POWER STEERING FLUID BLEEDING

Scheme 75

Scheme 76

1. Check fluid level.
2. Turn steering wheel fully to left and right several times with engine not running.
3. Recheck fluid level. If level has lowered, add fluid.
4. Repeat steps 2 and 3 until fluid level stabilizes.
5. Start engine and let it idle.
6. Turn steering wheel fully to left and right several times.
7. Check that fluid has not foamed, and that fluid level has not dropped.
8. If necessary, add fluid and repeat steps 6 and 7.

FLUID PRESSURE CHECK

INSPECTION OF FLUID PRESSURE

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Assemble SST (0K201 323 AA1A) as shown in figure, and tighten its fittings. Tightening torque: 29-36 lb.ft (39-49 N.m, 4-5 kg.m)
2. Disconnect high-pressure hose from pump, and connect SST (0K210 323 AA1A) between hose and pump. NOTE: Before disconnecting hose, place marks at connections for proper reinstallation.
3. Bleed air from system.
4. Open gauge valve fully. Start engine and turn steering wheel fully left and right to raise fluid temperature to 122-140°F (50-60°C) . NOTE: If valve is left closed for more than 15 seconds, fluid temperature will increase excessively and damage oil pump.
5. Close gauge valve completely. Increase engine speed to 1,000 - 1,500 rpm and measure fluid pressure generated by power steering pump. If pressure is below specification, replace power steering pump assembly. Power steering pump fluid pressure: 1067-1138 psi (7358-7848 kPa, 75.0-80.0 kg/cm 2 )
6. Open gauge valve fully and again increase engine speed to 1,000 - 1,500 rpm .
7. Turn steering wheel fully to left and right and measure fluid pressure generated by gear housing. If pressure is below specifications, replace gear housing assembly. Gear housing fluid pressure: 1067-1138 psi (7358-7848 kPa, 75.0-80.0 kg/cm 2 ) NOTE: If steering wheel is kept in fully turned position for more than 15 seconds, fluid temperature will rise excessively and damage oil pump.
8. Remove SST(0K210 323 AA1A) . Replace and tighten high-pressure hose. Tighten to specified torque. Tightening torque: 29-36 lb.ft (39-49 N.m, 4-5 kg.m)
9. Bleed air from system.

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. Check drive belt for wear, cracks and fraying. Replace if necessary.
2. Measure drive belt tension with a tension gauge. TENSION
3. Measure deflection by applying moderate pressure (22 lb [98 N]) midway between pulleys. Adjust if necessary. DEFLECTION
