is not deformed, cracked or damaged. Check that the O-ring is not swollen. Check the reserve tank cap operation. TEXT IN ILLUSTRATION *1 Reserve Tank Cap *2 Radiator Cap Tester *a 30° or more Apply coolant (for inverter) to the O-ring and rubber packing before using a radiator cap tester. Install the reserve tank cap to the radiator cap tester. Pump the cap tester several times, and check the maximum pressure. JUDGMENT CRITERION Standard value (for brand-new cap) 15 to 44 kPa (0.2 to 0.4 kgf/cm 2 , 2.2 to 6.3 psi) Minimum standard value (for used cap) 15 kPa (0.2 kgf/cm 2 , 2.2 psi) Pump speed 1 pump per second NOTE: When using the cap tester, tilt it 30° or more. HINT: If the maximum pressure is less than the minimum standard value, replace the reserve tank cap.

Scheme 238

Scheme 238: REPLACEMENT
Scheme 238: REPLACEMENT

Scheme 239

Scheme 239
Scheme 239
  1. REMOVE NO. 1 ENGINE UNDER COVER
  2. DRAIN COOLANT (for Inverter) NOTE: Do not reuse the drained coolant because it may contain foreign objects. Collect the drained coolant and measure its volume to establish a benchmark. When adding coolant, make sure to add more coolant than the measured amount. Remove the reserve tank cap. WARNING: To avoid the danger of being burned, do not remove the reserve tank cap while the coolant for the inverter is still hot. Using a hexagon wrench (10 mm), remove the drain plug indicated in the illustration and drain the coolant. WARNING: Use caution when handling coolant immediately after driving or in summer because it may be hot. Install the plug with a new gasket. Torque: 39 N*m (397 kgf*cm, 29 ft.*lbf)
  3. ADD COOLANT (for Inverter) NOTE: Do not reuse the drained coolant because it may contain foreign objects. If the vehicle is driven with air in the inverter cooling system, damage may occur and the following DTCs may be set. DTC Code Detection Item P0A01-725 Motor Electronics Coolant Temperature Sensor Circuit Range / Performance P0A01-726 Motor Electronics Coolant Temperature Sensor Circuit Range / Performance P0A78-284 Drive Motor "A" Inverter Performance P0A78-286 Drive Motor "A" Inverter Performance P0A7A-322 Generator Inverter Performance P0A7A-324 Generator Inverter Performance P0A93-346 Inverter Cooling System Performance P0A94-553 DC / DC Converter Performance P0A94-557 DC / DC Converter Performance P0AEE-276 Motor Inverter Temperature Sensor "A" Circuit Range / Performance P0AEE-277 Motor Inverter Temperature Sensor "A" Circuit Range / Performance P3221-314 Generator Inverter Temperature Sensor Circuit Range / Performance P3221-315 Generator Inverter Temperature Sensor Circuit Range / Performance P3226-562 DC/DC Boost Converter Temperature Sensor P3226-563 DC/DC Boost Converter Temperature Sensor Slowly pour coolant into the reserve tank until it reaches the FULL line. Coolant quantity 2.9 liters (3.1 US qts, 2.6 Imp. qts.) When using the Techstream: Connect the Techstream to the DLC3. Turn the power switch on (IG). Enter the following menus: Powertrain / Hybrid Control / Active Test / Activate the Water Pump. Keep the coolant at the FULL line in the reserve tank to compensate for the drop in coolant level when the air bleeds. Standard Air bleeding from the inverter cooling system is completed when the noise made by the water pump becomes smaller and the circulation of coolant in the reserve tank improves. HINT: Loud noise made by the water pump and poor circulation of coolant in the reserve tank indicates that there is air in the cooling system. When not using the Techstream: Turn the power switch on (READY).*1 Turn the power switch off and add coolant to the FULL line because the coolant level drops as the air bleeds.*2 NOTE: Be sure to turn the power switch off before adding SLLC. Do not work on the components in the engine compartment while the vehicle is in the READY-on state because the engine is in intermittent operation. Repeat steps *1 and *2 until air bleeding from the cooling system is completed. Standard Air bleeding from the inverter cooling system is completed when the noise made by the water pump becomes smaller and the circulation of coolant in the reserve tank improves. HINT: Loud noise made by the water pump and poor circulation of coolant in the reserve tank indicates that there is air in the cooling system. After the air is completely bled from the cooling system, tighten the reserve tank cap. Add coolant to the FULL line of the reserve tank.
  4. INSPECT FOR COOLANT LEAK (for Inverter) See step 1
  5. INSTALL NO. 1 ENGINE UNDER COVER

Scheme 240

Scheme 240: ILLUSTRATION
Scheme 240: ILLUSTRATION

Scheme 241

Scheme 241: ILLUSTRATION
Scheme 241: ILLUSTRATION

Scheme 242

Scheme 242: ILLUSTRATION
Scheme 242: ILLUSTRATION

Scheme 243

Scheme 243: REMOVAL
Scheme 243: REMOVAL

Scheme 244

Scheme 244
Scheme 244

Scheme 245

Scheme 245
Scheme 245

Scheme 246

Scheme 246
Scheme 246
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE COWL TOP PANEL OUTER SUB-ASSEMBLY HINT: Refer to «REMOVAL»(ref-398212-S42415717782011051600000) .
  5. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 29»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  6. REMOVE AIR CLEANER CAP SUB-ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398228-S21230789182011051600000)
  7. REMOVE AIR CLEANER CASE . Refer to «REMOVAL - Step 45»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  8. REMOVE HYBRID VEHICLE CONTROL ECU Raise the 2 levers while pushing the locks on the 2 levers, and disconnect the 2 connectors. Remove the 2 bolts. Disconnect the clamp and remove the hybrid vehicle control ECU. Remove the 4 screws and 2 ECM brackets.

Scheme 247

Scheme 247: INSTALLATION
Scheme 247: INSTALLATION
  1. INSTALL HYBRID VEHICLE CONTROL ECU Install the 2 ECM brackets with the 4 screws. Torque: 3.0 N*m (31 kgf*cm, 27 in.*lbf) Connect the clamp to the ECM bracket. Install the hybrid vehicle control ECU with the 2 bolts. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) Connect the 2 connectors. NOTE: Before connecting the connectors, make sure that dirt, water or other foreign matter is not present on the connecting parts of the connectors. The lever is securely engaged. The connector does not come out when its body is pulled.
  2. INSTALL AIR CLEANER CASE . Refer to «INSTALLATION - Step 48»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  3. INSTALL AIR CLEANER CAP SUB-ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-398228-S30370820282011051600000)
  4. INSTALL NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 95»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  5. INSTALL COWL TOP PANEL OUTER SUB-ASSEMBLY HINT: Refer to «INSTALLATION»(ref-398212-S22865702402011051600000) .
  6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  7. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  8. PERFORM INITIALIZATION HINT: Refer to «INITIALIZATION»(ref-398089-S31047356082011051600000) .

Scheme 248

Scheme 248: ILLUSTRATION
Scheme 248: ILLUSTRATION

Scheme 249

Scheme 249: ILLUSTRATION
Scheme 249: ILLUSTRATION

Scheme 250

Scheme 250: ILLUSTRATION
Scheme 250: ILLUSTRATION

Scheme 251

Scheme 251: ILLUSTRATION
Scheme 251: ILLUSTRATION

Scheme 252

Scheme 252: ILLUSTRATION
Scheme 252: ILLUSTRATION

Scheme 253

Scheme 253: ILLUSTRATION
Scheme 253: ILLUSTRATION

Scheme 254

Scheme 254: REMOVAL
Scheme 254: REMOVAL

Scheme 255

Scheme 255
Scheme 255

Scheme 256

Scheme 256
Scheme 256

Scheme 257

Scheme 257
Scheme 257

Scheme 258

Scheme 258
Scheme 258

Scheme 259

Scheme 259
Scheme 259
  1. PRECAUTION HINT: Refer to «PRECAUTION»(ref-398089-S41696268642011051600000) .
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE BATTERY SERVICE HOLE COVER See step 4
  5. REMOVE SERVICE PLUG GRIP See step 5
  6. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 28»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  7. REMOVE CONNECTOR COVER ASSEMBLY See step 9
  8. CHECK TERMINAL VOLTAGE See step 10
  9. INSTALL CONNECTOR COVER ASSEMBLY See step 7
  10. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 96»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  11. REMOVE REAR SEATBACK ASSEMBLY HINT: Refer to «REMOVAL»(/lexus/hs/i-2009-2012/remont/seats/#seat-service-information) .
  12. REMOVE TOOL WITH STAY BOX SUB-ASSEMBLY
  13. REMOVE NO. 1 LUGGAGE COMPARTMENT LAMP ASSEMBLY
  14. REMOVE FRONT LUGGAGE COMPARTMENT TRIM COVER . Refer to «REMOVAL - Step 5»(ref-398250-S07311317782011051600000)
  15. REMOVE NO. 4 HYBRID BATTERY INTAKE DUCT See step 3
  16. REMOVE NO. 3 HYBRID BATTERY EXHAUST DUCT Remove the 2 clips and No. 3 hybrid battery exhaust duct.
  17. REMOVE NO. 4 HYBRID BATTERY SHIELD PANEL See step 8
  18. REMOVE NO. 1 HYBRID BATTERY SHIELD SUB-ASSEMBLY See step 17
  19. REMOVE NO. 5 HYBRID BATTERY INTAKE DUCT See step 18
  20. REMOVE INVERTER TERMINAL WARNING: Wear insulated gloves. Remove the bolt, nut and inverter terminal.
  21. REMOVE HYBRID VEHICLE CONVERTER WARNING: Wear insulated gloves. NOTE: Insulate the removed terminals with insulating tape. Disconnect the 2 connectors from the hybrid battery junction block assembly. Remove the nut, disengage the 4 clamps and disconnect the wire harness from the hybrid vehicle converter. Disconnect the 3 connectors from the hybrid battery junction block assembly. Disconnect the connector from the hybrid vehicle converter. Remove the 5 nuts and hybrid vehicle converter.

Scheme 260

Scheme 260: INSTALLATION
Scheme 260: INSTALLATION
  1. INSTALL HYBRID VEHICLE CONVERTER WARNING: Wear insulated gloves. Install the hybrid vehicle converter with the 5 nuts. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) Connect the connector to the hybrid vehicle converter. NOTE: Make sure that the connector is fully engaged. Connect the 3 connectors to the hybrid battery junction block assembly. NOTE: Make sure that the connectors are fully engaged. Connect the wire harness to the hybrid vehicle converter with the nut and 4 clamps. TEXT IN ILLUSTRATION *1 Red Tape Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) NOTE: Make sure that the connectors are fully engaged. Be sure to connect the connector to each correct terminal as shown in the illustration.
  2. INSTALL INVERTER TERMINAL WARNING: Wear insulated gloves. Install the bolt, nut and inverter terminal. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf)
  3. INSTALL NO. 5 HYBRID BATTERY INTAKE DUCT See step 4
  4. CHECK HIGH VOLTAGE CABLE CONNECTION CONDITION See step 5
  5. INSTALL NO. 1 HYBRID BATTERY SHIELD SUB-ASSEMBLY See step 6
  6. INSTALL NO. 4 HYBRID BATTERY SHIELD PANEL See step 4
  7. INSTALL NO. 3 HYBRID BATTERY EXHAUST DUCT Install the No. 3 hybrid battery exhaust duct with the 2 clips. NOTE: Ensure that the duct is installed securely.
  8. INSTALL NO. 4 HYBRID BATTERY INTAKE DUCT See step 3
  9. INSTALL FRONT LUGGAGE COMPARTMENT TRIM COVER . Refer to «INSTALLATION - Step 6»(ref-398250-S40959276962011051600000)
  10. INSTALL NO. 1 LUGGAGE COMPARTMENT LAMP ASSEMBLY
  11. INSTALL TOOL WITH STAY BOX SUB-ASSEMBLY
  12. INSTALL REAR SEATBACK ASSEMBLY HINT: Refer to «INSTALLATION»(/lexus/hs/i-2009-2012/remont/seats/#seat-service-information) .
  13. INSTALL SERVICE PLUG GRIP See step 1
  14. INSTALL BATTERY SERVICE HOLE COVER See step 2
  15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  16. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)

Scheme 261

Scheme 261: ILLUSTRATION
Scheme 261: ILLUSTRATION

Scheme 262

Scheme 262: ILLUSTRATION
Scheme 262: ILLUSTRATION

Scheme 263

Scheme 263: REMOVAL
Scheme 263: REMOVAL

Scheme 264

Scheme 264
Scheme 264

Scheme 265

Scheme 265
Scheme 265

Scheme 266

Scheme 266
Scheme 266

Scheme 267

Scheme 267
Scheme 267

Scheme 268

Scheme 268
Scheme 268

Scheme 269

Scheme 269
Scheme 269

Scheme 270

Scheme 270
Scheme 270

Scheme 271

Scheme 271
Scheme 271

Scheme 272

Scheme 272
Scheme 272

Scheme 273

Scheme 273
Scheme 273

Scheme 274

Scheme 274
Scheme 274

Scheme 275

Scheme 275
Scheme 275

Scheme 276

Scheme 276
Scheme 276

Scheme 277

Scheme 277
Scheme 277

Scheme 278

Scheme 278
Scheme 278
  1. PRECAUTION HINT: Refer to «PRECAUTION»(ref-398089-S41696268642011051600000) .
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE BATTERY SERVICE HOLE COVER See step 4
  5. REMOVE SERVICE PLUG GRIP See step 5
  6. REMOVE NO. 1 ENGINE UNDER COVER
  7. DRAIN COOLANT (for Inverter) See step 2
  8. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 28»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  9. REMOVE CONNECTOR COVER ASSEMBLY WARNING: Do not touch the high voltage connectors and terminals for 10 minutes after the service plug grip is removed. Wear insulated gloves. NOTE: Do not start the hybrid system with the service plug grip removed because it may cause a malfunction. Remove the 2 bolts and connector cover assembly. NOTE: Make sure to pull the inverter cover straight up, as a connector is connected to the bottom of the cover.
  10. CHECK TERMINAL VOLTAGE WARNING: Wear insulated gloves. NOTE: Do not allow any foreign objects or water to enter the inverter with converter assembly. Using a voltmeter, measure the voltage between the terminals of the 2 phase connectors (N-P). Standard voltage 0 V HINT: Use a measuring range of DC 750 V or more on the voltmeter.
  11. TEMPORARILY INSTALL CONNECTOR COVER ASSEMBLY Temporarily install the connector cover with the bolt to prevent any foreign objects or water from entering the inverter with converter assembly.
  12. REMOVE NO. 5 INVERTER BRACKET Remove the bolt and disconnect the earth wire. Remove the 2 bolts and No. 5 inverter bracket.
  13. SEPARATE GENERATOR CABLE WARNING: Wear insulated gloves. NOTE: Insulate the removed terminals with insulating tape. Do not allow any foreign objects or water to enter the inverter with converter assembly. Remove the 2 bolts (A). NOTE: Removing the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. While loosening the bolt (B), disconnect the motor cable. NOTE: Removing the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. Cover the hole where the cable was connected with tape or equivalent (non-residue type) to prevent entry of foreign matter. Disconnect the wire harness clamp.
  14. SEPARATE MOTOR CABLE WARNING: Wear insulated gloves. NOTE: Insulate the removed terminals with insulating tape. Do not allow any foreign objects or water to enter the inverter with converter assembly. Remove the 2 bolts (A). NOTE: Removing the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. While loosening the bolt (B), disconnect the generator cable. NOTE: Removing the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. Cover the hole where the cable was connected with tape or equivalent (non-residue type) to prevent entry of foreign matter. Disconnect the wire harness clamp.
  15. REMOVE INVERTER RESERVE TANK ASSEMBLY Disconnect the water hose from the inverter reserve tank assembly. Remove the 2 bolts and inverter reserve tank assembly. Disconnect the water hose and remove the inverter reserve tank assembly.
  16. DISCONNECT WATER HOSE Remove the clip, and disconnect the water hose. NOTE: Do not damage the water hose protector when removing the clip. Disconnect the coolant hose from the inverter with converter assembly. Put a piece of cloth in the pipe and in the disconnected hose or cover the pipe and hose with plastic bags as shown in the illustration, in order to prevent coolant from spilling near the inverter with converter assembly.
  17. REMOVE CONNECTOR COVER ASSEMBLY WARNING: Do not touch the high voltage connectors and terminals for 10 minutes after the service plug grip is removed. Wear insulated gloves. NOTE: Do not start the hybrid system with the service plug grip removed because it may cause a malfunction. Remove the bolt and connector cover assembly. NOTE: Make sure to pull the inverter cover straight up, as a connector is connected to the bottom of the cover.
  18. SEPARATE AIR CONDITIONING HARNESS ASSEMBLY WARNING: Wear insulated gloves. NOTE: Insulate the removed terminals with insulating tape. Do not allow any foreign objects or water to enter the inverter with converter assembly. Disconnect the air conditioning harness assembly. Disengage the wire harness clamp.
  19. SEPARATE FRAME WIRE WARNING: Wear insulated gloves. NOTE: Insulate the removed terminals with insulating tape. Do not allow any foreign objects or water to enter the inverter with converter assembly. Remove the bolt. Disconnect the wire harness clamp and frame wire.
  20. TEMPORARILY INSTALL CONNECTOR COVER ASSEMBLY Temporarily install the connector cover with the bolt to prevent any foreign objects or water from entering the inverter with converter assembly.
  21. DISCONNECT LOW VOLTAGE CONNECTOR NOTE: Insulate the removed terminals with insulating tape. Do not allow any foreign objects or water to enter the inverter with converter assembly. Raise the lock lever and disconnect the low voltage connector. Disconnect the low voltage connector from the inverter with converter assembly.
  22. REMOVE INVERTER WITH CONVERTER ASSEMBLY WARNING: Wear insulated gloves. Remove the 2 bolts, nut and inverter with converter assembly. NOTE: Since the inverter with converter assembly is very heavy, 2 people are needed to remove the inverter with converter assembly. When removing the inverter with converter assembly, do not damage the parts around it. To prevent damage, do not hold the inverter with converter assembly by the connectors. To prevent damage due to static electricity, do not touch the terminals of the disconnected connectors.
  23. REMOVE HIGH VOLTAGE FUSE WARNING: Wear insulated gloves. HINT: Perform this procedure only when replacement of the high voltage fuse is necessary. Remove the bolt and connector cover assembly. NOTE: Make sure to pull the inverter cover straight up, as a connector is connected to the bottom of the cover. Remove the 2 nuts and high voltage fuse. Temporarily install the connector cover with the bolt to prevent any foreign objects or water from entering the inverter with converter assembly.

Scheme 279

Scheme 279: INSTALLATION
Scheme 279: INSTALLATION

Scheme 280

Scheme 280
Scheme 280

Scheme 281

Scheme 281
Scheme 281

Scheme 282

Scheme 282
Scheme 282

Scheme 283

Scheme 283
Scheme 283

Scheme 284

Scheme 284
Scheme 284

Scheme 285

Scheme 285
Scheme 285
  1. INSTALL HIGH VOLTAGE FUSE WARNING: Wear insulated gloves. HINT: Perform this procedure only when replacement of the high voltage fuse is necessary. Remove the bolt and connector cover assembly. NOTE: Make sure to pull the inverter cover straight up, as a connector is connected to the bottom of the cover. Install the high voltage fuse with 2 new nuts. Torque: 4.0 N*m (41 kgf*cm, 35 in.*lbf) NOTE: Be sure to use a torque wrench to tighten the nuts. Temporarily install the connector cover with the bolt to prevent any foreign objects or water from entering the inverter with converter assembly.
  2. INSTALL INVERTER WITH CONVERTER ASSEMBLY WARNING: Wear insulated gloves. Temporarily install the inverter with converter assembly with the 2 bolts and nut. NOTE: Since the inverter with converter assembly is very heavy, 2 people are needed to install the inverter with converter assembly. When installing the inverter with converter assembly, do not damage the parts around it. To prevent damage, do not hold the inverter with converter assembly by the connectors. To prevent damage due to static electricity, do not touch the terminals of the disconnected connectors. Fully tighten the 2 bolts and nut in the order shown in the illustration. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
  3. CONNECT LOW VOLTAGE CONNECTOR NOTE: Make sure that the connectors are fully engaged. Make sure that the connector does not come out when its body is pulled. Do not allow any foreign objects or water to enter the inverter with converter assembly. Connect the low voltage connectors and lock the connector with the lock lever.
  4. REMOVE CONNECTOR COVER ASSEMBLY See step 17
  5. CONNECT FRAME WIRE WARNING: Wear insulated gloves. NOTE: Make sure that the connectors are fully engaged. Make sure that the connector does not come out when its body is pulled. Do not allow any foreign objects or water to enter the inverter with converter assembly. Connect the frame wire and wire harness clamp to the inverter with converter assembly. Fix the frame wire to the inverter with converter assembly with the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
  6. CONNECT AIR CONDITIONING HARNESS ASSEMBLY WARNING: Wear insulated gloves. NOTE: Make sure that the connectors are fully engaged. Make sure that the connector does not come out when its body is pulled. Do not allow any foreign objects or water to enter the inverter with converter assembly. Connect the air conditioning harness assembly to the inverter with converter assembly. Engage the wire harness clamp.
  7. INSTALL CONNECTOR COVER ASSEMBLY WARNING: Wear insulated gloves. NOTE: Make sure that the interlock is fully engaged. Do not allow any foreign objects or water to enter the inverter with converter assembly. Install the connector cover assembly with the 2 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
  8. CONNECT WATER HOSE Connect the water hose with the clip. TEXT IN ILLUSTRATION *1 Front Side *2 Matchmark NOTE: Do not damage the water hose protector when installing the clip. Make sure to align the clip and matchmarks so that they face the right side of the vehicle.
  9. INSTALL INVERTER RESERVE TANK ASSEMBLY Connect the water hose with inverter reserve tank assembly. TEXT IN ILLUSTRATION *1 Upper Side NOTE: Align the hose clamp as shown in the illustration. Install the inverter reserve tank assembly with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the water hose to the inverter reserve tank assembly. TEXT IN ILLUSTRATION *1 Upper Side *2 Matchmark NOTE: Align the hose clamps and the matchmarks as shown in the illustration.
  10. CONNECT MOTOR CABLE WARNING: Wear insulated gloves. NOTE: Do not allow any foreign objects or water to enter the inverter with converter assembly. Connect the motor cable. Tighten the bolt (B) and insert the motor cable into the inverter with converter assembly. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Tightening the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. Finish installing the motor cable to the inverter with converter assembly with the 2 bolts (A). Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Tightening the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. Connect the wire harness clamp.
  11. CONNECT GENERATOR CABLE WARNING: Wear insulated gloves. Connect the generator cable. Tighten the bolt (B) and insert the generator cable into the inverter with converter assembly. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Tightening the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. Finish installing the generator cable to the inverter with converter assembly with the 2 bolts (A). Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Tightening the bolts (A) and (B) in the wrong order may cause the cable or the inverter with converter to break. Connect the wire harness clamp.
  12. INSTALL NO. 5 INVERTER BRACKET Temporarily install the No. 5 inverter bracket with the 2 bolts. Fully tighten the 2 bolts in the order shown in the illustration. Torque: 16 N*m (163 kgf*cm, 12 ft.*lbf) Connect the earth wire with the bolt. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf)
  13. INSTALL SERVICE PLUG GRIP See step 1
  14. INSTALL BATTERY SERVICE HOLE COVER
  15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  16. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  17. ADD COOLANT (for Inverter) See step 3
  18. INSPECT FOR COOLANT LEAK (for Inverter) See step 1
  19. INSTALL NO. 1 ENGINE UNDER COVER
  20. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 96»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)

Scheme 286

Scheme 286: ILLUSTRATION
Scheme 286: ILLUSTRATION

Scheme 287

Scheme 287: REMOVAL
Scheme 287: REMOVAL
  1. REMOVE HYBRID BATTERY JUNCTION BLOCK ASSEMBLY HINT: Refer to «REMOVAL»(ref-398232-S25270654792011051600000) .
  2. REMOVE BATTERY SMART UNIT WARNING: Wear insulated gloves. Disconnect the 3 connectors. Remove the nut and battery smart unit.
