SPECIFICATIONS

DescriptionNm
Plenum chamber nuts10
Battery positive cable to bulkhead20

TORQUE SPECIFICATION

Scheme 1

Scheme 1: AIR DISTRIBUTION AND FILTERING
Item NumberDescription
1Forced ventilation outlet
2Windshield duct
3Face level duct
4Front footwell duct
5Heater assembly
6Rear footwell duct
7Rear face duct
8Rear blower

GENERAL

The air distribution and filtering system controls the distribution and quality of air supplied to the vehicle interior. The system consists of

  1. Air ducts.
  2. Air registers and vents.
  3. A cabin air filter.

AIR DUCTS

Air from the heater assembly is distributed around the vehicle interior through distribution ducts to outlets in the instrument panel, the front and rear footwells, and the rear of the cubby box between the front seats.

Scheme 2

Scheme 2: AIR DUCTS

AIR REGISTERS AND VENTS

In the instrument panel, the air ducts are connected to fixed vents for the windshield and side windows and adjustable registers for face level air. An adjustable register is also installed on the rear of the cubby box for rear face level air. The footwell outlets are fixed vents formed in the end of the related air ducts.

Scheme 3

Scheme 3: CABIN AIR FILTER
Item NumberDescription
1Air outlet to heater assembly
2Fixing lug
3Door catch
4Door
5Particle or particle/odor filter
6Inlet grille
7Seal

The cabin air filter consists of a serviceable particle filter, or a particle/odor filter, which is installed in the air inlet duct.

The cabin air filter prevents odors and/or particulate matter from entering the vehicle with the fresh air.

Scheme 4

Scheme 4: REMOVAL

Scheme 5

Scheme 5
  1. Release the center registers. Carefully release the 4 internal clips, apply an even outward pressure until the last clip is released.
  2. Remove the center registers. Disconnect the 4 electrical connectors. Release the temperature blend door control cable.
  3. Remove the hazard flasher switch.

INSTALLATION

  1. Install the hazard flasher switch.
  2. Install the center registers. Attach the temperature blend door control cable. Connect the 4 electrical connectors. Position and secure the clips.

Scheme 6

Scheme 6: REMOVAL
  1. Remove the driver side register. Carefully release the 4 internal clips, apply an even outward pressure until the last clip is released. Disconnect the electrical connector.
  1. Install the driver side register. Connect the electrical connector. Position and secure the clips.

Scheme 7

Scheme 7: REMOVAL

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Remove the instrument panel end trim panel. Release sufficient door aperture seal for access. Carefully release the 4 clips.
  2. Remove the driver's side register. See «Driver Side Register»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  3. Remove the driver side register trim panel. Remove the 3 screws. Disconnect the headlamp switch electrical connector.
  4. Remove the headlamp switch. Carefully release the 4 clips.
  1. Install the headlamp switch.
  2. Install the driver side register trim panel. Connect the headlamp switch electrical connector. Install the 3 screws.
  3. Install the driver's side register. See «Driver Side Register»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  4. Install the instrument panel end trim panel. Carefully align and secure the clips. Install the aperture seal.

REMOVAL

  1. Remove the passenger side register. Carefully release the 4 internal clips, apply an even outward pressure until the last clip is released. Disconnect the electrical connector.
  1. Install the passenger side register. Connect the electrical connector. Position and secure the clips.
WARNINGPersons working on the supplemental restraint system (SRS) must be fully trained and have been issued with the safety guidelines.
WARNINGAllow a period of 10 minutes to elapse after disconnecting the battery before undertaking any work on the SRS.
WARNINGThe SRS electrical connectors are unique. DO NOT force, or attempt to connect electrical connectors to the wrong sockets.
WARNINGThe correct procedures must always be used when working on SRS components.
WARNINGIt is imperative that before any work is undertaken on the SRS system, the appropriate information is read thoroughly.
WARNINGAlways disconnect both battery cables before beginning work on the SRS system. Disconnect the ground cable first. Never reverse connect the battery.
WARNINGTake extra care when handling SRS components.

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
  2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  3. Remove the instrument panel end trim panel. Release sufficient door aperture seal for access. Carefully release the 4 clips. Disconnect the electrical connector from the passenger air bag deactivation switch.
  4. Remove the passenger side register. See «Passenger Side Register»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  5. Remove the passenger side register trim panel. Remove the 3 screws.
  1. Install the passenger side register trim panel. Install the 3 screws.
  2. Install the passenger side register. See «Passenger Side Register»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  3. Install the instrument panel end trim panel. Connect the passenger air bag deactivation switch electrical connector. Carefully align and secure the clips. Install the aperture seal.
  4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 12

Scheme 12: REMOVAL

Scheme 13

Scheme 13

Scheme 14

Scheme 14
  1. Secure the hood in the service position. Release the support struts.
  2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  3. Remove the hood seal from the plenum chamber.
  4. Remove the plenum chamber. Remove the 2 nuts. Vehicles with diesel engine only: Release the air conditioning (A/C) line bracket.
  5. Remove the pollen filter. Release the 4 clips. Release the pollen filter housing cover.
  1. Install the pollen filter. Secure the pollen filter housing cover.
  2. Install the plenum chamber. Vehicles with diesel engine only: Attach the A/C line bracket. Tighten the nuts to 10 Nm (7 lb.ft).
  3. Install the hood seal.
  4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  5. Connect the hood support struts.

Scheme 15

Scheme 15: REMOVAL
  1. Remove the upper center registers. Reposition the upper center registers towards the instrument panel. Release the 3 front clips. Release the 2 rear clips.
  1. Install the upper center registers. Secure the 5 clips.
