Generators & Regulators: Removal & Installation Land Rover Freelander I рестайлинг

Charging System 3 illustrations ~262 words

Removal

  1. Disconnect negative battery cable. See «BATTERY DISCONNECT/CONNECT»(ref-167773-S11362941102004102300000).
  2. Remove top arm by unscrewing 4 bolts securing engine mounting bracket to engine front plate and remove bracket. (Scheme 1)
  3. Using a 3/8" square drive socket bar, raise accessory drive belt tensioner and release drive belt from generator pulley. (Scheme 2)
  4. Release and remove accessory drive belt from remaining pulleys.

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2
Scheme 2

Installation

  1. Install NEW drive belt if needed to crankshaft pulley.
  2. Before installation, clean out pulley grooves and tensioner pulley running surface.
  3. Raise belt tensioner and connect drive belt to steering pump, generator and compressor pulleys. Ensure drive belt is correctly located in pulley grooves.
  4. Position engine mounting front bracket to engine front plate and tighten bolts to specifications. See «TORQUE SPECIFICATIONS»(ref-167773-S40752571992004102100000) .
  5. Install top arm.
  6. Connect negative battery cable.
  1. Disconnect negative battery cable. See «BATTERY DISCONNECT/CONNECT»(ref-167773-S11362941102004102300000).
  2. Remove accessory drive belt. See «ACCESSORY DRIVE BELT»(ref-167773-S37736280232004102300000).
  3. Release battery lead terminal cover at generator, loosen terminal nut and disconnect lead from terminal. (Scheme 3)
  4. Disconnect generator multiplug.
  5. Remove lower bolt and upper nut and bolt securing generator to front mounting plate.
  6. Remove generator.

Scheme 3

Scheme 3
Scheme 3
  1. Position generator to front mounting plate.
  2. Position engine mounting front bracket to engine front plate and tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-167773-S40752571992004102100000) .
  3. Using a 3/8" square drive socket bar, raise accessory drive belt tensioner and fit drive belt to pulleys.
  4. Connect generator multiplug.
  5. Position battery cable to generator, tighten nut to specification. Position terminal cover. See «TORQUE SPECIFICATIONS»(ref-167773-S40752571992004102100000) .
  6. Install accessory drive belt and top arm.
  7. Connect negative battery cable.
