Automatic Transmission - Servicing: Adjustments Land Rover Discovery III

Adjust

1. Position vehicle on ramp. See «JACKING & HOISTING»(ref-169035-S01110894692004112900000).
2. Select position Park.
3. Loosen selector cable trunnion nut. (Scheme 128)
4. Ensure that gearbox selector lever is in Park position, (fully forward) and tighten trunnion nut.
5. Lower ramp.

Scheme 128

1. Loosen outer cable locknuts. (Scheme 129)
2. Adjust the rear locknut until it is in contact with the back of the abutment bracket, and the gap between the throttle and the inner driven lever is 0.5 mm +/- 0.4 mm (0.020 +/- 0.015 in).
3. Tighten cable front nut to lock cable to abutment bracket.

Scheme 129
