Replacement Kia Rio III

Exterior: Removal & Installation 7 illustrations ~119 words

Replacement

CAUTIONWhen removing and installing the fender, an assistant is necessary. Be careful not to damage the fender and body. When removing the clips, use a clip remover.

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Remove the front bumper cover. (Refer to the " «FRONT BUMPER»(ref-536132-S32457192892013031400000) ")
  2. Remove the head lamps. (Refer to the " «HEAD LAMPS»(ref-536133-S19461277212013031400000) ")
  3. Using a screwdriver or remover, remove the front pillar trim (A).
  4. Disconnect the tweeter speaker connector (A).
  5. Loosen the delta glass mounting nuts. Tightening torque: 3.9 ~ 4.4 N.m (0.4 ~ 0.45 kgf.m, 2.9 ~ 3.3 lb-ft)
  6. Remove the delta glass (A).
  7. Loosen the wheel guard (A) mounting screws.
  8. After loosening the mounting screws, then remove the front bumper side mounting bracket (A).
  9. After loosening the mounting bolts, then remove the fender assembly (A).
  10. Installation is the reverse of removal.
