Lighting System: Specifications Kia Rio III

Exterior Lights 13 illustrations ~105 words

Specification

Item			Bulb Watt (W)	Bulb Type
Front	Head lamp (High)		60/55	H1
	Head lamp (Low)		60/55	H7
	Position lamp		5	P21/5W
	Position lamp		0.8	LED
	DRL		21	P21/5W
	Turn signal lamp		28	PY21W
	Fog lamp		55	9006
Rear	Tail lamp	Inside	5	W5W
		Inside	0.5	LED
		Outside	5	P21/5W
		Outside	0.5	LED
	Stop lamp	Inside	5	LED
		Outside	21	P21/5W
		Outside	5	LED
	Turn signal lamp		21	PY21W
	Back up lamp		16	W16W
	High mounted stop lamp		2.2	LED
	License plate lamp		5	W5W
Interior	Overhead console lamp		10	W10W
	Room lamp		10	FESTOON 10W
	Luggage lamp		5	FESTOON 5W

Scheme 1

Scheme 1: Component Location (1)

Scheme 1: Component Location (1)

Scheme 2

Scheme 2: [4 Door]

Scheme 2: [4 Door]

Scheme 3

Scheme 3: [5 Door]

Scheme 3: [5 Door]

Scheme 4

Scheme 4: Component

Scheme 4: Component

Head Lamp Component Call-Out
1. Head lamp assembly lens & housing	4. Dust cover
2. Head lamp bulb (Low)	5. Turn signal lamp bulb
3. Head lamp bulb (High)	6. Socket

Scheme 5

Scheme 5: Head Lamp

Scheme 5: Head Lamp

Scheme 6

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 13

Disconnect the negative (-) battery terminal.
Remove the radiator grille upper cover (A), after loosening the mounting clips.
Loosening the head lamp mounting bolts (2EA) and disconnect the head lamp connector (A). Then, remove the head lamp assembly (B). NOTE: Take care not to scratch the head lamp lens or fender.
Remove the dust cap (A) and disconnect the connector. Then remove the head lamp (high / low) bulb(B).
Remove the turn signal lamp bulb.
