INSPECTION
- Disconnect the vacuum hose from the throttle body, and connect a vacuum pump to the vacuum hose.
- Check the following points when the engine is cold [engine coolant temperature 60°C(140°F) or below] and when it is warm [engine coolant temperature 80°C(176°F) or higher].
| Engine operating condition | Applied vacuum | Result |
|---|---|---|
| Idling | 50 kPa (7.3 psi) | Vacuum is held |
| 3,000 rpm |
WHEN ENGINE IS COLD
| Engine operating condition | Applied vacuum | Result |
|---|---|---|
| Idling | 50 kPa (7.3 psi) | Vacuum is held |
| Within 3 minutes after engine start at 3,000 rpm | Try to apply vacuum | Vacuum is released |
| After 3 minutes have passed after engine start at 3,000 rpm | 50 kPa (7.3 psi) | Vacuum will be held momentarily, after which, it will be released |
WHEN ENGINE IS WARM
Scheme 11
- Look for loose connections, sharp bends or damage to the fuel vapor lines.
- Look for distortion, cracks or fuel leakage.
- After removing the EVAP. canister, inspect for cracks or damage.
Note. When disconnecting the vacuum hose, make an identification mark on it so that it can be reconnected to its original position.
Scheme 12
Scheme 13
- Disconnect the vacuum hose from the solenoid valve.
- Detach the harness connector.
- Connect a vacuum pump to the nipple to which the red-striped vacuum hose was connected.
- Apply vacuum and check when voltage is applied to the PCSV and when the voltage is discontinued. PCSV CHECK Battery voltage Normal condition When applied Vacuum is released When discontinued Vacuum is maintained
- Measure the resistance between the terminals of the solenoid valve. PCSV coil resistance (ohms ): 20~24 ohms at -20°C (-4°F) 22~26 ohms at 0°C (32°F) 24~28 ohms at 20°C (68°F) 25~29 ohms at 40°C (104°F) 27~31 ohms at 60°C (140°F) 29~33 ohms at 80°C (176°F)
