Multicasting

HD Radio FM stations are able to broadcast multiple digital program streams(channels) over a single FM frequency. For example, a HD Radio FM station can run a main channel of music and a sub channel of news(or even two different music channels) at one frequency. But only the program content of the main channel is also broadcasted analog.

HD Radio signal delay

"To overcome the delay that digital systems inherently produce, HD Radio technology first uses the audio signal of the analog broadcasting when you tune to an AM station or to the main channel of a FM station. After that, the system will blend from analog to digital signal. Normally, this blending is very smooth. If you experience a skip in program content of several seconds, the radio station has not implemented HD Radio broadcasting correctly. This is not a problem with your audio system. Due to the fact that sub channels are only broadcasting digital, blending from analog to digital signal is not possible if you tune to a sub channel. In this case playback of the sub channel starts after several seconds, this is a normal function."

Automatic switching between digital and analog broadcasting

"If the reception of the digital signal is lost, the system switches automatically to the analog signal. As soon as the digital signal is available again it will switch back. Due to the fact that sub channels are only broadcasted digital, first the system mutes playback if you have tuned to a sub channel and the digital signal is lost. Additionally, the main line shows the message No HD signal in place of station name. Second, after 1 minute with the digital signal lost, the system will automatically tune to the analog signal of the corresponding frequency."

Text based information

HD Radio stations are able to broadcast text based informations, e.g. station name, song title and artist name. The Driver Information System is able to display these informations.

Function

1. Color Touch Screen The simple, intuitive menus on UVO's vivid color LCD touch screen make operation easy.
2. Advanced Voice Control Microsoft speech technology can learn multiple users' speaking patterns, and responds quickly to long phrases.
3. Easy Feature Updates With its flexible Windows® Embedded Automotive platform, the UVO system is incredibly easy to update.
4. HD Radio™ Technology UVO offers available HD Radio™ Technology - the digital evolution of AM and FM radio.
5. Rear-Camera Display Whenever you shift into reverse, UVO's rear-camera display lets you see behind your vehicle.
6. Digital Jukebox UVO's in-dash hard drive is large enough to hold up to 700 megabytes of music.

Front Speaker

1. Install the front speaker.
2. Install the front door trim.

Rear Speaker

1. Install the rear speaker.
2. Install the rear door trim.

Tweeter Speaker

1. Install the tweeter speaker after connecting the tweeter speaker connector.
2. Install the front pillar trim.

Scheme 31

Scheme 32

Scheme 33

1. Remove the antenna jack from the audio unit and antenna.
2. Check for continuity between the center poles of antenna cable.
3. Check for continuity between the outer poles of antenna cable. There should be continuity.
4. If there is no continuity, replace the antenna cable.
5. Check for continuity between the center pole (A) and outer pole (B) of antenna cable. There should be no continuity.
6. If there is continuity, replace the antenna cable.

Scheme 34

Scheme 35

1. Remove the rear roof trim. (Refer to the «ROOF TRIM»(ref-536097-S11146997132013031400000) .
2. Disconnect the antenna cable and the connector (A).
3. Remove the roof antenna(A) after removing a nut(B).

R-3: Check the steering wheel remote control

1. Check the steering wheel remote control connector specification (Refer to «Audio Remote Control»(ref-536136-S32722846302013031400000) «INSPECTION»(ref-536136-S03101693832013031400000) ") OK Replace the audio head unit. (Refer to «R-1»(ref-536136-S04143035852013031400000) ) NG Replace the steering wheel remote control switch.

Scheme 36

1. Remove the audio head unit OK FOR PA30A, BA900 Tester Connection Condition Specified Condition CON-A1 <--> RL SPK + Always Below 1ohms CON-A10 <-->RL SPK - Always Below 1ohms CON-A2 <--> FL SPK + Always Below 1ohms CON-A11 <--> FL SPK - Always Below 1ohms CONA3 <--> FR SPK + Always Below 1ohms CON-A12 <--> FR SPK - Always Below 1ohms CON-A4 <--> RR SPK + Always Below 1ohms CON-A13 <--> RR SPK - Always Below 1ohms CON-A1, 2, 3, 4, 10, 11, 12, 13 <--> GND Always OPEN

Scheme 37

1. Remove the audio head unit
2. Check the output of audio head unit and external amplifier using the oscilloscope OK FOR PA30A, BA900 Tester Connection Condition Specified Condition CON-A1 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A10 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A2 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A11 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A3 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A12 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A4 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A13 <--> GND Audio sound is being produced A waveform synchronized with sound is output

R-6: Radio Broadcast cannot be Received (Bad reception)

1. Check the radio broadcast reception after replacing the audio head unit OK If Audio is normal operating, replace the audio head unit NG Go to step 2
2. Check the antenna jack NG Check again the radio broadcast reception after connecting the antenna jack OK Go to step 3
3. Check the antenna amp input voltage (Refer to "Antenna - Glass antenna circuit inspection" NG Check the antenna amp input voltage (Refer to " «ANTENNA CABLE»(ref-536136-S05336962672013031400000) " OK Go to step 4
4. Check the feeder cable connection (Refer to " «ANTENNA CABLE»(ref-536136-S05336962672013031400000) ") NG Check again after repairing or replacing the antenna feeder cable. OK Go to step 5
5. Check again the radio broadcast reception after replacing the external amplifier OK If Audio is normal operating, replace the external amplifier NG Go to step 6
6. Check and repair the glass antenna. (Refer to "Antenna - Glass antenna test")

R-7: Check that speakers are installed tightly

NG

1. Install the speakers tightly.

OK

1. Go to step 1

1. Noise source description Condition in Which Noise Occurs Noise Type Depressing accelerator pedal increases noise, and stopping engine stops noise immediately Generator nosie When A/C or heater is operating Blower motor noise When rapidly accelerating on unpaved road When engine switch is turned on (IG) Fuel pump noise When horn switch is pressed and released When horn switch is pressed and held down Horn noise Running engine causes soft noise, and stopping engine stops noise immediately Ignition noise Noise occurs synchronously with turn signal flash Flasher noise Noise occurs during window washer operation Washer noise Running engine causes noise, but stopping engine does not stop noise Engine coolant temperature sensor noise When wiper is operating Wiper noise When brake pedal is depressed Stop light switch noise Other Static electricity on vehicle OK Check the noise source NG Check again after replacing the audio head unit
2. Repair or replace the noise source

Scheme 38

OK

1. Remove the audio head unit

NG

1. Go to step 1

1. Check the input signal of Illumination (+) TESTER CONNECTION AND SPECIFIED CONDITION - FOR PA30A Tester Connection Condition Specified Condition CON-A8 <--> GND Always 9~16 V TESTER CONNECTION AND SPECIFIED CONDITION - FOR BA900 Tester Connection Condition Specified Condition CON-C5 <--> GND Always 9~16 V CON-C4 <--> GND Always Below 1ohms NG Check the vehicle wiring OK Go to step 2
2. Check the illumination (-) input signal using the oscilloscope TESTER CONNECTION AND SPECIFIED CONDITION - FOR PA30A Tester Connection Condition Specified Condition CON-A17 <--> GND Always Check the PWM waveform TESTER CONNECTION AND SPECIFIED CONDITION - FOR BA900 Tester Connection Condition Specified Condition CON-A17/H17 <--> GND Always Check the PWM waveform NG Check the vehicle wiring and cluster PWM output. OK Go to step 3
3. Check the vehicle illumination control unit.

R-10: Check the mic input condition

TESTER CONNECTION AND SPECIFIED CONDITION - FOR PA30A

TESTER CONNECTION AND SPECIFIED CONDITION - FOR BA900

NG

1. Check the vehicle wiring and B/T mic

OK

1. Go to step 1

1. Test again after replacing the B/T mic

R-12: Disc cannot be inserted or ejected right after insertion

1. Is the ignition key at ACC or ON? OK Go to step 2 NG Turn the key to ON
2. Power ON reset. Disconnect the 2 audio fuses, wait 5 minutes with ignition switch off. And then insert both fuse. Then turn the ignition key ON. Is CD ejected? OK Loock for foreign matters in CD player. Such as paper lables, coins etc. NG Go to step 3
3. If CD does not eject, don't try removing it. The player may be damaged. Please replace the CD player.

R-13: Sound sometimes skips when parking

1. Is CD face scratched or dirty? OK CD is defective, or clean CD NG Go to step 2
2. Does it play properly if CD is replaced with an existing proper CD? OK Replace CD NG Repair or replace CD player
