Air Conditioning (Diagnostics - Introduction): Other Lexus GS III facelift

PRECAUTION

Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected.

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Input signal to A/C amplifier

Output signal to A/C amplifier

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

1. GENERAL The air conditioning system has the following features: In compliance with the temperature set with the temperature control switch, the A/C amplifier calculates the outlet temperature based on the input signals from various sensors. In addition, corrections in accordance with the signals from the room humidity sensor and the water temperature sensor are added to control the outlet air temperature. Controls the blower motor in accordance with the airflow volume that has been calculated by A/C amplifier based on the input signals from various sensors. Automatically changes the outlets in accordance with the outlet mode ratio that has been calculated by the A/C amplifier based on the input signals from various sensors. Automatically controls the air inlet control damper in accordance with the airflow volume that has been calculated by the A/C amplifier. Based on the signals from the ambient temperature sensor, this control calculates the outside temperature, which is then corrected in the air conditioning amplifier, and shown in the multi-information display in the combination meter. Turns the rear defogger and outside rear mirror heaters on for 15 minutes when the rear defogger switch is pressed. Turns them off if the switch is pressed while they are operating. The A/C amplifier automatically controls the air inlets based on the signals from the smog ventilation sensor. Checks the sensors in accordance with operation of the air conditioner switches. HINT: The smart connector has a built-in IC that enables communication with the A/C amplifier servomotor driving and position detection. The A/C amplifier equipped with the function of controlling the indicator lighting.
2. MODEL POSITION AND DAMPER OPERATION Control Damper Control Position Damper Position Operation Air Inlet Control Damper FRESH B Brings in fresh air. RECIRC A Recirculates internal air. Air Mix Control Film Damper Driver and Front Passenger Side MAX COOL to MAX HOT (TEMP. SETTING 18 to 32°C (64 to 90°F)) C, D, E Varies the mixture ratio of the fresh air and the recirculation air in order to regulate the temperature continuously from HOT to COOL. Mode Control Film Damper Driver and Front Passenger Side FACE I, J, L, P, U Air blows out of the front and rear center registers, and side registers. *1 BI - LEVEL I, Q, M, R, T Air mainly blows out of the front and rear center registers, side registers, and footwell register ducts. FOOT H, K, N, O, S Air mainly blows out of the front and rear footwell register ducts. In addition, air blows out slightly from the front and side defrosters, and the side registers. *2 FOOT / DEF G, K, N, O, T Air mainly blows out of the front and side defrosters to defrost the windshield. Air also blows out from the front and rear footwell register ducts, and the side registers. *2 DEF F, K, N, O, U Air blows out of the front and side defrosters and side registers to defrost the windshield. *1: In the multi mode, air blows out of all the air outlets except the front and side defroster. *2: In the multi mode, air blows out of all the air outlets.
3. AIR OUTLETS AND AIRFLOW VOLUME Air Outlet Mode Selectable Mode Register Driver Passenger Rear Automatic Manual Center Side Center Side Center FACE U FACE L B/L U B/L L FOOT (DEF=0) FOOT D FOOT R FOOT F F/D DEF - - - - - Air Outlet Position Symbol A B C D E Air Outlet Mode Footwell Defroster Driver Passenger Driver Passenger Front Rear Front Rear Front Side Front Side FACE U - - - - - - - - FACE L - - - - B/L U - - - - B/L L - - - - FOOT (DEF=0) - - - - FOOT D FOOT R FOOT F F/D DEF - - - - Air Outlet Position Symbol F G H I J K L M HINT: The size of the circle indicates the proportion of airflow volume. There are 4 sizes.
