Compression

Ensure battery is fully charged. Turn ignition off. Disconnect ignition coils. Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed, and throttle wide open. See COMPRESSION SPECIFICATIONS table.

COMPRESSION SPECIFICATIONS

Exhaust System Backpressure

Exhaust system can be tested with a vacuum or pressure gauge. If using a pressure gauge, remove HO2S or air injection check valve (if equipped). Connect a 0-5 psi pressure gauge and run engine at 2500 RPM. If exhaust system backpressure is greater than 2 psi, exhaust system or catalytic converter is plugged. Repair as necessary.

If using a vacuum gauge, connect vacuum gauge hose to intake manifold vacuum port. Start engine. Observe vacuum gauge. Open throttle part way and hold steady. If vacuum gauge indication slowly drops after stabilizing, inspect exhaust system for restriction and repair as necessary.

FUEL SYSTEM

Note. If fuel pressure is not as specify, perform fuel filter inspection. For fuel filter location, removal & installation, see FUEL FILTER under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article. If fuel filter check okay, check fuel pump. See FUEL PUMP OPERATION .

Except Optima & Magentis (Canadian)

To release fuel pressure, remove rear seat cushion. Locate access to fuel pump harness connector. Disconnect fuel pump harness connector. Start engine and allow to idle until it stalls. Turn ignition off. Disconnect negative battery cable. When testing or repair is complete, reconnect fuel pump connector and negative battery cable. Install rear seat cushion. Prime fuel system. See PRIMING FUEL SYSTEM .

Optima & Magentis (Canadian)

To release fuel pressure, locate access to fuel pump harness connector in trunk. Disconnect fuel pump harness connector. Start engine and allow to idle until it stalls, turn ignition off. Disconnect negative battery cable. When testing or repairs are complete, reconnect fuel pump harness connector and negative battery cable. Prime fuel system. See PRIMING FUEL SYSTEM .

PRIMING FUEL SYSTEM

After performing any operation that requires releasing fuel pressure, fuel system should be primed to prevent long cranking times. To prime fuel system, jumper Data Link Connector (DLC) terminal FUEL PUMP and (B+). On Optima & Magentis (Canadian), DLC is located on left side under dash. On models except Optima & Magentis (Canadian), DLC is located on left side of engine compartment. (Scheme 4), (Scheme 5) or (Scheme 6). Turn ignition on for no longer than 10 seconds to run pump and pressurize fuel system. Turn ignition off and remove jumper wire. Check for leaks. Repair any leaks as necessary.

Scheme 4

Scheme 5

Scheme 6

FUEL PRESSURE

Fuel Pressure (Optima & Magentis (Canadian))

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect high-pressure fuel hose from fuel delivery pipe. Cover hose connection using rags to avoid spraying of fuel.
2. Using Fuel Pressure Gauge Adapter (09353-38000), install fuel pressure gauge to fuel delivery pipe. (Scheme 7)or (Scheme 8). Torque fuel gauge adapter bolts to 18-26 ft. lbs. (24-35 N.m). Connect negative battery cable.
3. Using fuel pump check terminal connector, activate fuel pump and ensure no fuel leakage is present at pressure gauge or connection. See «PRIMING FUEL SYSTEM»(ref-133259-S29693625662002022000000). If no leaks are present, start engine and allow to idle.
4. Disconnect vacuum hose from fuel pressure regulator, and plug hose end. Measure and record fuel pressure at idle. Reconnect vacuum hose, and again measure and record fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. If fuel pressures are not within specification, go to next step. If measurements are okay, go to step 8.
5. If fuel pressure is less than specified, check following conditions: Restricted fuel filter. Fuel pressure regulator leaking fuel to fuel return side. Leaking in-tank fuel pick-up hose. Low fuel pump discharge pressure. Repair or replace as necessary. Recheck fuel pressure.
6. If fuel pressure is greater than specified, check for sticking fuel pressure regulator, or a restricted or bent fuel return hose or pipe. Repair or replace fuel hose or pipe and fuel pressure regulator. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article.
7. If fuel pressure does not change when regulator vacuum hose is connected and disconnected, check for following conditions: Restricted or damaged vacuum hose. Restricted manifold vacuum port. Sticking or poorly seated fuel pressure regulator valve. Repair or replace as necessary. Recheck fuel pressure.
8. If fuel pressures are as specified, stop engine and check for decrease in fuel pressure gauge. Fuel pressure should hold for approximately 5 minutes. If fuel pressure decreases slowly after engine is stopped, check for leaking injector. See «FUEL INJECTOR LEAKAGE TEST»(ref-133259-S37634165282002041600000) under FUEL INJECTORS. Replace as necessary. If fuel pressure decreases immediately after engine is stopped, check-valve inside fuel pump is not working. Replace fuel pump. To replace fuel pump, see «FUEL PUMP»(ref-133270-S26369348112002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article. After repairs are completed, recheck fuel pressure.
9. After testing is completed, release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect fuel pressure gauge from adapter. Ensure hose connection is covered by shop towel to prevent fuel spray. Remove adapter bolts and adapter. Install NEW "O" ring, and reinstall fuel line with original bolts. Apply battery voltage to fuel pump drive connector terminal. (Scheme 4) Check for fuel leaks. Repair any leaks as necessary.

Scheme 7

Scheme 8

Fuel Pressure (Rio)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect high-pressure fuel hose from fuel delivery pipe. Cover hose connection using rags to avoid spraying of fuel. Disconnect battery negative cable. Install fuel pressure gauge (0K2A1 131 001A) on to high-pressure fuel line. (Scheme 9) Connect battery negative cable.
2. Using fuel pump check terminal connector, operate fuel pump and ensure no fuel leakage is present at pressure gauge or connection. See «PRIMING FUEL SYSTEM»(ref-133259-S29693625662002022000000). If no leaks are present, check fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table.
3. If fuel pressure is greater than specified, check for sticking fuel pressure regulator or a restricted or bent fuel return hose or pipe. Repair or replace fuel hoses or pipes and fuel pressure regulator as necessary. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article. If fuel pressure is less than specified, go to next step.
4. Clamp return line and check if fuel pressure rises. If pressure does rise, replace fuel pressure regulator. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL OVERHAUL & INSTALLATION article. If pressure does not rise, measure fuel pump maximum pressure. See «MAXIMUM FUEL PRESSURE (RIO & SPECTRA)»(ref-133259-S10226130262002022000000).
5. Stop engine and check for decrease in fuel pressure gauge. See «HOLDING FUEL PRESSURE (RIO & SPECTRA)»(ref-133259-S39437820102002022000000). Fuel pressure should hold for approximately 25 minutes. If fuel pressure decreases slowly after engine is stopped, check for leaking injector. See «FUEL INJECTOR LEAKAGE TEST»(ref-133259-S37634165282002041600000) under FUEL INJECTORS. Replace fuel injectors as necessary. If fuel pressure decreases immediately after engine is stopped, check-valve inside fuel pump is not working. Replace fuel pump. To replace fuel pump, see «FUEL PUMP»(ref-133270-S26369348112002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article. After repairs are completed, recheck fuel pressure.
6. After testing is completed, release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect fuel pressure gauge from adapter. Ensure hose connection is covered by shop towel to prevent fuel spray. Remove adapter bolts and adapter. Replace any old seals with NEW seals, and reinstall fuel line. Apply battery voltage to fuel pump drive connector terminal. (Scheme 5) Check for fuel leaks. Repair any leaks as necessary.

Scheme 9

Scheme 10

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect high-pressure fuel hose from fuel delivery pipe. Cover hose connection using rags to avoid spraying of fuel.
2. Using Fuel Pressure Gauge Adapter (09353-24100), install fuel pressure gauge to fuel delivery pipe (Scheme 10) Connect negative battery cable.
3. Using fuel pump check terminal connector, operate fuel pump and ensure no fuel leakage is present at pressure gauge or connection. See «PRIMING FUEL SYSTEM»(ref-133259-S29693625662002022000000). If no leaks are present, start engine and allow to idle.
4. Disconnect vacuum hose from fuel pressure regulator, and plug hose end. Measure and record fuel pressure at idle. Reconnect vacuum hose, and again measure and record fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. If measurements are not within specification, go to next step. If measurements are okay, go to step 8.
5. If fuel pressure is less than specified, check following conditions: Restricted fuel filter. Fuel pressure regulator leaking fuel to fuel return side. Leaking in-tank fuel pick-up hose. Low fuel pump discharge pressure. Repair or replace as necessary. Recheck fuel pressure.
6. If fuel pressure is greater than specified, check for sticking fuel pressure regulator. A restricted or bent fuel return hose or pipe. Repair or replace fuel hose or pipe as necessary, or replace fuel pressure regulator. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL OVERHAUL & INSTALLATION article.
7. If fuel pressure does not change when regulator vacuum hose is connected and disconnected, check for following conditions: Restricted or damaged vacuum hose. Restricted manifold vacuum port. Sticking or poorly seated fuel pressure regulator valve. Repair or replace as necessary. Recheck fuel pressure.
8. If fuel pressures are as specified, stop engine and check for decrease in fuel pressure gauge. Fuel pressure should hold for approximately 5 minutes. If fuel pressure decreases slowly after engine is stopped, check for leaking injector. See «FUEL INJECTOR LEAKAGE TEST»(ref-133259-S37634165282002041600000) under FUEL INJECTORS. Replace as necessary. If fuel pressure decreases immediately after engine is stopped, check-valve inside fuel pump is not working. Replace fuel pump. See «FUEL PUMP»(ref-133270-S26369348112002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article. After repairs are completed, recheck fuel pressure and go to next step.
9. After testing is completed, release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect fuel pressure gauge from adapter. Ensure hose connection is covered by shop towel to prevent fuel spray. Remove adapter bolts and adapter. Install NEW "O" ring, and reinstall fuel line with original bolts. Torque bolts to 27-35 INCH lbs. (3-4 N.m). Apply battery voltage to fuel pump drive connector terminal. (Scheme 6) Check for fuel leaks. Repair any leaks as necessary.

Fuel Pressure (Spectra)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect battery negative cable. Install Fuel Pressure Gauge (0K2A1 131 001) on service port at center of fuel rail. (Scheme 11)
2. Connect battery negative cable. To operate fuel pump, jumper DLC terminals FUEL PUMP and (B+). DLC is located on left side of engine compartment. (Scheme 5)
3. Turn ignition on for 10 seconds or less. Check fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. Turn ignition off and remove jumper wire.
4. If fuel pressure is too high, check for restricted return line. If return line is open, replace pressure regulator. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL OVERHAUL & INSTALLATION article.
5. If fuel pressure is too low, block return line. Operate fuel pump again and see if pressure rises. If pressure rises, replace fuel pressure regulator. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL OVERHAUL & INSTALLATION article. If pressure does not rise, check fuel pump maximum pressure. See «MAXIMUM FUEL PRESSURE (RIO & SPECTRA)»(ref-133259-S10226130262002022000000).

Scheme 11

Fuel Pressure (Sportage)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect battery negative cable. Install fuel pressure gauge on service fuel rail near fuel filter. (Scheme 12) Connect battery negative cable.
2. Using fuel pump check terminal connector, operate fuel pump and ensure no fuel leakage is present at pressure gauge or connection. See «PRIMING FUEL SYSTEM»(ref-133259-S29693625662002022000000).
3. Start engine and allow it to idle. Disconnect vacuum hose from pressure regulator, and plug hose end, Measure and record fuel pressure at idle. Reconnect vacuum hose, and again measure and record fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. If pressure is not as specified, check fuel line and filter for restrictions. For fuel filter location, removal & installation, see FUEL FILTER under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article. Also check holding fuel pressure and maximum fuel pressure. See «HOLDING FUEL PRESSURE (SPORTAGE)»(ref-133259-S25424025542002022000000) and «MAXIMUM FUEL PRESSURE (SPORTAGE)»(ref-133259-S38124905072002022000000) test.

Scheme 12

Holding Fuel Pressure (Rio & Spectra)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect battery negative cable. Install fuel pressure gauge on to high-pressure fuel line. For Rio (Scheme 9)or (Scheme 11). Connect battery negative cable.
2. Jumper DLC terminals FUEL PUMP and (B+). DLC is located on left side of engine compartment. (Scheme 5) Turn ignition on for 10 seconds or less to operate fuel pump and pressurize system. Turn ignition off and remove jumper wire.
3. On Rio, check fuel pressure after 25 minutes. On Spectra, check fuel pressure after 15 minutes. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. If pressure is not as specified, check fuel pump, pressure regulator and injectors.

Holding Fuel Pressure (Sportage)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect battery negative cable. Install fuel pressure gauge on service port at front of fuel rail. Connect battery negative cable.
2. Jumper DLC terminals FUEL PUMP and (B+). DLC is located on left side of engine compartment. (Scheme 5) Turn ignition on for 10 seconds or less to operate fuel pump and pressurize system. Turn ignition off and remove jumper wire.
3. Pinch off fuel return hose at pressure regulator. Observe fuel pressure for 5 minutes. It should stay above specified pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. If pressure drops below specification, replace pressure regulator. See «FUEL PRESSURE REGULATOR»(ref-133270-S21121922522002022000000) under FUEL SYSTEM in REMOVAL OVERHAUL & INSTALLATION article. Also check fuel pump and injectors.

MAXIMUM FUEL PRESSURE

Note. Maximum fuel pressure specifications and test procedures for Optima & Magentis (Canadian) and Sedona are not available from manufacturer.

Maximum Fuel Pressure (Rio & Spectra)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect battery negative cable. Remove rear seat cushion. Connect Fuel Pressure Gauge (0K2A1 131 001) to main fuel line at fuel tank. (Scheme 13) Connect battery negative cable.
2. To operate fuel pump, jumper DLC terminals FUEL PUMP and (B+). DLC is located on left side of engine compartment. (Scheme 5) Turn ignition on. Check maximum fuel pressure. Do not run fuel pump longer than necessary to check fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. If fuel pressure is not as specified, replace fuel pump. See «FUEL PUMP»(ref-133270-S26369348112002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article.

Scheme 13

Maximum Fuel Pressure (Sportage)

1. Release fuel pressure. See «FUEL PRESSURE RELEASE»(ref-133259-S32931119272002022000000). Disconnect battery negative cable. Connect fuel pressure gauge to fuel filter and plug outlet of gauge, install clamps as shown (Scheme 14) Connect battery negative cable.
2. To operate fuel pump, jumper DLC terminals FUEL PUMP and (B+). DLC is located on left side of engine compartment. (Scheme 5) Turn ignition on. Measure maximum fuel pressure. Do not operate fuel pump longer than necessary to check fuel pressure. See «FUEL PRESSURE SPECIFICATIONS»(ref-133259-S39733966572002041200000) table. Turn ignition off and remove jumper wire. If pressure is not as specified, replace fuel pump. See «FUEL PUMP»(ref-133270-S26369348112002022000000) under FUEL SYSTEM in REMOVAL, OVERHAUL & INSTALLATION article.

Scheme 14

FUEL PRESSURE SPECIFICATIONS

ECM Control Relay (Optima & Magentis (Canadian) 2.4L)

1. Remove ECM control relay located in vehicle right side of dash. (Scheme 15) Check for continuity between relay terminals No. 1 and No. 3. (Scheme 16) If continuity does not exist, go to next step. If continuity exists, replace relay.
2. Check for continuity between relay terminals No. 4 and No. 6. (Scheme 16) If continuity does not exist, go to next step. If continuity exists, replace relay.
3. Connect a jumper wire between positive battery terminal and relay terminal No. 5. Connect another jumper wire between negative battery terminal and relay terminal No. 7. Check continuity between relay terminals No. 1 and No. 3. If continuity exists, go to next step. If continuity does not exist, replace relay.
4. Connect a jumper wire between positive battery terminal and relay terminal No. 6. Connect another jumper wire between negative battery terminal and relay terminal No. 8. Check for battery voltage at terminal No. 4.Voltage should exist. If battery voltage does not exist, replace relay.

Scheme 15

Scheme 16

Fuel Pump & Main Relays (Optima & Magentis (Canadian) 2.7L)

Note. Use same procedure to check fuel pump or main relay.

1. Remove fuel pump or main relay, located in vehicle right side of dash. (Scheme 15) Check for continuity between relay terminals No. 1 and No. 5. (Scheme 17) If continuity does not exist, go to next step. If continuity exists, replace relay.
2. Connect a jumper wire between positive battery terminal and relay terminal No. 4. Connect another jumper wire between negative battery terminal and relay terminal No. 2. Go to next step.
3. Check continuity between relay terminals No. 1 and No. 5. Continuity should exist. If continuity does not exist, replace relay.

Scheme 17

Fuel Pump & Main Relays (Rio)

Note. Use same procedure to check fuel pump or main relay.

1. Remove fuel pump or main relays from fuse/relay box. Located at left side of engine compartment. Check for continuity between relay terminals No. 2 and No. 3. (Scheme 18) If continuity does not exist, go to next step. If continuity exists, replace relay.
2. Connect a jumper wire between positive battery terminal and relay terminal No. 1. Connect another jumper wire between negative battery terminal and relay terminal No. 4. Go to next step.
3. Check continuity between relay terminals No. 2 and No. 3. Continuity should exist. If continuity does not exist, replace relay.

Scheme 18

Fuel Pump & Main Relays (Sedona)

Note. Testing for fuel pump and main relays for Sedona is not available from manufacturer.

Fuel Pump & Main Relays (Spectra)

Note. Use same procedure to check fuel pump or main relay.

1. Remove fuel pump or main relay from fuse/relay box. Located at left side of engine compartment. Check for continuity between relay terminals No. 1 and 3. (Scheme 19) If continuity does not exist, go to next step. If continuity exists, replace relay.
2. Connect a jumper wire between positive battery terminal and relay terminal No. 2. Connect another jumper wire between negative battery terminal and relay terminal No. 4.
3. Check continuity between relay terminals No. 1 and 3. Continuity should exist. If continuity does not exist, replace relay.

Scheme 19

Fuel Pump & Main Relays (Sportage)

Note. Use same procedure to check fuel pump or main relay.

1. Remove fuel pump or main relay from fuse/relay box. Located at right side of engine compartment. Check for continuity between relay terminals No. 1 and 5. (Scheme 20) If continuity does not exist, go to next step. If continuity exists, replace relay.
2. Connect a jumper wire between positive battery terminal and relay terminal No. 4. Connect another jumper wire between negative battery terminal and relay terminal No. 2.
3. Check continuity between relay terminals No. 1 and 5. Continuity should exist. If continuity does not exist, replace relay.

Scheme 20

SPARK

Note. All models are equipped with a Distributorless Ignition System (DIS).

Note. Ensure high tension leads are routed properly after removal and installation.

Check for spark at each spark plug wire using a high output spark tester. Check spark plug wire resistance on suspect wires. High tension wire resistance should not exceed 16,000 ohms per 3.3 feet.

CAMSHAFT POSITION SENSOR

Camshaft Position Sensor (CMP) sensor detects No. 1 piston at TDC of compression stroke. ECM uses input for fuel and ignition control. For CMP sensor testing, see CAMSHAFT POSITION SENSOR under SENSORS & SWITCHES in SYSTEM & COMPONENT TESTING article.

CRANKSHAFT POSITION SENSOR

Crankshaft Position Sensor (CKP) sensor detects crankshaft angle. ECM uses input to determine engine speed, misfire detection, and for fuel and ignition control. For CKP sensor testing, see CRANKSHAFT POSITION SENSOR under SENSORS & SWITCHES in SYSTEM & COMPONENT TESTING article.

IGNITION COIL POWER SOURCE

Ensure ignition is off. Disconnect ignition coil harness connectors. Turn ignition on. Check for battery voltage at ignition power source wire. To identify wire, see IGNITION COIL POWER SOURCE table. On all models, if battery voltage is not present, check battery feed circuit, main fuse, ignition switch and wiring harness.

IGNITION COIL POWER SOURCE

Optima & Magentis (Canadian) 2.4L & Sedona

Note. Power transistor is built into ignition coil.

To perform primary coil resistance check, connect negative (-) terminal of a 3 volt power supply to terminal No. 2 of power transistor. (Scheme 21) Check for continuity, about.78 Ohm, between terminals No. 2 and 3. Continuity should exist when terminal No. 1 is connected to 3 volt power (+) supply. When 3 volt power supply is removed, continuity should no longer exist. If problem exists, replace power transistor/ignition coil. To test secondary resistance measure resistance between high-voltage terminals of ignition coil (Scheme 21) For resistance specification, see IGNITION COIL RESISTANCE table.

Scheme 21

Optima & Magentis (Canadian) 2.7L

Measure resistance between connector terminals No. 1 and 2, 1 and 3 and 1 and 4. (Scheme 22) For ignition coil resistance, see IGNITION COIL RESISTANCE table. If resistance is not as specified, replace coil pack.

Scheme 22

Rio, Spectra & Sportage

To check primary coil resistance, disconnect ignition coil harness connector. Using ohmmeter, check primary resistance between positive (+) and negative (-) terminal of coil or coil pack. Check secondary resistance between coil towers. For resistance check procedure on Rio (Scheme 23) For Spectra and Sportage resistance check procedure (Scheme 24) And see IGNITION COIL RESISTANCE table for resistance specification. If readings are not within specification, replace ignition coil(s).

Scheme 23

Scheme 24

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

Note. Base idle speed inspection procedure for Optima & Magentis (Canadian) is not available from manufacturer.

Ensure engine is at normal operating temperature. Turn off all electrical loads. Set transaxle or transmission in Park or Neutral and steering wheel on straight forward position. Connect non-inductive tachometer positive lead to terminal No. 3 of underhood Data Link Connector (DLC), or tachometer inductive pick-up on spark plug wire. (Scheme 5) Start engine and allow it to idle. Check idle speed. See IDLE SPEED SPECIFICATIONS table.

Sedona

Ensure engine is at normal operating temperature. Turn off all electrical loads. Set transaxle in Park or Neutral and steering wheel on straight ahead position. Loosen the accelerator cable. Connect tachometer to spark plug wire. Ground No. 8 and ignition timing adjustment terminals of underhood Data Link Connector (DLC). (Scheme 6) Run engine for 5 seconds at 2000-3000 RPM. Let engine idle for 2 minutes. Check engine base idle speed. See IDLE SPEED SPECIFICATIONS table. If base idle speed is out of specification, adjust using the idle speed adjustment screw, located on throttle body assembly. Turn ignition off. Disconnect ground lead wires from DLC. Run engine for 10 minutes. Recheck engine idle speed. Adjust accelerator cable.

IDLE SPEED SPECIFICATIONS

Base ignition timing inspection procedure for Optima & Magentis (Canadian) is not available from manufacturer.

Rio & Spectra

Ensure engine is at normal operating temperature. Turn off all electrical loads. Set transaxle in Park or Neutral and steering wheel on straight forward position. Remove provided inspection rubber plug on plastic coils cover, over number one spark plug wire. Connect timing light inductive pick-up to number one spark plug wire. If timing light inductive pick-up is too large, plastic coils cover have to be removed. Start engine and allow it to idle. Check base ignition timing. Timing mark on crankshaft pulley and mark on timing belt cover should be aligned to specification. See BASE IGNITION TIMING table. If timing is not within specification, check for faulty sensor or incorrect camshaft timing. Check power and grounds. If camshaft timing, sensors, power and grounds are okay, replace Engine Control Module (ECM).

Ensure engine is at normal operating temperature. Turn off all electrical loads. Set transaxle in Park or Neutral and steering wheel on straight forward position. Ground ignition timing adjustment terminal of underhood Data Link Connector (DLC). (Scheme 6) Start engine and allow it to idle. Check base ignition timing. Timing mark on crankshaft pulley and mark on timing belt cover should be aligned to specification. See BASE IGNITION TIMING table. If timing is not within specification, check for faulty sensor or incorrect camshaft timing. Check power and grounds. If camshaft timing, sensors, power and grounds are okay, replace Engine Control Module (ECM).

Sportage

Ensure engine is at normal operating temperature. Turn off all electrical loads. Set transmission in Park or Neutral and steering wheel on straight forward position. Connect timing light inductive pick-up to number one spark plug wire. Start engine and allow it to idle. Check base ignition timing. Timing mark on crankshaft pulley and mark on timing belt cover should be aligned to specification. See BASE IGNITION TIMING table. If timing is not within specification, check for faulty sensor or incorrect camshaft timing. Check power and grounds. If camshaft timing, sensors, power and grounds are okay, replace Engine Control Module (ECM).

BASE IGNITION TIMING

SUMMARY

If no faults were found while performing BASIC DIAGNOSTIC PROCEDURES , proceed to appropriate SELF-DIAGNOSTICS article. If no hard codes are found in self-diagnostics, proceed to TROUBLE SHOOTING - NO CODES article for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.) or intermittent diagnostic procedures.
