Description
Driver Airbag (DAB) is installed in the steering wheel and electrically connected to SRSCM via the clock spring. It protects the driver by deploying the airbag when frontal crash occurs. The SRSCM determines deployment of the Driver Airbag (DAB).
| CAUTION | Never attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury. |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Disconnect the battery negative cable and wait for at least three minutes before beginning work.
- Remove the driver airbag module mounting bolts (A).
- Remove the wiring fixing clip (C) and disconnect the horn connector (A).
- Release the connector locking pin, then disconnect the driver airbag module connector (B). CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover facing up.
- Remove the steering wheel and steering wheel column shroud. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-536086-S11460282932013031400000) ")
- Disconnect the clock spring and horn connector (A), then remove the clock spring.
The passenger airbag (PAB) is installed inside the crash pad and protects the front passenger in the event of a frontal crash. The SRSCM determines if and when to deploy the PAB.
| CAUTION | Never attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury. |
Scheme 6
Scheme 7
- Disconnect the battery negative cable and wait for at least three minutes before beginning work.
- Remove the glove box housing. (Refer to the " «INTERIOR (CRASH PAD)»(ref-536097-S26973898002013031400000) ")
- Disconnect the passenger airbag connector (B) and remove the PAB mounting bolt (A).
- Remove the crash pad. (Refer to the " «INTERIOR (CRASH PAD)»(ref-536097-S26973898002013031400000) ") NOTE: If the PAB has been deployed, replace the damaged crash pad.
- Remove the heater duct from the crash pad.
- Remove the mounting bolts from the crash pad. And then remove the passenger airbag. CAUTION: The removed airbag module should be stored in a clean, dry place with the airbag cushion up.
The Side Airbags (SAB) are installed inside the front seat and protects the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of side airbag by using Side Impact Sensor (SIS) signal.
| CAUTION | Never attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury. |
Scheme 8
Curtain airbags are installed inside the headliner (LH and RH) and protect the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of curtain airbag by using side impact sensor (SIS) signal.
| CAUTION | Never attempt to measure the circuit resistance of the airbag module even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury. |
Scheme 9
Scheme 10
Scheme 11
- Disconnect the battery negative cable and wait for at least 3 minutes before beginning work.
- Remove the roof trim. (Refer to the " «ROOF TRIM»(ref-536097-S11146997132013031400000) ")
- Disconnect the curtain airbag harness connector (A).
- After loosening the mounting bolts remove the curtain airbag.
