PRECAUTION
- WHEN DISCONNECTING CABLE FROM NEGATIVE AUXILIARY BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) auxiliary battery terminal, initialize the following system after the cable is reconnected. System Name See Procedure Parking Assist Monitor System Refer to «INITIALIZATION»(ref-568589-S03492911652013072300000) Power Door Lock Control System
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
| Component | Outline |
|---|---|
| Power switch Transponder key amplifier | Transmits the power switch signal to the power management control ECU. Informs the driver of the power source mode or system abnormality with the illumination stage of the indicator light. Receives the ID code and transmits it to the certification ECU (smart key ECU assembly) when the key battery is low. |
| Certification ECU | Performs key verification. Controls the electrical key antenna (outside), electrical key antenna (indoor) and door lock/unlock sensor. Receives the open signal from the back door opener switch and outputs a signal to the main body ECU via CAN communication. Outputs smart entry door lock/unlock commands. Transmits the gearshift control lock/unlock command signals to the transmission control ECU assembly. Outputs immobilizer set/unset commands. Controls the security indicator light and power switch indicator. Forms the smart entry detection area. |
| ID code box | Receives gearshift control unlock or engine immobilizer unset signals from the certification ECU (smart key ECU assembly), certifies them, and transmits each unset signal to transmission control ECU assembly or power management control ECU. |
| Power management control ECU | Changes the power source mode in 4 stages (off, on (ACC), on (IG), on (READY) in accordance with the shift state and stop light switch. Controls the push-button start function in accordance with signals received from switches and ECUs. The power management control ECU and certification ECU (smart key ECU assembly) permit starting of the hybrid control system after receiving an unlock signal from the transmission control ECU. |
| Transmission control ECU assembly | Locks/unlocks gearshift control based on lock/unlock request signals from the certification ECU (smart key ECU assembly). Detects gearshift control lock/unlock status and transmits it to other ECUs. Activates the shift control actuator based on signals from the power management control ECU when gearshift control is unlocked. Controls the application timing of current to the parking lock motor based on signals from the rotation angle sensor. |
| Combination meter | Operates various warnings (messages on the multi-information display, sounding of the buzzer in the combination meter, blinking or illumination of the master warning light) according to the command signals from the certification ECU (smart key ECU assembly). Displays information when the smart access system with push-button start has a malfunction. Outputs a vehicle speed signal to the main body ECU. |
| Security indicator light | Blinks when the engine immobilizer system is set (the hybrid control system cannot be started) according to certification ECU (smart key ECU assembly) control (immobilizer function). |
| IG, ACC relay | Turns on/off according to power management control ECU control and provides power to each system. |
| Stop light switch assembly | Detects that the brake pedal has been depressed (switch is on) and outputs a signal to the power management control ECU. |
| Front door outside handle assembly LH/RH | Sends request signals from the door electrical oscillator via the built-in electrical key antenna and forms the vehicle exterior detection area. Door lock sensor operation signals to the certification ECU (smart key ECU assembly) (entry lock function). Uses the built-in touch sensor to detect the operation of the front door outside handle assembly and sends signals to the certification ECU (smart key ECU assembly) (entry unlock function). |
| Door electrical oscillator | Sends request signals from the certification ECU (smart key ECU assembly) to the electrical key antenna built into the front door outside handle assembly. |
| No. 1 indoor electrical key antenna assembly (front floor) No. 2 indoor electrical key antenna assembly (center floor) | Sends the request code from the certification ECU (smart key ECU assembly) and forms the vehicle interior detection area. |
| No. 3 indoor electrical key antenna assembly (inside luggage) | Sends the request code from the certification ECU (smart key ECU assembly) and forms the luggage compartment interior detection area. |
| Electrical key antenna (outside luggage) | Sends the request code from the certification ECU (smart key ECU assembly) and forms the luggage compartment exterior detection area. |
| Back door opener switch | Sends switch operation signals to the certification ECU (smart key ECU assembly). |
| Door control receiver | Receives the smart access system with push-button start code/ wireless code sent from the key and sends it to the certification ECU (smart key ECU assembly). |
| Electrical key | Sends the ID code upon receiving a request signal. |
CUSTOMIZE PARAMETERS
- CUSTOMIZE SMART ACCESS SYSTEM WITH PUSH-BUTTON START (for Start Function) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Smart key/Access or Warning. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Ignition Available Area (Entry ignition available area) All Function that sets the area that the key must be in before the power switch can be operated. Front or All Certification ECU (smart key ECU assembly) Key Low Battery Warning (Warn when key battery becomes weak) ON Enables or disables the sounding of the buzzer when the key battery is low and the power switch is turned off after being on (IG) for 20 minutes or more. ON or OFF Certification ECU (smart key ECU assembly) Customizing with the multi-display (w/Navigation System (for HDD)) Turn the power switch on (IG). Enter the following menus: Setup / Vehicle / Vehicle Customization. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Access System with Elec. Key On Function that enables or disables the smart access system with push-button start. On or Off Certification ECU (smart key ECU assembly) Customizing with the Combination meter assembly (w/o Navigation System (for HDD)) HINT: Press and hold the DISP switch (steering pad switch assembly) when entering an item. Briefly press the DISP switch (steering pad switch assembly) when selecting an item. Turn the power switch on (IG). Enter the following menus: Settings / Vehicle Settings Select the setting by referring to the table below. Display Default Content Setting Relevant ECU ACCESS SYSTEM WITH ELEC. KEY ON Function that enables or disables the smart access system with push-button start. ON or OFF Certification ECU (smart key ECU assembly) Press and hold the DISP (steering pad switch assembly). The setting completion screen will be displayed. Return to the item selection screen. Entry cancel function (manual operation) NOTE: Because the key (for card type) does not have a wireless transmitter function, it cannot be used to change the entry unlock mode. HINT: While the smart access system with push-button start is canceled, it is possible to lock and unlock the doors with the wireless operation, and the start system can be operated by holding the key against the power switch. The following functions are disabled when the smart access system with push-button start is canceled. Entry unlock/lock functions Push start function Key lock-in prevention function Entry warning functions When canceling the system through manual operation: Make sure the following conditions are met: The power switch is off. The driver door is closed. The driver door is unlocked. Press the unlock button of the key. Open the driver door within 5 seconds of completing the step above (driver door: closed at beginning of step --> opened). With the driver door open, press the unlock button of the key 2 times within 5 seconds of completing the step above. NOTE: If the driver door is closed before or while pressing the unlock button, the entry cancel setting mode will end. Close and open the driver door twice within 30 seconds of completing the above step (driver door: open at beginning of step --> closed --> opened --> closed --> opened). With the driver door open, press the unlock button of the key 2 times within 30 seconds of completing the step above. NOTE: If the driver door is closed before or while pressing the unlock button, the entry cancel setting mode will end. Close and open the driver door within 30 seconds of completing the step above (driver door: open at beginning of step --> closed --> opened). Close the driver door within 5 seconds of completing the above step. Check that the wireless buzzer sounds twice (short beeps) to confirm that the smart access system with push-button start has been canceled. Perform the following procedure to restore the smart access system with push-button start to the active state from the canceled state. Perform the procedures to cancel the smart access system with push-button start again. Check that the wireless buzzer sounds once (short beep) to confirm that the smart access system with push-button start has been restored to the active state. HINT: The system changes between the canceled state and the active state each time the procedure to cancel the system through manual operation is performed. The buzzer sounds twice when the system changes from the active state to the canceled state, and sounds once when the system changes from the canceled state to the active state.
TERMINALS OF ECU
HINT
For the layout of the certification ECU (smart key ECU assembly) terminals, refer to the following. Refer to TERMINALS OF ECU .
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
- CHECK POWER MANAGEMENT CONTROL ECU Disconnect the A20, H3 and H4 connectors. Measure the voltage and resistance according to the value(s) in the table below. Tester Connection Input/Output Wiring Color Terminal Description Condition Specified Condition Related Data List Item A20-2 (IG2D) - Body ground Output V - Body ground IG2 signal 20°C (68°F) 131 to 230 ohms IG2 Relay Monitor (Outside) A20-23 (STP) - Body ground Input L - Body ground Stop light switch signal Brake pedal depressed --> Brake pedal released 9 V or higher --> 1 V or less Stop Light Switch1 H3-1 (AM22) - Body ground Input W - Body ground +B power supply Power switch off 9.5 to 14 V - H4-7 (AM21) - Body ground Input W - Body ground +B power supply Power switch off 9.5 to 14 V - H3-6 (E1) - Body ground - W-B - Body ground Ground Always Below 1 ohms - H4-4 (E12) - Body ground - W-B - Body ground Ground Always Below 1 ohms - H4-24 (CA1L) - Body ground Input/Output V - Body ground CAN communication line Always 10 kohms or higher - H4-25 (CA1H) - Body ground Input/Output P - Body ground CAN communication line Always 10 kohms or higher - H4-17 (SSW2) - Body ground Input Y - Body ground SSW2 contact signal (backup for SSW1 and has same behavior as SSW1) HINT: Backup for SSW1. Behaves the same way as SSW1. Power switch pushed --> Power switch not pushed Below 1 ohms --> 10 kohms or higher Start Switch2 H3-7 (SSW1) - Body ground Input B - Body ground SSW1 contact signal Power switch pushed --> Power switch not pushed Below 1 ohms --> 10 kohms or higher Start Switch1 H4-1 (ACCD) - Body ground Output G - Body ground ACC signal 20°C (68°F) 81.49 to 118.98 ohms ACC Relay Monitor H4-2 (IG1D) - Body ground Output B - Body ground IG1 signal 20°C (68°F) 54.32 to 79.32 ohms IG1 Relay Monitor (Outside) H4-11 (LIN2) - Body ground Input/Output B - Body ground LIN communication line Always 10 kohms or higher - If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the A20, H3 and H4 connectors. Measure the voltage and check for pulses according to the value(s) in the table below. Tester Connection Input/Output Wiring Color Terminal Description Condition Specified Condition Related Data List Item A20-2 (IG2D) - H3-6 (E1) Output V - W-B IG2 signal Power switch on (ACC) --> Power switch on (IG) 1 V or less --> 9 V or higher IG2 Relay Monitor (Outside) H3-9 (INDW) - H3-6 (E1) Output G - W-B Power switch indicator (orange) illumination output Brake pedal released, park (P) selected, power switch on (ACC), or on (IG) --> Other than previous condition 7 V or higher --> 1 V or less - A20-22 (PCON) - H3-6 (E1) Output LG - W-B P position signal Park (P) selected Pulse generation (See waveform 1 (Scheme 11) ) - A20-28 (PPOS) - H3-6 (E1) Input V - W-B P position signal Park (P) selected Pulse generation (See waveform 1 (Scheme 11) ) - H4-17 (SSW2) - H3-6 (E1) Output Y - W-B SSW2 contact signal (backup for SSW1 and has same behavior as SSW1) HINT: Backup for SSW1. Behaves the same way as SSW1. Power switch pushed --> Power switch not pushed 9 V or higher --> 1 V or less Start Switch2 H3-7 (SSW1) - H3-6 (E1) Output B - W-B Power switch signal Power switch pushed --> Power switch not pushed 9 V or higher --> 1 V or less Start Switch1 H4-1 (ACCD) - H3-6 (E1) Output G - W-B ACC signal Power switch off --> Power switch on (ACC) 1 V or less --> 8.5 V or higher ACC Relay Monitor H4-2 (IG1D) - H3-6 (E1) Output B - W-B IG1 signal Power switch on (ACC) --> Power switch on (IG) 1 V or less --> 9 V or higher IG1 Relay Monitor (Outside) H3-8 (INDS) - H3-6 (E1) Output R - W-B Power switch indicator (green) illumination output Brake pedal depressed, park (P) selected 7 V or higher - H3-14 (SPDI) - H3-6 (E1) Input V - W-B Vehicle speed signal Power switch on (IG), vehicle being driven at approx. 5 km/h (3 mph) Pulse generation (See waveform 2 (Scheme 12) ) Vehicle Speed Signal H4-20 (IMO) - H3-6 (E1) Output L - W-B ID code box communication input (Signal input from power management control ECU to ID code box) Power switch off 11 to 14 V Engine Start Request EFI Code Receive Within 3 seconds of hybrid control system start or within 3 seconds of power switch turned on (IG) after auxiliary battery cable disconnected and reconnected Pulse generation (See waveform 3 (Scheme 13) ) H4-21 (IMI) - H3-6 (E1) Input R - W-B ID code box communication output (Signal output from ID code box to power management control ECU) Power switch off 11 to 14 V Power switch on (IG) Pulse generation (See waveform 3 (Scheme 13) ) Using an oscilloscope, check the signal waveform of the ECU. Waveform 1 Tester Connection CH1: A20-22 (PCON) - H3-6 (E1) CH2: A20-28 (PPOS) - H3-6 (E1) Tool Setting 10 V/DIV., 10 ms./DIV. Vehicle Condition Power switch on (IG) Waveform 2 Tester Connection H3-14 (SPDI) - H3-6 (E1) Tool Setting 5 V/DIV., 10 ms./DIV. Vehicle Condition Driving at approx. 20 km/h (12 mph) HINT: The wavelength becomes shorter as the vehicle speed increases. Waveform 3 (Reference) TEXT IN ILLUSTRATION *a Approximately 160 ms *b Approximately 510 ms MEASUREMENT CONDITION Item Content Tester Connection H4-20 (IMO) - H3-6 (E1) Tool Setting 2 V/DIV., 200 ms./DIV. Condition Within 3 seconds of hybrid control system start or within 3 seconds of power switch turned on (IG) after auxiliary battery cable disconnected and reconnected Waveform 2 (Reference) TEXT IN ILLUSTRATION *a Approximately 160 ms *b Approximately 510 ms MEASUREMENT CONDITION Item Content Tester Connection H4-21 (IMI) - H3-6 (E1) Tool Setting 2 V/DIV., 200 ms./DIV. Condition Power switch on (IG)
