Steering System: Overview Kia Spectra I рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. Disconnect (-) terminal of battery.
2. Place vehicle in a straight forward position.
3. Loosen four bolts from steering wheel and remove driver's air bag module. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-150641-S19457306762002112000000) .
4. Disconnect horn switch electrical connector.
5. Make an alignment mark on steering wheel and steering shaft for proper installation.
6. Remove retaining nut and snap ring from end of steering shaft.
7. Remove steering wheel with a suitable puller. NOTE: Do not remove steering wheel by hitting end of shaft with a hammer. Damage to shaft threads and shaft support bearings could occur.
8. Remove three lower steering column panel screws and separate upper and lower steering column panels.
9. Remove three combination switch screws.
10. Disconnect combination switch electrical connectors.
11. Slide combination switch off steering column shaft.
12. Disconnect ignition switch electrical connector.
13. Remove ignition switch screw.
14. Remove ignition switch.
15. Remove two universal joint pinch bolts.
16. Remove two lower column bracket nuts.
17. Remove one upper column bracket bolt.
18. Remove steering column from vehicle.
