Gasoline Engine Control System: Specifications Kia Spectra I рестайлинг 2

Testing & Diagnostics 12 illustrations ~150 words

SPECIFICATION

Air Flow (kg/h)Output Voltage (V)
4.90.70
7.30.90
12.21.18
20.81.51
28.31.73
38.91.97
64.72.40
113.32.90
185.33.35
256.03.64
404.64.07
476.74.25
603.254.6

AIR FLOW VOLTAGE OUTPUT REFERENCE

Scheme 33

Scheme 33: CIRCUIT DIAGRAM
Scheme 33: CIRCUIT DIAGRAM

Scheme 34

Scheme 34: FUNCTION AND OPERATION PRINCIPLE
Scheme 34: FUNCTION AND OPERATION PRINCIPLE

Intake Air Temperature Sensor (IATS) is installed inside the Mass Air Flow Sensor (MAFS) and detects the intake air temperature. To calculate precise air quantity, correction of the air temperature is needed because air density varies according to the temperature. So the ECM uses not only MAFS signal but also IATS signal. This sensor has a Negative Temperature Coefficient (NTC) and its resistance is in inverse proportion to the temperature.

Temperature [°C (°F)]Resistance (kohms)
40(-40)41.26 ~ 47.49
30(-22)23.94 ~ 27.21
20(-4)14.26 ~ 16.02
10(14)8.72 ~ 9.69
0(32)5.50 ~ 6.05
10(50)3.55 ~ 3.88
20(68)2.35 ~ 2.54
25(77)1.94 ~ 2.09
30(86)1.61 ~ 1.73
40(104)1.11 ~ 1.19
60(140)0.57 ~ 0.60
80(176)0.31 ~ 0.32

INTAKE AIR TEMPERATURE SENSOR SPECIFICATION

Temperature [°C (°F)]Resistance (kohms)
40(-40)48.14
20(-4)14.13 ~ 16.83
0(32)5.79
20(68)2.31 ~ 2.59
40(104)1.15
60(140)0.59
80(176)0.32

ENGINE COOLANT TEMPERATURE SENSOR SPECIFICATION

Scheme 35

Scheme 35: CIRCUIT DIAGRAM
Scheme 35: CIRCUIT DIAGRAM
Throttle AngleOutput Voltage (V)
C.T0.25 ~ 0.9
W.O.TMin. 4.0V

SENSOR OUTPUT VOLTAGE SPECIFICATION

ItemsSpecification
Sensor Resistance (kohms)1.6 ~ 2.4 kohms at 20°C (68°F)

SENSOR RESISTANCE SPECIFICATION

Scheme 36

Scheme 36: CIRCUIT DIAGRAM
Scheme 36: CIRCUIT DIAGRAM
ItemSpecification
Capacitance (pF)950 ~ 1,350
Resistance (Mohms)4.87

ITEM SPECIFICATION

Scheme 37

Scheme 37: WAVEFORM
Scheme 37: WAVEFORM

Scheme 38

Scheme 38: CIRCUIT DIAGRAM
Scheme 38: CIRCUIT DIAGRAM
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2ohms at 20°C (68°F)

COIL RESISTANCE SPECIFICATION

Scheme 39

Scheme 39: CIRCUIT DIAGRAM
Scheme 39: CIRCUIT DIAGRAM
ItemsSpecification
Closing Coil Resistance (ohms)14.6 ~ 16.2 at 20°C (68°F)
Opening Coil Resistance (ohms)11.1 ~ 12.7 at 20°C (68°F)

COIL RESISTANCE SPECIFICATION

Duty (%)Air Flow Rate (m 2 f/h)
151.0 ~ 2.3
357.5 ~ 12.7
7043.0 ~ 55.0
9663.0 ~ 71.0

AIR FLOW RATE SPECIFICATION

Scheme 40

Scheme 40: CIRCUIT DIAGRAM
Scheme 40: CIRCUIT DIAGRAM
ItemSpecification
Coil Resistance (ohms6.9 ~ 7.9ohms at 20°C (68°F)

COIL RESISTANCE SPECIFICATION

Scheme 41

Scheme 41: CIRCUIT DIAGRAM
Scheme 41: CIRCUIT DIAGRAM
Temperature [°C (°F)]Resistance (kohms)
40(-40)52.15
20(-4)16.52
0(32)6.0
20(68)2.45
40(104)1.11
60(140)0.54
80(176)0.29

CVVT OIL TEMPERATURE SENSOR SPECIFICATION

Scheme 42

Scheme 42: CIRCUIT DIAGRAM
Scheme 42: CIRCUIT DIAGRAM
ItemSpecification
Coil Resistance (ohms)26.0ohms at 20 °C (68°F)

COIL RESISTANCE SPECIFICATION

Scheme 43

Scheme 43: CIRCUIT DIAGRAM
Scheme 43: CIRCUIT DIAGRAM
Pressure (kPa)Output Voltage (V)
6.670.5
02.5
+6.674.5

FUEL TANK PRESSURE SENSOR SPECIFICATION

Scheme 44

Scheme 44: SCHEMATIC DIAGRAM
Scheme 44: SCHEMATIC DIAGRAM
