MONITOR STRATEGY
| Related DTC | P0401: EGR valve high flow rate / low flow rate |
| Required sensors/Components (Main) | EGR valve assembly, manifold absolute pressure sensor |
| Required sensors/Components (Related) | Engine coolant temperature sensor, vehicle speed sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 3 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs are not present | None |
| Time after engine started | 3 seconds or more |
| Time after engine fuel cut | 1 second or more |
| Engine speed | 1050 to 1800 rpm |
| Vehicle speed | 20 km/h (12.5 mph) or more |
| Engine speed change (per 65 msec.) | 40 to 10 rpm |
| Time after engine load becomes stable (Brake, lock-up) | More than 1 sec |
| Shift position | Except P or N |
| Engine coolant temperature | 75°C (167°F) or higher |
| Battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
TYPICAL MALFUNCTION THRESHOLDS
| Manifold pressure change | Less than 1.8125 kPa (14 mmHg) |
| Engine speed | 1400 rpm |
Scheme 182
Scheme 182: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) .
- Turn the engine switch off and wait for 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
- Drive the vehicle at 60 km/h (37 mph) for 5 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 30 seconds or more [D].
- Drive the vehicle at 60 km/h (37 mph) and shift the transmission to 2nd gear [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Perform fuel cut operation for 5 seconds or more with the accelerator pedal fully released [F]. HINT: When "Idle Fuel Cut" in the Data List is ON, fuel cut is operating.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Exhaust Gas Recirculation/VVT / Current [G].
- Check that the Exhaust Gas Recirculation/VVT / Current monitor is Complete. HINT: If the monitor is Incomplete, perform the driving pattern again.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Exhaust Gas Recirculation/VVT / Details / EGR FLOW INSUFFICIENCY / Details.
- Check the test Details (EGR FLOW INSUFFICIENCY). HINT: Make sure that the values are between MIN and MAX.
- If the monitor is still Incomplete, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0401.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the DTC judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, drive the vehicle again at 60 km/h (37 mph) and shift the transmission to 2nd gear, perform fuel cut operation for 5 seconds or more with the accelerator pedal fully released, and then check the DTC judgment result.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 183
Scheme 183: WIRING DIAGRAM
| Related DTCs | P0403: Exhaust gas recirculation control circuit range check |
| Required Sensors/Components (Main) | EGR valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Engine | Running |
| Battery voltage | 10.5 V or higher |
| Starter | OFF |
| One of the following conditions is met | Condition 1, 2, 3 or 4 |
| 1. Both conditions are met | Condition A and B |
| A. Motor phase 1 output terminal voltage | Low |
| B. Either condition is met | |
| Motor | Driving |
| Motor phase 1 | Not operating |
| 2. Both conditions are met | Condition A and B |
| A. Motor phase 2 output terminal voltage | Low |
| B. Either condition is met | |
| Motor | Driving |
| Motor phase 2 | Not operating |
| 3. Both conditions are met | Condition A and B |
| A. Motor phase 3 output terminal voltage | Low |
| B. Either condition is met | |
| Motor | Driving |
| Motor phase 3 | Not operating |
| 4. Both conditions are met | Condition A and B |
| A. Motor phase 4 output terminal voltage | Low |
| B. Either condition is met | |
| Motor | Driving |
| Motor phase 4 | Not operating |
Scheme 184
Scheme 184: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) .
- Start the engine and warm it up [B].
- Drive the vehicle at 20 km/h (12 mph) or more for 10 minutes [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0403.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0412: Secondary air injection system air switching valve circuit range check (Bank 1) |
| Required Sensors/Components (Main) | Air injection control driver |
| Required Sensors/Components (Related) | Air switching valve assembly |
| Frequency of Operation | Once per drive cycle |
| Duration | 3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Secondary air injection pump | Operating |
| Secondary air injection switching valve | Operating |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Monitor runs whenever following DTCs not present | None |
| Secondary air injection pump | Not operating |
| Secondary air injection switching valve | Not operating |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Diagnostic signal duty ratio from air injection control driver | 31% or more, and 48% or less |
COMPONENT OPERATING RANGE
| Diagnostic signal duty ratio from air injection control driver | 70% or more, and 90% or less when secondary air injection system operating. 0% when secondary air injection system not operating. |
CONFIRMATION DRIVING PATTERN
Note. This Air Injection Check only allows technicians to operate the secondary air injection system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While secondary air injection system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing Air Injection Check repeatedly may cause damage to the secondary air injection system. If it is necessary to repeat the check, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the engine switch turned on (IG) or the engine running. Turn the engine switch off when the Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the engine switch off.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG).
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) .
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Air injection check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing ENTER (Next).
- Perform the following to confirm the secondary air injection system pending codes: Press ENTER (Exit).
- Check for pending DTCs. OK No pending DTC is output.
- After "Air injection check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0412.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the engine switch off.
Scheme 185
Scheme 185: WIRING DIAGRAM
PROCEDURE
- INSPECT AIR SWITCHING VALVE ASSEMBLY Inspect the air switching valve assembly for bank 1. Refer to «INSPECTION - Step 1»(ref-524251-S02533730292013012800000) . NG --> See step 4 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR SWITCHING VALVE - BODY GROUND) Disconnect the air switching valve connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C35-4 (GND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR SWITCHING VALVE - AIR INJECTION CONTROL DRIVER) Disconnect the air switching valve connector. Disconnect the air injection control driver connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C35-5 (+B) - A13-6 (VV) Always Below 1 ohms C35-5 (+B) or A13-6 (VV) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
- REPLACE AIR SWITCHING VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06527927302013012800000)
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-524251-S27959668022013012800000)
| Related DTCs | P0416: Secondary air injection system air switching valve circuit range check low voltage (Bank 2) P0417: Secondary air injection system air switching valve circuit range check high voltage (Bank 2) |
| Required Sensors/Components | Air injection VSV relay (AI-VSV) |
| Required Sensors/Components | ECM |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Current air switching valve relay | ON |
| Last air switching valve relay | ON |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Monitor runs whenever following DTCs not present | None |
| Current air switching valve relay | OFF |
| Last air switching valve relay | OFF |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Air switching valve relay output terminal voltage | Low |
| Air switching valve relay output terminal voltage | High |
Note. This Air Injection Check only allows technicians to operate the secondary air injection system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While secondary air injection system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing Air Injection Check repeatedly may cause damage to the secondary air injection system. If it is necessary to repeat the check, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the engine switch turned on (IG) or the engine running. Turn the engine switch off when the Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the engine switch off.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG).
- Turn the Techstream on.
- Clear DTCs (if stored). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) .
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Air injection check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing ENTER (Next).
- Perform the following to confirm the secondary air injection system pending codes: Press ENTER (Exit).
- Check for pending DTCs. OK No pending DTC is output.
- After "Air injection check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0416 or P0417.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the engine switch off.
Scheme 186
Scheme 186: WIRING DIAGRAM
| Related DTCs | P0418: Secondary air injection system air pump circuit range check (Bank 1) |
| Required Sensors/Components (Main) | Air injection control driver |
| Required Sensors/Components (Related) | Air pump assembly |
| Frequency of Operation | Once per drive cycle |
| Duration | 3 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Secondary air injection pump | Operating |
| Secondary air injection switching valve | Operating |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Monitor runs whenever following DTCs not present | None |
| Secondary air injection pump | Not operating |
| Secondary air injection switching valve | Not operating |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Diagnostic signal duty ratio from air injection control driver | 11% or more, and 29% or less |
| Diagnostic signal duty ratio from air injection control driver | 70% or more, and 90% or less when secondary air injection system operating. 0% when secondary air injection system not operating. |
Note. This Air Injection Check only allows technicians to operate the secondary air injection system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While secondary air injection system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing Air Injection Check repeatedly may cause damage to the secondary air injection system. If it is necessary to repeat the check, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the engine switch turned on (IG) or the engine running. Turn the engine switch off when the Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the engine switch off.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG).
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) .
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Air injection check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing ENTER (Next).
- Perform the following to confirm the secondary air injection system pending codes: Press ENTER (Exit).
- Check for pending DTCs. OK No pending DTC is output.
- After "Air injection check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0418.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the engine switch off.
- CHECK HARNESS AND CONNECTOR (AIR PUMP - AIR INJECTION CONTROL DRIVER, BATTERY AND BODY GROUND) Disconnect the air pump connector. Disconnect the air injection control driver connector. Disconnect the cable from the positive (+) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A15-2 - A14-2 (VP) Always Below 1 ohms A15-4 - Body ground Always Below 1 ohms A14-1 (BATT) - Positive (+) battery terminal Always Below 1 ohms A15-2 or A14-2 (VP) - Body ground Always 10 kohms or higher A14-1 (BATT) or Positive (+) battery terminal - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK AIR PUMP ASSEMBLY Inspect the air pump assembly. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-524251-S00337661632013012800000) . NG --> See step 3 OK --> See step 6
- REPLACE AIR PUMP ASSEMBLY Replace the air pump assembly. Refer to «REMOVAL»(ref-524251-S31616325492013012800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0418) Start the engine and warm it up. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear DTCs (if stored). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Enter the following menus: Powertrain / Engine and ECT / Utility / Air injection check / Automatic Mode. Start the engine after the Techstream initialization is finished. Perform the System Check operation by pressing Next. After operating the secondary air injection system, perform the following to confirm the secondary air injection system pending codes: Press the Exit button. Check pending DTCs. OK No pending DTC is output. Turn the engine switch off. NOTE: When performing the Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the engine switch turned on (IG) or the engine running. Turn the engine switch off when the Air Injection Check operation finishes. NG --> See step 5 OK --> END
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-524251-S27959668022013012800000)
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-524251-S27959668022013012800000)
| Related DTCs | P0420: Catalyst Deterioration (for Bank 1) P0430: Catalyst Deterioration (for Bank 2) |
| Required Sensors/Components (Main) | Air fuel ratio sensor, heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor, mass air flow meter, crankshaft position sensor and engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | About 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0011, P0021 (VVT system - Advance) P0012, P0022 (VVT system - Retard) P0013, P0023 (Exhaust VVT oil control valve) P0014, P0024 (Exhaust VVT system - Advance) P0015, P0025 (Exhaust VVT system - Retard) P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Rear oxygen sensor heater) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0136, P0137, P0138, P0139, P0156, P0157, P0158, P0159, P0607 (Rear oxygen sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301 - P0308 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351 - P0358 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0401 (EGR system) P0412, P0418, P1613 (Secondary air injection system control) P0416, P0417, P2440, P2441, P2442, P2443, P2444, P2445, P2447 (Secondary air injection system) P0500 (Vehicle speed sensor) P1340 (Camshaft position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Front oxygen/Air fuel ratio sensor) |
| Battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Idling | OFF |
| Engine speed | Less than 3200 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 75% |
| All of following conditions (a), (b) and (c) met | |
| (a) Mass air flow | 7.5 to 75 g/sec. |
| (b) Estimated front catalyst temperature | 650 to 820°C (1202 to 1508°F) |
| (c) Estimated rear catalyst temperature | 400 to 700°C (752 to 1292°F) |
| Transmission gear | 4th or higher |
The estimated catalyst temperature can be read through the Data List using the Techstream.
| Oxygen Storage Capacity (OSC) of Three-way Catalytic Converter (TWC) | Less than 0.12 g |
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.
Scheme 187
Scheme 187: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG).
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that Catalyst Efficiency / Current is Incomplete.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at approximately 60 km/h (38 mph) for 10 minutes or more [B]. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor does not change to Complete, and no pending DTCs are stored, perform the following procedure.
- Drive the vehicle at a speed between 75 and 100 km/h (47 and 63 mph) for 10 minutes or more [D]. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [E].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Check if any DTCs (pending DTCs) are stored.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 OR P0430) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0420 or P0430 is output A P0420 or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume. Perform the Control the Injection Volume operation with the engine idling. Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of - 12.0% to +12.0%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) +12% Rich Below 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) -12% Lean Higher than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen) +12% Rich Higher than 0.55 V O2S B1S2 or O2S B2S2 (Heated oxygen) -12% Lean Below 0.4 V Result Status of AFS Voltage B1S1 or AFS Voltage B2S1 Status of O2S B1S2 or O2S B2S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leaks from exhaust system EGR valve assembly A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the air fuel ratio sensor and heated oxygen sensor alternate correctly. Refer to "Data List / Active Test" [AFS Voltage B1S1, AFS Voltage B2S1, O2S B1S2 and O2S B2S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-524126-S20424571482013012800000) . B --> See step 11 C --> See step 7 D --> See step 8 A: Go to next step
- CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 6 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 16 OK: Go to next step
- CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) According to the DTCs output above (Check for Any Other DTCs Output), proceed to the next step referring to the table below. RESULT Result Proceed to P0420 is output A P0430 is output B P0420 and P0430 are output A and B B --> See step 14 A --> See step 15
- CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 12
- CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO NG --> See step 10
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 17 OK --> CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-524262-S00247626492013012800000)
- REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-524262-S09514782142013012800000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE EXHAUST MANIFOLD ASSEMBLY RH AND FRONT EXHAUST PIPE ASSEMBLY (TWC: FRONT CATALYST AND REAR CATALYST). Refer to «REMOVAL»(ref-524275-S11014308002013012800000)
- REPLACE EXHAUST MANIFOLD ASSEMBLY LH AND FRONT NO. 2 EXHAUST PIPE ASSEMBLY (TWC: FRONT CATALYST AND REAR CATALYST). Refer to «REMOVAL»(ref-524275-S11014308002013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 2 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0452, P0453 (EVAP system) |
| EVAP key-off monitor runs when all of following conditions met | |
| Atmospheric pressure | 70 to 111 kPa-a (525 to 833 mmHg-a) |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Engine switch | Off |
| Time after key off | 5, 7 or 9.5 hours |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key off | Conditions 1 and 2 |
| 1. Duration that vehicle driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
"Saturated" indicates that the EVAP pressure change is less than 0.286 kPa-g (2.14 mmHg-g) in 60 seconds.
| One of following conditions met | |
| EVAP pressure just after reference pressure measurement started | Higher than -0.25 kPa-g (-1.88 mmHg-g) |
| Reference pressure | Below -4.85 kPa-g (-36.4 mmHg-g) |
| Reference pressure | 1.057 kPa-g (-7.93 mmHg-g) or higher |
| Reference pressure | Not saturated within 360 seconds |
| Reference pressure difference between first and second measurement | 0.9 kPa-g (6.75 mmHg-g) or more |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 23 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P043E, P043F, P2401, P2402 or P2419.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine and wait 15 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 23 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG)
- Turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO P0441) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0441 is output A DTC P0441 and other DTCs are output B HINT: If any DTCs other than P0441 are output, perform troubleshooting for those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 5 NG --> See step 3
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 6 OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-524264-S01445730802013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-524264-S01445730802013012800000)
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P0452 and P0453 15 seconds: P0451 |
| MIL Operation | Immediate: P0452 and P0453 2 driving cycles: P0451 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0452, 0453 (EVAP system) |
| Atmospheric pressure (absolute pressure) | 70 to 111 kPa-a (525 to 833 mmHg-a) |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 4.4 to 40°C (40 to 104°F) |
| Either of following conditions met | A or B |
| A. Engine condition | Running |
| B. Time after key off | 5, 7 or 9.5 hours |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Either of following conditions met | (a) or (b) |
| (a) Engine switch | On (IG) |
| (b) ECM | Wake up by soak timer |
| Frequency that EVAP pressure changes 0.3 kPa-g (2.25 mmHg-g) or more | 10 times or more in 10 seconds |
P0451: CANISTER PRESSURE SENSOR NOISE
| EVAP pressure | Below 42.1 kPa-a (315.9 mmHg-a) |
P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE
| EVAP pressure | Higher than 123.8 kPa-a (928.4 mmHg-a) |
P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 23 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air.
- Check that the intake air temperature is between 4.4°C and 40°C (40 and 104°F).
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0451, P0452 or P0453.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 15 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0452, 0453 (EVAP system) |
| Atmospheric pressure | 70 to 111 kPa-a (525 to 833 mmHg-a) |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 4 km/h (2.5 mph) |
| Engine switch | Off |
| Time after key off | 5, 7 or 9.5 hours |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key off | Conditions 1 and 2 |
| 1. Duration that vehicle driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure when vacuum introduction complete | Higher than reference pressure x 0.2 |
| EVAP pressure when vacuum introduction complete | Between reference pressure and reference pressure x 0.2 |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 23 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0455 or P0456.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0500: Vehicle speed sensor "A" pulse input error |
| Required Sensors/Components (Main) | Wheel Speed Sensor, Combination meter assembly and Skid control ECU |
| Required Sensors/Components (Related) | Park/neutral position switch assembly, Output speed sensor (SP2) |
| Frequency of Operation | Continuous |
| Duration | 5 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Time after engine switch off to on (IG) | 3 seconds or more |
| Vehicle speed at output speed sensor (SP2) | 9 km/h (5.59 mph) or more |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Vehicle speed sensor signal | No pulse input |
Scheme 188
Scheme 188: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine.
- Drive the vehicle at 24 km/h (15 mph) or more for a total of 30 seconds or more [B].
- Stop the vehicle.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0500.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 189
Scheme 189: WIRING DIAGRAM
- READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. OK Vehicle speeds displayed on Techstream and speedometer display are equal. NG --> See step 2 OK --> See step 5
- CHECK COMBINATION METER SYSTEM Inspect the circuits that send vehicle speed signals to this system in the meter system. Refer to «Speed Signal Circuit»(ref-524274-S36888352762013012800000) . During inspection for the meter section, if there is an instruction that indicates to go back to inspections for each system, proceed to the next step. NEXT: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - COMBINATION METER) Disconnect the ECM connector. Disconnect the combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition G3-32 (+S) - G44-18 (SPD) Always Below 1 ohms Reconnect the ECM connector. Reconnect the combination meter connector. NG --> See step 4 OK --> See step 6
- CHECK HARNESS AND CONNECTOR (ECM - NO. 4 JUNCTION BLOCK) Disconnect the ECM connector. Disconnect the No. 4 junction block connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 4A-93 - G44-18 (SPD) Always Below 1 ohms Reconnect the ECM connector. Reconnect the No. 4 junction block connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPAIR OR REPLACE NO. 4 JUNCTION BLOCK
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0505: ISC function |
| Required Sensors/Components (Main) | ETCS |
| Required Sensors/Components (Related) | Crankshaft position sensor, Engine coolant temperature sensor, and Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0011, P0021 (VVT system - Advance) P0012, P0022 (VVT system - Retard) P0013, P0023 (Exhaust VVT oil control valve) P0014, P0024 (Exhaust VVT system - Advance) P0015, P0025 (Exhaust VVT system - Retard) P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0171, P0172, P0174, P0175 (Fuel system) P0301 - P0308 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351 - P0358 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0401 (EGR system) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P1340 (Camshaft position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Front oxygen/Air fuel ratio sensor) P0705 (Shift lever position switch) P0748, P0778 (Pressure control solenoid) P0973, P0974, P0976, P0977, P0979, P0980, P0982, P0983, P0985, P0986 (Shift solenoid) |
| Engine | Running |
| Either condition is met | 1 or 2 |
| 1. Both of following conditions A and B met | |
| A. Engine speed - Target engine speed | Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on) |
| B. IAC flow rate learned value | 2.48 L/sec. or less, or 11.0 L/sec. or more for 5 seconds or more |
| 2. Both of following conditions C and D met | |
| C. Frequency that both of following conditions (a) and (b) met | 5 times or more |
| (a) Engine speed - Target engine speed | Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on) |
| (b) Vehicle condition | Stopped after being driven at 10 km/h (6.25 mph) or more |
| D. Either condition is met | (c) or (d) |
| (c) IAC flow rate learned value | 2.48 L/sec. or less, or 11.0 L/sec. or more |
| (d) Amount of change of IAC flow rate learned value | +2.86 L/sec. or more, or -4.69 L/sec. or less |
Scheme 190
Scheme 190: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- Idle the engine for 5 minutes or more [C]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine for 20 seconds or more [E].
- Repeat step [E] 5 times.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0505 is output A P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524271-S36516277682013012800000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 9 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leaks in air induction system. NG --> See step 10 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 6 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 13 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY Check for contamination between the throttle valve and housing, and check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 11 OK: Go to next step
- CONFIRM WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P0505 is output A No DTC is output B B --> END A --> See step 12
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-524251-S33794709982013012800000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-524246-S40846759042013012800000)
- REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-524262-S00817459492013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
| Related DTCs | P050A: Cold start idle air speed control system |
| Required sensors/Components (Main) | Throttle body assembly |
| Required sensors/Components (Related) | Mass air flow meter assembly Engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0011, P0021 (VVT system - Advance) P0012, P0022 (VVT system - Retard) P0013, P0023 (Exhaust VVT oil control valve) P0014, P0024 (Exhaust VVT system - Advance) P0015, P0025 (Exhaust VVT system - Retard) P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0171, P0172, P0174, P0175 (Fuel system) P0301 - P0308 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351 - P0358 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0401 (EGR system) P0500 (Vehicle speed sensor) P1340 (Camshaft position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Front oxygen/Air fuel ratio sensor) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Time after shift position changed | 2 seconds or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Accumulated mass air flow | Less than 77 g (varies with ECT) |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following the menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 26 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values to obtain the total fuel trim. Result Total of Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 6 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 19 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. OK --> See step 19 NG --> See step 17
- REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-524262-S00817459492013012800000) . NEXT --> See step 19
- CHECK PCV SYSTEM Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524271-S36516277682013012800000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 14 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leaks in air induction system. NG --> See step 15 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 16 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 12 NG --> See step 11
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 17 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1) or Control the VVT System (Bank 2). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Engine Condition OFF Normal engine speed ON Engine idles roughly or stalls soon after camshaft timing oil control valve switched from off to on NG --> See step 18 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 18.3 gm/s. and 25.8 gm/s. (shift lever: N; A/C: Off). OK --> See step 19 NG --> See step 20
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 19
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. NEXT --> See step 19
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 19
- REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . NEXT --> See step 19
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 20 A --> See step 27
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-524109-S04822504082013012800000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-3 (VG) - C29-14 (VG) Always Below 1 ohms C27-2 (E2G) - C29-13 (E2G) Always Below 1 ohms C27-3 (VG) or C29-14 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER ASSEMBLY Replace the mass air flow meter assembly. Refer to «REMOVAL»(ref-524262-S00293573342013012800000) . HINT: If the result of the inspection performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 25 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
| Related DTCs | P050B: Cold start ignition timing performance |
| Required Sensors/Components (Main) | Throttle body assembly |
| Required Sensors/Components (Related) | Mass air flow meter assembly Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0011, P0021 (VVT system - Advance) P0012, P0022 (VVT system - Retard) P0013, P0023 (Exhaust VVT oil control valve) P0014, P0024 (Exhaust VVT system - Advance) P0015, P0025 (Exhaust VVT system - Retard) P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0171, P0172, P0174, P0175 (Fuel system) P0301 - P0308 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351 - P0358 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0401 (EGR system) P0500 (Vehicle speed sensor) P1340 (Camshaft position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Front oxygen/Air fuel ratio sensor) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Accumulated time when ignition timing retard is cut off | 5 seconds or more |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P050B is output A P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 26 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 6 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 19 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. OK --> See step 19 NG --> See step 17
- REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly. Refer to «REMOVAL»(ref-524262-S00817459492013012800000) . NEXT --> See step 19
- CHECK PCV HOSE Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524271-S36516277682013012800000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 14 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leak in the air induction system. NG --> See step 15 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 16 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 12 NG --> See step 11
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 17 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1) or Control the VVT System (Bank 2). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Engine Condition OFF Normal engine speed ON Engine idles roughly or stalls soon after camshaft timing oil control valve switched from off to on NG --> See step 18 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 18.3 gm/s. and 25.8 gm/s. (shift lever: N; A/C: Off). OK --> See step 19 NG --> See step 20
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 19
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. NEXT --> See step 19
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 19
- REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . NEXT --> See step 19
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 20 A --> See step 27
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-524109-S04822504082013012800000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-3 (VG) - C29-14 (VG) Always Below 1 ohms C27-2 (E2G) - C29-13 (E2G) Always Below 1 ohms C27-3 (VG) or C29-14 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER ASSEMBLY Replace the mass air flow meter assembly. Refer to «REMOVAL»(ref-524262-S00293573342013012800000) . HINT: If the result of the inspection performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 25 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
| Related DTCs | P0550: Power steering oil pressure switch range check (Chattering) P0552: Power steering oil pressure switch range check (Low Resistance) P0553: Power steering oil pressure switch range check (High Resistance) |
| Required sensors/Components (Main) | Power steering oil pressure switch |
| Frequency of operation | Continuous |
| Duration | 0.5 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| Time after starter signal ON to OFF | 2 seconds or more |
| Power steering oil pressure switch voltage | Below 0.28 V, or higher than 4.9 V |
| Power steering oil pressure switch voltage | Below 0.28 V |
| Power steering oil pressure switch voltage | Higher than 4.9 V |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 5 seconds [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0550, P0552 or P0553.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK HARNESS AND CONNECTOR (ECM - POWER STEERING OIL PRESSURE SWITCH) Disconnect the ECM connector. Disconnect the power steering oil pressure switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C23-2 (PSP) - C29-16 (PSP) Always Below 1 ohms C23-1 (VC) - C28-15 (VCV1) Always Below 1 ohms C23-3 (E2) - C29-7 (E2) Always Below 1 ohms C23-2 (PSP) or C29-16 (PSP) - Body ground Always 10 kohms or higher C23-1 (VC) or C28-15 (VCV1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE POWER STEERING OIL PRESSURE SWITCH Replace the power steering oil pressure switch. Refer to «REMOVAL»(ref-524262-S20406027822013012800000) . NEXT: Go to next step
- CONFIRM WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P0550, P0552 and/or P0553 is output A No DTC is output B B --> END A --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0560: ECM system voltage |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Stand-by RAM | Initialized |
| ECM power source | Below 3.5 V |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 191
Scheme 191: WIRING DIAGRAM
- CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the ECM connector. Disconnect the cable from the positive (+) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition G44-24 (BATT) - Battery positive (+) terminal Always Below 1 ohms G44-24 (BATT) or Battery positive (+) terminal - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT BATTERY Check that the battery is not depleted. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-524267-S28637136902013012800000) . OK Battery is not depleted. NG --> REPLACE BATTERY OK: Go to next step
- CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR BATTERY TERMINAL OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0560 is output A No DTC is output B B --> See step 6 A --> See step 5
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | None |
| Frequency of operation | Continuous |
| Duration | 16 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| Main CPU and sub CPU mirroring | Fail |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. OK P0604 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTC | P0606: ECM range check |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not present | None |
| Either condition A or B is met | |
| A. DMA communication | No response |
| B. Watchdog from monitoring processor | Not toggle |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 1 second or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. OK P0606 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0607: Control module performance |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Heated oxygen sensor |
| Frequency of operation | Continuous |
| Duration | 60 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever the following DTCs are not present | None |
| Engine | Running |
| Estimated heated oxygen sensor temperature | 450 to 800°C (842 to 1472°F) |
| Heated oxygen sensor transistors | Fail |
Scheme 192
Scheme 192: CONFIRMATION DRIVING PATTERN
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on [B].
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [C].
- Start the engine and wait 2 minutes [D].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
- Idle the engine for 1 minute [F].
- Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [I].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [I] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 193
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . RESULT Result Proceed to P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A Only P0607 is output B B --> See step 3 A: Go to next step
- INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Refer to the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-524266-S10062126342013012800000) . Then proceed to "Inspect ECM". If P0137 or P0157 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-524266-S10062126342013012800000) . Then proceed to "Inspect ECM". If P0138 or P0158 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-524266-S10062126342013012800000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT --> See step 6
- CHECK FOR EXHAUST GAS LEAK Allow the engine to idle, and then rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "Perform Confirmation Driving Pattern". If no exhaust gas leaks are present, proceed to "Perform Confirmation Driving Pattern". HINT: If no exhaust gas leaks are present, there may be a malfunction in the heated oxygen sensor circuit. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Connect the Techstream to the DLC3. Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or higher. Perform the driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle. Drive the vehicle between 60 and 80 km/h (35 and 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A Only P0607 is output B No DTC is output C B --> See step 7 C --> See step 6 A: Go to next step
- INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Refer to the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-524266-S10062126342013012800000) . Then proceed to "Inspect ECM". If P0137 or P0157 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-524266-S10062126342013012800000) . Then proceed to "Inspect ECM". If P0138 or P0158 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-524266-S10062126342013012800000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT: Go to next step
- INSPECT ECM Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTCs. RESULT Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 16 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| When either condition below is met | Condition 1 or 2 |
| 1. When all conditions below are met | |
| CPU reset | 1 time or more |
| Learned throttle position - Learned accelerator pedal position | 0.4 V or higher |
| Electronic throttle actuator | OFF |
| 2. CPU reset | 2 times or more |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. OK P060A is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 16 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| When one of following conditions is met | Condition 1, 2, 3 or 4 |
| 1. Internal control module serial communication | Fail |
| 2. AD converter | Fail |
| 3. Knock sensor circuit | Fail |
| 4. Knock sensor serial communication | Fail |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328, P032C, P032D, P0332, P0333, P033C or P033D are output C B --> See step 3 C --> See step 4 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- GO TO DTC P0327, P0328, P032C, P032D, P0332, P0333, P033C OR P033D. Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor); DTC P032C: Knock Sensor 3 Circuit Low; DTC P032D: Knock Sensor 3 Circuit High; DTC P0332: Knock Sensor 2 Circuit Low Input (Bank 2); DTC P0333: Knock Sensor 2 Circuit High Input (Bank 2); DTC P033C: Knock Sensor 4 Circuit Low Input; DTC P033D: Knock Sensor 4 Circuit High Input»(ref-524266-S41721193602013012800000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| Difference of main accelerator pedal position and sub accelerator pedal position | 0.3 V or more |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. OK P060D is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| DMA communication error | Not detected |
| When one of following conditions is met | Condition 1 or 2 |
| 1. Difference of main throttle position and sub throttle position | 0.3 V or more |
| 2. Stop light switch signal (CPU) and stop light switch signal (Monitor IC) | Different |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. OK P060E is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0617: Starter signal |
| Required Sensors/Components (Main) | Starter relay (ST), Park/neutral position switch assembly, Power management control ECU |
| Required Sensors/Components (Related) | Speed sensor, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 20 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | 20 km/h (12.43 mph) or more |
| Engine speed | 1000 rpm or more |
Scheme 194
Scheme 194: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Idle the engine for 5 seconds or more [B].
- Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0617.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 195
Scheme 195: WIRING DIAGRAM
- READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Starter Signal. Check the value displayed on the Techstream when the engine switch is turned on (IG) and when the engine is started. OK Condition Starter Signal Engine switch turned on (IG) Close Engine started Open NG --> See step 2 OK --> See step 5
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION - Step 1»(ref-524256-S29021654012013012800000) . NG --> See step 6 OK: Go to next step
- REPAIR OR REPLACE HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read DTCs. RESULT Display (DTC Output) Proceed to P0617 A No DTC B B --> END A --> See step 7
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-524256-S42278416762013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P062F: Internal control module EEPROM error |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 11 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Permanent fault code data | Mismatch (3 times or more) |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No DTC output A DTC P062F output B B --> See step 2 A --> See step 3
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
| Related DTCs | P0630: VIN not programmed |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ CURRENT DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0630 is output A P0630 and other DTCs are output B HINT: If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. B --> See step 3 A: Go to next step
- INPUT VIN WITH TECHSTREAM Refer to Registration. Refer to «REGISTRATION»(ref-524126-S21249119222013012800000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | Within 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Throttle actuator power supply voltage | 7 V or higher |
| Engine switch | From on (IG) to off (Temporary Fail ON) |
| Throttle actuator power supply | ON |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the Techstream off.
- Turn the engine switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Turn the engine switch on (IG).
- Wait 10 seconds or more.
- Turn the engine switch off.
- Wait 15 seconds or more.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the Techstream off. Turn the engine switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the engine switch on (IG). Wait 10 seconds or more. Turn the engine switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. OK P0657 is not output. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0724: Stop light switch/Range check/Rationality |
| Required sensors/Components | Stop light switch assembly, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Engine switch | On (IG) |
| GO (Vehicle speed is 30 km/h (18.65 mph) or more) | Once |
| STOP (Vehicle speed is less than 3 km/h (1.86 mph)) | Once |
| Stop light switch | Stuck on |
Scheme 196
Scheme 196: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0724.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [E].
- Start the engine [C].
- Accelerate the vehicle to 30 km/h (18.65 mph) or more, and then depress the brake pedal and decelerate the vehicle to 3 km/h (1.86 mph) or less [D]. Repeat step [D] 5 times. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result [E].
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK STOP LIGHT SWITCH ASSEMBLY INSTALLATION Check the stop light switch assembly installation. OK Stop light switch assembly is installed correctly. NG --> See step 6 OK: Go to next step
- INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly. Refer to «INSPECTION - Step 1»(ref-524276-S37129129582013012800000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition G45-18 (STP) - Body ground Brake pedal is depressed 11 to 14 V G45-18 (STP) - Body ground Brake pedal is released Below 1 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-524276-S30404324862013012800000)
- SECURELY REINSTALL STOP LIGHT SWITCH ASSEMBLY. Refer to «INSTALLATION»(ref-524276-S35507361272013012800000)
| Related DTCs | P106A: Evaporative emission system pressure sensor - manifold absolute pressure correlation P106B: Evaporative emission system pressure sensor - secondary air injection system pressure sensor correlation |
| Required Sensors/Components (Main) | Canister pressure sensor Manifold absolute pressure sensor Pressure sensor (Air switching valve assembly (Bank 1 or Bank 2)) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per drive cycle |
| Duration | Less than 65 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0107, P0108 (Manifold absolute pressure) P0401 (EGR system) P0452, P0453 (EVAP system, Evaporative emission system pressure sensor) |
| Time elapsed after engine stop | 50 minutes |
| Time after ECM started by soak-timer | 60 seconds or more |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 10°C (14°F) or higher |
| Monitor runs whenever following DTCs not present | P0452, P0453 (EVAP system) P2431, P2432, P2433, P2436, P2437, P2438 (Secondary air injection system pressure sensor) P2440, P2441, P2442, P2443, P2444, P2445, P2447 (Secondary air injection system) |
| Time elapsed after engine stop | 50 minutes |
| Time after ECM started by soak-timer | 60 seconds or more |
| Battery voltage | 10.5 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 10°C (14°F) or higher |
| Difference between EVAP pressure and manifold absolute pressure | More than 7.22 kPa (54 mmHg) |
| Difference between EVAP pressure (Vapor Pressure Pump*) and secondary air injection system pressure sensor (bank 1) (Air Pump Pressure (Absolute)*) | More than 6.98 kPa (52 mmHg) |
| Difference between EVAP pressure (Vapor Pressure Pump*) and secondary air injection system pressure sensor (bank 2) (Air Pump2 Pressure (Absolute)*) | More than 6.98 kPa (52 mmHg) |
*: Name of Data List item
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) [A].
- Start the engine.
- Idle the engine for 10 seconds [B].
- Turn the engine switch off.
- Soak the vehicle for 55 minutes [C].
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If no pending DTC is output, perform the steps below.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P106A or P106B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO P106A, P106B) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P106A is output A P106B is output B P106A and P106B are output C P106A, P106B and other DTCs are output D HINT: If any DTCs other than P106A or P106B are output, perform troubleshooting for those DTCs first. B --> See step 3 C --> See step 6 D --> See step 8 A: Go to next step
- REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL»(ref-524262-S01653891792013012800000) . NEXT --> See step 7
- READ VALUE USING TECHSTREAM (AIR PUMP PRESSURE (ABSOLUTE), AIR PUMP2 PRESSURE (ABSOLUTE) AND VAPOR PRESSURE PUMP) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Air Pump Pressure (Absolute), Air Pump2 Pressure (Absolute) and Vapor Pressure Pump. Read the value. RESULT Result Proceed to Difference between Air Pump Pressure (Absolute) and Vapor Pressure Pump is more than 3.5 kPa (26 mmHg) A Difference between Air Pump2 Pressure (Absolute) and Vapor Pressure Pump is more than 3.5 kPa (26 mmHg) B B --> See step 5 A: Go to next step
- REPLACE AIR SWITCHING VALVE ASSEMBLY (FOR BANK 1) Replace the air switching valve assembly for bank 1. Refer to «REMOVAL»(ref-524251-S06527927302013012800000) . NEXT --> See step 7
- REPLACE AIR SWITCHING VALVE ASSEMBLY (FOR BANK 2) Replace the air switching valve assembly for bank 2. Refer to «REMOVAL»(ref-524251-S34147328552013012800000) . NEXT --> See step 7
- REPLACE CANISTER Replace the canister. Refer to «REMOVAL»(ref-524251-S05625440442013012800000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Enter the following menus: Powertrain / Engine and ECT / Data List. Compare the Data List items Air Pump Pressure (Absolute) and Vapor Pressure Pump, Air Pump2 Pressure (Absolute) and Vapor Pressure Pump, and Vapor Pressure Pump and MAP. Confirm that the difference between Vapor Pressure Pump and MAP, and between Vapor Pressure Pump, Air Pump Pressure (Absolute) and Air Pump2 Pressure (Absolute) is 3.5 kPa (26 mmHg) or less. NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
| Related DTCs | P1340: Camshaft position sensor range check P1340: Camshaft position / Crankshaft position misalignment P1342: Camshaft position sensor range check (low voltage) P1343: Camshaft position sensor range check (high voltage) |
| Required Sensors/Components (Main) | Camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds |
| MIL Operation | 2 driving cycles: P1340 camshaft position sensor range check Immediate: P1340 camshaft position / crankshaft position misalignment and P1342, P1343 camshaft position sensor range check |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Starter | ON (Not including when starter turned ON multiple times) |
| Minimum battery voltage while starter ON | Below 11 V |
P1340 CAMSHAFT POSITION SENSOR RANGE CHECK
| Monitor runs whenever following DTCs not present | P0342, P0343 (VVT sensor) P1342, P1343 (Camshaft position sensor) |
| Engine speed | 600 rpm or more |
| Starter | OFF |
| Camshaft position sensor range | 0.3 to 4.7 V |
P1340 CAMSHAFT POSITION/CRANKSHAFT POSITION MISALIGNMENT
| Monitor runs whenever following DTCs not present | P0340 (VVT sensor) P1340 (Camshaft position sensor) |
| Time after engine switch off to on (IG) | 2 seconds or more |
| Battery voltage | 8 V or higher |
| Starter | OFF |
P1342, P1343 CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position signal | No signal |
P1340 CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position and crankshaft position phase | Misaligned |
P1340 CAMSHAFT POSITION/CRANKSHAFT POSITION MISALIGNMENT
| Camshaft position sensor voltage | Below 0.3 V |
P1342 CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor voltage | Higher than 4.7 V |
P1343 CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor signal | Camshaft position sensor voltage fluctuates when the camshaft rotates 3 signals per revolution of camshaft |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P1340, P1342 or P1343.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 197
Scheme 197: WIRING DIAGRAM
