INSPECTION PROCEDURE
HINT
This code will be set if any of the power window switches is stuck or if there is a problem with any of the wires which connect to the power window master switch, each power window ECU, and each power window switch.
Scheme 33
Scheme 34
Scheme 35
- CHECK WIRE HARNESS (LIN COMMUNICATION) Disconnect the power window regulator master switch and power window ECU connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition I5-16 (LIN2) - I4-9 (LIN) Always Below 1 ohms I5-17 (LIN1) - H5-9 (LIN) Always Below 1 ohms I5-17 (LIN1) - K3-9 (LIN) Always Below 1 ohms I5-17 (LIN1) - J3-9 (LIN) Always Below 1 ohms I5-16 (LIN2) - Body ground Always 10 kohms or higher I5-17 (LIN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT POWER WINDOW SWITCH Disconnect the power window switch connectors. Measure the resistance according to the value(s) in the table below. Standard resistance Front passenger and rear power window switch Tester Connection Condition Specified Condition 2 (U) - 4 (A) - 5 (E) Auto UP Below 1 ohms 2 (U) - 5 (E) Manual UP Below 1 ohms 5 (E) - 10 (D) Manual DOWN Below 1 ohms 4 (A) - 10 (D) - 5 (E) Auto DOWN Below 1 ohms NG --> REPLACE POWER WINDOW SWITCH OK: Go to next step
- CHECK WIRE HARNESS (POWER WINDOW (MASTER) SWITCH - POWER WINDOW ECU) Measure the resistance according to the value (s) in the table below. Standard resistance Driver side Front passenger side Rear LH side Rear RH side Tester Connection Condition Specified Condition I5-12 (E) - I4-1 (E) Always Below 1 ohms I5-15 (D) - I4-7 (DWN1) Always Below 1 ohms I5-18 (LED) - I4-5 (LED) Always Below 1 ohms I5-20 (U) - I4-10 (UP1) Always Below 1 ohms I5-12 (E) - Body ground Always Below 1 ohms I5-15 (D) - Body ground Always 10 kohms or higher I5-18 (LED) - Body ground Always 10 kohms or higher I5-20 (U) - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition H6-2 (U) - H5-10 (UP1) Always Below 1 ohms H6-4 (A) - H5-4 (AUTO) Always Below 1 ohms H6-5 (E) - Body ground Always Below 1 ohms H6-8 (LED) - H5-5 (LED) Always Below 1 ohms H6-10 (D) - H5-7 (DWN1) Always Below 1 ohms H5-1 (E) - Body ground Always Below 1 ohms H6-2 (U) - Body ground Always 10 kohms or higher H6-4 (A) - Body ground Always 10 kohms or higher H6-8 (LED) - Body ground Always 10 kohms or higher H6-10 (D) - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition K4-2 (U) - K3-10 (UP1) Always Below 1 ohms K4-4 (A) - K3-4 (AUTO) Always Below 1 ohms K4-5 (E) - Body ground Always Below 1 ohms K4-8 (LED) - K3-5 (LED) Always Below 1 ohms K4-10 (D) - K3-7 (DWN1) Always Below 1 ohms K3-1 (E) - Body ground Always Below 1 ohms K4-2 (U) - Body ground Always 10 kohms or higher K4-4 (A) - Body ground Always 10 kohms or higher K4-8 (LED) - Body ground Always 10 kohms or higher K4-10 (D) - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition J4-2 (U) - J3-10 (UP1) Always Below 1 ohms J4-4 (A) - J3-4 (AUTO) Always Below 1 ohms J4-5 (E) - Body ground Always Below 1 ohms J4-8 (LED) - J3-5 (LED) Always Below 1 ohms J4-10 (D) - J3-7 (DWN1) Always Below 1 ohms J3-1 (E) - Body ground Always Below 1 ohms J4-2 (U) - Body ground Always 10 kohms or higher J4-4 (A) - Body ground Always 10 kohms or higher J4-8 (LED) - Body ground Always 10 kohms or higher J4-10 (D) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> END
Note. When using Techstream to troubleshoot the LIN communication line: Connect Techstream to the vehicle, and turn the courtesy light switch on and off at 1.5 second intervals until communication between the tester and vehicle begins.
