Audio: Removal & Installation Kia Rio II рестайлинг

Installation

1. Install the audio remote control switch on the steering wheel.
2. Connect the audio remote control switch connector.
3. Install the steering wheel.
4. Install the driver airbag module.

Scheme 5

1. Check for resistance between No. 6 and No. 7 terminals in each switch position. [Audio System] TERMINAL RESISTANCE REFERENCE CHART Switch Connector terminal Resistance (±5%) VOLUME DOWN 6-7 6.81 kohms VOLUME UP 6-7 4.61 kohms MODE 6-7 2.11 kohms SEEK DOWN 6-7 1.1 kohms SEEK UP 6-7 430 ohms MUTE 6-7 3.11 kohms

Scheme 6

1. Check for resistance between No. 6 and No. 7 terminals in each switch position. [Audio System] TERMINAL RESISTANCE REFERENCE CHART Switch Connector terminal Resistance (±5%) Voltage (±0.22V) Volume down 6-7 (LH) 6.81 kohms 3.0V Volume up 6-7 (LH) 4.61 kohms 2.5V Mode 6-7 (LH) 2.11 kohms 1.5V Seek down 6-7 (LH) 1.1 kohms 1.0V Seek up 6-7 (LH) 430 ohms 0.4V Mute 6-7 (LH) 3.11 kohms 2V

Scheme 7

Scheme 8
