Body Control Module (BCM): Overview Kia Soul I рестайлинг

Description

Body control module (A) receives various input switch signals controlling time and alarm functions for Variant INT wiper, MIST wiper, rear wiper & washer, seat belt warning (reminder), over speed warning, tail lamp auto cut, DRL, front fog lamp, decayed room lamp, rear defogger timer, power window timer, central lock/unlock, tail gate release control, IGN key reminder, crash door unlock, keyless entry, panic.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Wiper Data Flow
2. Washer Interlocking Wiper Turn Wiper switch ON after T1 when turning Washer switch on at the status of IGN2 ON and if the input of Washer switch is between 0.06 and 0.2sec, turn the output of Wiper relay OFF after T3. But, ignore the input the input of Washer switch after operating Washer interlocking wiper. T1: 0.3±0.03sec, T2: 0.06~0.2sec, T3: 0.7±0.1sec, T2 is less than 0.06sec: T3=0 Turn Wiper relay ON after T1 when turning Washer switch ON at the status of IGN2 ON and if the input of Washer switch is more than 0.2sec, turn the output of wiper relay off for 2.5 ~ 3.8sec after turning washer switch OFF. But, ignore the input of Washer switch occurred while Washer interlocking Wiper is being operated and accept it from the input of Washer switch after operating Washer interlocking Wiper. T1: 0.3 ± 0.03s, T2: more than 0.2sec, T3: 2.5 ~ 3.8s Turn the output of WASHER INTERLOCKING WIPER when Washer switch is turned ON for more than 0.2sec during the operation of INT WIPER. If Washer switch is turned on for less than 0.2sec, turn the output of Wiper Relay once. T1: 0.3 ± 0.03s, T2: more than 0.2s, T3: 2.5 ~ 3.8s, T4: INT TIME - 0.7s, T5: 0.06 ~ 0.2s, T6: 0.7 ± 0.1s In case of starting (IGN1 ON & IGN2 OFF) ignore the input of Washer switch.
3. Mist Interlocking Wiper Turn the output of Wiper Relay for 700ms when Mist switch ON at the status of IGN2 ON. T1: Min 60 ms, T2: Max 100ms, T3: 700 ± 100ms If the input of Mist switch is continuous (for more than 700ms), keep the condition of Wiper Relay is ON and if Mist switch is turned OFF turn the output of Wiper Relay for 700ms from that point. Ignore the input of Mist switch while operating WIPER by INT WIPER, WASHER Interlocking WIPER. T1: Min 60 ms, T2: Max 100ms, T3: 700 ± 100ms, T4: 700ms
4. Variable INT Wiper Variable INT Wiper is operated by INT volume when the input of INT WIPER switch is ON at the status of IGN2 ON. T1: 0.3sec MAX, T2: 0.7 ± 1SEC T3: T2 + pause time
5. Rear Wiper Control
6. Rear Washer Inter Locking Rear Wiper Rear Wiper Realy is turned ON after T1 When Rear Washer switch is turned ON at the status of IGN2 ON. If input of Rear Washer switch is less than 0.2sec and more than 0.06sec, Rear Wiper Realy is turned OFF after T3. Ignore the input of Rear Washer switch operating Rear Washer interlocking Rear Wiper accepts the input of Rear Washer switch after the operating Rear Washer interlocking Rear Wiper. T1: 0.3 ± 0.03sec, T2: 0.06 ~ 0.2sec T3: 0.7 ± 0.1sec, T2 is less than 0.06sec: T3=0 Rear Wiper Relay is turned ON after T1 When Rear Washer switch is turned ON at the status of IGN2 ON. If input of Rear Washer switch is more than 0.2sec, output of Rear Wiper Relay is turned OFF after output of Rear Wiper Relay is turned ON for more than 2.5sec and less than 3.8sec after Rear Washer switch OFF. Ignore the input of Rear Washer switch operating Rear Washer interlocking Rear Wiper accept the input of Rear Washer switch after the operating Rear Washer interlocking Rear Wiper. T1: 0.3 ± 0.03sec, T2: more than 0.2sec T3: 2.5 ~ 3.8sec If the input of Rear Washer switch is more than 0.2sec operating Rear Wiper INT, output of Rear Washer interlocking Rear Wiper is turned ON. If the input of Rear Washer is less than 0.2sec, turn the output of Rear Washer interlocking Rear Wiper once. T1: 0.3 ± 0.03sec, T2: more than 0.2sec, T3: 2.5 ~ 3.8sec, T4: 1Cucle -0.7sec, T5: 0.06 ~ 0.2sec, T6: 0.7 ± 0.1sec
7. Rear Wiper ON IF Rear Wiper ON switch is ON at the status of IGN2 ON, the output of Rear Wiper Relay is turned ON for 700ms. T1: Min 60ms, T2: Max 100ms, T3: 700 ± 100ms If the input of Rear Wiper ON switch is continuous (for more than 700ms), keep the condition of Rear Wiper Relay ON is ON and if Rear Wiper ON switch is turned OFF turn the output of Rear Wiper Relay for 700ms from that point.
8. Rear Wiper INT If Rear Wiper INT switch is turned ON, Rear Wiper Relay is operated in a cycle (0.7sec ON & 6sec OFF). T1 = 0.7s ± 0.1s, T2=6s ± 0.6s

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Exterior Lamp Control Data Flow
2. Tail Lamp Auto Cut Turn IGN KEY OFF when turning Tail Lamp switch ON after turning IGN KEY ON and turn Tail Lamp Relay OFF (automatic blackout) when Driver Door open switch is opened. Also, Tail Lamp Relay OFF(automatic blackout) even though IGN KEY is turned OFF after opening Driver Door open switch at the condition that IGN KEY is ON.. When turning Tail Lamp switch ON again form OFF after the automatic blackout, Tail Lamp Relay will be turned ON and AUTO CUT function will be cancelled. When turning IGN KEY ON after the automatic blackout, Tail Lamp Relay will be turned ON and AUTO CUT function will be cancelled. AUTO CUT will be kept when removing or installing B+ at the status of AUTO CUT. Tail Lamp Relay will be kept turning OFF though Driver Door open switch is closed from opened at the status of AUTO CUT. *1 IGN KEY ON: (Push Knob SW or Key In SW ON or IGN 1 ON or IGN 2 ON) IGN KEY ON: (Push Knob SW and Key In SW OFF and IGN 1 OFF and IGN 2 OFF)
3. Daytime Running Lamps If Alt 'L' is High, DRL control put in operation. If Head Lamp Low Relay is turned ON or Head Lamp High Switch is turned ON during DRL control operating, DRL control is cancelled.
4. Head Lamp Low If Head Lamp switch is turned ON at the status of IGN2 ON, output of Head Lamp Low Relay is turned ON. If IGN2 is turned OFF or Head Lamp switch is turn OFF, output of Head Lamp Low Relay is turned OFF.
5. Front Fog Lamp If IGN2 ON, Head Lamp Low Relay ON, Head Lamp High Switch OFF and Front Fog Switch ON, turn Front Fog Relay ON. Turn Front Fog Relay OFF excluding this condition.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Interrior Room Lamp Data Flow
2. Decayed Room Lamp & Keyless Unlock Timer When removing or installing the Battery Start Room Lamp on the state of 20min, if the DOOR is OPENED. Start Room Lamp when it is OFF if the DOOR is CLOSED.
3. Room Lamp Off Condition 1 State Description Initial condition Room Lamp OFF and DOOR CLOSE Event UNLOCK by TX(Transmitter) or key In ON --> OFF Action Room Lamp ON for 30± 3 sec. Condition 2 State Description Initial condition Room Lamp OFF Event Any DOOR OPEN for over 0.1 sec. when ALL DOORS are closed Action ROOM LAMP ON for 20 min Condition 3 State Description Initial condition Room Lamp OFF and IGN1 OFF Event IGN1 ON and DOOR OPEN for over 0.1 sec. Action ROOM LAMP ON T1: 20 ± 1min, T2: 30 ± 3sec
4. Room Lamp On for 30s Condition 1 State Description Initial condition ROOM LAMP ON for 30s and IGN1 OFF Event DOOR OPEN for over 0.1 sec. when ALL DOORS are closed. Action ROOM LAMP ON for 20min Condition 2 State Description Initial condition ROOM LAMP ON for 30s and IGN1 OFF Event UNLOCK by TX Action ROOM LAMP ON for 30s Condition 3 State Description Initial condition ROOM LAMP ON for 30s and IGN1 OFF Event IGN1=ON, or after 30sec, or ALL DOOR UNLOCK --> LOCKED or TX LOCK & ALL DOORS CLOSED & ALL DOOR LOCKED Action The state go to ROOM LAMP DECAYING state Room Lamp decaying for 2 ± 0.2 sec and OFF T1: 20 ± 1min, T2: 30 ± 3sec
5. Room Lamp On for 20min Condition 1 State Description Initial condition Room Lamp ON for 20min and IGN1 OFF Event IGN1 ON Action ROOM LAMP ON Condition 2 State Description Initial condition Room Lamp ON for 20min and IGN1 OFF Event DOOR CLOSE and ALL DOOR LOCK Or after 20min Action ROOM LAMP DECAYING for 2 ± 0.2 sec and OFF Condition 3 State Description Initial condition ROOM LAMP ON for 20min and IGN1 OFF Event DOOR CLOSE Action ROOM LAMP ON for 30s T1: 20 ± 1min, T2: 30 ± 3sec
6. Room Lamp Decaying Condition 1 State Description Initial condition ROOM LAMP DECAYING and IGN1 OFF Event DOOR OPEN for over 0.1 sec. when All doors are closed Action ROOM LAMP ON for 20min Condition 2 State Description Initial condition ROOM LAMP DECAYING and IGN1 OFF and DOOR CLOSE Event UNLOCK by TX Action ROOM LAMP ON for 30s Condition 3 State Description Initial condition ROOM LAMP DECAYING Event After decaying Action ROOM LAMP OFF Condition 4 State Description Initial condition ROOM LAMP DECAYING Event IGN1 ON and DOOR OPEN for 0.1 sec. Action ROOM LAMP ON T1: 20 ± 1min, T2: 30 ± 3sec.
7. Room Lamp On Condition 1 State Description Initial condition Room Lamp ON and IGN1 ON and DOOR OPEN Event DOOR CLOSE Action ROOM LAMP DECAYING for 2 ± 0.2 sec. and OFF Condition 2 State Description Initial condition Room Lamp ON and IGN1 ON and DOOR OPEN Event IGN1 OFF Action ROOM LAMP ON for 20min Condition 3 State Description Initial condition Room Lamp ON and IGN1 ON and DOOR OPEN Event DOOR CLOSE and IGN1 OFF Action ROOM LAMP ON for 30s T1: 20 ± 1min, T2: 30 ±3sec NOTE: ROOM LAMP should not be flickered when turning IGN1 ON. Exposure for the ROOM LAMP should be more than 32 steps.
8. Buzzer Control SPECIFICATION of BUZZER SOUND Frequency Frequency DUTY Cycle Sound pressure Remark SEAT BELT WARNING/SEAT BELT REMINDER OVER SPEED WARNING 800Hz 50% 1.0s 70±10dB Decreasing sound KEY OPERATED WARNING 800Hz 50% 0.6s 70±10dB Decreasing sound Priority: S/BELT WARNING/SEAT BELT REMINDER > OVER SPEED WARNING > KEY OPERATED WARNING Keep the output up to the OFF cycle when turning the output OFF. Measurement distance for sound pressure: 1.0 m

Scheme 29

Scheme 30

1. Warning Control Data Flow
2. Seat Belt Warning Timer From State IGN1 Off (Default State) State Description Initial condition IGN1 OFF Event Driver side seat belt is belted and IGN1 ON Action Start Bulb check 6 seconds driver indicator blinking The automaton state is changed to IGN1 ON DRIVER BELTED Initial condition IGN1 OFF Event Driver side seat belt is unbelted and IGN1 ON Action Start Bulb check 6 seconds driver indicator blinking Start Bulb check 6 seconds buzzer warning If ALT L=ON then start ALT L 6s indicator blinking & ALT L 6s buzzer The automaton state is changed to IGN1 ON DRIVER UNBELTED From State IGN1 On Driver Belted State Description Initial condition IGN1 ON DRIVER BELTED Event IGN1 OFF Action Stop Bulb check 6 seconds driver indicator blinking Stop ALT L 6 seconds driver indicator blinking The automaton state is changed to IGN1 OFF Initial condition IGN1 ON DRIVER BELTED Event Driver side seat belt is unbelted Action Start Normal 6 seconds driver indicator blinking Start Normal 6 seconds buzzer warning The automaton state is changed to IGN1 ON DRIVER UNBELTED Initial condition IGN1 ON DRIVER BELTED Event ALT L 0 --> 1 Action Start ALT L 6 seconds driver indicator blinking From State IGN1 On Driver Unbelted State Description Initial condition IGN1 ON DRIVER UNBELTED Event IGN1 OFF Action Stop Bulb check 6 seconds driver indicator blinking Stop Normal 6 seconds driver indicator blinking Stop ALT L 6 seconds driver indicator blinking Stop ALT L 6 seconds buzzer warning The automaton state is changed to IGN1 OFF Initial condition IGN1 ON DRIVER UNBELTED Event Driver side seat belt is belted Action Stop Normal 6 seconds driver indicator blinking Stop ALL 6 seconds buzzer warning The automaton state is changed to IGN1 ON DRIVER BELTED Initial condition IGN1 ON DRIVER UNBELTED Event Vehicle Speed > or = 10km/h Action Start buzzer and driver indicator Pattern (10 times (6sec ON/24sec OFF) + 6sec ON) The automaton state is changed to PATTERN Initial condition IGN1 ON DRIVER UNBELTED Event ALT'L 0 --> 1 Action Start ALT L 6seconds driver indicator blinking & ALT L 6seconds buzzer warning From State Pattern State Description Initial condition PATTERN Event IGN1 OFF Action Stop Buzzer and driver indicator Pattern Stop ALL 6s driver indicator blinking Stop ALL 6s buzzer warning The automaton state is changed to IGN1 OFF Initial condition PATTERN Event Driver side seat belt is belted Action Stop Buzzer and driver indicator Pattern Stop Normal 6s driver indicator blinking Stop ALL 6s buzzer warning The automaton state is changed to IGN1 ON DRIVER BELTED Initial condition PATTERN Event Vehicle Speed < or = 5km/h Action Stop Buzzer and driver indicator Pattern If 6s buzzer period, after 6s warning stop Pattern The automaton state is changed to IGN1 ON DRIVER UNBELTED
3. Key Operated Warning When Driver Door Switch is ON at the status of KEY IN ON, Buzzer will be outputted per 0.6sec continuously. If KEY IN turns OFF or Driver Door Switch is CLOSED during Buzzer output, the output will turn OFF. When IGN1 turns ON while outputting, the output will be stopped. T1: 0.6 ± 0.1sec

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Rear Defogger Control Data Flow
2. Rear Defogger Timer With the Enging Running (charging voltage at Alt 'L' terminal, 12v at IGN1) and the Rear Defogger turned on, the Rear Defogger relay will stay ON for 20min. If Rear Defogger switch turns ON again while Rear Defogger relay output is ON, turn Rear Defogger relay output OFF. The Defogger will turn OFF if there is no charging voltage at Alt 'L' or there is not 12v at ING1 even though the Rear Defogger relay output is ON. If Alt'L' is over 10 Volts Engine is RUNNING (Alt'L' ON) and if Alt'L' is less than 5 Volts ENGINE is STOPPED (Alt'L' OFF). Also, AltL is between 5 and 10 Volts, keep the previous condition. Rear Defogger relay should not be outputted when turning Alt'L' ON while Rear Defogger switch is pressed. T1: 20 ± 1min
3. Power Window Timer Turn Power window Relay output ON when turning IGN2 ON. Turn Power window Relay output OFF after keeping Power window Relay output for 30sec when IGN2 is OFF. Turn Power window Relay OFF immediately when opening Driver Door Switch or Passenger Door Switch within the condition (2) above. Turn Power window Relay output OFF when IGN2 is OFF while Driver Door Switch or Passenger Door Switch is open. T1: 30 ± 3sec

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Door Lock/unlock Control Data Flow
2. Door Lock/unlock Relay Control NON-APPLICABLE SPEC FOR 2-TURN Mode Unlock Relay Driver Door Unlock Relay Lock Relay CENTRAL LOCK OFF NC ON CENTRAL UNLOCK ON NC OFF 2-Turn Unlock Spec (For North America) Mode Unlock Relay Driver Unlock Relay Lock Relay CENTRAL LOCK OFF OFF ON CENTRAL UNLOCK ON ON OFF DRIVER UNLOCK OFF ON OFF Turn the present output OFF immediately when reciprocal output is requested while outputting and start outputting reciprocally in 100ms. However, output the last request if there is request for output during the delay of 100ms. Execute LOCK output and ignore UNLOCK output when the condition for LOCK and UNLOCK is occurred at the same time. Execute Driver Door Unlock output by the Unlock Relay output when Unlock Relay is requested during Driver Unlock Relay output. (For North America)
3. Door Key Lock/unlock In case of DOOR KEY LOCK (UNLOCK) signal of driver's seat, handle as KEY LOCK (UNLOCK) of driver's seat is inputted if the knob in the driver's seat is LOCKED (UNLOCKED) after checking it for 3s. In case of DOOR KEY LOCK (UNLOCK) signal of the passenger seat, handle as KEY LOCK (UNLOCK) of the passenger seat is inputted if the knob in the passenger seat is LOCKED (UNLOCKED) after checking it for 3s.
4. Central Door Lock/unlock If Driver Door Key Lock Switch or Passenger Door Key Lock Switch turns ON, turn Door Lock Relay output ON during T1. But prohibit the output when KEY IN ON and IGN1 are ON. When Driver Door Key Unlock and Passenger Door Key Unlock turn ON, turn Door Unlock Relay and Driver Door Unlock Relay output ON during T1. Turn CENTRAL LOCK *1) ON during T1 when receiving TX LOCK signal. But ignore LOCK input when Driver Door SW or Passenger Door SW is ON. Turn CENTRAL UNLOCK *2) ON during T1 when receiving TX UNLOCK signal. LOCK/UNLOCK by SAFETY KNOB is not interlock (Mechanical operation). Malfunction should be free when joining BATTERY (Also malfunction should be free at the location of Key In Switch ON). Input which is less than 60msec should not be received (KEY LOCK/UNLOCK Switch). Do not execute the output of DOOR LOCK (UNLOCK) by KNOB change. If Power Window Lock Switch is ON, turn Lock Relay output ON for T1. (NORTH AMERICA) If Power window Lock Switch is ON, turn CENTRAL UNLOCK output ON for T1. (NORTH AMERICA) But, inhibit operating by Power window Unlock Switch at Lock state by TX. *1) CENTRAL LOCK: Refer to control mode for each Spec. *2) CENTRAL LOCK: Refer to control mode for each Spec. T1: 0.5 ± 0.1sec
5. 2-Turn Unlock If Driver Door Key Unlock Switch turns OFF from ON within T1 after Driver Door Key Unlock Switch turns ON from OFF(Driver Door Unlock Switch becomes UNLOCKED mechanically and does not output BCM.), turn Driver Unlock Relay, Unlcok Relay(Central Unlock) output ON duting T2. If TX UNLOCK is received within T1 after Driver Door Key Unlock Switch turns ON from OFF (Driver Door Unlcok Switch becomes UNLOCKED mechanically and does not output BCM.), turn Driver Unlock Relay and Unlock Relay (Central Unlock) output ON during T2. Turn Driver Unlock Relay output ON during T2 when receiving TX UNLOCK signal. However, turn Driver Unlock Relay, Unlock Relay (Central Unlock) output duting T2 if TX UNLOCK is received within T1. Also, turn Driver Unlock Relay, Unlock Relay (Central Unlock) ON during T2 in case that Driver Door Key Unlock Switch turns ON from OFF within T1 after receiving TX UNLOCK. Regard as the same TX even though different signal which is registered within T1 is received. If turn Lock Relay output ON by TX Lock or Driver/Assist Key lock Switch, T1 is initialized. Assist Key Unlock Switch turns ON from OFF, turn Driver Unlock Relay and Unlock Relay (Central Unlock) output ON during T2. T1: 4 ± 1sec, T2: 0.5 ± 0.1sec
6. IGN Key Reminder This function will not be operated if the speed of cars exceeds 3km/h. Perform Unlock Relay output for 1s after 0.5s when the condition becomes to be KEY IN = ON& Driver Door open Switch = OPEN & Driver Door Unlock Switch = LOCK(Regions for North America). Perform Driver Unlock Relay output for 1s after 0.5s when the condition becomes to be KEY IN = ON & Driver Door open Switch = OPEN & Driver Door Unlock Switch = LOCK. (Spec for North America ONLY) Perform Unlock Relay output for 1s in 0.5s when the condition becomes to be KEY IN = ON & Assist Door Open Switch =OPEN & Assist Door Unlock Switch = LOCK. Output CENTRAL UNLOCK for 1s in 0.5s based on (4) if (1), (3) and (4) are satisfied. Output UNLOCK up to 3 times(excluding output for 1s) if LOCK condition is maintained though UNLOCK output is performed for 1s by (2), (3), (4) (cycle for 1s: 0.5s ON/OFF). Try UNLOCK once when DOOR is CLOSED while keeping LOCK condition after performing (6). Output Driver Unlock Relay once only for 1s when Driver Door open Switch is closed within 0.5s since Driver Door Unlock Switch is changed from UNLOCK to LOCK during KEY IN = ON(North America SPEC ONLY). Output CENTRAL UNLOCK once only for 1s when Assist Door Open Switch is closed within 0.5s since Assist Door Unlock Switch is changed from UNLOCK to LOCK during KEY IN = ON. Output Driver Unlock Relay for 1s when Driver Door Unlock Switch becomes LOCK from UNLOCK within 0.5s since Driver Door open Switch is changed from OPEN to CLOSE during KEY IN = ON(North America SPEC ONLY) Output CENTRAL UNLOCK once only for 1s if Assist Door Unlock Switch becomes to be LOCK from UNLOCK within 0.5s since Assist Door Open Switch is changed from OPEN to CLOSE during KEY IN = ON. Jugde if RETRY output is performed or not at the point of the beginnig of RETRY output(in 1.5s from the initial UNLOCK output). Output UNLOCK though the condition is not kept for 0.5sec after realizing that of UNLOCK. But, do not output UNLOCK in case that KEY IN is OFF at the point of 0.5s passed after realizing the condition by the change of UNLOCK --> LOCK in Driver Door Unlock Switch or Assist Door Unlock Switch. T1, T3: 0.5 ± 0.1sec, T2: 1 ± 0.1sec, T4: 0.5sec Max ** KEY IN ON: Key In ON or IGN1 ON or IGN2 ON KEY IN OFF: Key In OFF and IGN1 OFF and IGN2 OFF
7. Crash Door Unlock Always perform CENTRAL UNLOCK output whenever Crash Sensor signal is inputted(Duty 20%±10%) while IGN1 is ON. (But ignore Sensor input during 5sec output.) Jugde Sensor Fail if Crash Sensor signal is more than T3, Crash Door Unlock is not operated. Keep CENTRAL UNLOCK output for the time left though IGN1 turns OFF from ON while outputting CENTRAL UNLOCK. Do not output CENTRAL UNLOCK if IGN1 switch turns ON from OFF after Crash Sensor signal is already inputted.. Output CENTRAL UNLOCK during T3 Driver Door Unlock switch or Assist Door Unlock switch or Rear Door Unlock switch turns to LOCK from UNLOCK after outputting CENTRAL UNLOCK. Do not perform AUTO DOOR LOCK function at the condition of CRASH UNLOCK. CRASH DOOR UNLOCK function has priority to LOCK/UNLOCK control by other functions. Ignore the request for LOCK/UNLOCK by other functions while or after outputting CRASH DOOR UNLOCK. But, control LOCK/UNLOCK by other functions if IGN1 switch becomes OFF. T1: Min 40ms, T2: 5 ± 0.5s, T3: 20 ± 2ms, T4: 16 ± 2ms, T5: 4 ± 2ms
