Tailgate Release Control

  1. Permission Mode State State Description Initial condition No permission state Event DR Door Unlock switch ON Action The state goes to permission state Initial condition 30s permission state Event DR Door Unlock switch ON Action The state goes to permission state Initial condition Permission state Event When vehicle speed is under 5km/h, T/Gate switch ON Action Tail Gate Relay ON for 0.5sec The state goes to permission state
  2. No Permission State State Description Initial condition 30s Permission state Event T/GATE TIMER IS EXPIRED or LOCK command by RKE & Driver Lock state or T/gate open to close Action The state goes to NO permission state Initial condition Permission state Event DR Door Unlock switch OFF Action The state goes to NO permission state

Scheme 46

Scheme 46: Removal

Scheme 47

Scheme 47

Scheme 48

Scheme 48
  1. Disconnect the negative (-) battery terminal.
  2. Remove the glove box. (Refer to the " «CRASH PAD»(ref-537227-S36224571332013032200000) ")
  3. Remove the BCM (A) after removing the connector (B) and nuts (2EA).

BCM Logic Output

PIN NameCapacityAvailability in Power
Horn relayDC 12V 200mA(indective load)B+
Hazard relayDC 12V 200mA(indective load)B+
Room lampDC 12V 30W LAMPB+
Defogger relayDC 12V 200mA(indective load)B+
Unlock relayDC 12V 200mA(indective load)B+
Lock relayDC 12V 200mA(indective load)B+
Dead lock relay/Drive door unlock relayDC 12V 200mA(indective load)B+
Power window relayDC 12V 200mA(indective load)B+
Front fog relayDC 12V 200mA(indective load)B+
Tail lamp relayDC 12V 200mA(indective load)B+
Head lamp relayDC 12V 200mA(indective load)IG2
Wiper relayDC 12V 200mA(indective load)IG2
Seat belt indicator lampDC 12V 1.2W(LED)IG1
Assist seat belt indicator lampDC 12V 1.2W(LED)IG1
K line communicationB+
Internal chime buzzerB+
Tail gate relayDC 12V 200mA(indective load)B+
Over speed indicator lampDC 12V 1.2W(LED)IG1
DRL (Canada) relayDC 12V 200mA(indective load)B+
Rear wiper relayDC 12V 200mA(indective load)IG2

Scheme 49

Scheme 49: Trouble Diagnostics When Using Diagnosis Tool

Scheme 50

Scheme 50

Scheme 51

Scheme 51

Scheme 52

Scheme 52
  1. The body control system can be diagnosed by using the GDS. The BCM communicates with the GDS which then displays inputs and outputs along with codes.
  2. To diagnose the BCM function, select the menu of model and body control module.
  3. To consult the present input/out value of BCM, "Current DATA". It provides information of BCM input/output conditions of power supply, turn signal/brake lamp, headlamp, door locks, outside mirror, wiper, auto-light and transmitters etc.
  4. To perform functional test on BCM outputs, select "ACTUATION TEST"
