COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Automatic Light Control Sensor | (Scheme 14) |
| Body ECU No. 1 | In Passenger Side Junction Block Behind Right Kick Panel |
| Body ECU No. 2 | In Driver Side Junction Block Behind Left Kick Panel |
| Combination Switch | (Scheme 14) |
| Daytime Running Light Main Relay (W/ DRL System) | (Scheme 14) |
| Daytime Running Light No. 3 & No. 4 Relay (W/ DRL System) | (Scheme 14) |
| Daytime Running Light Resister | (Scheme 14) |
| DOME Fuse | In Passenger Side Junction Block Behind Right Kick Panel |
| Driver Side Junction Block | (Scheme 14) |
| Engine Room No. 1 Junction Block | (Scheme 14) |
| ECU-IG Fuse | In Driver Side Junction Block Behind Left Kick Panel |
| FOG Fuse | In Driver Side Junction Block Behind Left Kick Panel |
| Fog Light Relay | In Driver Side Junction Block Behind Left Kick Panel |
| GAUGE Fuse | In Driver Side Junction Block Behind Left Kick Panel |
| Glove Compartment Door Courtesy Switch | (Scheme 15) |
| H-LP L LWR Fuse & H-LP R LWR Fuse | In Engine Room No. 1 Junction Block |
| H-LP L UPR Fuse & H-LP R UPR Fuse (W/O DRL System) | In Engine Room No. 1 Junction Block |
| Headlights | (Scheme 14) |
| Headlight Beam Level Control Actuator | (Scheme 16) |
| Headlight Beam Level Control ECU | (Scheme 16) |
| Headlight Control Relay | In Engine Room No. 1 Junction Block |
| Height Control Sensor | (Scheme 16) |
| Ignition Switch | (Scheme 14) |
| Light Control ECU | (Scheme 14) |
| Luggage Compartment Courtesy Switch | (Scheme 15) |
| Luggage Compartment Key Lock & Unlock Switch | (Scheme 15) |
| Passenger Side Junction Block | (Scheme 15) |
| Rheostat Light Control | (Scheme 15) |
| Taillight Control Relay | In Driver Side Junction Block Behind Left Kick Panel |
| TAIL Fuse | In Driver Side Junction Block Behind Left Kick Panel |
COMPONENT LOCATIONS
