Engine Controls - Self-Diagnostics: Overview Kia Spectra I рестайлинг

Testing & Diagnostics 2 illustrations

DIAGNOSTIC TROUBLE CODE IDENTIFICATION

Code (1)Description
P0030Front HO2S Heater Circuit Malfunction
P0031Front HO2S Heater Circuit Malfunction
P0032Front HO2S Heater Circuit Malfunction
P0036Rear Heated Oxygen Sensor Heater Circuit Malfunction
P0037Rear Heated Oxygen Sensor Heater Circuit Low Input
P0038Rear Heated Oxygen Sensor Heater Circuit High Input
P0101Mass Or Volume Air Flow Circuit Range/Performance Malfunation
P0102Mass Or Volume Air Flow Circuit Low Input
P0103Mass Or Volume Air Flow Circuit High Input
P0110Intake Air Temperature Sensor Circuit Range/Performance Malfunction
P0112Intake Air Temperature Sensor Circuit Low Input
P0113Intake Air Temperature Sensor Circuit High Input
P0116Engine Coolant Temperature Circuit Range/Performance Malfunction
P0117Engine Coolant Temperature Sensor Circuit Low Input
P0118Engine Coolant Temperature Sensor Circuit High Input
P0121Throttle Position Sensor Circuit Range/Performence Malfunction
P0122Throttle Position Sensor Circuit Low Input
P0123Throttle Position Sensor Circuit High Input
P0128Engine Coolant Thermostat Stuck Open
P0130Front Heated Oxygen Sensor Circuit Malfunction
P0131Front Heated Oxygen Sensor Circuit Low Input
P0132Front Heated Oxygen Sensor Circuit High Input
P0133Front Heated Oxygen Sensor Slow Response
P0134Front Heated Oxygen Sensor Circuit No Activity Detected
P0136Rear Heated Oxygen Sensor Circuit Malfunction
P0137Rear Heated Oxygen Sensor Circuit Low Input
P0138Rear Heated Oxygen Sensor Circuit High Input
P0139Rear Heated Oxygen Sensor Circuit Slow Response
P0140Rear Heated Oxygen Sensor Circuit No Activity Detected
P0170Fuel Trim Mafunction
P0171Fuel System Too Lean
P0172Fuel System Too Rich
P0201Fuel Injector No. 1 Circuit Malfunction
P0202Fuel Injector No. 2 Circuit Malfunction
P0203Fuel Injector No. 3 Circuit Malfunction
P0204Fuel Injector No. 4 Circuit Malfunction
P0300Random/Multiple Cylinder Misfire
P0301Cylinder No. 1 Misfire Detected
P0302Cylinder No. 2 Misfire Detected
P0303Cylinder No. 3 Misfire Detected
P0304Cylinder No. 4 Misfire Detected
P0335Crankshaft Position Sensor Circuit Malfunction
P0336Crankshaft Position Sensor Circuit Range/Performance
P0340Camshaft Position Sensor Circuit Malfunction
P0422Main Catalyst Efficiency Below Threshold
P0441EVAP Emission Control System Purge Control Solenoid Valve Stuck Open
P0442EVAP Emission Control System Small Leak
P0444EVAP Emission Control System Purge Control Solenoid Valve Circuit Low Input
P0445EVAP Emission Control System Purge Control Solenoid Valve Circuit High Input
P0461Fuel Level Sensor Circuit Range/Performance Malfunction
P0462Fuel Level Sensor Circuit Low Input
P0463Fuel Level Sensor Circuit High Input
P0501Vehicle Speed Sensor Circuit Malfunction
P0506IAC System Idle Low
P0507IAC System Idle High
P0562Battery Backup Circuit Low Input
P0563Battery Backup Circuit High Input
P0605Internal Engine Control Module Malfunction
P1307Chassis Acceleration Sensor Signal Malfunction
P1308Chassis Acceleration Sensor Signal Low Input
P1309Chassis Acceleration Sensor Signal High Input
P1401EVAP Emission Control System Malfunction
P01402Leak Detection Module Pump Circuit Malfunction
P1403Leak Detection Module Solenoid Valve Circuit Malfunction
P01404Leak Detection Module Heater Circuit Malfunction
P1505Air Control Valve Opening Coil Signal Low Input
P1506Idle Air Control Valve Opening Coil Signal High Input
P1507Idle Air Control Valve Closing Coil Signal Low Input
P1508Idle Air Control Valve Closing Coil Signal High Input
P1586Automatic Transaxle Or Manual Transaxle Encoding Malfunction
P1693Transaxle Control Module Request For Malfunction Indicator Light On
(1) For diagnosis of transmission codes, see appropriate DIAGNOSIS article in AUTOMATIC TRANSMISSIONS.
(1)For diagnosis of transmission codes, see appropriate DIAGNOSIS article in AUTOMATIC TRANSMISSIONS.

DIAGNOSTIC TROUBLE CODE IDENTIFICATION

ECM LOCATION & ECM CONNECTOR IDENTIFICATION

Engine Control Module (ECM) is located below center of instrument panel, under carpet on passenger's side. (Scheme 25)and (Scheme 26).

Scheme 25

Scheme 25: ECM LOCATION & ECM CONNECTOR IDENTIFICATION
Scheme 25: ECM LOCATION & ECM CONNECTOR IDENTIFICATION

Scheme 26

Scheme 26
Scheme 26
