Audio System: Removal & Installation Kia Rio III

Removal

Note. Take care not to scratch the center fascia panel and related parts. Eject all the disc before removing the audio unit to prevent damaging the CD player's load mechanism.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the negative (-) battery terminal.
2. Using a screwdriver or trim remover, remove the center fascia panel (A).
3. Disconnect the start/stop button connector (A) and hazard switch connector (B).
4. After loosening the mounting screws, then remove the audio assembly (A).
5. Disconnect the audio connector and cable (A).

Installation

1. Connect the audio unit connectors and cable.
2. Install the audio unit.
3. Install the crash pad center fascia garnish.
4. Check the audio system. NOTE: Make sure the audio head unit connectors are plugged in properly, and the antenna cable is connected properly.

Scheme 14

Scheme 15

1. Troubleshooting for Speaker Basic inspection of speaker Inspect the sound from speaker after verifying that the speaker mounting screws is removed and the wiring connector is connected precisely to remove vibration transmitted from body trims and surrounding parts. Case Troubleshooting No. Case Inspection/Remedy 1 Trembling sound Before replacing the speaker, inspect that the mounting screw is installed normally. After re-installing the speaker, verify that no trembling sound is heard. When hearing a trembling sound again, replace the speaker with new one. 2 Noise Check if the wiring connector is connected normally. If not, reconnect the wiring connector. In case of radio static, check if there is a noise from CD. If a noise is heard with the radio and CD on, replace the speaker with new one. NOTE: In case there is only radio static, this causes from poor radio reception. Thus the speaker needs no repair and replacement. 3 Speaker in operative Inspection of the wiring connection between the battery and the speaker Before replacing the speaker, inspect the wiring connection between the battery and the speaker is normal. Check the supplying power to the speaker and the resistance, then inspect the sound quality. Specified impedance: 4 ± 0.6ohms (Scheme 15): Checking Supplying Power To Speaker And Resistance If the speaker works poorly, replace it with new one. CAUTION: When handling the speakers, do not damage the speaker with impact, Like drop or throw. Be careful not to cover water and oil over the speaker. Caution during handling of speaker because the material of diaphragm is paper which is easy to be torn by impact and external force. Modifying the audio system may cause damage the speakers. If this is the case, The speakers are not covered by the manufacturer's warranty.

Scheme 16

1. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-536122-S21591303232013031400000) ")
2. Remove the front speaker (A) after loosening 3 screws.

Scheme 17

1. Remove the rear door trim panel. (Refer to the " «REAR DOOR»(ref-536122-S04199767692013031400000) ")
2. Remove the rear speaker (A) after removing 3 screws.

Scheme 18

Scheme 19

1. Remove the front pillar trim (A).
2. Remove the tweeter speaker (A) after disconnecting the connector and loosening 2 screws.

1. Install the roof antenna, then connect the cable and the connector.
2. Install the rear roof trim.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Check the audio remote control switch (A) for resistance between No. 5 and No. 7 terminals in each switch position. Switch Connector terminal Resistance (± 5%) SEEK UP 6-7 (LH) 430 ohms SEEK DOWN 6-7 (LH) 1.11 kohms MODE 6-7 (LH) 2.11 kohms MUTE 6-7 (LH) 3.11 kohms VOLUME UP 6-7 (LH) 4.61 kohms VOLUME DOWN 6-7 (LH) 6.81 kohms CANCEL 3-4 (RH) 180 ohms SET - 3-4 (RH) 330 ohms RES + 3-4 (RH) 550 ohms ON/OFF 3-4 (RH) 880 ohms SLD 3-4 (RH) 1.44 kohms VOICE 3-4 (RH) 10.71 kohms Switch Connector terminal Resistance(± 5%) END 5-6 (Lower LH) 18.91 kohms SEND 5-6 (Lower LH) 40.91 kohms TRIP 5-6 (Lower RH) 2.54 kohms RESET 5-6 (Lower RH) 5.54 kohms

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Disconnect the negative (-) battery terminal.
2. Remove the driver airbag module. (Refer to «REMOVAL»(ref-536085-S25766889762013031400000) .
3. Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-536086-S11460282932013031400000) ")
4. Remove the steering wheel cover (A) after loosening 6 screws.
5. Remove the remote control switch (B) after loosening 2 screws and disconnecting the connector (A). [RH] [LH]

1. Reassemble the steering wheel remote control switch after connecting the connector.
2. Reassemble the steering wheel.
3. Reassemble the driver airbag module. NOTE: Make sure the audio remote control switch and the airbag module connectors are plugged in properly.

Scheme 28

Scheme 29

1. Install the multimedia jack.
2. Connect the multimedia jack connector. NOTE: Make sure the multimedia connector and the console upper cover connectors are plugged in properly.

R-1: Replace the audio head unit

1. Check the same problems after replacing the audio head unit OK If Audio is normal operating, replace the audio head unit NG Check the vehicle wiring. (Refer to removal procedure. R-2)

Scheme 30

1. Remove the audio head unit.
2. Check the specified condition of terminal. OK Tester Connection Condition Specified Condition CON-B11 <--> GND Always 9~12 V CON-B12 <--> GND Always 9~12 V CON-B24 <--> GND Always Below 1ohms NG Check again after repairing or replacing the Cable harness or Connector.
