SPECIFICATIONS
| Item | Specification |
|---|---|
| Heated oxygen sensor (H02S) removal* | Apply WD40 or equivalent |
| Heated oxygen sensor (H02S) threads | Apply suitable high temperature anti-seize compound to threads of sensor (Castrol Optimol) |
* Apply to area around sensor threads prior to attempting to remove sensor
| Item | Specification |
|---|---|
| Engine management system | |
| Make | Denso |
| Camshaft position sensor | |
| Make | Denso |
| Type | MRE (hall affect) |
| Crankshaft position sensor | |
| Make | Denso |
| Type | Variable reluctance |
GENERAL SPECIFICATION
| Description | Nm |
|---|---|
| Camshaft position (CMP) sensor bolt+ | 10 |
| Catalyst monitor sensor | 45 |
| Catalyst monitor sensor harness support bolt | 6 |
| Crankshaft position (CKP) sensor Torx bolt | 10 |
| Engine control module (ECM) bracket bolts | 6 |
| Flywheel sensor bolt | 10 |
| Flywheel sensor bracket screws | 10 |
| Fuel rail pressure sensor | 6 |
| Heated oxygen sensor (H02S)++ | 45 |
| Knock sensor retaining bolt | 20 |
| Mass air flow (MAF) sensor Torx screws | 2 |
TORQUE SPECIFICATIONS
+ Apply clean engine oil to a new CMP sensor O-ring seal
++ Apply anti-seize lubricant to threads of sensor - See Lubricants
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Heated Oxygen Sensor (HO2S) Pre-catalyst |
| 2 | HO2S Pre-catalyst |
| 3 | Variable Camshaft Timing (VCT) solenoid |
| 4 | Mass Air Flow (MAF) sensor |
| 5 | Camshaft Profile Switching (CPS) solenoid - rear |
| 6 | Plenum variable intake manifold valve |
| 7 | Intake tract variable intake manifold valve |
| 8 | Engine Coolant Temperature (ECT) sensor |
| 9 | Engine oil level/temperature sensor |
| 10 | Engine Control Module (ECM) |
| 11 | Camshaft Position (CMP) sensor (2 off) |
| 12 | Fuel rail temperature/pressure sensor |
| 13 | Knock sensors (2 off) |
| 14 | Crankshaft Position (CKP) sensor |
| 15 | Electric throttle |
| 16 | Purge valve |
| 17 | Manifold Absolute Pressure (MAP) sensor |
| 18 | Injectors (6 off) |
| 19 | CPS solenoid - Front |
| 20 | Ignition coil (6 off) |
| 21 | HO2S Post-catalyst |
| 22 | HO2S Post-catalyst |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | Accelerator Pedal Position (APP) sensor |
| 2 | Speed control inhibitor switch |
| 3 | Stop lamp switch |
| 4 | Fuel Pump Driver Module (FPDM) |
| 5 | Ambient air temperature sensor |
| 6 | Battery Junction Box (BJB) |
| 7 | Battery |
