MONITOR STRATEGY
| Related DTCs | P0010: Camshaft timing oil control valve range check (Bank 1) P0020: Camshaft timing oil control valve range check (Bank 2) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not present | None |
| All of following conditions met | |
| Starter | OFF |
| Engine switch | On (IG) |
| Time after engine switch off to on (IG) | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of following conditions met | |
| A. All of following conditions met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% |
| B. All of following conditions met | |
| Battery voltage | 13 V or higher |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% |
| C. Both of following conditions met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
COMPONENT OPERATING RANGE
| Camshaft timing oil control valve duty ratio | 3 to 100% |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 245
Scheme 245: WIRING DIAGRAM
PROCEDURE
- CHECK FOR DTC Clear the DTCs after recording the freeze frame data and DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Start the engine and allow it to idle. Then check for DTCs. Check that P0010 or P0020 is not output. OK P0010 or P0020 is not output. NG --> See step 2 OK --> See step 4
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION - Step 1»(ref-524262-S19814365142013012800000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the camshaft timing oil control valve connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C12-1 - C29-19 (OC1+) Always Below 1 ohms C10-1 - C28-19 (OC2+) Always Below 1 ohms C12-2 - C29-20 (OC1-) Always Below 1 ohms C10-2 - C28-20 (OC2-) Always Below 1 ohms C12-1 or C29-19 (OC1+) - Body ground Always 10 kohms or higher C10-1 or C28-19 (OC2+) - Body ground Always 10 kohms or higher C12-2 or C29-20 (OC1-) - Body ground Always 10 kohms or higher C10-2 or C28-20 (OC2-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524262-S07212957182013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0011: Advanced camshaft timing (for Bank 1) P0012: Retarded camshaft timing (for Bank 1) P0021: Advanced camshaft timing (for Bank 2) P0022: Retarded camshaft timing (for Bank 2) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly and Camshaft timing gear assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor, VVT sensor and Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediate Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0016, P0018 (VVT system) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P1340 (Camshaft position sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 500 to 4000 rpm |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
- If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.
Scheme 246
Scheme 246: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0013: Exhaust camshaft timing oil control valve (for Bank 1) P0023: Exhaust camshaft timing oil control valve (for Bank 2) |
| Required sensors/Components (Main) | Exhaust camshaft timing oil control valve assembly |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| All of following conditions met | |
| Starter | OFF |
| Engine switch | On (IG) |
| Time after engine switch off to on (IG) | 0.5 seconds or more |
| One of following conditions met | |
| A. All of following conditions met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% |
| B. All of following conditions met | |
| Battery voltage | 13 V or higher |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% |
| C. Both of following conditions met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
| Camshaft timing oil control valve duty cycle | 3 to 100% |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0013 or P0023.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 247
Scheme 247: WIRING DIAGRAM
- CHECK FOR DTC (DTC P0013 OR P0023) Connect the Techstream to the DLC3. Clear the DTCs after recording the freeze frame data and DTCs. Turn the engine switch off. Start the engine and allow it to idle. Then check for DTCs. Check that P0013 or P0023 is not output. OK P0013 or P0023 is not output. NG --> See step 2 OK --> See step 4
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION - Step 1»(ref-524262-S19814365142013012800000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the camshaft timing oil control valve connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C13-1 - C29-21 (OE1+) Always Below 1 ohms C13-2 - C29-22 (OE1-) Always Below 1 ohms C11-1 - C28-21 (OE2+) Always Below 1 ohms C11-2 - C28-22 (OE2-) Always Below 1 ohms C13-1 or C29-21 (OE1+) - Body ground Always 10 kohms or higher C13-2 or C29-22 (OE1-) - Body ground Always 10 kohms or higher C11-1 or C28-21 (OE2+) - Body ground Always 10 kohms or higher C11-2 or C28-22 (OE2-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524262-S07212957182013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0014: Advanced camshaft timing (for Bank 1) P0015: Retarded camshaft timing (for Bank 1) P0024: Advanced camshaft timing (for Bank 2) P0025: Retarded camshaft timing (for Bank 2) |
| Required sensors/Components (Main) | Camshaft timing oil control valve assembly and Camshaft timing exhaust gear assembly |
| Required sensors/Components (Related) | Crankshaft position sensor, VVT sensor and Engine coolant temperature sensor |
| Frequency of operation | Continuous |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing: 2 driving cycles Retarded camshaft timing: Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust VVT oil control valve) P0017, P0019 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P1340 (Camshaft position sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 500 to 4000 rpm |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0014, P0015, P0024 or P0025 is output A P0014, P0015, P0024 or P0025 and other DTCs are output B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Turn the A/C on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1, VVT Ex OCV Duty #2 and VVT Ex Chg Angle #2]. Refer to «DATA LIST / ACTIVE TEST»(ref-524126-S20424571482013012800000) . NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Warm up the engine. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the output pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 4 OK --> See step 10
- CHECK VALVE TIMING (CHECK FOR LOOSENESS IN TIMING CHAIN AND WHETHER TIMING CHAIN HAS JUMPED TOOTH) Remove the cylinder head cover LH and RH. Turn the crankshaft pulley and align its groove with the "0" alignment mark of the timing chain cover. Check that the alignment marks of the camshaft timing gears and camshaft timing exhaust gears are at the positions shown in the illustration. HINT: If the alignment marks are not as shown, turn the crankshaft one revolution clockwise. OK Alignment marks on camshaft timing gears are aligned as shown in the illustration. NG --> See step 11 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION - Step 1»(ref-524262-S19814365142013012800000) . NG --> See step 12 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter. Refer to «DISASSEMBLY»(ref-524246-S09113665982013012800000) . Check that the filter is not clogged. OK Filter is not clogged. NG --> CLEAN OR REPLACE OIL CONTROL VALVE FILTER OK: Go to next step
- REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing exhaust gear assembly. Refer to «REMOVAL»(ref-524246-S42817166632013012800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Perform the Confirmation Driving Pattern. OK No pending DTC is output and All Readiness is NORMAL. HINT: DTC P0014, P0015, P0024 or P0025 is stored when foreign objects in the engine oil are caught in some parts of the system. These codes will remain stored even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 13 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-524246-S09750024602013012800000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524262-S07212957182013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0016: Camshaft timing misalignment at idling (Bank 1 Intake Side) P0017: Camshaft timing misalignment at idling (Bank 1 Exhaust Side) P0018: Camshaft timing misalignment at idling (Bank 2 Intake Side) P0019: Camshaft timing misalignment at idling (Bank 2 Exhaust Side) |
| Required Sensors/Components (Main) | Camshaft timing gear assembly, Camshaft timing exhaust gear assembly |
| Required Sensors/Components (Related) | VVT sensor, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 1 minute |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0016, P0018 (VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0017, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P1340 (Camshaft position sensor) |
| Engine speed | 400 to 1400 rpm |
| Monitor runs whenever following DTCs not present | P0013, P0023 (Exhaust VVT oil control valve) P0017, P0019 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0017, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P1340 (Camshaft position sensor) |
| Engine speed | 400 to 1400 rpm |
| One of following conditions met | |
| VVT learned value at maximum retarded valve timing | Less than 22.23°CA |
| VVT learned value at maximum retarded valve timing | More than 46.68°CA |
| One of following conditions met | |
| VVT learned value at maximum advanced valve timing | Less than 82.23°CA |
| VVT learned value at maximum advanced valve timing | More than 106.68°CA |
Scheme 248
Scheme 248: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016, P0017, P0018 or P0019.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016, P0017, P0018 OR P0019) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0016, P0017, P0018 or P0019 is output A P0016, P0017, P0018 or P0019 and other DTCs are output B HINT: If any DTCs other than P0016, P0017, P0018 or P0019 are output, perform troubleshooting for those DTCs first. B --> See step 8 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the A/C on. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2) or Control the VVT Exhaust Linear (Bank 1) or Control the Exhaust VVT Linear (Bank 2) / All Data / VVT Change Angle #1, VVT Change Angle #2, VVT Ex Chg Angle #1, VVT Ex Chg Angle #2. Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. NG --> See step 4 OK: Go to next step
- ADJUST VALVE TIMING Adjust the valve timing. Refer to «REASSEMBLY»(ref-524246-S09750024602013012800000) . NEXT --> See step 7
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION - Step 1»(ref-524262-S19814365142013012800000) . NG --> See step 9 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter. Refer to «DISASSEMBLY»(ref-524246-S09113665982013012800000) . Check that the filter is not clogged. OK Filter is not clogged. NG --> CLEAN OR REPLACE OIL CONTROL VALVE FILTER OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly. Refer to «REMOVAL»(ref-524246-S42817166632013012800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the output pending DTCs using the Techstream. OK No pending DTC is output. NG --> See step 10 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524262-S07212957182013012800000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
| Related DTCs | P0031: Air fuel ratio sensor heater (for Bank 1) open/short (Low electrical current) P0032: Air fuel ratio sensor heater (for Bank 1) open/short (High electrical current) P0051: Air fuel ratio sensor heater (for Bank 2) open/short (Low electrical current) P0052: Air fuel ratio sensor heater (for Bank 2) open/short (High electrical current) P101D: Air fuel ratio sensor heater (for Bank 1) performance P103D: Air fuel ratio sensor heater (for Bank 2) performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 11 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P101D, P103D (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 10 seconds or more |
| Air fuel ratio sensor heater duty cycle | 50% or more |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 10 seconds or more |
| Air fuel ratio sensor heater duty cycle | More than 0% |
| Monitor runs whenever following DTCs not stored | P0031, P0051 (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 10 seconds or more |
| Air fuel ratio sensor heater duty cycle | 10 to 60% |
| Air fuel ratio sensor heater ON current | 0.8 A or higher |
| Air fuel ratio sensor heater current | Below 0.8 A |
| Hybrid IC high current limiter port | Fail |
| Hybrid IC high current limiter port | Fail |
| Air fuel ratio sensor heater current | 0.8 A or higher |
Refer to "Data List / Active Test" [A/F Heater Duty #1, A/F Heater Duty #2]. Refer to DATA LIST / ACTIVE TEST .
Scheme 249
Scheme 249: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031, P0032, P0051, P0052, P101D or P103D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated oxygen sensor heater (for Bank 1) range check (Low electrical current) P0038: Heated oxygen sensor heater (for Bank 1) range check (High electrical current) P0057: Heated oxygen sensor heater (for Bank 2) range check (Low electrical current) P0058: Heated oxygen sensor heater (for Bank 2) range check (High electrical current) P0141: Heated oxygen sensor heater performance (for Bank 1) P0161: Heated oxygen sensor heater performance (for Bank 2) P102D: Heated oxygen sensor heater stuck ON (for Bank 1 Sensor 2) P105D: Heated oxygen sensor heater stuck ON (for Bank 2 Sensor 2) |
| Required Sensors/Components (Main) | Heated oxygen sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous: P0037, P0038, P0057, P0058 P102D and P105D Once per driving cycle: P0141 and P0161 |
| Duration | 0.5 seconds: P0037 and P0057 Within 3 seconds: P0038 and P0058 10 seconds: P0141 and P0161 0.5 seconds: P102D and P105D |
| MIL Operation | Immediate: P0037, P0038, P0057, P0058, P102D and P105D 2 driving cycles: P0141 and P0161 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0032, P0052 (Air fuel ratio sensor heater) P0038, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heater OFF current learned value | Acquired |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0038, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Heated oxygen sensor heater OFF current | Higher than 3.5 A |
| Hybrid IC high current limiter port | Fail |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Fuel cut | OFF |
| Time after fuel cut ON to OFF | 30 seconds or more |
| Accumulated heater ON time | 100 seconds or more |
| Learned heater OFF current operation | Complete |
| Monitor runs whenever following DTCs not stored | None |
| Duration that rear heated oxygen sensor impedance is below 15 kohms | 2 seconds or more |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation | Complete |
| Hybrid IC high current limiter port | Fail |
When the values for the Data List items O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2 are not 0 A, the heater is on.
| Heater current - Learned heater OFF current | 0.3 A or less |
| Heated oxygen sensor heater ON current | 1 A or less |
| Hybrid IC high current limiter port | Fail |
| Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heated oxygen sensor heater ON current | Higher than 1 A |
| Heated oxygen sensor heater current | 0.4 to 1 A (when engine idling, Heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P0141, P0161, P102D or P105D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P006A: manifold absolute pressure - mass or volume air flow correlation |
| Required Sensors/Components (Main) | Manifold absolute pressure sensor Mass air flow meter assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Time after engine start | 5 seconds |
| Engine coolant temperature | 70°C (158°F) or higher |
| Intake air temperature | 5.5°C (41.9°F) or higher |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Engine load fluctuation (per 8 msec.) | 10% or less |
| VVT system | Stable |
| EGR valve | Closed |
| Engine speed | 250 to 2000 rpm |
| Engine load (normal operation) | 35% or less |
| Engine load (fail-safe) | 41% or less |
| Pressure correlation | 24 kPa (180 mmHg) or higher |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the A/C switch and all accessory switches off and the shift lever in P or N.
- Idle the engine for 30 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P006A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. Drive the vehicle at 60 km/h (37 mph) for 5 minutes or more. Idle the engine for 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P006A is output A P006A and other DTCs are output B HINT: If any DTCs other than P006A are output, perform troubleshooting for those DTCs first. B --> See step 10 A: Go to next step
- CHECK PCV HOSE (HOSE CONNECTION) Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524271-S36516277682013012800000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 11 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leaks in intake system. NG --> See step 12 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAP) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAP. Read the MAP value. Standard Switch Condition Techstream Display Engine switch on (IG) 80 to 110 kPa (600 to 825 mmHg) HINT: Standard atmospheric pressure is 101 kPa. For every 100 m increase in elevation, pressure drops by 1 kPa. This varies by weather (high atmospheric pressure, low atmospheric pressure). Also, check "Atmosphere Pressure" in the Data List. OK --> See step 6 NG --> See step 5
- REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL»(ref-524262-S01653891792013012800000) . NEXT: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 8 NG --> See step 7
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 13 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P006A) Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off. HINT: The A/C switch and all accessory switches should be off, and the shift lever should be in N or P. Idle the engine for 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P006A is output A No DTC output B B --> END A: Go to next step
- INSPECT MASS AIR FLOW METER ASSEMBLY Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off, and the shift lever should be in N or P. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Check MAF in the Data List during idling. Standard 3.4 to 6.2 gm/s NG --> See step 14 OK --> See step 15
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-524251-S33794709982013012800000)
- REPAIR OR REPLACE INTAKE SYSTEM. Refer to «REMOVAL»(ref-524246-S40846759042013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- REPLACE MASS AIR FLOW METER ASSEMBLY. Refer to «REMOVAL»(ref-524262-S00293573342013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor, Engine coolant temperature sensor and Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0335, P0337, P0338 (Crankshaft position sensor) P0452, P0453 (EVAP system pressure sensor) P2401, P2402 (Leak detection pump) P2419, P2420 (EVAP system vent valve) |
| Throttle position (TP) sensor voltage | 0.2 to 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature | 70°C (158°F) or higher |
| Estimated load | 30 to 70% |
| Both conditions 1 and 2 met | |
| 1. Average engine load value ratio | Less than 0.85, or more than 1.15 (varies with estimated engine load) |
| 2. Average air-fuel ratio | Less than -20%, or more than 20% |
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0101 is output A P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leaks in air induction system. NG --> See step 10 OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 11 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 6 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 9 OK: Go to next step
- REPLACE MASS AIR FLOW METER ASSEMBLY Replace the mass air flow meter assembly. Refer to «REMOVAL»(ref-524262-S00293573342013012800000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off and wait for 30 seconds. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0101. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-524246-S40846759042013012800000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-524251-S33794709982013012800000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 rpm 2 driving cycles: Engine speed 4000 rpm or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Mass air flow meter voltage | Below 0.2 V |
| Mass air flow meter voltage | Higher than 4.9 V |
| Mass air flow meter voltage | 0.4 V to 2.2 V |
Scheme 250
Scheme 250: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 rpm for 5 seconds [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 251
Scheme 251: WIRING DIAGRAM
| Related DTCs | P0107: Manifold absolute pressure sensor range check (Low voltage) P0108: Manifold absolute pressure sensor range check (High voltage) |
| Required Sensors/Components (Main) | Manifold absolute pressure sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Starter | Off |
| Time after starter ON to OFF | 2 seconds or more |
| Manifold absolute pressure sensor voltage | Below 0.5 V |
| Manifold absolute pressure sensor voltage | Higher than 4.5 V |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 5 seconds [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0107 or P0108.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 252
Scheme 252: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature change since engine stop | 40°C (-72°F) or more |
| Engine coolant temperature before engine stop | 70°C (158°F) or higher |
| Accumulated mass air flow amount before engine stop | 3935 g or more |
| Key-off duration | 30 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature | 70°C (158°F) or higher |
| Accumulated mass air flow amount | 3935 g or more |
| Either of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature change | Less than 1°C (2°F) |
| Intake air temperature change | Less than 1°C (2°F) |
Scheme 253
Scheme 253: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter assembly) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0111 and other DTCs are output A P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE MASS AIR FLOW METER ASSEMBLY. Refer to «REMOVAL»(ref-524262-S00293573342013012800000)
Scheme 254
- The intake air temperature sensor, mounted on the mass air flow meter, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes see scheme 1
- The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
- Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability. HINT: When DTC P0112 or P0113 is stored, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. The ECM continues operating in fail-safe mode until a pass condition is detected.
| DTC No. | DTC Detection Condition | Trouble Area |
| P0112 | Short in the intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic). | Short in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter assembly) ECM |
| P0113 | Open in the intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic). | Open in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter assembly) ECM |
When either of these DTCs is stored, check the intake air temperature by entering the following menus: Powertrain / Engine and ECT / All Data / Intake Air.
| Temperature Displayed | Malfunction |
| 40°C (-40°F) | Open circuit |
| 140°C (284°F) or higher | Short circuit |
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Intake air temperature sensor voltage [Intake Air] | Below 0.18 V [Higher than 140°C (284°F)] |
| Intake air temperature sensor voltage [Intake Air] | Higher than 4.91 V [Below -40°C (-40°F)] |
| Intake air temperature sensor voltage [Intake Air] | 0.18 to 4.91 V [-40 to 140°C (-40 to 284°F)] |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 255
Scheme 255: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (Fluctuating) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Engine coolant temperature sensor voltage | Below 0.14 V, or higher than 4.91 V |
| Engine coolant temperature sensor voltage [Coolant Temp] | Below 0.14 V [Higher than 140°C (284°F)] |
| Engine coolant temperature sensor voltage [Coolant Temp] | Higher than 4.91 V [Below -40°C (-40°F)] |
| Engine coolant temperature sensor voltage [Coolant Temp] | 0.14 to 4.91 V [-40 to 140°C (-40 to 284°F)] |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 256
Scheme 256: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor cold start monitor P0116: Engine coolant temperature sensor soak monitor |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Below 60°C (140°F) |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 1846 g or more |
| Fuel cut | OFF |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Monitor runs whenever following DTCs not present | P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Soak time | 5 hours or more |
| Either condition (a) or (b) met | |
| (a) Engine coolant temperature | 60°C (140°F) or higher |
| (b) Accumulated mass air flow | 3926 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) [varies with engine coolant temperature of last trip engine stop] |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 257
Scheme 257: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the driving pattern being interrupted (possibly due to factors such as traffic conditions), the driving pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0116 is output A P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, perform troubleshooting for those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-524250-S40977348082013012800000) . Measure the valve opening temperature of the thermostat. Standard opening temperature 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-524250-S40675615342013012800000) . NG --> See step 5 OK --> See step 3
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-524262-S05147910282013012800000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-524250-S40977348082013012800000)
| Related DTCs | P011B: Engine coolant temperature / Intake air temperature sensor correlation |
| Required Sensors/Components (Main) | Engine coolant temperature/Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not stored | P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P2610 (ECM internal engine off timer) |
| Both of following conditions met | Conditions 1 and 2 |
| 1. All of following conditions met | Conditions (a), (b), (c) and (d) |
| (a) Time engine not running after engine switch on (IG) | Less than 20 seconds |
| (b) Soak time | 7 hours or more |
| (c) Battery voltage | 10.5 V or higher |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions is met | Condition (a) or (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or higher |
| (b) Engine coolant temperature before engine start | 10°C (14°F) or higher |
| Temperature deviation (engine coolant temperature - intake air temperature) | More than 25°C (45°F) or less than -20°C (-36°F) |
Scheme 258
Scheme 258: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Turn the engine switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P011B output A P011B and other DTCs output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to create conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle outside temperature gauge (if equipped) are not suitable for comparison with the intake air temperature reading. The outside temperature gauge has a significant delay built-in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE MASS AIR FLOW METER ASSEMBLY. Refer to «REMOVAL»(ref-524262-S00293573342013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-524262-S05147910282013012800000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Fluctuating) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Fluctuating) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0121, P0122, P0123, P0220, P0222 and P0223 0.5 seconds: P2135 Case 1 0.4 seconds: P2135 Case 2 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions A or B met | |
| A. Engine switch on (IG) | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223 AND P2135
| Monitor runs whenever following DTCs not present | P0120, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) |
| Either of following conditions A or B met | |
| A. Engine switch | On (IG) |
| B. Electronic throttle actuator power | ON |
| VTA1 voltage | 0.2 V or less, or 4.54 V or higher |
| When either condition below is met | |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | More than 1.6 V |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Less than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or higher |
| Either of following conditions A or B met | |
| A. VTA2 voltage | 1.75 V or less |
| B. Both of the following conditions are met | |
| VTA2 voltage | 4.8 V or higher |
| VTA1 voltage | 0.2 to 2.02 V |
| VTA2 voltage | 1.75 V or less |
| Both of the following conditions are met | |
| VTA2 voltage | 4.8 V or higher |
| VTA1 voltage | 0.2 to 2.02 V |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| Both of the following conditions are met | |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | 0.2 to 4.54 V |
| VTA2 voltage | 1.75 to 4.8 V |
| Difference between VTA1 and VTA2 voltages | More than 0.02 V |
Scheme 259
Scheme 259: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator and the throttle valve is returned to a 7° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
The ECM continues operating in fail-safe mode until a pass condition is detected, and the engine switch is then turned off.
Scheme 260
Scheme 260: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Thermostat, cooling system |
| Required Sensors/Components (Related) | Engine coolant temperature sensor and mass air flow meter assembly |
| Frequency of Operation | Once per driving cycle |
| Duration | 62 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or higher 110 seconds: Engine coolant temperature at engine start -19.44 to -8.33°C (-3 to 17°F) 20 minutes: Engine coolant temperature at engine start below -19.44°C (-3°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0101, P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0128 (Thermostat) |
| Engine coolant temperature | Below 0°C (32°F) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is 10°C (50°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Wait 21 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0125 is output A P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-524250-S40977348082013012800000) . Check the valve opening temperature of the thermostat. Standard opening temperature 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-524250-S40977348082013012800000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-524262-S05147910282013012800000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat |
| Required Sensors/Components (Related) | Engine coolant temperature sensor, Intake air temperature sensor, Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 900 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0011, P0021 (VVT system - Advance) P0012, P0022 (VVT system - Retard) P0013, P0023 (Exhaust VVT oil control valve) P0014, P0024 (Exhaust VVT system - Advance) P0015, P0025 (Exhaust VVT system - Retard) P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301 - P0308 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351 - P0358 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0401 (EGR system) P0500 (Vehicle speed sensor) P1340 (Camshaft position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Front oxygen/Air fuel ratio sensor) |
| Battery voltage | 11 V or higher |
| Either of following conditions 1 or 2 met | |
| 1. All of following conditions met | |
| Engine coolant temperature at engine start - intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions met | |
| Engine coolant temperature at engine start - intake air temperature at engine start | More than 7°C (12.6°F) |
| Engine coolant temperature at engine start | 56°C (133°F) or less |
| Intake air temperature at engine start | 10°C (14°F) or higher |
| Accumulated time at vehicle speed of 128 km/h (80 mph) or more | Less than 20 seconds |
| Duration that both of following conditions (a) and (b) met | 5 seconds or more |
| (a) Estimated engine coolant temperature | 75°C (167°F) or higher |
| (b) Engine coolant temperature sensor output | Below 75°C (167°F) |
Scheme 261
Scheme 261: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (0 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 rpm and then racing the engine, etc. to raise the engine speed to a speed of 4000 rpm or more will cause data capture to start.
- After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0128 is output A P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-524250-S40977348082013012800000) . Measure the valve opening temperature of the thermostat. Standard opening temperature 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-524250-S40675615342013012800000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-524250-S40977348082013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
| Related DTCs | P0136: Heated oxygen sensor (for Bank 1) output voltage (Abnormal voltage output) P0136: Heated oxygen sensor (for Bank 1) impedance (Low) P0137: Heated oxygen sensor (for Bank 1) output voltage (Low voltage) P0137: Heated oxygen sensor (for Bank 1) impedance (High) P0138: Heated oxygen sensor (for Bank 1) output voltage (Extremely high) P0139: Heated oxygen sensor output voltage during fuel cut (for Bank 1) P0156: Heated oxygen sensor (for Bank 2) output voltage (Abnormal voltage output) P0156: Heated oxygen sensor (for Bank 2) impedance (Low) P0157: Heated oxygen sensor (for Bank 2) output voltage (Low voltage) P0157: Heated oxygen sensor (for Bank 2) impedance (High) P0158: Heated oxygen sensor (for Bank 2) output voltage (Extremely high) P0159: Heated oxygen sensor output voltage during fuel cut (for Bank 2) |
| Required Sensors/Components (Main) | Heated oxygen sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor, engine coolant temperature sensor, mass air flow meter, throttle position sensor and air fuel ratio sensor |
| Frequency of Operation | Once per driving cycle: Active air-fuel ratio control detection Continuous: Other |
| Duration | 20 seconds: Active air-fuel ratio control detection 90 seconds: Heated oxygen sensor impedance (High) 30 seconds: Heated oxygen sensor impedance (Low) 10 seconds: Heated oxygen sensor output voltage (Stuck high) 7 seconds: Heated oxygen sensor voltage (During fuel cut) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Rear oxygen sensor heater) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel system) P0301 - P0308 (Misfire) P0335 (Crankshaft position sensor) P0401 (EGR system) P0412, P0418, P1613 (Secondary air injection system control) P0451, P0452, P0453 (EVAP system) P0500, P0722 (Vehicle speed sensor) P1340 (Camshaft position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Front oxygen/Air fuel ratio sensor) P0416, P0417, P2440, P2441, P2442, P2443, P2444, P2445, P2447 (Secondary air injection system) |
| Active air-fuel ratio control | Executing |
| Active air-fuel ratio control begins when all of following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idling | OFF |
| Engine speed | Less than 3200 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Fuel cut | OFF |
| Engine load | 10 to 70% |
| Transmission gear | 4th or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT AND LOW VOLTAGE)
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | Below 700°C (1292°F) |
| ECM monitor | Completed |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) |
| ECM monitor | Completed |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or higher |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 75°C (167°F) or higher |
| Estimated catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | ON |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| 1. All of following conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) Oxygen Storage Capacity (OSC) | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT)
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air-fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | Below 0.21 V |
| (c) Oxygen Storage Capacity (OSC) | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW)
| Duration following condition met | 30 seconds or more |
| Heated oxygen sensor impedance | Below 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration following condition met | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or higher |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration following condition met | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Either condition is met | |
| Total airflow volume reached after start of fuel-cut while rear heated oxygen sensor voltage remains at 0.2 V or higher | More than 15.3 g |
| Time for rear heated oxygen sensor voltage to drop from 0.35 V to 0.2 V during fuel-cut | 1 second or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| Duration following condition met | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 and 0.9 V |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
P0136, P0137, P0138, P0156, P0157 and P0158
Scheme 262
Scheme 262: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transmission in 4th gear or higher, drive the vehicle at 60 to 120 km/h (40 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 263
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 60 km/h (40 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139 or P0159.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, shift the transmission to 2nd gear, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 264
Scheme 264: WIRING DIAGRAM
| Related DTCs | P014C: Air fuel ratio sensor (bank 1) slow response (rich to lean) P014D: Air fuel ratio sensor (bank 1) slow response (lean to rich) P014E: Air fuel ratio sensor (bank 2) slow response (rich to lean) P014F: Air fuel ratio sensor (bank 2) slow response (lean to rich) P015A: Air fuel ratio sensor (bank 1) delayed response (rich to lean) P015B: Air fuel ratio sensor (bank 1) delayed response (lean to rich) P015C: Air fuel ratio sensor (bank 2) delayed response (rich to lean) P015D: Air fuel ratio sensor (bank 2) delayed response (lean to rich) |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when the following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idle | OFF |
| Engine speed | 1000 to 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2 or more |
| Catalyst monitor | Not yet |
| Mass air flow | 2.5 to 12 gm/sec |
| Rich to Lean Response rate deterioration level | 0.02 V or less |
AIR FUEL RATIO SENSOR (BANK 1) SLOW RESPONSE (RICH TO LEAN)
| Lean to Rich Response rate deterioration level | 0.02 V or higher |
AIR FUEL RATIO SENSOR (BANK 1) SLOW RESPONSE (LEAN TO RICH)
| Rich to Lean Response rate deterioration level | 0.02 V or less |
AIR FUEL RATIO SENSOR (BANK 2) SLOW RESPONSE (RICH TO LEAN)
| Lean to Rich Response rate deterioration level | 0.02 V or higher |
AIR FUEL RATIO SENSOR (BANK 2) SLOW RESPONSE (LEAN TO RICH)
| Rich to Lean delay level | 500 ms or more |
AIR FUEL RATIO SENSOR (BANK 1) DELAYED RESPONSE (RICH TO LEAN)
| Lean to Rich delay level | 500 ms or more |
AIR FUEL RATIO SENSOR (BANK 1) DELAYED RESPONSE (LEAN TO RICH)
| Rich to Lean delay level | 500 ms or more |
AIR FUEL RATIO SENSOR (BANK 2) DELAYED RESPONSE (RICH TO LEAN)
| Lean to Rich delay level | 500 ms or more |
AIR FUEL RATIO SENSOR (BANK 2) DELAYED RESPONSE (LEAN TO RICH)
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation pattern will activate the A/F sensor response monitor.
Scheme 265
Scheme 265: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) .
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details.
- Check that the monitor item O2 Sensor is Incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1, and LR DELAY B2S1 do not exist in the Detail of O2 Sensor monitor at this time (the initial value of "0.000" is indicated in each test item).
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check that the monitor item O2 Sensor becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1, and LR DELAY B2S1.
- If the monitor item O2 Sensor does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the A/F sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-524126-S26886227982013012800000) .
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C and P015D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the DTC judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other are output B HINT: If any DTCs other than DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION»(ref-524262-S10540619972013012800000) . NG --> See step 11 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 1»(ref-524264-S22234113962013012800000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensor is installed to the vehicle. NG --> See step 12 OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read pending DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC is not output (Pending DTC is not output) B B --> See step 13 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-524262-S00247626492013012800000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read pending DTCs. RESULT Result Proceed to DTC is not output (Pending DTC is not output) A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output B B --> See step 14 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-524262-S00247626492013012800000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-524262-S00247626492013012800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-524126-S03735106152013012800000)
- CHECK EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-524266-S28982804202013012800000)
| Related DTCs | P0171: Fuel trim lean (for Bank 1) P0172: Fuel trim rich (for Bank 1) P0174: Fuel trim lean (for Bank 2) P0175: Fuel trim rich (for Bank 2) |
| Required Sensors/Components | Air fuel ratio sensor, Mass air flow meter, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT oil control valve) P0011, P0021 (VVT system - Advance) P0012, P0022 (VVT system - Retard) P0013, P0023 (Exhaust VVT oil control valve) P0014, P0024 (Exhaust VVT system - Advance) P0015, P0025 (Exhaust VVT system - Retard) P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P006A, P0107, P0108 (Manifold absolute pressure) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351 - P0358 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0401 (EGR system) P0412, P0418, P1613 (Secondary air injection system control) P1340 (Camshaft position sensor) P0416, P0417, P2440, P2441, P2442, P2443, P2444, P2445, P2447 (Secondary air injection system) P0500 (Vehicle speed sensor) |
| Fuel system status | Closed loop |
| Battery voltage | 11 V or higher |
| Either of following conditions 1 or 2 met | |
| 1. Engine speed | Less than 1100 rpm |
| 2. Engine load | 11.5% or more |
| Catalyst monitor | Not executed |
| Purge-cut | Executing |
| Either of following conditions 1 or 2 met | |
| 1. Average of short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average of short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 266
Scheme 266: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at a speed between 60 and 135 km/h (38 and 85 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171, P0172, P0174 OR P0175) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0171, P0172, P0174 or P0175 is output A P0171, P0172, P0174 or P0175 and other DTCs are output B HINT: If any DTCs other than P0171, P0172, P0174 or P0175 are output, troubleshoot those DTCs first. B --> See step 25 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524271-S36516277682013012800000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 26 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leaks in air induction system. NG --> See step 27 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.0% to +12.0%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) +12% Rich Below 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) -12% Lean Higher than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen) +12% Rich Higher than 0.55 V O2S B1S2 or O2S B2S2 (Heated oxygen) -12% Lean Below 0.4 V Result Status of AFS Voltage B1S1 or AFS Voltage B2S1 Status of O2S B1S2 or O2S B2S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - - A Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Fuel injector assembly blockage Gas leaks from exhaust system Intake system Fuel pressure Mass air flow meter assembly Manifold absolute pressure sensor Engine coolant temperature sensor EGR valve assembly A Rich Rich Actual air fuel ratio rich - Fuel injector assembly leakage or blockage Gas leaks from exhaust system Ignition system Fuel pressure Mass air flow meter assembly Manifold absolute pressure sensor Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor EGR valve assembly B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1, AFS Voltage B2S1, O2S B1S2 and O2S B2S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-524126-S20424571482013012800000) . B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp. Read Coolant Temp twice, when the engine is both cold and warmed up. Standard With cold engine: Same as ambient air temperature. With warm engine: Between 75°C and 100°C (167°F and 212°F). NG --> See step 28 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 18.3 gm/s. and 25.8 gm/s. (shift lever: N; A/C: Off). NG --> See step 18 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-524273-S28719777252013012800000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FOR SPARKS AND IGNITION See step 8 NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Check the injection and volume. Refer to «INSPECTION - Step 1»(ref-524269-S37380659192013012800000) . OK --> See step 15 NG --> See step 29
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 30 OK: Go to next step
- CHECK TERMINAL VOLTAGE (+B OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 23 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 1»(ref-524264-S22234113962013012800000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-524262-S00247626492013012800000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0171, P0172, P0174 or P0175 is output A DTC is not output B B --> END A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 18 NG --> See step 17
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 32 OK: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-524109-S04822504082013012800000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0171, P0172, P0174 or P0175 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-3 (VG) - C29-14 (VG) Always Below 1 ohms C27-2 (E2G) - C29-13 (E2G) Always Below 1 ohms C27-3 (VG) or C29-14 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER ASSEMBLY Replace the mass air flow meter assembly. Refer to «REMOVAL»(ref-524262-S00293573342013012800000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P0171, P0172, P0174 or P0175 is output B B --> See step 31 A --> END
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - NO. 1 INTEGRATION RELAY) See step 6 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT NO. 1 INTEGRATION RELAY (A/F) Inspect the No. 1 integration relay (A/F). Refer to «ON-VEHICLE INSPECTION - Step 4»(ref-524262-S35068267992013012800000) . NG --> See step 33 OK --> See step 34
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-524251-S33794709982013012800000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-524246-S40846759042013012800000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-524262-S05147910282013012800000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-524269-S42378634592013012800000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-524262-S00247626492013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- REPLACE NO. 1 INTEGRATION RELAY. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-524272-S42449560502013012800000)
- CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-524264-S01180072842013012800000)
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire P0307: Cylinder 7 misfire P0308: Cylinder 8 misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor and camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature, intake air temperature sensors and mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emissions-related misfire 200 to 600 crankshaft revolutions: Catalyst-damaging misfire |
| MIL Operation | 2 driving cycles: MIL illuminates when misfire detected MIL flashes immediately: When catalyst-damaging misfire occurs |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT system - Misalignment) P0017, P0019 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0327, P0328, P0332, P0333, P032C, P032D, P033C, P033D (Knock sensor) P0335 (Crankshaft position sensor) P1340 (Camshaft position sensor) P0351 - P0358 (Igniter) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or higher |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 5900 rpm |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | Higher than -7°C (19°F) |
| (b) Engine coolant temperature | Higher than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | 1000 crankshaft revolutions |
| Except above | 1000 crankshaft revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| All of following conditions 1, 2 and 3 met | 200 crankshaft revolutions x 3 |
| 1. Driving cycle | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 2200 rpm |
| Except above | Crankshaft 200 revolutions |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| Number of misfires per 200 revolutions | 72 or more (varies with intake air amount and engine speed) |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 267
Scheme 267: WIRING DIAGRAM
Scheme 268
Scheme 269
Refer to DTC P0102. Refer to WIRING DIAGRAM .
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG).
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-524126-S23069627772013012800000) .
- Read the misfire counts of each cylinder (cylinder No. 1 to No. 8) with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle several times with the conditions, such as engine speed and engine load, as shown in Misfire RPM and Misfire Load in the freeze frame data. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below with the engine speed and engine load the same as Misfire RPM and Misfire Load in the freeze frame data. Engine Speed Duration Idling 7.0 minutes or more 1000 4.0 minutes or more 2000 2.0 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the engine switch off until the stored DTCs and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTCs, freeze frame data and other data will be cleared.
- Record the DTCs, freeze frame data and misfire counts.
- Turn the engine switch off and wait for at least 30 seconds.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO MISFIRE CODES) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 and/or P0308 is output A P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 and/or P0308 and other DTCs are output B HINT: If any DTCs other than P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 and P0308 are output, troubleshoot those DTCs first. B --> See step 41 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524271-S36516277682013012800000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 42 OK: Go to next step
- READ VALUE USING TECHSTREAM (MISFIRE RPM AND MISFIRE LOAD) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Misfire RPM and Misfire Load. Read and note the Misfire RPM and Misfire Load values. HINT: The Misfire RPM and Misfire Load values indicate the vehicle conditions under which the misfire occurred. NEXT: Go to next step
- READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Catalyst OT MF F/C. Read the value displayed on the Techstream. RESULT Data List Techstream Display Proceed to Catalyst OT MF F/C AVAIL (Avail) A NOT AVL (Not Avl) B B --> See step 6 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Prohibit the Catalyst OT Misfire prevent F/C. Perform the Active Test. NOTE: When performing the Active Test, make sure the vehicle is stopped and the engine is either idling or being revved at 3000 rpm or less. NEXT: Go to next step
- READ VALUE USING TECHSTREAM (MISFIRE COUNT) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 Misfire Rate, #2, #3, #4, #5, #6, #7 and #8. Allow the engine to idle. Read each value for CYL #1 to #8 (Cylinder #1 Misfire Rate to #8) displayed on the Techstream. If no misfire counts occur in any cylinders, perform the following procedures: Move the shift lever to D. Check CYL #1 to #8 (Cylinder #1 Misfire Rate to #8). If misfire counts are still not displayed, perform procedure "A" and "B", and then check the misfire counts again. Procedure A: Drive the vehicle while satisfying the Misfire RPM and Misfire Load values noted in the "Read Value Using Techstream (Misfire RPM and Misfire Load)" procedure above. Procedure B: Read CYL #1 to #8 (Cylinder #1 Misfire Rate to #8) or the DTCs output on the Techstream. RESULT Result Proceed to Most misfires occur in only 1 or 2 cylinders A 3 cylinders or more have equal misfire counts B HINT: If it is difficult to reproduce misfires for each cylinder, check the Data List item called Misfire Margin. Try to find vehicle driving conditions that lower the Misfire Margin value. Values above 30% are considered normal. If the freeze frame data's record of the engine coolant temperature is below 75°C (167°F), the misfire may be detected only when the engine is cold. If the freeze frame data's record of the Engine Run Time is less than 120 seconds, the misfire may be detected immediately after the engine is started. B --> See step 20 A: Go to next step
- INSPECT SPARK PLUG Inspect the spark plug of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-524247-S37516351052013012800000) . NG --> See step 43 OK: Go to next step
- CHECK FOR SPARKS AND IGNITION Perform a spark test. Refer to «REMOVAL»(ref-524262-S23907377132013012800000) . WARNING: Always disconnect all the injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Spark jumps across electrode gap. NG --> See step 38 OK: Go to next step
- CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524246-S42637380202013012800000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE). Refer to «PROCEDURE - Step 1»(ref-524264-S32204479942013012800000) NG --> See step 51 OK: Go to next step
- CHECK HARNESS AND CONNECTOR. Refer to «PROCEDURE - Step 3»(ref-524264-S32204479942013012800000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY OF MISFIRING CYLINDER Check the fuel injector injection [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION - Step 1»(ref-524269-S37380659192013012800000) . NG --> See step 46 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leakage in air induction system. NG --> See step 47 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-524273-S28719777252013012800000) . NG --> See step 40 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> See step 49 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 18.3 gm/s. and 25.8 gm/s. (shift lever: N; A/C: Off). NG --> See step 33 OK: Go to next step
- CHECK VALVE TIMING See step 4 NG --> See step 48 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 33 NG --> See step 19
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. OK --> See step 33 NG --> See step 59
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524270-S25831447522013012800000) . OK No leakage in air induction system. NG --> See step 52 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-524273-S28719777252013012800000) . NG --> See step 40 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> See step 54 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 18.3 gm/s. and 25.8 gm/s. (shift lever: N; A/C: Off). NG --> See step 33 OK: Go to next step
- CHECK VALVE TIMING See step 4 NG --> See step 53 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: When performing the Active Test, make sure the shift lever is in P or N. The A/C switch and all accessory switches should be off. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm that Throttle Idle Position is ON and check the engine idling condition and the value of MAP in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) Step 0 Step 0 to 30 Idling condition Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) MAP value is at least 10 kPa (75 mmHg) higher than when EGR valve is fully closed OK --> See step 27 NG --> See step 26
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL»(ref-524251-S06751532262013012800000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. NG --> See step 60 OK: Go to next step
- INSPECT SPARK PLUG Inspect the spark plug of the misfiring cylinder. Refer to «REMOVAL»(ref-524262-S23907377132013012800000) . NG --> See step 55 OK: Go to next step
- CHECK FOR SPARKS AND IGNITION Perform a spark test. Refer to «REMOVAL»(ref-524262-S23907377132013012800000) . WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Sparks jump across electrode gap. NG --> See step 38 OK: Go to next step
- CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-524246-S42637380202013012800000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE). Refer to «PROCEDURE - Step 1»(ref-524264-S32204479942013012800000) NG --> See step 56 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (FUEL INJECTOR - ECM). Refer to «PROCEDURE - Step 3»(ref-524264-S32204479942013012800000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY OF MISFIRING CYLINDER Check the fuel injector injection [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION - Step 1»(ref-524269-S37380659192013012800000) . NG --> See step 57 OK: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-524109-S04822504082013012800000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 or P0308. Check the DTC judgment result. RESULT Display (DTC Output) Proceed to ABNORMAL (P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 or P0308 output) A NORMAL (No DTC output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C27-3 (VG) - C29-14 (VG) Always Below 1 ohms C27-2 (E2G) - C29-13 (E2G) Always Below 1 ohms C27-3 (VG) or C29-14 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER ASSEMBLY Replace the mass air flow meter assembly. Refer to «REMOVAL»(ref-524262-S00293573342013012800000) . HINT: If the results of the inspections performed in steps 16 and 23 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . Turn the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 or P0308. Check the DTC judgment result. RESULT Display (DTC Output) Proceed to NORMAL (No DTC output) A ABNORMAL (P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307 or P0308 output) B B --> See step 44 A --> END
- CHANGE TO NORMAL SPARK PLUG AND CHECK SPARK OF MISFIRING CYLINDER Change the installed spark plug to a spark plug that functions normally. Perform a spark test. WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the injector connectors. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 39 OK --> See step 45
- CHANGE TO NORMAL IGNITION COIL ASSEMBLY AND CHECK SPARK OF MISFIRING CYLINDER Change the ignition coil assembly to an ignition coil assembly that functions normally. Perform a spark test. WARNING: Always disconnect all fuel injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the fuel injector connectors. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 58 OK --> See step 50
- CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 61
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524126-S26606347652013012800000)
- REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-524251-S33794709982013012800000)
- REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-524262-S23907377132013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-524262-S23907377132013012800000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-524269-S42378634592013012800000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-524246-S40846759042013012800000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-524246-S09750024602013012800000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-524262-S05147910282013012800000)
- REPLACE IGNITION COIL ASSEMBLY. Refer to «REMOVAL»(ref-524262-S23907377132013012800000)
- GO TO FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(ref-524264-S03958269082013012800000)
- REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-524246-S40846759042013012800000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-524246-S09750024602013012800000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-524262-S05147910282013012800000)
- REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-524262-S23907377132013012800000)
- GO TO FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(ref-524264-S03958269082013012800000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-524269-S42378634592013012800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-524262-S01887464392013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-524251-S06751532262013012800000)
- REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-524269-S41706281042013012800000)
| Related DTCs | P0327: Knock sensor (for Bank 1 Sensor 1) open/short (Low voltage) P0328: Knock sensor (for Bank 1 Sensor 1) open/short (High voltage) P0332: Knock sensor (for Bank 2 Sensor 1) open/short (Low voltage) P0333: Knock sensor (for Bank 2 Sensor 1) open/short (High voltage) P032C: Knock sensor (for Bank 1 Sensor 2) open/short (Low voltage) P032D: Knock sensor (for Bank 1 Sensor 2) open/short (High voltage) P033C: Knock sensor (for Bank 2 Sensor 2) open/short (Low voltage) P033D: Knock sensor (for Bank 2 Sensor 2) open/short (High voltage) |
| Required Sensors/Components (Main) | Knock sensor (Bank 1, 2 Sensor 1, 2) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 5 seconds or more |
| Knock sensor voltage | Below 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE): P0327, P0332, P032C AND P033C
| Knock sensor voltage | Higher than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE): P0328, P0333, P032D AND P033D
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine and wait 5 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327, P0328, P032C, P032D, P0332, P0333, P033C or P033D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 270
Scheme 270: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor range check/rationality P0337: Crankshaft position sensor check (Low voltage) P0338: Crankshaft position sensor check (High voltage) |
| Required sensors/Components (Main) | Crankshaft position sensor |
| Required sensors/Components (Related) | Camshaft position sensor |
| Frequency of operation | Continuous |
| Duration | P0335: 4.7 seconds P0337, P0338: 4 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
P0335: Crankshaft Position Sensor Range Check
| Engine speed | 450 rpm or more |
| Starter | OFF |
| Time after starter turned from ON to OFF | 3 seconds or more |
| Crankshaft position sensor voltage | 0.3 to 4.7 V |
| Starter | ON |
| Minimum battery voltage while starter ON | Below 11 V |
| Crankshaft position sensor voltage | 0.3 to 4.7 V |
| Monitor runs whenever following DTCs not present | None |
P0337, P0338 CRANKSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)
| Engine speed signal | No signal |
P0335 CRANKSHAFT POSITION SENSOR RANGE CHECK
| Crankshaft position sensor voltage | Below 0.3 V |
P0337 CRANKSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE)
| Crankshaft position sensor voltage | Higher than 4.7 V |
P0338 CRANKSHAFT POSITION SENSOR RANGE CHECK (HIGH VOLTAGE)
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution |
| Crankshaft position sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 20 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335, P0337 or P0338.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 271
Scheme 271: WIRING DIAGRAM
| Related DTCs | P0340: VVT position sensor (for Bank 1) verify pulse input P0342: VVT position sensor (for Bank 1) range check (low voltage) P0343: VVT position sensor (for Bank 1) range check (high voltage) P0345: VVT position sensor verify pulse input (for Bank 2) P0347: VVT position sensor (for Bank 2) range check (low voltage) P0348: VVT position sensor (for Bank 2) range check (high voltage) |
| Required Sensors/Components (Main) | VVT position sensor (for Bank 1 and 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0342, P0343, P0347, P0348 (VVT sensor) |
| Engine speed | 600 rpm or more |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Engine switch | On (IG) |
| Monitor runs whenever following DTCs are not present | P0340, P0345 (VVT sensor) |
| Starter | OFF |
| Engine switch on (IG) and time after engine switch is off to on (IG) | 2 seconds or more |
| Battery voltage | 8 V or higher |
P0342, P0343, P0347, P0348
| VVT sensor signal | No signal |
| VVT sensor voltage | Below 0.3 V |
| VVT sensor voltage | Higher than 4.7 V |
| VVT sensor signal | No signal |
| VVT sensor voltage | Below 0.3 V |
| VVT sensor voltage | Higher than 4.7 V |
| VVT sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 272
Scheme 272: WIRING DIAGRAM
| Related DTCs | P0351: Igniter (cylinder 1) malfunction P0352: Igniter (cylinder 2) malfunction P0353: Igniter (cylinder 3) malfunction P0354: Igniter (cylinder 4) malfunction P0355: Igniter (cylinder 5) malfunction P0356: Igniter (cylinder 6) malfunction P0357: Igniter (cylinder 7) malfunction P0358: Igniter (cylinder 8) malfunction |
| Required Sensors/Components (Main) | Igniter |
| Required Sensors/Components (Related) | ECM |
| Frequency of Operation | Continuous |
| Duration | About 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions A or B met | |
| A. Engine speed | 1500 rpm or less |
| B. Starter | OFF |
| Either of following conditions C or D met | |
| C. Both of following conditions (a) and (b) met | |
| (a) Engine speed | 500 rpm or less |
| (b) Battery voltage | 6 V or higher |
| D. All of following conditions (a), (b) and (c) met | |
| (a) Engine speed | More than 500 rpm |
| (b) Battery voltage | 10 V or higher |
| (c) Number of sparks after CPU reset | 5 sparks or more |
| IGF signal | ECM does not receive any IGF signals despite ECM sending IGT signal to igniter |
| IGF signal | Igniter transmits IGF signal when it receives IGT signal from ECM |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353, P0354, P0355, P0356, P0357 or P0358.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 273
Scheme 273: WIRING DIAGRAM
Scheme 274
| Related DTCs | P0365: VVT position sensor (for Bank 1) verify pulse input P0367: VVT position sensor (for Bank 1) range check (low voltage) P0368: VVT position sensor (for Bank 1) range check (high voltage) P0390: VVT position sensor (for Bank 2) verify pulse input P0392: VVT position sensor (for Bank 2) range check (low voltage) P0393: VVT position sensor (for Bank 2) range check (high voltage) |
| Required Sensors/Components (Main) | VVT position sensor (for Bank 1 and 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0367, P0368, P0392, P0393 (Exhaust VVT sensor) |
| Engine speed | 600 rpm or more |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Engine switch | On (IG) |
| Monitor runs whenever following DTCs are not present | P0365, P0390 (Exhaust VVT sensor) |
| Starter | OFF |
| Engine switch | On (IG) |
| Time after engine switch off to on (IG) | 2 seconds or more |
| Battery voltage | 8 V or higher |
P0367, P0368, P0392, P0393
| Exhaust VVT sensor signal | No signal |
| Exhaust VVT sensor voltage | Below 0.3 V |
| Exhaust VVT sensor voltage | Higher than 4.7 V |
| VVT sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the engine switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the engine switch off and wait for at least 30 seconds.
- Turn the engine switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0365, P0367, P0368, P0390, P0392 or P0393.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-524126-S41645429092013012800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 275
Scheme 275: WIRING DIAGRAM
