Hands Free System: Diagnosis Kia Rio III

Collision/avoidance 5 illustrations

Inspection

  1. Check the hands free remote control switch for resistance between No. 4 and No. 5 terminals in each switch position.

Scheme 4

Scheme 4: Audio + Bluetooth [LH]
Scheme 4: Audio + Bluetooth [LH]
SwitchConnector terminalResistance (±5%)
End of call6-818.91 kohms
Send6-840.91 kohms

Scheme 5

Scheme 5: Cruise + Voice + Limit [RH]/Cruise + Voice [RH]
Scheme 5: Cruise + Voice + Limit [RH]/Cruise + Voice [RH]
SwitchConnector terminalResistance (±5%)
Voice3-410.71 kohms

Scheme 6

Scheme 6: Bluetooth [Lower]
Scheme 6: Bluetooth [Lower]
SwitchConnector terminalResistance (±5%)
End of call5-618.91 kohms
Send5-640.91 kohms

Scheme 7

Scheme 7: Removal
Scheme 7: Removal

Scheme 8

Scheme 8
Scheme 8
  1. Disconnect the negative (-) battery terminal.
  2. Remove the driver airbag module. (Refer to the «AIRBAG MODULES & CLOCK SPRING»(ref-536085) .
  3. Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-536086-S11460282932013031400000) ")
  4. Remove 2 screws on the steering wheel.
  5. Remove the steering wheel cover (A) after loosening 6 screws.
  6. Remove the hands free switch.
