Battery, Mounting and Cables — Land Rover Range Rover L322 (2005-2009)

SPECIFICATIONS

Description	Nm
Battery clamp bolts	10
Battery terminal nuts	10
Battery tray bolts	12

TORQUE SPECIFICATIONS

Scheme 2

Scheme 2: BATTERY AND CABLES

Item Number	Description
1	Battery Junction Box (BJB)
2	+VE battery cable
3	VE battery cable
4	Battery

The 110 Ah/850 A EN battery is located in the engine compartment, on the passenger side. It sits in a tray and is secured with clamp plates and bolts.

The battery terminal posts allow for the battery cables to be connected with clamp type connections.

The battery is semi-sealed. Each casing has a vent to allow for thermal expansion and to vent oxygen and hydrogen gases, which are produced under certain charging conditions.

The battery incorporates an integral temperature compensated hydrometer to provide a visual indication of the relative density and level of the electrolyte. The indicator shows different colors to show battery condition as follows

GREEN - shows that the battery is charged and in a serviceable condition
DARK (turning to black) - shows that the battery is in a low state of charge and requires recharging
CLEAR or YELLOW - the battery is no longer serviceable and must be replaced.

If the battery shows CLEAR or YELLOW the battery has an internal fault. Do not attempt to charge or jump-start the vehicle with the battery in this condition.

When removing the battery, ensure the alarm is disarmed and the ignition is switched off. Always disconnect the negative terminal first and then the positive. When refitting the battery, always fit the positive terminal first followed by the negative.

If the battery requires recharging, always use an approved constant current charger, designed for lead-calcium batteries. DO NOT use a fast charger, as permanent damage to the battery may occur.

Scheme 3

Scheme 3: TRANSPORTATION CUT-OFF DEVICE

Item Number	Description
1	Electrical power disconnected
2	Electrical power connected

During production of the vehicle a transportation cut-off switch is connected in series between the battery negative terminal and the battery ground cable, to minimize battery drain during vehicle storage and delivery. The transportation cut-off switch provides a convenient method of disconnecting power from all of the electrical systems on the vehicle, but allows power to be easily restored to start and drive the vehicle during loading and unloading.

Operating the transportation cut-off switch generates fault codes in some system diagnostics. The fault codes are cleared, and the transportation cut-off switch is removed, during the Pre Delivery Inspection (PDI), prior to handover of the vehicle to the customer.

JUNCTION BOXES

A number of junction boxes are used to distribute power throughout the vehicle. For more information on fuse ratings and circuits protected, refer to the Electrical Circuit Diagrams.

AUXILIARY JUNCTION BOX

Note. The Auxiliary Junction Box (AJB) is fitted to diesel vehicles only.

The AJB is mounted on the engine bulkhead, behind the battery. The AJB receives its main power supply from the battery and provides circuit protection for the glowplug system.

BATTERY JUNCTION BOX

The battery junction box (BJB) is located in the e-box, on the right-hand (RH) side of the engine compartment. The battery junction box (BJB) receives its main power supply from the battery via the central junction box (CJB) and contains fusible links, blade fuses and relays.

CENTRAL JUNCTION BOX

The central junction box (CJB) is located behind the glove box and receives its main power supply from the battery. The central junction box (CJB) contains fusible links, blade fuses and relays. The central junction box (CJB) also provides the main power supply to the battery junction box (BJB) and the rear junction box.

REAR JUNCTION BOX

The rear junction box is located on the right-hand (RH) side of the luggage compartment, behind the side trim casing. The rear junction box contains blade fuses and relays, and receives its main power supply from the central junction box (CJB).

PRINCIPLES OF OPERATION

For a detailed description of the battery system and operation, refer to the relevant Description and Operation section of the workshop manual. REFER to: BATTERY AND CABLES

INSPECTION AND VERIFICATION

CAUTION

Diagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not guarantee confirmation of a fault and may also cause additional faults in the vehicle being checked and/or the donor vehicle.

Verify the customer concern.
Visually inspect for obvious signs of mechanical or electrical damage. Visual Inspection Mechanical Electrical Generator Drive belt Drive belt tensioner Generator pulley Check the security of the generator fixings Generator Battery Battery connections Starter motor Harnesses and connectors Fuses Charge warning lamp function Engine Control Module (ECM)
If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

DTC INDEX

Note. Generic scan tools may not read the codes listed, or may read only five digit codes. Match the five digits from the scan tool to the first five digits of the seven digit code listed to identify the fault (the last two digits give additional information read by the manufacturer-approved diagnostic system).

Note. When performing electrical voltage or resistance tests, always use a digital multimeter (DMM) accurate to three decimal places, and with an up-to-date calibration certificate. When testing resistance, always take the resistance of the DMM leads into account.

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

Note. If DTCs are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent concern may be the cause. Always check for loose connections and corroded terminals.

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to General Information

MIDTRONICS EXP-1080 USER GUIDE

Carry out the following

PINPOINT TEST A : VOLTAGE DROP TEST CONDITIONS DETAILS/RESULTS/ACTIONS NOTE: This test checks for high resistance between the battery terminal and the battery clamp 1 Start the engine, turn on the following: (1) Air conditioning (2) Blower fan on full speed (3) Headlights on main beam (4) Heated screen - rear (5) Heated screen - front (if installed) (6) Heated seats (if installed) 2 Connect the multimeter between the battery negative terminal and the battery clamp as shown in picture below (do not disconnect the battery at this stage) 3 Set the multimeter to read DC voltage and record the reading. Is reading equal to or below 0.1 volts? Yes GO to A2. No Switch all electrical loads and engine off, return the vehicle to an ignition off condition. Disconnect the battery negative clamp, clean clamp and terminal then reconnect and repeat test GO to A1. A2: POWER CIRCUIT NOTE: This test checks for high resistance between the battery terminal and the battery clamp 1 Start the engine, turn on the following: (1) Air conditioning (2) Blower fan on full speed (3) Headlights on main beam (4) Heated screen - rear (5) Heated screen - front (if installed) (6) Heated seats (if installed) 2 Connect the multimeter between the battery positive terminal and the battery clamp as shown in picture below (do not disconnect the battery at this stage) 3 Set the multimeter to read DC voltage and record the reading Is reading equal to or below 0.1 volts? Yes Carry out midtronics battery test procedure No Switch all electrical loads and engine off, return the vehicle to an ignition off condition. Disconnect the battery power clamp, clean clamp and terminal then reconnect and repeat test GO to A2

Scheme 4

Scheme 4: MIDTRONICS EXP-1080 USER GUIDE

Scheme 5

Reference	Description
1	LCD screen with main menu
2	Control panel (key board and power button)
3	Positive and negative fly leads
4	Fly leads connection
5	Temperature sensor
6	Infra-red sensor (data transfer for printer)
7	Amp hour
8	Battery rating (CCA)
9	Rating units
10	Battery type

Scheme 6

Scheme 7

Scheme 8

The following steps must be carried out to ensure correct operation of the EXP-1080 during the battery test procedure

Checks	Action
Battery fluid leakage, check for battery fluid leaks or damage to the battery casing	NOTE: If visible damage to the case is evident do not return battery under warranty Replace the battery if there is any battery fluid leaks evident
Battery vent pipe routing	Check for routing, ensure there are no kinks
EXP-1080 fly lead, condition of clamps	Clean or replace as required
EXP-1080 fly lead connection	Confirm secure connection

NOTE
If visible damage to the case is evident do not return battery under warranty

Note. The Midtronics EXP-1080 is suitable for testing flooded and absorbed glass mat (AGM) type batteries

Typical Values

Amp Hour	CCA (Cold Cranking Amps	Rating Units
12	200	EN
70	760	SAE
80	700	SAE
80	800	SAE
90	800	SAE
95	850	SAE
90	950	SAE
105	950	SAE

Midtronics Battery Test Procedure

This midtronics battery test procedure will confirm the serviceability of the battery

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. Connect the fly-lead to the midtronics EXP-1080
2. Connect the fly-leads to the battery terminals
Black lead to negative terminal
Red lead to positive terminal
Confirm the connections are secure
3. The EXP-1080 will power on automatically when connected to a battery, screen below is displayed NOTE: MAIN MENU SCREEN
4. Main Menu . Select Battery test and press SELECT NOTE: BATTERY LOCATION
5. Battery Location . Select either, Out of vehicle or In Vehicle as appropriate
Select Next NOTE: BATTERY RATING
6. BATTERY RATING . Select the correct battery rating from the pre-installed list, (Goto step 10). Or
To manually enter the correct battery type, specification and CCA rate. Scroll using the arrow keys on the midtronics panel and select Other from the menu
Select Next NOTE: BATTERY TYPE
7. Battery Type . Select the correct battery type ( Regular or AGM )
Select Next NOTE: RATING UNITS
8. Rating Units . Select the correct rating units. Refer to the battery label for correct specification. Options EN, DIN, SAE
Select Next NOTE: BATTERY RATING
9. BATTERY RATING . Scroll using the arrow keys on the midtronics panel, select the correct CCA rating (For CCA refer to battery label)
Select Next NOTE: TEMPERATURE NOTE: Ensure that the temperature sensor does not touch any part of the battery or vehicle, this will cause damage not be covered under the midtronics warranty and will require the unit to be returned to a service center
10. Temperature . Aim the temperature sensor towards the battery casing (Maintain distance of 5cm)
Select Next NOTE: TESTING
11. Testing . The screen displays clock hand's rotating, the EXP-1080 will automatically advance when test has completed NOTE: SURFACE CHARGE NOTE: If there is no surface charge this step will not show. Go to next step
11a. Surface Charge . Ensure the ignition state is on . Switch on the headlights (high beam) until EXP-1080 shows Turn off headlights then return ignition state to off NOTE: BATTERY CHARGE NOTE: If the state of charge is sufficient this step will not show. Go to next step
11b. Battery Charge . Select Before Charging if battery has not been on a recommended mains charger for a minimum of 6 hours
Select After Charging if battery has been on a recommended mains charger for a minimum of 6 hours NOTE: DEEP SCAN TECHNOLOGY NOTE: This test is automated and will show if required. Go to next step
12. Testing . The EXP-1080 will carry out the deep scan test, then automatically advance when test has completed Number Description 1 Battery test result 2 CCA (Measured capacity rating) 3 Voltage 4 CCA (Manually entered) 5 Temperature NOTE: RESULTS Test Result Action GOOD BATTERY Test complete no action required GOOD - RE-CHARGE Charge battery using a recommended mains charger (minimum 50 amp) until charging complete CHARGE AND RE-TEST Charge battery using a recommended mains charger (minimum 50 amp) until charging complete. Retest. If the result is the same replace battery REPLACE BATTERY / BAD CELL BATTERY Replace battery. Do Not Recharge UNABLE TO COMPLETE TEST Disconnect battery from vehicle and re-test NOTE: TEST CODE NOTE: Battery test code, must be given if a battery, starter motor or generator is exchanged under warranty NOTE: STATE OF HEALTH NOTE: General health of the battery and its ability to deliver its specified performance compared with a new battery NOTE: SOC (State Of Charge) NOTE: BATTERY STATE OF CHARGE
Results . From the result display use the arrow keys on the control panel to view the test code
The test code must be quoted with every battery claim under warranty

Flooded Battery Care Point

If the vehicle is equipped with a flooded battery, ensure the replacement battery is a flooded battery of the same specification (cold cranking amperage (CCA) / amp hour rating (Ah)) as the original battery

Under no circumstances should you fit a flooded battery to a vehicle that originally had an AGM battery, unless formally instructed by Jaguar/Land Rover

AGM Battery Care Point

If the vehicle is equipped with an absorbed glass mat (AGM) battery, ensure the replacement battery is a AGM battery of the same specification (cold cranking amperage (CCA) / amp hour rating (Ah)) as the original battery, unless formally instructed by Jaguar/Land Rover

REMOVAL
