LIN Communication System (Diagnostic Codes & Symptom Tests): Overview Lexus GS IV

Communication Devices 13 illustrations ~526 words

DESCRIPTION

This DTC is output when LIN communication between the master switch and main body ECU (multiplex network body ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B1206No communication between master switch and main body ECU (multiplex network body ECU) for 10 seconds or moreMain body ECU (multiplex network body ECU) Front multiplex network door ECU LH Multiplex network master switch assembly Harness or connector

Scheme 191

Scheme 191: WIRING DIAGRAM

This DTC is output when LIN communication between the sliding roof drive gear sub-assembly and main body ECU (multiplex network body ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B1273No communication between sliding roof drive gear sub-assembly and main body ECU (multiplex network body ECU) for 10 seconds or moreMain body ECU (multiplex network body ECU) Cowl side junction block LH Sliding roof drive gear sub-assembly Harness or connector

HINT

For vehicles with sliding roof system only.

Scheme 192

Scheme 192: WIRING DIAGRAM

The rear control switch communicates with the air conditioning amplifier assembly through the LIN communication system.

If the LIN communication system malfunctions, the air conditioning amplifier assembly does not operate even if the rear control switch is operated.

DTC CodeDTC Detection ConditionTrouble Area
B14B3Lost communication with the rear control switch.Rear control switch Air conditioning amplifier assembly Harness or connector

The refreshing seat switch communicates with the air conditioning amplifier assembly through the LIN communication system. If the LIN communication system malfunctions, the air conditioning amplifier assembly does not operate even if the refreshing seat switch is operated.

DTC CodeDTC Detection ConditionTrouble Area
B14B5Lost communication with the refreshing seat switch.Refreshing seat switch Air conditioning amplifier assembly Harness or connector

This DTC is stored when there is an open, short or ECU communication malfunction between the power management control ECU and certification ECU (smart key ECU assembly).

DTC No.DTC Detection ConditionTrouble Area
B2287There is an open, short or ECU communication malfunction between power management control ECU and certification ECU (smart key ECU assembly).Power management control ECU Certification ECU (smart key ECU assembly) Harness or connector

Scheme 193

Scheme 193: WIRING DIAGRAM

This DTC is output when LIN communication between the front power window regulator motor assembly LH and main body ECU (multiplex network body ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B2321No communication between front power window regulator motor assembly LH and main body ECU (multiplex network body ECU) for 10 seconds or moreMain body ECU (multiplex network body ECU) Front multiplex network door ECU LH Front power window regulator motor assembly LH Harness or connector

Scheme 194

Scheme 194: WIRING DIAGRAM

This DTC is output when LIN communication between the front power window regulator motor assembly RH and main body ECU (multiplex network body ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B2322No communication between front power window regulator motor assembly RH and main body ECU (multiplex network body ECU) for 10 seconds or moreMain body ECU (multiplex network body ECU) Front multiplex network door ECU RH Front power window regulator motor assembly RH Harness or connector

Scheme 195

Scheme 195: WIRING DIAGRAM

This DTC is output when LIN communication between the rear power window regulator motor assembly RH and main body ECU (multiplex network body ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B2323No communication between rear power window regulator motor assembly RH and main body ECU (multiplex network body ECU) for 10 seconds or moreMain body ECU (multiplex network body ECU) Rear power window regulator motor assembly RH Harness or connector

Scheme 196

Scheme 196: WIRING DIAGRAM

This DTC is output when LIN communication between the rear power window regulator motor assembly LH and main body ECU (multiplex network body ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B2324No communication between rear power window regulator motor LH and main body ECU (multiplex network body ECU) for 10 seconds or moreMain body ECU (multiplex network body ECU) Rear power window regulator motor assembly LH Harness or connector

Scheme 197

Scheme 197: WIRING DIAGRAM

The main body ECU (multiplex network body ECU) monitors the LIN communication bus between the components related to the door and sliding roof intermittently. DTC B2325 is output when a malfunction in the LIN communication bus between the components related to the door and sliding roof is detected 3 times consecutively.

DTC CodeDTC Detection ConditionTrouble Area
B2325Main body ECU (multiplex network body ECU) detects malfunction of LIN communication bus between components related to door and sliding roof 3 times consecutivelyMain body ECU (multiplex network body ECU) Multiplex network master switch assembly Front multiplex network door ECU LH Front multiplex network door ECU RH Front power window regulator motor assembly LH Front power window regulator motor assembly RH Rear power window regulator motor assembly LH Rear power window regulator motor assembly RH Sliding roof drive gear sub-assembly* Harness or connector
  1. *: w/ Sliding Roof System

Scheme 198

Scheme 198: WIRING DIAGRAM

The certification ECU (smart key ECU assembly) monitors the LIN communication bus between the components related to certification intermittently. DTC B2785 is output when a malfunction in the LIN communication bus between the components related to certification is detected 3 times consecutively.

DTC CodeDTC Detection ConditionTrouble Area
B2785Certification ECU (smart key ECU assembly) detects malfunction in LIN communication bus between components related to certification 3 times consecutivelyCertification ECU (smart key ECU assembly) ID code box (immobilizer code ECU) Power management control ECU Steering lock actuator assembly Harness or connector

Scheme 199

Scheme 199: WIRING DIAGRAM

This DTC is output when LIN communication between the certification ECU (smart key ECU assembly) and steering lock actuator assembly stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B2786Periodic transmission from steering lock actuator assembly stops for 10 seconds or moreCertification ECU (smart key ECU assembly) Steering lock actuator assembly Harness or connector

Scheme 200

Scheme 200: WIRING DIAGRAM

This DTC is output when LIN communication between the certification ECU (smart key ECU assembly) and ID code box (immobilizer code ECU) stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B2789No communication between certification ECU (smart key ECU assembly) and ID code box (immobilizer code ECU) for 10 seconds or moreCertification ECU (smart key ECU assembly) ID code box (Immobilizer code ECU) Harness or connector

Scheme 201

Scheme 201: WIRING DIAGRAM

This DTC is stored when LIN communication between the certification ECU (smart key ECU assembly) and power management control ECU stops for 10 seconds or more.

DTC CodeDTC Detection ConditionTrouble Area
B278CNo communication between the certification ECU (smart key ECU assembly) and power management control ECU for 10 seconds or more.Power management control ECU Certification ECU (smart key ECU assembly) Harness or connector

Scheme 202

Scheme 202: WIRING DIAGRAM

The LIN communication of the components related to the rain sensor occurs between the rain sensor and windshield wiper switch assembly.

Scheme 203

Scheme 203: WIRING DIAGRAM
