Audio System: Specifications Kia Rio III

Entertainment Systems 5 illustrations

Specification

ItemSpecification
ModelRadio / MP3 / CD (PA30A)Radio / MP3 / VCD (BA900/UVO)
Power supplyDC 14.4V
Load Impedance4ohms X 4
Tuning typePLL synthesized type
Frequency range / Channel spaceFM87.5~107.9 MHz / 200KHz
AM530~1710 KHz / 10KHz
Antenna80PF 75ohms
Dark currentMax. 1.0 mA (Head unit only)Max. 3.0 mA (Head unit only)

Scheme 1

Scheme 1: Components Location
Scheme 1: Components Location

Scheme 2

Scheme 2: Components
Scheme 2: Components

Terminal specification(PA30A)

NoTerminal DescriptionConditionSpecified Condition
A1Loudspeaker Rear Left+Needed connection to the carAnalog output
A2Loudspeaker Front Left+Needed connection to the carAnalog output
A3Loudspeaker Front Right+Needed connection to the carAnalog output
A4Loudspeaker Rear Right+Needed connection to the carAnalog output
A5
A6
A7
A8Rheostat from vehicle +Needed connection to the car
A9ILL DIM CANCELNeeded connection to the car
A10Loudspeaker Rear LeftNeeded connection to the carAnalog output
A11Loudspeaker Front LeftNeeded connection to the carAnalog output
A12Loudspeaker Front RightNeeded connection to the carAnalog output
A13Loudspeaker Rear RightNeeded connection to the carAnalog output
A14
A15
A16
A17Rheostat from vehicleNeeded connection to the car
A18Remote Power supply for AntennaAcc on9V ~ 18V
B1
B2
B3
B4Steering Wheel Remote ControlSteering Wheel switch pushed0.5V ~ 3V
B5
B6USB D+USB device is inserted3.2V ~ 3.45
B7USB/iPod powerUSB/iPod device is inserted4.9V ~ 5.1V
B8AUX Right Sound SignalExternal Auxiliary device is Audio playing (At time of Aux jack use)A waveform synchronized with sound is output
B9AUX Reference GroundAlwaysBelow 1 ohm
B10Bluetooth MIC+Input the Voice Signal via MICA waveform synchronized with Voice data via MIC
B11AccessoryEngine switch on(ACC)11 ~ 14 V
B12BatteryAlways11 ~ 14 V
B13
B14
B15
B16Speed Sensor SignalEngine switch on(IGN), car is moved slowlyApprox. 5V Level Pulse Generation
B17Steering Wheel Remote Control GndAlwaysBelow 1 ohm
B18USB DUSB device is inserted3.2V ~ 3.45
B19IPod detection lineIPod device is insertedGND
B20AUX Signal Input DetectAuxiliary device is inserted0V(Low) --> 5V(High)
B21AUX Left Sound SignalExternal Auxiliary device is Audio playing (At time of Aux jack use)A waveform synchronized with sound is output
B22Bluetooth MICInput the Voice Signal via MICA waveform synchronized with Voice data via MIC
B23
B24GroundAlwaysBelow 1 ohm

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: System Block Diagram
Scheme 4: System Block Diagram

Scheme 5

Scheme 5
Scheme 5
