Air Conditioning Land Rover Range Rover L322

Automatic HVAC System 38 illustrations ~3251 words

SPECIFICATIONS

ItemSpecification
Compressor oil typeSanden SP-10 PAG oil
Compressor oil - vehicles fitted with 2 zone120 cm 3
Compressor oil - vehicles fitted with 4 zone170 cm 3

LUBRICANT

ItemSpecification
Refrigerant typeR134A
Air conditioning refrigerant - vehicles fitted with 2 zone700 grammes (24.69 ounces)
Air conditioning refrigerant - vehicles fitted with 4 zone880 grammes (31 ounces)

SYSTEM REFRIGERANT SPECIFICATION/CAPACITY

DescriptionNmLb-ft
Compressor mounting bolts2518
Compressor mounting bracket bolts
M8 bolt2518
M10 bolt4835
Accessory drive belt tensioner bolt
Vehicles fitted with M8 bolt2518
Vehicles fitted with M10 bolt4835
Refrigerant line to bulkhead bolts64
Thermostatic expansion valve (TXV) to refrigerant line clamp bolts54
Refrigerant line to compressor bolt2216
Refrigerant line to condenser107
Refrigerant liquid line to front evaporator bolts - vehicles fitted with 4 zone97
Refrigerant suction lines to front evaporator bolts - vehicles fitted with 4 zone1813
Refrigerant lines to rear evaporator bolts - vehicles fitted with 4 zone97

TORQUE SPECIFICATIONS

Scheme 16

Scheme 16: COMPONENT LOCATION - TdV8
Scheme 16: COMPONENT LOCATION - TdV8
Item NumberDescription
1Condenser
2High pressure servicing connection
3Refrigerant pressure sensor
4Low pressure servicing connection
5Thermostatic expansion valve
6Evaporator
7Air conditioning (A/C) compressor
8Receiver drier module

Scheme 17

Scheme 17: COMPONENT LOCATION - 4.2L/4.4L
Scheme 17: COMPONENT LOCATION - 4.2L/4.4L
Item NumberDescription
1Thermostatic expansion valve
2Evaporator
3Low pressure servicing connection
4A/C compressor
5Receiver drier module
6Condenser
7High pressure servicing connection
8Refrigerant pressure sensor (reference)

OVERVIEW

The air conditioning (A/C) system transfers heat from the vehicle interior to the outside atmosphere to provide the heater assembly with dehumidified cool air. The system is a sealed, closed loop, filled with a charge weight of R134a refrigerant as the heat transfer medium. Oil is added to the refrigerant to lubricate the internal components of the air conditioning (A/C) compressor.

To accomplish the transfer of heat, the refrigerant is circulated around the system, where it passes through 2 pressure/temperature regimes. In each of the pressure/temperature regimes, the refrigerant changes state, during which process maximum heat absorption or release occurs. The low pressure/temperature regime is from the thermostatic expansion valve, through the evaporator to the air conditioning (A/C) compressor; the refrigerant decreases in pressure and temperature at the thermostatic expansion valve, then changes state from liquid to vapor in the evaporator, to absorb heat. The high pressure/temperature regime is from the air conditioning (A/C) compressor, through the condenser and receiver drier to the thermostatic expansion valve; the refrigerant increases in pressure and temperature as it passes through the air conditioning (A/C) compressor, then releases heat and changes state from vapor to liquid in the condenser.

Some vehicles may be fitted with a 4 zone climate control system. Refer to Auxiliary Climate Control .

A/C COMPRESSOR

The air conditioning (A/C) compressor circulates refrigerant around the system by compressing low pressure, low temperature vapor from the evaporator and discharging the resultant high pressure, high temperature vapor to the condenser. Although similar in appearance, the air conditioning (A/C) compressor installed on TdV8 vehicles differs slightly to the one installed on 4.2L and 4.4L vehicles.

Scheme 18

Scheme 18: A/C COMPRESSOR
Scheme 18: A/C COMPRESSOR
Item NumberDescription
1Pulley
2Clutch connector
3Outlet port
4Inlet port
5Pressure relief valve

Scheme 19

Scheme 19
Scheme 19
Item NumberDescription
1Pulley
2Electrical connector
3Inlet port
4Outlet port

The air conditioning (A/C) compressor fitted to both petrol and diesel vehicles is a variable displacement unit. The secondary accessory drive belt, driven by the engine crankshaft, drives the air conditioning (A/C) compressor via a pulley and an electromagnetic clutch. Operation of the clutch is controlled by a power feed from the automatic temperature control (ATC) module.

The air conditioning (A/C) compressor is a 7 cylinder swash plate unit with a minimum displacement of 5.5 cm 3 /rev (0.34 in 3 /rev) and maximum displacement of 163 cm 3 /rev (9.95 in 3 /rev). A control valve in the air conditioning (A/C) compressor automatically adjusts the displacement (i.e. flow of refrigerant), between the minimum and maximum values, to match the thermal load of the evaporator. By matching the refrigerant flow to the thermal load of the evaporator, the variable air conditioning (A/C) compressor maintains a relatively constant evaporator temperature of approximately 3 to 4°C (37 to 39°F).

To protect the refrigerant system from unacceptably high pressure, a pressure relief valve is installed in the outlet side of the air conditioning (A/C) compressor. The pressure relief valve is set to open at 3.5 to 4.1 MPa (508 to 595 lbf/in 2 ) and vents excess pressure into the engine compartment. The pressure relief valve closes again when the pressure decreases to 3.01 MPa (437 lbf/in 2 ).

The clutch of the air conditioning (A/C) compressor incorporates a thermal cut-off fuse, which disconnects the power feed from the automatic temperature control (ATC) module if the temperature increases to 182 ± 5 °C (360 ± 9 °F).

Scheme 20

Scheme 20: CONDENSER AND RECEIVER DRIER
Scheme 20: CONDENSER AND RECEIVER DRIER
Item NumberDescription
1Cap
2Spring clip
3Sealing plug
4Desiccant module
5Condenser
6Outlet pipe
7Inlet pipe
Item NumberDescription
1Right-hand (RH) end tank
2Condenser core
3Left-hand (LH) end tank
4High pressure line connector block
5Condenser attachment brackets
6Receiver drier pipes
7Receiver drier attachment bracket
Item NumberDescription
1Receiver Drier
2Clamp
3Condenser RH end tank
4O-ring seals
5Inlet pipe
6Outlet pipe
7Collar
8Bolt

The condenser transfers heat from the refrigerant to the surrounding air to convert the vapor from the air conditioning (A/C) compressor into a liquid. A receiver drier module, integrated onto the left-hand (LH) side of the condenser, incorporates a filter and a desiccant to remove solid impurities and moisture from the refrigerant. The receiver drier module also functions as a reservoir for liquid refrigerant, to accommodate changes of heat load at the evaporator.

The condenser is installed immediately in front of the radiator.

The condenser is classified as a sub-cooling condenser and consists of a fin and tube heat exchanger installed between two end tanks.

4.2L AND 4.4L

Divisions in the end tanks separate the heat exchanger into a three pass upper (condenser) section and a single pass lower (sub-cooler) section, which are interconnected by the receiver drier module. The desiccant cluster and the filter in the receiver drier module are serviceable items retained in position by a threaded plug.

TDV8

Divisions in the end tanks separate the heat exchanger into a four pass upper (condenser) section and a two pass lower (sub-cooler) section. A connector block on the left end tank of the condenser provides connections for the high pressure lines from the A/C (air conditioning) compressor and the evaporator. Two pipes at the bottom of the right end tank of the condenser provide connections for the receiver drier.

THERMOSTATIC EXPANSION VALVE

The thermostatic expansion valve meters the flow of refrigerant into the evaporator, to match the refrigerant flow with the heat load of the air passing through the evaporator matrix.

The temperature and pressure of the refrigerant leaving the evaporator act on the thermostatic expansion valve to control the volume of refrigerant flowing through the evaporator. The warmer the air flowing through the evaporator matrix, the more heat available to evaporate refrigerant and thus the greater the volume of refrigerant allowed through the metering valve.

Scheme 21

Scheme 21: EVAPORATOR
Scheme 21: EVAPORATOR
Item NumberDescription
1Insulated connecting pipes
2Thermostatic expansion valve
3Evaporator

The evaporator is installed in the heater assembly between the blower and the heater matrix, to absorb heat from the exterior or recirculated air. Low pressure, low temperature refrigerant changes from liquid to vapor in the evaporator, absorbing large quantities of heat as it changes state.

Most of the moisture in the air passing through the evaporator condenses into water, which drains through the floorpan to the underside of the vehicle through two drain tubes.

REFRIGERANT LINES

To maintain similar flow velocities around the system, the diameter of the refrigerant lines varies to suit the two pressure/temperature regimes. The larger diameters are installed in the low pressure/temperature regime and the smaller diameters are installed in the high pressure/temperature regime.

Low and high pressure charging connections are incorporated into the refrigerant lines near the front RH corner of the engine compartment.

CONTROL DIAGRAM

Item NumberDescription
1Evaporator
2Thermostatic expansion valve
3Desiccant (in modulator)
4Filter (in modulator)
5Electric cooling fan
6Refrigerant pressure sensor
7Condenser
8A/C compressor
9High pressure servicing connection
10Low pressure servicing
11Blower
12Air flows: Ambient air flow through condenser
13Fresh/Recirculated air flow through blower
14Cooled air flow to vehicle interior

Note. A = Refrigerant liquid; B = Refrigerant vapor

Scheme 22

Scheme 22: REMOVAL
Scheme 22: REMOVAL

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Recover the air conditioning (A/C) refrigerant. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  3. Remove the air cleaner. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
  4. Disconnect the A/C clutch electrical connector.
  5. Disconnect the refrigerant lines from the A/C compressor. Remove the 2 bolts. Remove and discard the 2 O-ring seals.
  6. Raise and support the vehicle.
  7. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  8. Release the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Release the accessory drive belt from the power steering pump pulley.
  9. Release the A/C compressor. Fully loosen the upper front bolt. Remove the remaining 2 bolts.
  10. Reposition the A/C compressor mounting bracket. Remove the 2 bolts.
  11. Remove the A/C compressor. Remove the bolt.

INSTALLATION

  1. Install the A/C compressor. Install the upper front bolt.
  2. Secure the A/C compressor mounting bracket. Tighten the bolts to 25 Nm (18 lb.ft).
  3. Secure the A/C compressor. Tighten the bolts to 25 Nm (18 lb.ft).
  4. Secure the accessory drive belt. Rotate the tensioner assembly counter-clockwise.
  5. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  6. Connect the refrigerant lines to A/C compressor. Clean the component mating faces. Install the new O-ring seals. Tighten the bolts to 10 Nm (7 lb.ft).
  7. Connect the A/C clutch electrical connector.
  8. Install the air cleaner. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
  9. Recharge the A/C system. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  10. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

REMOVAL

  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Recover the air conditioning (A/C) refrigerant. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  3. Remove the air cleaner. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
  4. Disconnect the A/C clutch electrical connector.
  5. Disconnect the refrigerant lines from the A/C compressor. Remove the 2 bolts. Remove and discard the 2 O-ring seals.
  6. Raise and support the vehicle.
  7. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  8. Release the accessory drive belt. Rotate the tensioner assembly counter-clockwise. Release the accessory drive belt from the power steering pump pulley.
  9. Release the A/C compressor. Fully loosen the upper front bolt. Remove the remaining 2 bolts.
  10. Reposition the A/C compressor mounting bracket. Remove the 2 bolts.
  11. Remove the A/C compressor. Remove the bolt.
  1. Install the A/C compressor. Install the upper front bolt.
  2. Secure the A/C compressor mounting bracket. Tighten the bolts to 25 Nm (18 lb.ft).
  3. Secure the A/C compressor. Tighten the bolts to 25 Nm (18 lb.ft).
  4. Secure the accessory drive belt. Rotate the tensioner assembly counter-clockwise.
  5. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  6. Connect the refrigerant lines to A/C compressor. Clean the component mating faces. Install the new O-ring seals. Tighten the bolts to 10 Nm (7 lb.ft).
  7. Connect the A/C clutch electrical connector.
  8. Install the air cleaner. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-44l) .
  9. Recharge the A/C system. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  10. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

ALL VEHICLES

Scheme 27

Scheme 27: REMOVAL
Scheme 27: REMOVAL

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Recover the air conditioning (A/C) refrigerant. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  3. Raise and support the vehicle.
  4. Remove the power steering pump. Refer to «Power Steering Pump - 3.6L (TdV8) Diesel»(/land-rover/range-rover/l322-2005-2009/remont/manual-power-steering/#power-steering) .
  5. Remove the accessory drive belt idler pulley. Refer to «Accessory Drive Belt Idler Pulley»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-42l) or Refer to «Accessory Drive Belt Idler Pulley»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-44l) .
  6. Disconnect the A/C compressor electrical connector.
  7. Disconnect the A/C compressor low-pressure refrigerant line. Remove the 2 bolts. Remove the bracket. Remove and discard the O-ring seal.
  8. Disconnect the A/C compressor high-pressure refrigerant line. Remove the bolt. Remove and discard the O-ring seal.
  9. Remove the LH front wheel and tire. Refer to «Wheel and Tire»(/land-rover/range-rover/l322-2005-2009/remont/wheel-tire-system/#wheels-and-tires) .
  10. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) . LEFT-HAND DRIVE VEHICLES
  11. Release the universal joint from the steering gear. Remove and discard the bolt.
  12. Disconnect the steering gear electrical connector.
  13. Reposition the steering gear. Remove and discard the 2 bolts. Remove and discard the 2 nuts.
  14. Disconnect the charge air cooler LH inlet hose. Release the clip.
  15. Remove the A/C compressor rear bolt.
  16. Remove the A/C compressor. Remove the 2 bolts.
  17. Remove the A/C compressor low-pressure refrigerant line. Remove the bolt. Remove and discard the O-ring seal.
  1. Install the A/C compressor low-pressure refrigerant line. Install a new O-ring seal. Tighten the bolt to 23 Nm (17 lb.ft).
  2. Install the A/C compressor. Loosely install the 2 A/C compressor front bolts.
  3. Install the A/C compressor rear bolt. Tighten the bolt to 23 Nm (17 lb.ft).
  4. Connect the charge air cooler LH inlet hose. Tighten the clip.
  5. Reposition the steering gear. Install the bolts. Tighten the new nuts to 100 Nm (74 lb.ft).
  6. Connect the steering gear electrical connector.
  7. Connect the universal joint to the steering gear. Tighten the new bolt to 24 Nm (18 lb.ft).
  8. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  9. Install the LH front wheel and tire. Refer to «Wheel and Tire»(/land-rover/range-rover/l322-2005-2009/remont/wheel-tire-system/#wheels-and-tires) .
  10. Tighten the A/C compressor front bolts to 23 Nm (17 lb.ft).
  11. Connect the A/C compressor refrigerant lines. Install new O-ring seals. Install the bracket. Tighten the bolts to 23 Nm (17 lb.ft).
  12. Connect the A/C compressor electrical connector.
  13. Install the accessory drive belt idler pulley. Refer to «Accessory Drive Belt Idler Pulley»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-42l) or Refer to «Accessory Drive Belt Idler Pulley»(/land-rover/range-rover/l322-2005-2009/remont/accessory-drive-belts/#accessory-drive-44l) .
  14. Install the power steering pump. Refer to «Power Steering Pump - 3.6L (TdV8) Diesel»(/land-rover/range-rover/l322-2005-2009/remont/manual-power-steering/#power-steering) .
  15. Recharge the A/C system. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  16. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 37

Scheme 37: REMOVAL
Scheme 37: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Raise and support the vehicle.
  3. Remove the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
  4. Remove the condenser core. Remove the Torx screw.
  1. Install the condenser core. Tighten the Torx screw.
  2. Install the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
  3. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Raise and support the vehicle.
  3. Remove the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
  4. Remove the condenser core. Remove the Torx screw.
  1. Install the condenser core. Tighten the Torx screw.
  2. Install the radiator assembly. Refer to «Radiator»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
  3. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 38

Scheme 38: REMOVAL
Scheme 38: REMOVAL

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Raise and support the vehicle.
  3. Remove the fuel cooler radiator.
  4. Remove the power steering fluid cooler. Refer to «Power Steering Fluid Cooler - 3.6L (TdV8) Diesel»(/land-rover/range-rover/l322-2005-2009/remont/manual-power-steering/#power-steering) .
  5. Remove the condenser core. Remove the 3 bolts.
  6. Remove the receiver drier. Remove the receiver drier support bracket clamp. Remove the bolt. Remove the clamp. Remove and discard the 2 O-ring seals.
  1. Install the receiver drier. Install new O-ring seals. Install the clamps. Tighten the bolt to 10 Nm (7 lb.ft).
  2. Install the condenser core. Tighten the bolts to 8 Nm (6 lb.ft).
  3. Install the fuel cooler radiator.
  4. Install the power steering fluid cooler. Refer to «Power Steering Fluid Cooler - 3.6L (TdV8) Diesel»(/land-rover/range-rover/l322-2005-2009/remont/manual-power-steering/#power-steering) .
  5. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 41

Scheme 41: REMOVAL
Scheme 41: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Remove the hood latch panel. Refer to «Hood Latch Panel»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-sheet-metal-repairs) .
  3. Remove the radiator grille support. Refer to «Radiator Grille Support»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  4. Remove the condenser cooling fan. Disconnect the electrical connector. Release from the 4 clips.
  1. Install the condenser cooling fan. Secure with the clips. Connect the electrical connector.
  2. Install the radiator grille support. Refer to «Radiator Grille Support»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  3. Install the hood latch panel. Refer to «Hood Latch Panel»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-sheet-metal-repairs) .
  4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 42

Scheme 42: REMOVAL
Scheme 42: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Raise and support the vehicle.
  3. Remove the cooling module. Refer to «Cooling Module»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l) or Refer to «Cooling Module»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-44l) .
  4. Remove the condenser fan. Release the 4 clips.
  1. To install, reverse the removal procedure.
WARNINGPersons working on the supplemental restraint system (SRS) must be fully trained and have been issued with the safety guidelines.
WARNINGAllow a period of 10 minutes to elapse after disconnecting the battery before undertaking any work on the SRS.
WARNINGThe SRS electrical connectors are unique. DO NOT force, or attempt to connect electrical connectors to the wrong sockets.
WARNINGThe correct procedures must always be used when working on SRS components.
WARNINGIt is imperative that before any work is undertaken on the SRS system, the appropriate information is read thoroughly.
WARNINGAlways disconnect both battery cables before beginning work on the SRS system. Disconnect the ground cable first. Never reverse connect the battery.
WARNINGTake extra care when handling SRS components.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47
  1. Set the footwell duct air outlet to closed.
  2. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
  3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  4. Remove the heater and evaporator core housing. Refer to «Heater Core and Evaporator Core Housing»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#heating-and-ventilation) .
  5. Reposition the heater and evaporator core housing for access.
  6. Remove the left-hand footwell duct. Remove the 2 screws.
  7. Remove the thermostatic expansion valve cover. Release the wiring harness from the 2 tangs. Remove the 4 screws.
  8. Remove the right-hand footwell duct. Remove the 4 screws. Remove the clip.
  9. Disconnect the footwell duct actuator electrical connector.
  10. Release the evaporator temperature sensor from the heater and evaporator core housing.
  11. Remove the heater and evaporator core housing lower cover. Remove the 7 screws. Remove the 4 clips.
  12. Remove the thermostatic expansion valve. Remove the 2 bolts. Remove the 2 air conditioning (A/C) pipe clamps. Release the A/C pipes. Remove and discard the O-rings.
  13. Remove the evaporator core.
  1. Install the evaporator core.
  2. Install the thermostatic expansion valve. Clean the component mating faces. Lubricate and install the new O-rings. Install the A/C pipes. Install the 2 A/C pipe clamps. Tighten the screws to 6 Nm (4 lb.ft).
  3. Install the heater and evaporator core housing lower cover. Install the screws. Install the clips.
  4. Install the evaporator temperature sensor to the heater and evaporator core housing.
  5. Connect the footwell duct actuator electrical connector.
  6. Install the right-hand footwell duct. Install the screws. Install the clip.
  7. Install the thermostatic expansion valve cover. Install the screws. Secure the wiring harness to the tangs.
  8. Install the left-hand footwell duct. Install the screws.
  9. Reposition the heater and evaporator core housing for access.
  10. Install the heater and evaporator core housing. Refer to «Heater Core and Evaporator Core Housing»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#heating-and-ventilation) .
  11. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Raise and support the vehicle.
  3. Remove the condenser core. See «CONDENSER CORE - 3.6L (TDV8) DIESEL»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-conditioning) .
  4. Remove the receiver drier. Remove the receiver drier support bracket clamp. Remove the bolt. Remove the clamp. Remove and discard the 2 O-ring seals.
  1. Install the receiver drier. Install new O-ring seals. Install the clamps. Tighten the bolt to 10 Nm (7 lb.ft).
  2. Install the condenser core. See «CONDENSER CORE - 3.6L (TDV8) DIESEL»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-conditioning) .
  3. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 48

Scheme 48: REMOVAL
Scheme 48: REMOVAL

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Remove the plenum chamber. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  3. Recover the air conditioning (A/C) refrigerant. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  4. Disconnect the A/C pipes. Remove the 2 bolts. Remove and discard the 2 O-ring seals.
  5. Remove the floor console extension trim panel. Remove the screw. Release the 2 clips.
  6. Release the driver side closing trim panel. Remove the 4 screws. Remove the clip.
  7. Remove the driver side closing trim panel. Disconnect the 2 electrical connectors. Release the vehicle diagnostic socket.
  8. Remove the right-hand front footwell duct. Remove the 2 screws.
  9. Remove the passenger side closing trim panel. Remove the 3 screws. Remove the electrical connector.
  10. Remove the passenger side footwell duct. Remove the screw.
  11. Remove the thermostatic expansion valve cover. Release the wiring harness from the 2 tangs. Remove the 4 screws.
  12. Remove the thermostatic expansion valve. Remove the 2 bolts. Remove the 2 A/C pipe clamps. Remove the A/C pipes. Remove and discard the O-rings.
  1. Install the thermostatic expansion valve. Remove the blanking caps from the ports. Clean the component mating faces. Lubricate and install the new O-rings. Install the A/C pipes. Install the 2 A/C pipe clamps. Tighten the bolts to 6 Nm (4 lb.ft).
  2. Install the thermostatic expansion valve cover. Install the 4 screws. Secure the wiring harness to the tangs.
  3. Install the right-hand front footwell duct. Install the screws.
  4. Install the driver side closing trim panel. Connect the electrical connectors. Attach the vehicle diagnostic socket.
  5. Secure the driver side closing trim panel. Install the screws. Install the clip.
  6. Install the passenger side closing trim panel. Connect the electrical connector. Install the screws.
  7. Install the passenger side footwell duct. Install the screw.
  8. Install the floor console extension trim panel. Secure the clips. Install the screw.
  9. Connect the A/C pipes. Remove the blanking caps from the ports. Clean the component mating faces. Lubricate and install the new O-rings. Install the A/C pipes. Tighten the bolts to 6 Nm (4 lb.ft).
  10. Recharge the A/C system. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
  11. Install the plenum chamber. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  12. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

More articles — HVAC
