Installation
- Install the BCM after connecting the connector.
- Install the glove box.
Scheme 45
| PIN NO. | Connector A | Connector B | Connector C |
|---|---|---|---|
| 1 | Room lamp | Assist seat belt IND | GND 2 |
| 2 | IG 2 | Rear wiper ON switch | |
| 3 | Wiper relay | Front fog relay | Rear defogger switch |
| 4 | Rear wiper relay | ALT L | Wiper INT switch |
| 5 | T/Gate relay | Assist seat belt switch | Washer switch |
| 6 | Rear defogger relay | Speed sensor | T/Gate outside handle switch |
| 7 | DRL relay (Canada) | Crash sensor | Rear washer switch |
| 8 | Tail lamp relay | DRL disable switch | Tail lamp switch |
| 9 | Seat belt indicator | Seat belt switch | |
| 10 | Hazard relay | Power window unlock switch | Key in switch |
| 11 | Horn relay | Driver door key lock switch | Driver door open switch |
| 12 | IG 1 | Power window lock switch | Assist door open switch |
| 13 | B+ | Wiper INT volume | 4 door open switch |
| 14 | Driver door unlock switch | Rear wiper INT switch | Tail Gate door switch |
| 15 | Assist door unlock switch | Assist door key lock switch | |
| 16 | Rear door unlock switch | Diagnosis | MIST switch |
| 17 | Parking brake switch | ||
| 18 | Driver door key unlock switch | Head lamp switch | |
| 19 | Head lamp low relay | Front fog switch | |
| 20 | High indicator | Rear fog switch | |
| 21 | Head lamp high switch | ||
| 22 | Power window relay | Assist key unlock switch | |
| 23 | Lock relay | ||
| 24 | Unlock relay | ||
| 25 | GND 1 | ||
| 26 | Driver unlock relay |
