REPLACEMENT
HINT
The installation is in the reverse order of the removal. However, when there is a special point concerning the installation, it is indicated.
Scheme 296
Scheme 297
- REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ DEFROSTER NOZZLE DUCT (SEE STEP 47 IN «REPLACEMENT»(ref-228807-S32953263012006041100000) )
- REMOVE GPS ANTENNA Disengage the 4 clips. Remove the 2 screws and GPS antenna.
- INSTALL GPS ANTENNA Install the GPS antenna with the 2 screws. Install the 4 clips.
HINT
The installation is in the reverse order of the removal. However, when there is a special point concerning the installation, it is indicated.
Scheme 298
Scheme 299
Scheme 300
- REMOVE TELEPHONE ANTENNA ROD Turn the telephone antenna rod counterclockwise as indicated by the arrow mark in (Scheme 298) to remove it.
- REMOVE ROOF HEADLINING ASSY
- REMOVE TELEPHONE ANTENNA BASE Disconnect the connector. Remove the protector. Remove the 2 nuts and telephone antenna base.
- INSTALL TELEPHONE ANTENNA BASE Install the telephone antenna base with the 2 nuts. Torque: 3 - 9 N.m (31 - 92 kgf.cm, 27 - 80.in.lbf) Connect the connector. Install the protector.
