Interior: Removal & Installation Lexus ES XV40

Exterior/interior Trim 60 illustrations ~3621 words

INSTALLATION

  1. INSTALL REAR SUNSHADE RELAY NOTE: When reassembling the rear sunshade assembly, eliminate static electricity by touching the vehicle body to prevent the components from being damaged. Install the rear sunshade relay with the 2 screws. Connect the connector. Engage the 4 claws and install the rear sunshade relay cover. Install the screw.
  2. INSTALL REAR WINDOW SHADE ASSEMBLY Install the rear window shade assembly, and temporarily tighten the 4 bolts < A > and bolt < B >. Fully tighten the 5 bolts. Connect the connector.
  3. INSTALL NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY Engage the 6 claws and 3 clips, and install the No. 2 package tray trim panel assembly.
  4. INSTALL CENTER STOP LIGHT SET ( «INSTALLATION»(ref-283105-S36778177742008041700000) )
  5. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY Thread the 3 rear seat belt floor anchors into the package tray trim panel assembly. Insert the rear end of the package tray trim panel assembly into the rear window shade assembly. Engage the 2 clips and install the package tray trim panel assembly.
  6. INSTALL REAR SEAT SHOULDER BELT HOLE COVER ( «INSTALLATION»(ref-283085-S35330709052008041700000) )
  7. CONNECT REAR SEAT INNER WITH CENTER BELT ASSEMBLY RH ( «INSTALLATION»(ref-283085-S35330709052008041700000) )
  8. CONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH ( «INSTALLATION»(ref-283085-S35330709052008041700000) )
  9. CONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH ( «INSTALLATION»(ref-283085-S35330709052008041700000) )
  10. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH ( «INSTALLATION»(ref-283110-S31613301962008041700000) )
  11. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH ( «INSTALLATION»(ref-283110-S31613301962008041700000) )
  12. INSTALL REAR SEAT SIDE GARNISH LH (w/o Rear Seat Side Airbag) ( «INSTALLATION»(ref-283110-S31613301962008041700000) )
  13. INSTALL REAR SEAT SIDE AIRBAG ASSEMBLY LH (w/ Rear Seat Side Airbag) ( «INSTALLATION»(ref-283084-S18648232732008041700000) )
  14. INSTALL REAR SEAT SIDE GARNISH RH (w/o Rear Seat Side Airbag) ( «INSTALLATION»(ref-283110-S31613301962008041700000) )
  15. INSTALL REAR SEAT SIDE AIRBAG ASSEMBLY RH (w/ Rear Seat Side Airbag) HINT: Use the same procedure for the LH side and RH side.
  16. INSTALL REAR DOOR SCUFF PLATE LH ( «INSTALLATION»(ref-283110-S31613301962008041700000) )
  17. INSTALL REAR DOOR SCUFF PLATE RH ( «INSTALLATION»(ref-283110-S31613301962008041700000) )
  18. INSTALL REAR SEATBACK ASSEMBLY ( «INSTALLATION»(ref-283115-S15106762642008041700000) )
  19. INSTALL REAR CENTER SEAT HEADREST ASSEMBLY
  20. INSTALL REAR SEAT HEADREST ASSEMBLY
  21. INSTALL REAR SEAT CUSHION ASSEMBLY ( «INSTALLATION»(ref-283115-S15106762642008041700000) )
  22. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL (w/ Rear Seat Side Airbag)
  23. PERFORM INITIALIZATION (w/ Rear Seat Side Airbag) NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal ( «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
  24. INSPECT SRS WARNING LIGHT (w/ Rear Seat Side Airbag) ( «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31: REMOVAL
Scheme 31: REMOVAL

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60
  1. REMOVE REAR SEAT CUSHION ASSEMBLY ( «REMOVAL»(ref-283115-S40416737822008041700000) )
  2. REMOVE REAR SEAT HEADREST ASSEMBLY
  3. REMOVE REAR CENTER SEAT HEADREST ASSEMBLY
  4. REMOVE REAR SEATBACK ASSEMBLY ( «REMOVAL»(ref-283115-S40416737822008041700000) )
  5. REMOVE SEAT BELT ANCHOR COVER CAP LH ( «REMOVAL»(ref-283085-S02151801352008041700000) )
  6. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY LH ( «REMOVAL»(ref-283085-S02151801352008041700000) )
  7. REMOVE FRONT SEAT HEADREST ASSEMBLY (for Driver Seat)
  8. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER LH ( «REMOVAL»(ref-283115-S37038451012008041700000) )
  9. REMOVE FRONT SEAT INNER TRACK BRACKET COVER LH ( «REMOVAL»(ref-283115-S37038451012008041700000) )
  10. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER LH ( «REMOVAL»(ref-283115-S37038451012008041700000) )
  11. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER LH ( «REMOVAL»(ref-283115-S37038451012008041700000) )
  12. REMOVE FRONT SEAT ASSEMBLY LH ( «REMOVAL»(ref-283115-S37038451012008041700000) )
  13. REMOVE SEAT BELT ANCHOR COVER CAP RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  14. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  15. REMOVE FRONT SEAT HEADREST ASSEMBLY (for Front Passenger Seat)
  16. REMOVE FRONT SEAT OUTER TRACK BRACKET COVER RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  17. REMOVE FRONT SEAT INNER TRACK BRACKET COVER RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  18. REMOVE FRONT SEAT REAR OUTER TRACK BRACKET COVER RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  19. REMOVE FRONT SEAT REAR INNER TRACK BRACKET COVER RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  20. REMOVE FRONT SEAT ASSEMBLY RH ( «REMOVAL»(ref-283084-S41465971342008041700000) )
  21. REMOVE FRONT DOOR SCUFF PLATE LH Disengage the 12 claws and remove the front door scuff plate LH.
  22. REMOVE FRONT DOOR OPENING TRIM COVER LH Disengage the 3 claws and remove the front door opening trim cover LH.
  23. REMOVE SIDE INSTRUMENT PANEL LH ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  24. REMOVE FRONT PILLAR GARNISH LH Pull the upper portion of the garnish towards the inside of the cabin and disengage the 2 clips. Cut off clip < A >. Disengage the claw and remove the front pillar garnish LH. Remove clip < A > from the vehicle body. Protect the curtain shield airbag assembly. Thoroughly cover the airbag with a cloth or nylon sheet and fix the ends of the cover with adhesive tape, as shown in the illustration. NOTE: Cover the curtain shield airbag with a protective cover as soon as the front pillar garnish is removed.
  25. REMOVE REAR DOOR SCUFF PLATE LH Disengage the 8 claws and remove the rear door scuff plate LH.
  26. REMOVE LOWER CENTER PILLAR GARNISH LH Disengage the 2 claws and 5 clips, and remove the lower center pillar garnish LH.
  27. REMOVE UPPER CENTER PILLAR GARNISH LH Remove the 2 screws. Pull the lower part of the pillar garnish toward the inside of the vehicle. Using a clip remover, disengage the clip and remove the upper center pillar garnish LH.
  28. REMOVE REAR SEAT SIDE GARNISH LH (w/o Rear Seat Side Airbag) Disengage the 4 claws and rear seat side garnish LH.
  29. REMOVE REAR SEAT SIDE AIRBAG ASSEMBLY LH (w/ Rear Seat Side Airbag) ( «INSTALLATION»(ref-283084-S18648232732008041700000) )
  30. REMOVE ROOF SIDE INNER GARNISH ASSEMBLY LH Disengage the 5 clips and claw, and remove the roof side inner garnish assembly LH.
  31. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
  32. REMOVE FRONT DOOR OPENING TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
  33. REMOVE SIDE INSTRUMENT PANEL RH ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  34. REMOVE FRONT PILLAR GARNISH RH Pull the upper portion of the garnish towards the inside of the cabin and disengage the 2 clips. Cut off clip < A >. Disengage the claw and remove the front pillar garnish RH. Remove the clip < A > from the vehicle body. Protect the curtain shield airbag assembly. Thoroughly cover the airbag with a cloth or nylon sheet and fix the ends of the cover with adhesive tape, as shown in the illustration. NOTE: Cover the curtain shield airbag with a protective cover as soon as the front pillar garnish is removed.
  35. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
  36. REMOVE LOWER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  37. REMOVE UPPER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  38. REMOVE REAR SEAT SIDE GARNISH RH (w/o Rear Seat Side Airbag) HINT: Use the same procedure for the RH side and the LH side.
  39. REMOVE REAR SEAT SIDE AIRBAG ASSEMBLY RH (w/ Rear Seat Side Airbag) HINT: Use the same procedure for the RH side and the LH side.
  40. REMOVE ROOF SIDE INNER GARNISH ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  41. REMOVE INSTRUMENT PANEL FINISH PANEL END LH ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  42. REMOVE INSTRUMENT PANEL FINISH PANEL END RH ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  43. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  44. REMOVE UPPER CONSOLE PANEL ASSEMBLY WITH FRONT ASH RECEPTACLE ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  45. REMOVE HEATER SEAT SWITCH CONSOLE BASE (w/o Seat Heater System) ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  46. REMOVE HEATER SEAT SWITCH CONSOLE BASE (w/ Seat Heater System) ( «REMOVAL»(ref-283109-S39106719462008041700000) )
  47. REMOVE CONSOLE BOX POCKET ( «REMOVAL»(ref-283109-S29948361472008041700000) )
  48. REMOVE CONSOLE BOX CARPET ( «REMOVAL»(ref-283109-S29948361472008041700000) )
  49. REMOVE CONSOLE REAR END PANEL SUB-ASSEMBLY ( «REMOVAL»(ref-283109-S29948361472008041700000) )
  50. REMOVE REAR CONSOLE BOX ASSEMBLY ( «REMOVAL»(ref-283109-S29948361472008041700000) )
  51. REMOVE NO. 2 CONSOLE BOX DUCT ( «REMOVAL»(ref-283108-S41068793822008041700000) )
  52. REMOVE NO. 3 CONSOLE BOX DUCT ( «REMOVAL»(ref-283108-S41068793822008041700000) )
  53. DISCONNECT TRANSMISSION CONTROL CABLE ASSEMBLY ( «ON-VEHICLE INSPECTION»(ref-283092-S15604745822008041700000) )
  54. REMOVE SHIFT LEVER ASSEMBLY ( «DISASSEMBLY»(ref-283092-S20923912352008041700000) )
  55. REMOVE FLOOR CARPET BRACKET LH ( «REMOVAL»(ref-283108-S41068793822008041700000) )
  56. REMOVE FLOOR CARPET BRACKET RH ( «REMOVAL»(ref-283108-S41068793822008041700000) )
  57. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (w/ DVD Player)
  58. REMOVE SPARE WHEEL COVER TRAY (w/ DVD Player)
  59. REMOVE LUGGAGE HOLD BELT STRIKER ASSEMBLY (w/ DVD Player) ( «ON-VEHICLE INSPECTION»(ref-283122-S14482357792008041700000) )
  60. REMOVE NO. 1 LUGGAGE COMPARTMENT TRIM HOOK (w/ DVD Player) ( «DISASSEMBLY»(ref-283122-S28841380792008041700000) )
  61. REMOVE REAR FLOOR FINISH PLATE (w/ DVD Player) ( «DISASSEMBLY»(ref-283122-S28841380792008041700000) )
  62. REMOVE LUGGAGE COMPARTMENT INNER TRIM COVER RH (w/ DVD Player) ( «DISASSEMBLY»(ref-283122-S28841380792008041700000) )
  63. DISCONNECT STEREO COMPONENT AMPLIFIER ASSEMBLY CONNECTOR (w/ DVD Player) Disconnect the stereo component amplifier assembly connector.
  64. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER ( «REMOVAL»(ref-283127-S11090645222008041700000) )
  65. REMOVE RAIN SENSOR COVER (w/ Rain Sensor) ( «REMOVAL»(ref-283123-S00938566512008041700000) )
  66. REMOVE ROOF CONSOLE BOX ASSEMBLY Using a screwdriver, disengage the 2 claws and open the 2 covers. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Using a moulding remover, disengage the 2 clips. Disconnect the connectors and remove the roof console box assembly.
  67. REMOVE VISOR BRACKET COVER Using a moulding remover, disengage the 4 claws and remove the visor bracket cover. HINT: Use the same procedure to remove the cover on the other side.
  68. REMOVE VISOR ASSEMBLY LH Remove the 2 screws and visor assembly LH.
  69. REMOVE VISOR ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  70. REMOVE VISOR HOLDER Remove the visor holder by turning it counterclockwise. HINT: Use the same procedure to remove the hook on the other side.
  71. REMOVE COAT HOOK Remove the screw and coat hook. HINT: Use the same procedure to remove the coat hook on the other side.
  72. REMOVE SPOT LIGHT ASSEMBLY (for Standard) Using a moulding remover, disengage the 2 clips. Disconnect the connector and remove the spot light assembly.
  73. REMOVE SPOT LIGHT ASSEMBLY (for Glass Roof) Using a moulding remover, disengage the 2 clips. Disconnect the connector and remove the spot light assembly.
  74. REMOVE ASSIST GRIP SUB-ASSEMBLY Using a screwdriver, disengage the 4 claws and remove the 2 assist grip covers. HINT: Tape the screwdriver tip before use. Disengage the 2 clips and remove the assist grip sub-assembly. HINT: Use the same procedure for the other 3 assist grips.
  75. REMOVE ROOF HEADLINING ASSEMBLY (for Standard) Disconnect the No. 1 roof wire connector and disengage each clamp from the front pillar LH. Disconnect the antenna cord sub-assembly connector and disengage each clamp from the front pillar RH. Disconnect the antenna cord sub-assembly connector and disengage the clamp from the rear pillar RH. Disengage the 12 claws, 4 clips, and 11 fasteners. Remove the roof headlining assembly from the vehicle through the front right door.
  76. REMOVE ROOF HEADLINING ASSEMBLY (for Glass Roof) Disconnect the No. 1 roof wire connector and disengage each clamp from the front pillar LH. Disconnect the antenna cord sub-assembly connector and disengage the clamp from the rear pillar RH. Disengage the 12 claws, 4 clips, and 21 fasteners. Remove the roof headlining assembly from the vehicle through the front right door.
  77. REMOVE ANTENNA CORD SUB-ASSEMBLY ( «REMOVAL»(ref-283118-S00714397192008041700000) )
  78. REMOVE VANITY LIGHT ASSEMBLY Disengage the 2 claws and separate the bulb holder from the vanity light assembly as shown in the illustration. Disengage the claw and remove the vanity light assembly. HINT: Use the same procedure to remove the light on the other side.
  79. REMOVE NO. 1 ROOF WIRE (for Standard) Turn the visor connectors clockwise approximately 90° and separate the connectors from the roof headlining assembly. Remove the adhesive tape from the roof headlining assembly. Remove the No. 1 roof wire from the roof headlining assembly. Remove the double-sided tape from the roof headlining assembly.
  80. REMOVE NO. 1 ROOF WIRE (for Glass Roof) Turn the visor connectors clockwise approximately 90° and separate the connectors from the roof headlining assembly. Remove the adhesive tape from the roof headlining assembly. Remove the No. 1 roof wire from the roof headlining assembly. Remove the double-sided tape from the roof headlining assembly.

Scheme 61

Scheme 61: INSTALLATION
Scheme 61: INSTALLATION

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78
  1. INSTALL NO. 1 ROOF WIRE (for Standard) Apply new double-sided tape to the locations shown in the illustration while aligning the tape with the markings on the roof headlining. NOTE: Securely apply the double-sided tape to prevent the tape from being out of alignment and peeling off. Peel off the release paper from the double-sided tape. Attach the No. 1 roof wire along the double-sided tape so that the marking surface of the wire harness faces downward. NOTE: Securely attach the No. 1 roof wire. Failure to do so may cause abnormal noise. Turn the visor connectors clockwise approximately 90° to the connectors of the roof headlining. Apply adhesive tape to the locations shown in the illustration. HINT: As shown at point A in the illustration, line up and secure the reference tape of the wire harness to the tip of the roof headlining assembly.
  2. INSTALL NO. 1 ROOF WIRE (for Glass Roof) Apply new double-sided tape to the locations shown in the illustration while aligning the tape with the markings on the roof headlining. NOTE: Securely apply the double-sided tape to prevent the tape from being out of alignment and peeling off. Peel off the release paper from the double-sided tape. Attach the No. 1 roof wire along the double-sided tape so that the marking surface of the wire harness faces downward. NOTE: Securely attach the No. 1 roof wire. Failure to do so may cause abnormal noise. Turn the visor connectors clockwise approximately 90° to the connectors of the roof headlining. Apply adhesive tape to the locations shown in the illustration. HINT: As shown at point A in the illustration, line up and secure the reference tape of the wire harness to the tip of the roof headlining assembly.
  3. INSTALL VANITY LIGHT ASSEMBLY Install the vanity light to the roof headlining. Connect the 2 claws to install the bulb holder. HINT: Use the same procedure to install the light on the other side.
  4. INSTALL ANTENNA CORD SUB-ASSEMBLY ( «INSTALLATION»(ref-283118-S29304314512008041700000) )
  5. INSTALL ROOF HEADLINING ASSEMBLY (for Standard) Pull the roof headlining assembly into the vehicle through the front right door. Engage the 12 claws, 4 clips, and 11 fasteners. Connect the antenna cord sub-assembly connector and engage the clamp to the rear pillar RH. Connect the antenna cord sub-assembly connector and engage each clamp to the front pillar RH. Connect the No. 1 wire connector and engage each clamp to the front pillar LH.
  6. INSTALL ROOF HEADLINING ASSEMBLY (for Glass Roof) Pull the roof headlining assembly into the vehicle through the front right door. Engage the 12 claws, 4 clips, and 21 fasteners. Connect the antenna cord sub-assembly connector and engage the clamp to the rear pillar RH. Connect the antenna cord sub-assembly connector and engage each clamp to the front pillar RH. Connect the No. 1 wire connector and engage each clamp to the front pillar LH.
  7. INSTALL ASSIST GRIP SUB-ASSEMBLY Engage the 2 clips to an assist grip sub-assembly as shown in the illustration. Install the assist grip sub-assembly. Install the 2 assist grip covers to the assist grip sub-assembly. HINT: Use the same procedure for the other 3 assist grips.
  8. INSTALL SPOT LIGHT ASSEMBLY (for Standard) Connect the connector. Engage the 2 clips and install the spot light assembly.
  9. INSTALL SPOT LIGHT ASSEMBLY (for Glass Roof) Connect the connector. Engage the 2 clips and install the spot light assembly.
  10. INSTALL COAT HOOK Install the coat hook with the screw. HINT: Use the same procedure to install the hook on the other side.
  11. INSTALL VISOR HOLDER Set the claws of the visor holder as shown in the illustration. Engage the claws and install the visor holder. HINT: Use the same procedure to install the holder on the other side.
  12. INSTALL VISOR ASSEMBLY LH Install the visor assembly LH with the 2 screws.
  13. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  14. INSTALL VISOR BRACKET COVER Engage the 4 claws and install the visor bracket cover. HINT: Use the same procedure to install the cover on the other side.
  15. INSTALL ROOF CONSOLE BOX ASSEMBLY Connect the connector. Engage the 2 clips. Install the roof console box assembly with the 2 screws.
  16. INSTALL RAIN SENSOR COVER (w/ Rain Sensor) ( «INSTALLATION»(ref-283123-S18058778842008041700000) )
  17. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER ( «INSTALLATION»(ref-283127-S02177136522008041700000) )
  18. CONNECT STEREO COMPONENT AMPLIFIER ASSEMBLY CONNECTOR (w/ DVD Player) Connect the stereo component amplifier assembly connector.
  19. INSTALL LUGGAGE COMPARTMENT INNER TRIM COVER RH (w/ DVD Player) ( «REASSEMBLY»(ref-283122-S23367543842008041700000) )
  20. INSTALL REAR FLOOR FINISH PLATE (w/ DVD Player) ( «REASSEMBLY»(ref-283122-S23367543842008041700000) )
  21. INSTALL NO. 1 LUGGAGE COMPARTMENT TRIM HOOK (w/ DVD Player) ( «REASSEMBLY»(ref-283122-S23367543842008041700000) )
  22. INSTALL LUGGAGE HOLD BELT STRIKER ASSEMBLY (w/ DVD Player) ( «REASSEMBLY»(ref-283122-S23367543842008041700000) )
  23. INSTALL SPARE WHEEL COVER TRAY (w/ DVD Player)
  24. INSTALL LUGGAGE COMPARTMENT FLOOR MAT (w/ DVD Player)
  25. INSTALL FLOOR CARPET BRACKET LH
  26. INSTALL FLOOR CARPET BRACKET RH
  27. INSTALL SHIFT LEVER ASSEMBLY ( «INSTALLATION»(ref-283092-S20494244662008041700000) )
  28. CONNECT TRANSMISSION CONTROL CABLE ASSEMBLY ( «INSTALLATION»(ref-283092-S20494244662008041700000) )
  29. INSTALL NO. 2 CONSOLE BOX DUCT ( «INSTALLATION»(ref-283108-S27507012742008041700000) )
  30. INSTALL NO. 3 CONSOLE BOX DUCT ( «INSTALLATION»(ref-283108-S27507012742008041700000) )
  31. INSTALL REAR CONSOLE BOX ASSEMBLY ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  32. INSTALL CONSOLE REAR END PANEL SUB-ASSEMBLY ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  33. INSTALL CONSOLE BOX CARPET ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  34. INSTALL CONSOLE BOX POCKET ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  35. INSTALL HEATER SEAT SWITCH CONSOLE BASE (w/o Seat Heater System) ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  36. INSTALL HEATER SEAT SWITCH CONSOLE BASE (w/ Seat Heater System) ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  37. INSTALL UPPER CONSOLE PANEL ASSEMBLY WITH FRONT ASH RECEPTACLE ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  38. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  39. INSTALL INSTRUMENT PANEL FINISH PANEL END LH ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  40. INSTALL INSTRUMENT PANEL FINISH PANEL END RH ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  41. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH Engage the claw and 5 clips, and install the roof side inner garnish assembly LH.
  42. INSTALL REAR SEAT SIDE GARNISH LH (w/o Rear Seat Side Airbag) Install the 4 claws and install the rear seat side garnish LH.
  43. INSTALL REAR SEAT SIDE AIRBAG ASSEMBLY LH (w/ Rear Seat Side Airbag) ( «INSTALLATION»(ref-283084-S18648232732008041700000) )
  44. INSTALL UPPER CENTER PILLAR GARNISH LH Engage the clip. Install the upper center pillar garnish LH with the 2 screws.
  45. INSTALL LOWER CENTER PILLAR GARNISH LH Engage the 5 clips and 2 claws, and install the lower center pillar garnish LH.
  46. INSTALL REAR DOOR SCUFF PLATE LH Engage the 8 claws, then install the rear door scuff plate LH.
  47. INSTALL FRONT PILLAR GARNISH LH Remove the protective cover. Install a new clip < A > on the front pillar garnish LH. Engage the claw and 2 clips, then install the front pillar garnish LH.
  48. INSTALL SIDE INSTRUMENT PANEL LH ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  49. INSTALL FRONT DOOR OPENING TRIM COVER LH Engage the 3 claws and install the front door opening trim cover LH.
  50. INSTALL FRONT DOOR SCUFF PLATE LH Engage the 12 claws, and install the front door scuff plate LH.
  51. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
  52. INSTALL REAR SEAT SIDE GARNISH RH (w/o Rear Seat Side Airbag) HINT: Use the same procedure for the RH side and the LH side.
  53. INSTALL REAR SEAT SIDE AIRBAG ASSEMBLY RH (w/ Rear Seat Side Airbag) HINT: Use the same procedure for the RH side and the LH side.
  54. INSTALL UPPER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  55. INSTALL LOWER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  56. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
  57. INSTALL FRONT PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
  58. INSTALL SIDE INSTRUMENT PANEL RH ( «INSTALLATION»(ref-283109-S06931105292008041700000) )
  59. INSTALL FRONT DOOR OPENING TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
  60. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
  61. INSTALL FRONT SEAT ASSEMBLY LH ( «INSTALLATION»(ref-283115-S30488853982008041700000) )
  62. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER LH ( «INSTALLATION»(ref-283115-S30488853982008041700000) )
  63. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER LH ( «INSTALLATION»(ref-283115-S30488853982008041700000) )
  64. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER LH ( «INSTALLATION»(ref-283115-S30488853982008041700000) )
  65. INSTALL FRONT SEAT INNER TRACK BRACKET COVER LH ( «INSTALLATION»(ref-283115-S30488853982008041700000) )
  66. CONNECT FRONT SEAT OUTER BELT ASSEMBLY LH ( «INSTALLATION»(ref-283085-S41824513002008041700000) )
  67. INSTALL SEAT BELT ANCHOR COVER CAP LH ( «INSTALLATION»(ref-283085-S41824513002008041700000) )
  68. INSTALL FRONT SEAT HEADREST ASSEMBLY (for Driver Seat)
  69. INSTALL FRONT SEAT ASSEMBLY RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  70. INSTALL FRONT SEAT REAR OUTER TRACK BRACKET COVER RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  71. INSTALL FRONT SEAT REAR INNER TRACK BRACKET COVER RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  72. INSTALL FRONT SEAT OUTER TRACK BRACKET COVER RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  73. INSTALL FRONT SEAT INNER TRACK BRACKET COVER RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  74. CONNECT FRONT SEAT OUTER BELT ASSEMBLY RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  75. INSTALL SEAT BELT ANCHOR COVER CAP RH ( «INSTALLATION»(ref-283084-S01046447322008041700000) )
  76. INSTALL FRONT SEAT HEADREST ASSEMBLY (for Front Passenger Seat)
  77. INSTALL REAR SEATBACK ASSEMBLY ( «INSTALLATION»(ref-283115-S15106762642008041700000) )
  78. INSTALL REAR CENTER SEAT HEADREST ASSEMBLY
  79. INSTALL REAR SEAT HEADREST ASSEMBLY
  80. INSTALL REAR SEAT CUSHION ASSEMBLY ( «INSTALLATION»(ref-283115-S15106762642008041700000) )
  81. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal ( «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
  82. INSPECT SHIFT LEVER POSITION ( «ADJUSTMENT»(ref-283092-S33659894002008041700000) )
  83. ADJUST SHIFT LEVER POSITION ( «ADJUSTMENT»(ref-283092-S33659894002008041700000) )
  84. INSPECT FRONT SEAT ASSEMBLY ( «INSTALLATION»(ref-283115-S30488853982008041700000) )
  85. INSPECT SRS WARNING LIGHT ( «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) )

More articles — Interior
