PRECAUTION
Note. Some systems need to be initialized after reconnecting the negative (-) battery terminal ( INITIALIZATION ).
Scheme 79
Scheme 80
Scheme 81
Communication table
| Sender | Receiver | Signal | Line |
|---|---|---|---|
| Park/Neutral Position Switch | ECM | Park/neutral position switch shift position signal | |
| Combination Meter | ECM | Speed signal | |
| ECM | Main Body ECU | Park/neutral position switch shift position signal Speed signal | CAN |
| Main Body ECU | Rear Sunshade Relay | Park/neutral position switch shift position signal | |
| Rear Sunshade Switch | Rear Sunshade Relay | Rear sunshade OPEN/CLOSE signal |
COMMUNICATION REFERENCE
CUSTOMIZE PARAMETERS
- CUSTOMIZING FUNCTION WITH INTELLIGENT TESTER (REFERENCE) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. OTHERS CUSTOMIZE PARAMETERS SPECIFICATION System Default Contents Selection R OUTPUT TIME 0.7 sec. Function to change the time before reverse-linked sunshade lowering function is activated 0/0.7/0.9/1.2 R-SHADE REVERSE AVAIL NOT AVL/AVAIL of the rear sunshade reverse function NOT AVL/AVAIL
